Pulsar VD57 Manuel utilisateur

CAL. V657, VD57

CHRONOGRAPH

ENGLISH

TIME/CALENDAR

CHRONOGRAPH

●Hour, minute and second hands

●Date displayed in numerals

●Measures up to 60 minutes in 1/10 second increments.

●Split time measurement

English

2a: Normal position c: Second click

a b c

b: First click

CHRONOGRAPH

second hand

DISPLAY AND CROWN/BUTTONS

CROWN

CHRONOGRAPH

minute hand

Second hand

Date

Minute hand

CHRONOGRAPH

1/10-second hand

Hour hand

English

SCREW DOWN CROWN

[for models with screw down crown]

Locking the crown

1Turn Crown counterclockwise until you no

longer feel the threads turning.

2Crown can be pulled out.

1Push Crown back in to normal position.

2Turn Crown clockwise while pressing it lightly

until tight.

Unlocking the crown

English

●Before setting the time, be sure to check that the CHRONOGRAPH hands are in

“0” position when the chronograph is reset. (For resetting the chronograph, see

“CHRONOGRAPH” on page 6)

ADJUSTING CHRONOGRAPH HAND POSITION

* If any of the CHRONOGRAPH hands do not return to “0” position, follow the

procedure below to reset the hands.

Pull out to second click.

CROWN

CROWN Push back in to normal

position.

CROWN

Press repeatedly to reset

CHRONOGRAPH 1/10-

second hand to “0” position.

BPress repeatedly to reset

CHRONOGRAPH second

and minute hands to “0”

position.

▲

English

TIME/CALENDAR SETTING

123

1Pull out to first click, and turn clockwise until the previous day’s date

appears.

2Pull out to second click when Second hand is at the 12 o’clock position.

3Turn clockwise until the desired date appears.

4Turn to set Hour and Minute hands.

5Push back in to normal position in accordance with a time signal.

CROWN

English

CHRONOGRAPH

minute hand

✩After the measurement exceeds 1 minute, the CHRONOGRAPH 1/10-

second hand stays at “0” position.

When the measurement is stopped, it will move to indicate the elapsed 1/10

seconds.

CHRONOGRAPH

1/10-second hand AStart / Stop / Restart

CHRONOGRAPH

second hand BReset /

Split /Split release

Ex.: 15 minutes and 10.6 seconds

✩

English

1Use the stopwatch to determine

how many seconds it takes to go

1 km or 1 mile.

2Locate the second marker on the

main dial that corresponds to the

measured seconds, and the

tachymeter scale it indicates gives

the average speed per hour.

TACHYMETER

[for models with tachymeter scale on the dial]

To measure the hourly average speed of a vehicle

▲

Ex. 1

“90” (tachymeter scale figure) x

1 (km or mile) = 90 km/h or mph

Tachymeter

scale: “90”

Tachymeter scale can be used only when the time required is less than 60 seconds.

Ex. 2: If the measuring distance is extended to 2 km or miles or shortened to

0.5 km or miles and CHRONOGRAPH second hand indicates “90” on

CHRONOGRAPH

second hand:

40 seconds

English

To measure the hourly rate of operation

1Use the stopwatch to measure the

time required to complete 1 job.

2Locate the second marker on the

main dial that corresponds to the

measured seconds, and the

tachymeter scale it indicates gives

the average number of jobs

accomplished per hour.

Ex. 1

▲

“180” (tachymeter scale figure) x

1 job = 180 jobs/hour

CHRONOGRAPH

second hand:

20 seconds

Tachymeter

scale: “180”

Ex. 2: If 15 jobs are completed in 20 seconds:

“180” (tachymeter scale figure) x 15 jobs = 2700 jobs/hour

tachymeter scale:

“90” (tachymeter scale figure) x 2 (km or mile) = 180 km/h or mph

“90” (tachymeter scale figure) x 0.5 (km or mile) = 45 km/h or mph

English

ADJUSTING CHRONOGRAPH HAND POSITION

●The “0” position of the CHRONOGRAPH 1/10-second hand differs depending on the

models.

NOTES ON OPERATING THE WATCH

●The CHRONOGRAPH minute hand moves correspondingly with the CHRONOGRAPH

second hand.

●The hands move quickly if the respective buttons are kept pressed.

TIME/CALENDAR SETTING

●Do not set the date between 9:00 p.m. and 1:00 a.m. Otherwise, the date may not

change properly.

●When setting the hour hand, be sure to check that AM/PM is correctly set. The watch

is so designed that the date changes once in 24 hours.

* Turn the hands past the 12 o’clock marker to determine whether the watch is set for

the A.M. or P.M. period. If the date changes, the time is set for the A.M. period. If

not, the time is set for the P.M. period.

* Some models have the “0” position of the CHRONOGRAPH 1/10-second hand at 3

and 9 o’clock sides of the small dial. In that case, check if the hand is level with its

both ends pointing to those “0” positions.

●When setting the minute hand, first advance it 4 to 5 minute ahead of the desired time

and then turn it back to the exact minute.

English

●While the crown is at the second click, do not press the buttons. Otherwise, the

CHRONOGRAPH hands will move. To reset them to “0” position, see “ADJUSTING

CHRONOGRAPH HAND POSITION” on page 4.

CHRONOGRAPH

●While the chronograph is counting, do not pull out the crown to set the time. Otherwise,

the chronograph operation cannot be made.

●The CHRONOGRAPH 1/10-second scale and hand differ in design and shape depending

on the models.

* Some models have the CHRONOGRAPH 1/10-second scale graduated on the upper

half of the small dial and the hand which is so designed that both ends can indicate

the elapsed 1/10 second. In that case, read the marker on the scale where either end

of the hand points to.
