Planet EH-1600 Manuel utilisateur
Ethernet 10Base-T Hub
EH-500
EH-800A
EH-1600
Rev. 3.0
Trademarks
Copyright PLANET Technology Corp. 1998.
PLANET is a registered trademark of PLANET Technology
Corp. The information in this manual is subject to change
without notice. All other trademarks belong to their respective
owners.
Contents subject to revision without prior notice.
CE Marking Warning
This is a class A product. In a domestic environment this
product may cause radio interference in which case the user
may be required to take adequate measures.
FCC Warning
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
Instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his
own expense.
Revision
This user's manual is for PLANET SOHO hub model --
EH-500 , EH-800A , EH-1600
Rev: 4.0 (Jun, 1998)
Part No: EMH-5/8/16V4
EH-500/800A/1600 User’s Manual
3
TABLE OF CONTENTS
CHAPTER 1 INTORDUCTION....................................................5
PRODUCT INTRODUCTION..............................................................5
PRODUCT FEATURES......................................................................5
UNPACKING THE HUB ....................................................................6
CHAPTER 2 GENERAL DESCRIPTION....................................7
COVER PANEL OF EH-500/EH-800A/EH-1600 .............................7
LED INDICATOR ............................................................................8
FRONT & REAR PANEL ..................................................................8
Front Panel..............................................................................8
Rear Panel................................................................................9
CHAPTER 3 INSTALLATION ...................................................11
GETTING READY TO INSTALL THE HUB ........................................11
Power Requirement................................................................11
PREPARE TO INSTALL...................................................................11
STP port and STP/UTP Cable................................................11
BNC port and Coaxial Thin Cable.........................................12
AUI port .................................................................................12
INSTALLATION, STEP BY STEP.......................................................13
CHAPTER 4 TROUBLESHOOTING.........................................15
CHAPTER 5...................................................................................17
PRODUCT SPECIFICATION.....................................................17
EH-500/800A/1600 User’s Manual
5
CHAPTER 1 INTORDUCTION
Product Introduction
EH-500, EH-800A and EH-1600 is a standard Ethernet
concentrator that re-times and re-transmits the signal to each
network station on the LAN. It simplifies the implementation of
twisted-pair Ethernet compatible networks following the IEEE
802.3 10Base-2/5/T CSMA/CD standard. Each Hub has 5/8/16
modular RJ-45 STP ports and one BNC port; EH-1600 also have
an AUI port for attaching network devices (file server, bridge,
and workstations) or additional concentrators.
Product Features
EH-500/EH-800A/EH-1600 provides all the functions necessary
to support the requirements of Ethernet networks. These function
includes the following features:
♦5/8/16-port STP RJ-45 connector and one port BNC, one port
AUI(EH-1600).
♦Manchester decoder for clock and data recovery
♦Automatic preamble regeneration to compensate for any bit
loss
♦Lockup and auto-partition for jabber to isolate network
failures
♦Auto-Polarity correction
♦LEDs for Power, Collision, and Link, TX/RX per port
♦Desktop or wall-mountable(EH-500/EH-800A).
PLANET Ethernet Hub
6
Unpacking the Hub
Carefully unpack the package and check its contents against the
checklist given below.
Checklist of EH-500/EH-800A/EH-1600 10Base-2/5/T Hub
•5/8/16-port 10BASE-2/5/T Ethernet Hub
•Power Adapter
•User's Manual
•T-connector
Please inform your dealer immediately for any wrong, missing,
or damaged part if possible, retain the carton including the
original packing materials, and use them against to repack the
product in case there is a need to return it to us for repair.
EH-500/800A/1600 User’s Manual
7
CHAPTER 2 GENERAL DESCRIPTION
Cover Panel of EH-500/EH-800A/EH-1600
On the cover panel, there are Power, Collision LED. And one
LEDs for each RJ-45 STP & BNC, AUI port (EH-1600);. These
LED indicators help in diagnosing line troubles and indicate the
status of data transmission.
BNC DC 5~7.5V
EH-500
5-port 10BASE-2/T
Palm Top Hub
STP 1 STP2 STP3 STP4 OR DAISY-CHAIN
POWER
COLLISION
BNC
STP 4
STP 3
STP 2
STP 1
Link/RX
BNC DC 7.5V
POWER
COLLISION
BNC
1
2
3
4
EH-800A
8-port 10BASE-2/T
Palm Top Hub
5
6
7
8
STP 1 STP2 STP3 STP4 STP5 STP6 STP7 STP8 OR DAISY-CHAIN
Link: Green
RX: Blink
Figure 2-1 Cover Panel of EH-500 / EH-800A
BNC AUI DC 12V
EH-1600
16-port 10BASE-2/5/T
DeskTop Hub
DAISY-CHAIN OR STP 1 STP2 STP3 STP4 STP5 STP6 STP7 STP8 STP9 STP10 STP11 STP11 STP12 STP13 STP14 STP15 STP16
POWER
COLLISION
AUI
BNC
1 9
2 10
311
4 12
5 13
6 14
7 15
8 16
Link: Green
RX: Blink
Figure 2-2 Cover Panel of EH-1600
PLANET Ethernet Hub
8
LED indicator
LEDs Status Description
Power Steady Green Indicates hub is power on
Collision Blinking Red Blinks when network collision
are detected
Link/RX Steady Orange Indicates Link integrity pulses
are being received
Blinking
Orange Blinks when data is received
BNC Blinking
Orange Blinks when data is receiving /
transmitting
AUI Blinking
Orange
(EH-1600)
Blinks when data is receiving /
transmitting
Front & Rear Panel
Front Panel
As shown in Figure 2-3.
Figure 2-3 Front Panel of EH-500/ EH-800A/EH-1600
5/8/16-port RJ-45/STP connector and one daisy chain port.
Note: Use of both “DAISY-CHAIN”port and STP1 of EH-1600, STP8
of EH-800A or STP4 of EH-500 will make these two ports
malfunction.
EH-500/800A/1600 User’s Manual
9
Rear Panel
As shown in Figure 2-4.
Fi
gure 2-4 Rear Panel of EH-500/ EH-800A/EH-1600
There are one DC power connector, one BNC connector for the
hub, and one AUI connector for EH-1600.
Note: Pleases check the AC adapter bundled with this hub. The
DC output should be 5V~7.5VDC (EH-500) 7.5VDC
(EH-800A) or 12VDC (EH-1600). And it polarity should
be .
