PureLink PM Series Manuel utilisateur

PM Series Fiber Optic Extenders

Owner’s Manual

PM Series Fiber Optic Standalone and Wall-plate type Extender

PureLinkTM

535 East Crescent Ave

Ramsey NJ 07446, USA

Tel: 201.488.3232

Fax: 201.621.6118

Website : www.purelinkav.com

E-mail : info@purelinkav.com

For Technical Support, contact us at

support@purelinkav.com

PureLink by Dtrovision

TABLE OF CONTENTS

Chapter 1. Introduction

1.1 Safety Precautions --------------------------------------------------------------------------- 3

1.2 Product Introduction -------------------------------------------------------------------------- 4

1.3 Package Contents ----------------------------------------------------------------------------- 4

Chapter 2. Features and Specifications

2.1 Features ----------------------------------------------------------------------------------------- 5

2.2 Transmitter Specifications ------------------------------------------------------------------ 6

PM-FT101 --------------------------------------------------------------------------------------- 6

PM-FT102 --------------------------------------------------------------------------------------- 8

PM-FT103 --------------------------------------------------------------------------------------- 9

Transmitters Compatibility Chart ----------------------------------------------------------- 12

2.3 Receiver Specifications ---------------------------------------------------------------------- 13

PM-FR101 -------------------------------------------------------------------------------------- 13

PM-FR102 -------------------------------------------------------------------------------------- 14

PM-FR103 -------------------------------------------------------------------------------------- 16

Receivers Compatibility Chart ------------------------------------------------------------- 19

2.4 Operation and Reliability Specification --------------------------------------------------- 20

Chapter 3. Installation and Operating Instruction

3.1Installation --------------------------------------------------------------------------------------- 21

3.2Operating Instruction -------------------------------------------------------------------------- 21

3.3Cable Termination ----------------------------------------------------------------------------- 23

3.4Connector Pin Assignment ------------------------------------------------------------------ 24

Chapter 4. Additional Information

4.1 Warranty ------------------------------------------------------------------------------------------ 26

4.2 FCC/CE Statement --------------------------------------------------------------------------- 27

PureLink by Dtrovision

Chapter 1. Introduction

1.1 Safety Precautions

When using and installing Dtrovision PureLink product, adhere to the following basic safety

precautions.

Read and understand all instructions before using and installing this product.

The safety and operating instructions should be retained for future reference.

Always use the correct external power supply (indicated on the product label) when

operating this unit.

Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners

or aerosol cleaners. Use a damp cloth for cleaning.

Mishandling of this product may lead to a fire or explosion hazard.

Do not place any heavy objects or equipment on top of the product.

Keep away from wet, magnetic, and flammable surfaces or substances.

Air vents should be kept clean and unobstructed at all times.

Any external impact may cause damage to the operation of this unit.

Be sure this product is properly grounded (earthed) in order to prevent the risk of

electrical shock.

Turn off and unplug power before adding or removing Input/Output Boards.

Input/Output Boards may be damaged when they are replaced with power turned on.

Use surge protectors and/or AC line conditioners when powering this product.

Only use a fuse(s) with the correct fuse rating in your enclosure.

Make sure the product is on or attached to a stable surface.

If you experience any malfunctioning of product or have any question as to operation

of the product, please contact our customer service center.

PureLinkTM

Tel: 201.488.3232

Email: support@purelinkav.com

PureLink by Dtrovision

1.2Product Introduction

Pure fiber optic cable for video, audio, and control signal

PM series Fiber Optic (2 LC) extension system is designed to transmit video (DVI, HDMI

or VGA), audio (Embedded or analog stereo audio), control (RS232/422 and IR) over a

pure LC to LC fiber optic cable for long distance up to 6,600ft. This optical connection

enables to minimize electrical noise and EMI free that is ideal for long distance extension

of high definition HDMI/DVI or VGAvideo signal, HDMI embedded audio or 3.5mm

stereo analog audio, and control signal.

1.3Package Contents

Please make sure all of the following items are included in the package:

1) One of PM-FT101, FT102, FT103 Transmitter Module or

2) One of PM-FR101, FR102, FR103 Receiver Module

3) 5pin Phoenix Connector for RS-232/422

4) DC 12V Power Supply Unit with a Power Cord

PureLink by Dtrovision

Chapter 2. Features and Specifications

2.1Features

▶Transmitters directly compatible with PM Fiber Optic Input Board

PM Fiber Optic (2 LC) Transmitters can send signal directly to PM series Matrix

Router's Fiber Optic Input Board, eliminating the need of matching Receiver.

▶Receivers directly compatible with PM Fiber Optic Output Board

PM Fiber Optic (2 LC) Receivers can receive signal directly from PM series Matrix

Router's Fiber Optic Output Board, eliminating the need of matching Transmitter.

▶HDMI v1.4, 3D Support

Adopting latest HDMI version 1.4 enables to support 3D, 48-Bit Deep Color, 4K x 2K

resolution and 7.1 Channel Dolby TruHD & DTS MasterHD

▶Auto-EDID (EDID Library, Emulation)

PureLink's EDID library and emulation features failsafe EDID capture & storage to

provide constant and continuous EDID for source devices.

▶HDCP Compliant

▶Various Transmitter and Receiver Choices

There are three different type of transmitters and three different type of receivers to

make today's sophisticated digital AV environment simple and flexible.

▶RF6 1RU Rack Mountable Version Available

PM-FT101, PM-FT102, PM-FR101, and PM-FR102 are also available in PureLink's

popular RF6 Rack Mountable Extension Center Modules.

▶Analog Support (VGA and Component)

On PM-FT102 and PM-FT103 series, there are two video inputs; DVI/HDMI and VGA,

which are selectable via front panel button or serial command when it is connected PM

series Matrix Router. VGA port is designed to take component (YPbPr) signal with

appropriate adapters or cables.

▶USB Firmware Update

▶Long Distance Transmission up to 6,600ft (2,000 m)

PureLink by Dtrovision

▶Plug-N-Play

▶Resolutions up to WUXGA 1920x1200, HD 1080p @ 60Hz, and 4K2K

▶Integrated Noise-cancellation and Error-correct Logic for both Input and Output

Ports to prevent any damage caused by Electrical Noise.

2.2Specifications

Transmitters :

PM-FT101 : Standalone type (Loop Through)

Input: HDMI + 3.5mm stereo audio (x1) + RS-232/422

Output: Fiber Optic (2 LC) and HDMI Loop-Through

6,600ft, Compatible with PM-FIS4 input board

Front Connection Ports:

Power S/W: Power On/Off switch

Power LED: Power status indicator

Status LED: Video signal presence indicator

HDMI LED: HDMI signal indicator

EDID save S/W: EDID save button

EDID select S/W: EDID library function selection rotary switch

Firmware: USB firmware update port

PureLink by Dtrovision

Back Connection Ports:

HDMI/DVI In: HDMI/DVI input port

HDMI/DVI Out: HDMI/DVI Loop-thru output port

Audio In: Stereo audio input port

2 LC: Fiber Optic output port

RS-232/422: RS-232/422 communication port

DC In: DC 12V Power port

Model Name

PM-FT101 (HDMI version), PM-FT102-D (DVI version)

Input Signal

DVI / HDMI (TMDS)

3.5mm stereo audio

Output Signal

Fiber Optical Output ( > -10dbm (after 6,600ft (2km) transmission))

DVI / HDMI (Loop-thru)

Extinction Ratio

> 4db (after 6,600ft (2km) transmission)

Data Transmission

Speed

3.4 Gbps/ch, Total 10.2 Gbps Max

Supporting Display

Resolutions

PC: VGA ~ WUXGA

(up to 1920 x 1200 @60Hz)

HDTV: 480i ~ 1080p, 2K4K

Max. Distance

Single Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 6,600 ft (2km)

Multi Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 1,650 ft (500m)

Connector Type

DVI 29P/HDMI 19P Female (x 2)

3.5mm Stereo Jack

2 LC Optical Connector

3P /3.5MM Terminal Block (for Power)

5P /3.5MM Terminal Block (for RS-232/422)

Mini USB (for firmware update)

Conformations

DVI 1.0 , HDMI 1.4

HDCP Compliance

Yes

Power Rating

DC +12V, 4Watts Max

Dimension

6.3' x 4.4' x 1.7' (160 x 112 x 42 mm)

Weight

1.43 lbs (0.65 Kg)

PureLink by Dtrovision

PM-FT102 : Standalone type (2x1 switch)

Input: Selectable HDMI/DVI or VGA + 3.5mm stereo audio (x2) +

RS-232/422

Output: Fiber Optic (2 LC)

6,600ft, Compatible with PM-FIS4 input board

Front Connection Ports:

Power S/W: Power On/Off switch

Power LED: Power status indicator

Status LED: Video signal presence indicator

HDMI LED: HDMI signal indicator

VGA LED: VGA(or component) signal indicator

EDID save S/W: EDID save button

EDID select S/W: EDID library function selection rotary switch

Firmware: USB firmware update port

Back Connection Ports:

HDMI/DVI In: HDMI/DVI input port

VGA In: VGA (or component) input port

Audio In: Stereo audio input port

2 LC: Fiber Optic output port

RS-232/422: RS-232/422 communication port

DC In: DC 12V Power port

PureLink by Dtrovision

Model Name

PM-FT102 (HDMI version), PM-FT102-D (DVI version)

Input Signal

DVI / HDMI (TMDS), VGA (supports YPbPr component)

3.5mm stereo audio

Output Signal

Fiber Optical Output ( > -10dbm (after 6,600ft (2km) transmission))

Extinction Ratio

> 4db (after 6,600ft (2km) transmission)

Data Transmission

Speed

3.4 Gbps/ch, Total 10.2 Gbps Max

Supporting Display

Resolutions

PC: VGA ~ WUXGA

(up to 1920 x 1200 @60Hz)

HDTV: 480i ~ 1080p, 2K4K

Max. Distance

Single Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 6,600 ft (2km)

Multi Mode Fiber: 1920 x 1200 @ 60Hz or at 1080p : 1,650 ft (500m)

Connector Type

DVI 29P/HDMI 19P Female (x 2)

3.5mm Stereo Jack

2 LC Optical Connector

3P /3.5MM Terminal Block (for Power)

5P /3.5MM Terminal Block (for RS-232/422)

Mini USB (for firmware update)

Conformations

DVI 1.0 , HDMI 1.4

HDCP Compliance

Yes

Power Rating

DC +12V, 4Watts Max

Dimension

6.3' x 4.4' x 1.7' (160 x 112 x 42 mm)

Weight

1.43 lbs (0.65 Kg)

PM-FT103 : Wall plate type (2x1 switch), 2 Gang Decora style, white finish.

Input: Selectable HDMI or VGA + 3.5mm stereo audio (x1) + RS-232

Output: Fiber Optic (2 LC)

6,600ft, Compatible with PM-FIS4 input board

PureLink by Dtrovision

Front Connection Ports:

Power LED: Power status indicator

Status LED: Video signal presence indicator

HDMI LED: HDMI signal indicator

VGA LED: VGA(or component) signal indicator

EDID save S/W: EDID save button

EDID select S/W: EDID library function selection rotary switch

HDMI/DVI In: HDMI/DVI input port

VGA In: VGA (or component) input port

Audio In: Stereo audio input port

RS-232: RS-232 communication port

Back Connection Ports:

2 LC: Fiber Optic Output Port

DC In: DC 12V Power port

Model Name

PM-FT103

Input Signal

DVI / HDMI (TMDS), VGA (supports YPbPr component)

3.5mm stereo audio

Output Signal

Fiber Optical Output ( > -10dbm (after 6,600ft (2km) transmission))

Autres manuels pour PM Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels PureLink Extenseur

PureLink

PureLink VIP-101-E-WP Manuel utilisateur

PureLink

PureLink CSW320 Manuel utilisateur

PureLink

PureLink HW-100 Manuel utilisateur

PureLink

PureLink PureMedia 4K Manuel utilisateur

PureLink

PureLink FX1010 Manuel utilisateur

PureLink

PureLink HWCE-III Manuel utilisateur

PureLink

PureLink Media Axis HDBaseT MAX-CT101 Manuel utilisateur

PureLink

PureLink PureTools PT-HDBT-200 Manuel utilisateur

PureLink

PureLink HEXA PRO Manuel utilisateur

PureLink

PureLink HE101-U Manuel utilisateur

PureLink

PureLink DVI Pure Fiber Optic Extender Dual LinkODC Manuel utilisateur

PureLink

PureLink WHD030-V2 Manuel utilisateur

PureLink

PureLink HDX II Manuel utilisateur

PureLink

PureLink Media Axis MAX-FT101 Manuel utilisateur

PureLink

PureLink H3C-100-ARC Manuel utilisateur

PureLink

PureLink PM Series Manuel utilisateur

PureLink

PureLink PT-E-DV30 Manuel utilisateur

PureLink

PureLink HWCE TX Manuel utilisateur

PureLink

PureLink HTS50R Manuel utilisateur

PureLink

PureLink HOF2 Manuel utilisateur

PureLink

PureLink WHD030-V2 Manuel utilisateur

PureLink

PureLink Fiber Optic Extenders Manuel utilisateur

PureLink

PureLink DVI Pure Fiber Optic Extender Dual LinkODC Manuel utilisateur

PureLink

PureLink HCE II Manuel utilisateur

Manuels Extenseur populaires d'autres marques

SY HDBT-60T Manuel utilisateur

Appsys ProAudio

Appsys ProAudio ADX-16 Manuel utilisateur

Atlona

Atlona RS232 Manuel utilisateur

IDK

IDK OPF-TH1000-A Manuel utilisateur

Enable-IT

Enable-IT 824WP Manuel utilisateur

Worx

Worx Landroid RadioLink WA0864 Fiche technique

TP-Link

TP-Link TL-WA730RE Manuel utilisateur

Camplex

Camplex CMX-HDMI-SFPL Manuel utilisateur

SC&T

SC&T HE03-4K Manuel utilisateur

Marmitek

Marmitek MegaView70 Manuel utilisateur

Samsung

Samsung SCS-26UC4 Manuel utilisateur

Foxun

Foxun SX-GES24 Manuel utilisateur

MuxLab

MuxLab 500771 Manuel utilisateur

foxunhd

foxunhd SX-AEX01 Manuel utilisateur

TERK Technologies

TERK Technologies LFIRX2 Manuel utilisateur

Devolo

Devolo Audio Extender Manuel

Edimax

Edimax EW-7438RPn V2 Manuel utilisateur

Shinybow USA

Shinybow USA SB-6335T5 Manuel utilisateur
