PureLink F1 Manuel utilisateur

Owner’s Manual

Fiber Optic HDMI and USB Extension Modules

PureLinkTM

535 East Crescent Avenue

Ramsey, NJ 07446

USA

Tel: +1.201.488.3232

Fax: +1.201.621.6118

E-mail: sales@purelinkav.com

www.purelinkav.com

For order support, please contact your local dealer.

For technical support, please contact us at support@purelinkav.com

PureLink by Dtrovision

TABLE OF CONTENTS

Chapter 1. Product Overview

1.1 Safety Precautions --------------------------------------------------------------- 3

1.2 Product Description --------------------------------------------------------------- 4

1.3 Product Features --------------------------------------------------------------- 4

1.4 Common Application --------------------------------------------------------------- 4

1.5 What’s in the Box --------------------------------------------------------------- 5

1.6 Installation Guidelines --------------------------------------------------------------- 6

Chapter 2. Product Specifications

2.1 Electrical Specification --------------------------------------------------------------- 7

2.1-1 Transmitter Module ------------------------------------------------------------- 7

2.1-2 Receiver Module --------------------------------------------------------------- 8

2.1-3 HDMI Receptacle Pin Assignment ------------------------------------------ 8

2.2 Optical Specification --------------------------------------------------------------- 9

2.2-1 Transmitter Module --------------------------------------------------------------- 9

2.2-2 Receiver Module --------------------------------------------------------------- 9

2.3 Mechanical Specification ------------------------------------------------------------ 9

2.4 Environmental Specification ------------------------------------------------------- 10

2.5 System Requirements for Setup -------------------------------------------------- 10

2.6 Troubleshooting ----------------------------------------------------------------------- 10

2.7 Maintenance ------------------------------------------------------------------------- 11

2.8 UL/IEC Statement ----------------------------------------------------------------- 12

Chapter 3. Additional Information

3.1 Manufacturer’s Warranty (2-Year) ------------------------------------------------- 13

3.2 Customer Service ------------------------------------------------------------------- 13

PureLink by Dtrovision

Chapter 1. Product Overview

1.1 Safety Precautions

 All safety instructions should be read and understood before the unit is operated.

 The owner’s manual and safety instructions should be retained for future reference.

 Unplug this unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners. Use a damp

cloth only.

 Keep away from wet, magnetic, and flammable surfaces or substances.

 Always use the correct external power supply (indicated on the product label) when operating this unit.

 This unit may be equipped with a 3 wire grounding-type plug - a plug having a third (grounding) pin.

This pin will only fit in to a grounding type power outlet. If you are unable to insert the plug in to the

outlet, contact your electrician to replace your obsolete outlet.

 Air vents should be kept clean and unobstructed at all times.

 Please refrain from using frayed power cords and damaged wall outlets.

 Do not place any heavy objects or equipment on top of the unit.

If you experience any malfunctioning of product or have any question as to operation of the

product, please contact our customer service center.

PureLinkTM

Tel: 201.488.3232

Email: support@purelinkav.com

PureLink by Dtrovision

Welcome!

Congratulations on your purchase of the PureLink F1 Optical HDMI (High Definition Multimedia Interface) and

USB extension Modules. This manual contains information that will assist you in installing and operating the

product.

1.2 Product Description

The F1 fiber optical HDMI and USB extension module transmits Ultra-HD/4K HDMI v1.4b up to 300 meters

(1,000 ft), as well as USB up to 200 meters (650 ft), all over a single LC multi-mode fiber optic cable. The F1’s

compact size makes installation a snap, making it the most complete and reliable solution for long-distance

Ultra-HD/4K signal transmission.

1.3 Product Features

 HDMI 1.4b compatibility: Ultra-HD/4K transport and extension

 USB extension for full KVM operations

 Single fiber provides 300 meters (1,000 ft) HDMI 4K distance

 HDCP compliant

 Support live EDID and HDCP handshake

 Support USB 1.1

 Styled casing with bottom mounting attachments

 Maximum travel distance:

HDMI: 300 meters (1,000 ft)

HDMI + USB 1.1 Low speed: 200 meters (650 ft)

HDMI + USB 1.1 High speed 40 meters (135 ft)

*Common low speed device: Keyboard, mouse

*Common full speed device: External HDD, USB Hub, USB memory stick

1.4 Common Application

 Self-service Ticketing Kiosks (airports, movie theaters, etc.)

 Informational Kiosks (museums, galleries, exhibitions)

 Bank ATMs

 Digital Signage

 Interactive White Boards

 Conference System

 Video Wall System

 Medical, Broadcasting, Military

 Factory Automation and Traffic Control System

PureLink by Dtrovision

1.5 What’s in the Box

 F1 Optical HDMI Extension Module: One (1) pair (Tx, Rx)

 5V AC-DC Adaptor [USB Type] : One (1) unit

 USB cable : Two (2) units

 0.5 meters (1.6ft) HDMI copper cable : Two (2) units

 User’s Manual

 Option Product: TWF1 (PureLink’s multi-mode 1 LC fiber optic cable with TotalWire Technology)

1.6 Product application notes

Figure 1 – Schematic Connection Diagram of F1 Extension Modules

Figure 2 – Schematic Connection Diagram of F1 Extension Modules

PureLink by Dtrovision

1.7 Installation

Important : Please use the installation procedure below. Improper or no operation may result if the

start up sequence is not correctly followed.

Step 1

Carefully unpack the contents of the shipping group

Step 2

Plug micro USB-B cable (labeled as TX) to the female micro USB receptacle of the transmitter and then

connect the other end of the USB type A cable to the video source’s USB port.

Step 3

Plug micro USB-B cable (labeled as RX) to the micro USB receptable of the receiver and then connect the

other end of the USB type A cable to the 5V power adopter.

Step 4

Connect female USB cable (labeled as RX) from the receiver to the USB peripheral device such as

keyboard, mouse, printer, USB hub etc.

Step 5

Connect LC optical fiber cable (multi-mode) between the transmitter and the receiver.

Step 6

Connect HDMI cable between the source and the transmitter.

Step 7

Connect HDMI cable between the display and the receiver.

Step 8

Turn power on the source and the display

PureLink by Dtrovision

Chapter 2. Product Specifications

2.1 Electrical Specification

Category

Detail spec

Electrical

Electrical Connector

HDMI Receptacle Type

Video band-width

2.97Gbps

Maximum Reach

HDMI : 300m

HDMI + Full Speed USB : 40m

HDMI + Low Speed USB : 200m

Graphic Resolution Support

4096x2160@30Hz

External Power Connector

Micro USB

Optical

Optical Connector

LC Connector

Recommended Fiber

50/125um Multi Mode Fiber [OM3]

TX Module

850nm VCSEL

1310 InGaAs/InP laser diode

1550 InGaAs/InP PIN type photo diode

RX Module

1550 InGaAs/InP laser diode

850 InGaAs/InP PIN type photo diode

1310 InGaAs/InP PIN type photo diode

2.1-1 Transmitter Module

PARAMETER

Min

Typ

Max

Unit

Supply Voltage

4.5

5.5

Supply Current

450

470

Power consumption

0.85

TMDS Input Differential Voltage Level

150

1200

TMDS Input Common Mode Voltage

2.9

3.26

TMDS Min Differential Sensitivity (Peak-to-Peak)

150

TMDS Max Differential Input (Peak-to-Peak)

1560

TMDS Max Allowable Intra-Pair Skew at Connector

0.15Tbit+112ps

TMDS Max Allowable Inter-Pair Skew at Connector

0.2 Tcharacter+1.78ns

TDR Rise Time

200

PureLink by Dtrovision

2.1-2 Receiver Module

PARAMETER

Min

Typ

Max

Unit

Supply Voltage

4.5

5.5

Supply Current

400

420

Power consumption

2.1

TMDS Single-ended output swing voltage

400

600

TMDS Single-ended high level output voltage

3.3V-200mV

3.3V+10mV

TMDS Min Single-ended low level output voltage

3.3V-700mV

3.3V-400mV

TMDS Rise time/ fall time (20%-80%)

TMDS Intra-Pair Skew at Source Connector

0.15Tbit

TMDS Inter-Pair Skew at Source Connector

0.2 Tcharacter

TDR Clock duty cycle

40%

50%

60%

TMDS Differential Clock Jitter

0.25Tbit

2.1-3 HDMI Receptacle Pin Assignment

HDMI Connector Pin Assignment

Pin No.

Signal Name

Pin No.

Signal Name

TMDS DATA 2+

TMDS Clock Shield

TMDS DATA Shield

TMDS Clock -

TMDS DATA 2-

CEC

TMDS DATA 1+

Reserved (HDMI 1.0–1.3c)

TMDS DATA Shield

SCL (I²C Serial Clock for DDC)

TMDS DATA 1-

SDA (I²C Serial Data Line for DDC)

TMDS DATA 01+

DDC/CEC/HEC Ground

TMDS DATA Shield

+5 V (max 50 mA)

TMDS DATA 0-

Hot Plug detect (all versions)

TMDS Clock +

2.2 Optical Specification

PureLink by Dtrovision

2.2-1 Transmitter Module

PARAMETER

Min

Typ

Max

Unit

Output Power 10G

-2.5

2.5

dBm

Output Power 1G

-5

2.5

dBm

Output Power 10G Extinction Ratio

Output Power 1G Extinction Ratio

5.5

Sensitivity

-20

dBm

2.2-2 Receiver Module

PARAMETER

Min

Typ

Max

Unit

Output Power 1G

-5

2.5

dBm

Extinction Ratio

5.5

Output Power 10G Sensitivity

-20

dBm

Output Power 1G Sensitivity

-6

dBm

2.3 Mechanical Specification

Front : HDMI connector

Back : LC connector and Micro USB connector

2.4 Environmental Specification

PureLink by Dtrovision

Items

Status

Operating Temperature

32˚F ~ 122˚F (0˚C ~ 50˚C)

Operating Humidity

10% ~ 80%, non-condensing

Storage Temperature

-4˚F ~ 158˚F (-20˚C ~ 70˚C)

Storage Humidity

5% ~ 95%, non-condensing

Dimension (WxDxH)

2.20’ x 2.20’ x 0.56’ (56mm x 56mm x 14mm)

Weight w/o Packaging

90g

Weight

400g

2.5 System Requirements for Setup

 Hardware requirements

 You have to have a HDMI graphic controller or card having a HDMI port in your PC, SUN or Mac

systems. It should support the maximum graphic resolution feature of displays to be connected.

 No special requirements for memory size, CPU speed and chipsets, if you’ve already properly

installed your HDMI graphic controllers or cards.

 Software requirements

 No special restrictions, if you’ve already properly installed your HDMI graphic controller in your

OS.

 AC/DC Power Adapter Technical Advisory

The transmitter (Tx) module of F1 is designed for power protection circuit from conflict of power

supply between the external DC power adapter and your graphic card through the HDMI pin. It

offers an option of whether to use an AC/DC power adapter depending on power supply capability

of the graphic card through the +5V pin, you are using.

However, the receiver (Rx) module should be supplied by an AC/DC power adapter.

Note : In general, most of laptops or desktop PCs with PCI Express graphic card supply

enough power to operate Transmitter (Tx) module.

Table des matières

Autres manuels PureLink Extenseur

PureLink

PureLink PureMedia 4K Manuel utilisateur

PureLink

PureLink WHD100-V2 Manuel utilisateur

PureLink

PureLink PT-E-HD50 Manuel utilisateur

PureLink

PureLink DVI Pure Fiber Optic Extender Dual LinkODC Manuel utilisateur

PureLink

PureLink HTE Tx Manuel utilisateur

PureLink

PureLink WHD030-V2 Manuel utilisateur

PureLink

PureLink HW-100 Manuel utilisateur

PureLink

PureLink HWCE TX Manuel utilisateur

PureLink

PureLink PureLink DTS50R Manuel utilisateur

PureLink

PureLink CSW030 Manuel utilisateur

PureLink

PureLink WHD030-V2 Manuel utilisateur

PureLink

PureLink Fiber Optic Extenders Manuel utilisateur

PureLink

PureLink HWCE-III Manuel utilisateur

PureLink

PureLink CSW100 Manuel utilisateur

PureLink

PureLink HTS50R Manuel utilisateur

PureLink

PureLink PM Series Manuel utilisateur

PureLink

PureLink PureTools PT-HDBT-200 Manuel utilisateur

PureLink

PureLink PureMedia PM-CT101-U Manuel utilisateur

PureLink

PureLink DTS-1000RV Manuel utilisateur

PureLink

PureLink HOF1 Manuel utilisateur

PureLink

PureLink VIP-101-E-WP Manuel utilisateur

PureLink

PureLink WHD100T Manuel utilisateur

PureLink

PureLink FIBERX FX-P350 Manuel utilisateur

PureLink

PureLink Media Axis HDBaseT MAX-CT101 Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
