PureLink DS2200-060 Manuel utilisateur

User Manual

USB 2.0 Active Extension with Hub

ENGLISH

USB 2.0 Active Extension with Hub, Black

USB A Male to Hub 4x USB A Female

DS2200-060, DS2200-120

Designed in Germany

Table of Content

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . .4

Delivery Contents. . . . . . . . . . . . . . . . . . . . . . . . . .5

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Troubleshooting / FAQ . . . . . . . . . . . . . . . . . . . . . . .6

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Warranty and Liability . . . . . . . . . . . . . . . . . . . . . . .8

CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Disposal of the Device . . . . . . . . . . . . . . . . . . . . . . .9

Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

User Manual

USB 2.0 Active Extension with Hub

ENGLISH

Introduction

Thank you for purchasing the USB 2.0 Active Extension with Hub.

The Hi-Speed USB 2.0 Active Extension with Hub is an indispensable

accessory for PC and Mac users to bring USB peripherals such as

hard drives, printers, mice and keyboards within reach from behind

the desk or across the room. The active cable is bus powered with

an integrated amplication chipset to ensure the Hi-Speed USB

2.0 performance at longer lengths than a normal USB cable. The

combination of gold-plated connectors, bare copper conductors,

and foil & braid shielding provides superior cable performance and

error-free data transmission.

Intended Use

This product is intended for indoor use only. Do not use it outdoors.

Contact with moisture, e.g. in bathrooms, must be avoided under all

circumstances.

For safety and approval purposes (CE), you must not rebuild and/

or modify this product. If you use the product for purposes other

than those described above, the product may be damaged. In

addition, improper use can cause hazards such as short circuiting,

re, electric shock etc.

Read the instructions carefully and keep them. Make this product

available to third parties only together with its operating

instructions.

Safety Instructions

Read the operating instructions carefully and especially observe

the safety information. If you do not follow the safety instructions

and information on proper handling in this manual, we assume no

liability for any resulting personal injury or damage to property.

Such cases will invalidate the warranty/guarantee.

The device is not a toy. Keep it out of the reach of children and pets.

Do not leave packaging material lying around carelessly. These may

become dangerous playing material for children.

Suocation Risk! Keep packaging materials away from children!

Protect the product from extreme temperatures, direct sunlight,

strong jolts, high humidity, moisture, ammable gases, vapors and

solvents.

Do not place the product under any mechanical stress.

If it is no longer possible to operate the product safely, take it out

of operation and protect it from any accidental use. Safe operation

can no longer be guaranteed if the product:

• is visibly damaged,

• is no longer working properly,

• has been stored for an extended period in poor ambient

conditions or

• has been subjected to any serious transport-related stresses.

User Manual

USB 2.0 Active Extension with Hub

ENGLISH

Please handle the product carefully. Jolts, impacts or a fall even

from a low height can damage the product.

Also observe the safety and operating instructions of any other

devices which are connected to the product.

Consult an expert when in doubt about the operation, safety or

connection of the device.

Delivery Contents

1x USB 2.0 Active Extension with Hub, Black

1x User Manual

Features

USB 2.0 specication, backwards compatible with USB 1.1

The active extension cable is bus powered with an integrated

amplication chipset to ensure the Hi-Speed USB 2.0 performance

at longer lengths than a normal USB extension cable

Enjoy Hi-Speed USB 2.0 data transfer rate at up to 480Mbit/s.

Premium USB 2.0 repeater cable engineered with molded strain

relief connectors for durability and grip treads for easy plugging

and unplugging.

The combination of gold-plated connectors, bare copper conductors,

and foil & braid shielding provides superior cable performance and

error-free data transmission

Specications

Connector 1: USB Type A Male

Connector 2: USB Type A Female

Hi-Speed USB 2.0 up to 480Mbit/s data transfer rate

Plug&Play, no driver required

Cable Length

DS2200-060: 6m

DS2200-120: 12m

Troubleshooting / FAQ

Step 1

Check if the device is turned on.

If the device still does not work, go to step 2.

Step 2

Connect the device to DS2200-X again and restart the host.

If the device still does not work, go to step 3

User Manual

USB 2.0 Active Extension with Hub

ENGLISH

Step 3

Check „Device Manager“ on the host to see if it can detect a new

USB hub or not. If not, please try the other USB port or change the

host and try again.

If it still does not work, contact your dealer.

Maintenance

There are no components located inside the product that require

maintenance. Never open or attempt to dismantle the product.

Maintenance, modications and repairs are to be performed

exclusively by an expert or at a qualied shop.

If you have questions which remain unanswered by these operating

instructions, contact our technical support service or other technical

personnel.

Cleaning

Before cleaning the product, it must be disconnected from all other

connected products.

Only use dry and soft cloth to clean the product housing of the.

Do not use abrasives or solvents.

Do not use any aggressive cleaning agents, rubbing alcohol or other

chemical solutions as they can cause damage to the housing or

cause malfunctions.

To clean the product, use a soft, dry cloth. Do not apply too much

pressure to the housing as this may cause scratch marks.

You can easily remove dust using a soft bristled brush.

Warranty and Liability

The manufacturer guarantees full statutory warranty terms on all

new devices.

As the manufacturer has no inuence on installation, warranty only

applies to the product itself.

If any fault or damage is detected on your product, please contact

your dealer and provide your sales slip or invoice as evidence of

the purchase, if necessary. Your dealer will repair the fault either

on site, or send the device to the manufacturer. You make the work

of our technicians considerably easier, describing possible faults in

detail – only then can you be assured that intermittent faults, will

be found and repaired with certainty!

The manufacturer is not liable for damages to persons or property

caused by improper installation, operation or maintenance, not

described in this manual.

Do not alter or modify the product or its accessories.

User Manual

USB 2.0 Active Extension with Hub

ENGLISH

Any use other than described in this user`s manual is not permitted

and causes loss of warranty, loss of guarantee, and non-liability.

CE Conformity

PureLink GmbH hereby declares that this product series

DS2200-X complies with Directive 2014/30/EU.

The full text of the EU Declaration of Conformity is available at the

following Internet address:

www.purelink.de/ce/DS2200-X_CE.pdf

Disposal of the Device

WEEE-Reg. No.: DE 93 847 290

According to the European WEEE directive, any electrical and

electronic equipment must not be disposed of along with

consumer waste. As a consumer, you are committed by law to

deposit electrical and electronic devices at public collecting points

or to the dealer for free at the end of the device’s lifetime. Details

are regulated in the respective national legislations. The Wheelie

Bin symbol on the product, in the manual or on the packaging refers

to these terms. With the return of your used devices you actively

take part in protecting the environment.

Disclaimer

This product complies with the statutory national and European

requirements. All company names and product names are

trademarks of their respective owners.

We reserve our right for misprints and changes to the device,

packaging or user manual.
