Planet MII Series Manuel utilisateur

Fast / Gigabit Ethernet Switch Module

MII series

User's Manual

Trademarks

Contents subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other

trademarks belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work

properly in all environments and applications, and makes no warranty

and representation, either implied or expressed, with respect to

the quality, performance, merchantability, or tness for a particular

purpose.

PLANET has made every effort to ensure that this User’s Manual is

accurate; PLANET disclaims liability for any inaccuracies or omissions

that may have occurred.

Information in this User’s Manual is subject to change without notice

and does not represent a commitment on the part of PLANET. PLANET

assumes no responsibility for any inaccuracies that may be contained in

this User’s Manual. PLANET makes no commitment to update or keep

current the information in this User’s Manual, and reserves the right

to make improvements to this User’s Manual and/or to the products

described in this User’s Manual, at any time without notice.

If you nd information in this manual that is incorrect, misleading, or

incomplete, we would appreciate your comments and suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with

the Instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area

is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may

cause radio interference, in which case the user may be required to

take adequate measures.

WEEE Warning

To avoid the potential effects on the environment and human

health as a result of the presence of hazardous substances in

electrical and electronic equipment, end users of electrical

and electronic equipment should understand the meaning of

the crossed-out wheeled bin symbol. Do not dispose of WEEE as

unsorted municipal waste and have to collect such WEEE separately.

Revision

User’s manual for Fast / Gigabit Ethernet Switch Module

For model: MII-VSC / MII-VST / MII-VS15 / MII-VSA20 / MII-VSB20 /

MII-GT/ MII-SX / MII-LX / MII-L40 / MII-L70 / MII-SFP /

MII-LA15 / MII-LB15

Rev: 7.0 (JULY, 2008)

Part No: 2010-000021-007

Table of Contents

Chapter 1 OVERVIEW...................................................................... 5

Chapter 2 MODEL LIST ................................................................... 6

Chapter 3 CHECKLIST ..................................................................... 7

Chapter 4 INTRODUCTION ............................................................. 8

4-1 1-Port 100Base-FX Fast Ethernet Modules-MII-VSC /

MII-VST / MII-VS15 / MII-VSA20 / MII-VSB20 .................... 8

4-2 1-Port 1000Base-T Gigabit Ethernet Module-MII-GT ............11

4-3 1-Port 1000Base-SX/LX Gigabit Ethernet

Modules-MII-SX / MII-LX / MII-L40 / MII-L70 /

MII-LA15 / MII-LB15........................................................12

4-4 1-Port 1000Base-T/Mini GBIC interface Module-MII-SFP ......14

Chapter 5 Installing Optional Modules..............................................16

Chapter 1 OVERVIEW

Thank you for purchasing PLANET MII family Fast / Gigabit Ethernet

module. The MII family Fast / Gigabit Ethernet module can install into

PLANET FNSW / FGSW family Switch. The distance can be extended

from 100 meters (TP), 2 kilometers (Multi-mode, SC or ST), up to 120

kilometers (Single-mode, SC/LC).

Chapter 2 MODEL LIST

Your MII family Fast / Gigabit Ethernet module comes with one of the

following models.

Model Interface Fiber connector

and distance

Fast Ethernet

MII-VSC 100Base-FX Module (SC, MM, 2km)

MII-VST 100Base-FX Module (ST, MM, 2km)

MII-VS15 100Base-FX Module (SC, SM, 15km)

MII-VSA20 100Base-FX Module (SC, SM, 20km)

MII-VSB20 100Base-FX Module (SC, SM, 20km)

Gigabit Ethernet

MII-GT 10/100/1000Base-T Module (RJ-45, 100m)

MII-SX 1000Base-SX Module (SC, MM, 550m)

MII-LX 1000Base-LX Module (SC, SM, 10km)

MII-L40 1000Base-LX Module (SC, SM, 40km)

MII-L70 1000Base-LX Module (SC, SM, 70km)

MII-SFP 1000Base-T/Mini-GBIC Module (RJ-45, 100m)

MII-LA15 1000Base-LX Module (SC, SM, 15km)

MII-LB15 1000Base-LX Module (SC, SM, 15km)

Models with LX or last two numbered characters indicate the ber-port

is with “Single-Mode” optic ber connector and the number indicates

the maximum distance in km. The rest will be “Multi-Mode” optic

ber models.

Chapter 3 CHECKLIST

Your MII carton should contain the following items:

The MII family Fast / Gigabit Ethernet module

This user’s manual

If any item is missing or damaged, please consult the dealer from

whom you purchased your MII family Fast / Gigabit Ethernet module.

Chapter 4 INTRODUCTION

4-1 1-Port 100Base-FX Fast Ethernet Modules - MII-VSC /

MII-VST / MII-VS15 / MII-VSA20 / MII-VSB20

Figure 1. 1-Port 100Base-FX (SC, Multi-mode) Module Front View

Features:

● Comply with IEEE 802.3u, 100Base-FX Fast Ethernet standard

● 1 x 100Base-FX ber ports (SC/ST/single SC ber connectors)

● Store-and-Forward technology for abnormal packet ltering

● For establishing ber link with cable length up to 2km (Multi-mode

module) and 15/20km (Single-mode module) or 412m (half-duplex

mode)

● Slide switch for Half /Full-Duplex selection (default in full-duplex)

● Plug and Play Installation

Note

1. The fiber connector and distance support will be

different by various models.

2. The MII-VSA20/VSB20 should runs in pair. It means

you must connect MII-VSA20 in one end and another

MII-VSB20, for example, in the other end.

LED DEFINITION

LED Color Function

LNK/

ACT Green

Lit: indicate the link through that port is

successfully established.

Blink: indicate that the switch is actively sending

or receiving data over that port.

FDX Orange

Lit: indicate that port is operating in full-duplex

mode.

Off: indicate that port is operating in half-duplex

mode.

Blink: if a collision is detected when the port is

in half-Duplex mode.

Table 1. LED denition of 100Base- FX module

Slide switch settings:

Figure 2 shows the 100Base-FX module slide switch overview and the

screen in Figure 3 appears shows the web settings for working under

100Mbps full-duplex mode and half-duplex mode.

Please make sure you have correctly congured the 100Base-FX

module in the same duplex mode between the module’s slide switch

and web interface speed duplex mode settings of module slots before

physically installing the modules.

F U L L

H A L F

Figure 2. Slide switch overview of 100Base- FX module

Figure 3. 100Base- FX module duplex mode setting of web interface

Table 2 below shows the settings for working under 100Mbps full-

duplex mode and half-duplex mode. Both module (slide-switch) and the

switch (web interface) should be xed on the same mode.

Speed/duplex 100Full-duplex mode 100Half-duplex mode

Hardware (module) Full-duplex mode Half-duplex mode

Software (rmware) 100 Full 100 Half

Table 2. Settings of 100Base-FX module

Table 3 below shows the slide switch operation for full duplex and half

duplex mode.

Slide Switch Description

FDX

The module works on full duplex mode. The other side must

be also congured on full duplex mode. This provides up

to 2km distance by multi-mode module and 15/20km by

single-mode module.

HDX

The module works on half duplex mode. The other side must

be also congured on half duplex mode. This provides up to

412m distances.

Table 3. Slide switch settings of 100Base-FX module
