Table Top TV Stand Instruction Manual
V4.0
Model: PSTVS03
Thank you for choosing this PERLESMITH product! At PERLESMITH we strive
to provide you with the best quality products and services in the industry.
Should you have any issues, please don't hesitate to contact us at
Technical Support:
(US/CA)1-800-556-6806 Mon-Fri 8am - 8pm(CST)
(UK)44-808-196-3891 Mon-Fri 2pm - 10pm(UTC)
Website: www.perlesmith.com
IMPORTANT SAFETY INSTRUCTIONS
Please carefully read all instructions before attempting installation. If you do
not understand the instructions or have any concerns or questions, please
CAUTION: Avoid potential personal injuries and property damage!
Do not use this product for any purpose that is not explicitly specified in this
manual. Do not exceed weight capacity. We are not liable for damage or
injury caused by improper mounting, incorrect assembly or inappropriate use.
Weight Restrictions
DO NOT exceed the maximum weight
indicated. This TV stand is intended for use
only within the maximum weights indicated.
Use with products heavier than the
maximum weights indicated may result in
failure of the TV stand and its accessories,
causing possible damage and or injury.
WARNING
Check the VESA Pattern of TV before the Installation
200 mm ≈ 8 in
100 mm ≈ 4 in
300 mm ≈ 12 in
400 mm ≈ 16 in
600 mm ≈ 24 in
MAX:
600mm/24 in
MAX
:
400mm/16 in
Minimum VESA pattern: 200mm/8 in(W) x 100mm/4 in(H)
If your TV VESA is greater than 600x400 mm/24x16 in or less than
VESA 200x100mm/8x4 in, this TV stand is NOT compatible.
If this TV stand is NOT compatible, please contact customer service at
[email protected] to find a compatible product.
88 lbs.
(40 kg)
If your TV weighs more, this
TV stand is NOT compatible.
01 02 03 04 05 06 07 08 09 10 11
Tools Needed [Not Included]
Supplied Parts and Hardware for Step 1
Supplied Parts and Hardware
WARNING: This product contains small items that could be a choking hazard if
swallowed.
Before starting assembly, verify all parts are included and undamaged. Do not use
damaged or defective parts. lf you require replacement parts, please contact our
• Please note: Not all hardware included in this package will be used.
x1
Plastic Cover
03
(I) x1
5/32in (4mm)
Allen Key
(B) x3
M6x25mm Bolt
(A) x6
Rubber Foot
(D) x3
φ6.2xφ18x1.5
Plastic Washer
(C) x3
φ6.5xφ16x1.5
Washer
x1
Tempered Glass Base
01
x1
Support Pillar
02
Drill
3/8 in(10mm)
Socket Wrench Hammer
Phillips
Screwdriver
5/32 in(4mm)
Wood Drill
5/16 in(8mm)
Concrete Drill
01 02 03 04 05 06 07 08 09 10 11
M8
Note: The bolts are shown in accordance with the actual size
Supplied Parts and Hardware for Step 3
Supplied Hardware for Step 2
(I) x1
5/32in (4mm)
Allen Key
(E) x4
M6x12mm
Bolt
(I) x1
5/32in (4mm)
Allen Key
(E) x4
M6x12mm
Bolt
(F) x4
M5x8mm
Bolt
04 x2
Wall Plate
05 x2
Connection Plate
06 x1
Swivel Component
Supplied Parts and Hardware for Step 4
(H) x1
Cable Clip
(TV2) x4
M6x35mm
Bolt
(TV1) x4
M6x15mm
Bolt
(TV4) x4
M8x35mm
Bolt
(TV5) x4
M8x50mm
Bolt
(TV3) x4
M8x15mm
Bolt
M6
(G) x4
M6x35mm
Bolt
01 02 03 04 05 06 07 08 09 10 11
Supplied Part for
Step 5
Supplied Hardware for Step 7 (Optional)
x2
TV Bracket
07
(TV6) x4
Washer
[TV7] x4
D8 Steel
Washer
x1
08
Safety Rope
(Optional)
(TV8) x8
L2.5mm Spacer
(TV9) x4
L10mm Spacer
(TV10) x4
L22mm Spacer
x2
Safety Lock
J
Place rubber feet [A] on the tempered glass base [01] in the
corners
Note: Kindly note that the tempered glass base is designed to show the
shiny glass side facing up
Step 1-1
Step 1 Assemble the Base
This anchor is for
concrete or brick
walls ONLY. DO NOT
use them in drywall
or wood studs.
CAUTION!
Note: The lag screw is shown in
accordance with the actual size
Lag Screw
ST6x45mm
x1
A1
Wall Anchor
M8x40mm
x1
A2
01
A
01 02 03 04 05 06 07 08 09 10 11
Connect the lower support pillar [02b] to tempered glass
base [01]
Step 1-2
Secure the lower support pillar [02b] to tempered
glass base [01] using plastic cover [03], washers [C],
plastic washers [D], bolts [B] and allen key [I].
Stretch the upper support
pillar [02a] from lower
support pillar [02b]
Note: You may need
assistance with this step.
D
C
B
I
01
03
02b
Table
I
01
02b
02a
02
02b
01 02 03 04 05 06 07 08 09 10 11
Step 2 Connect the Upper Support Pillar [02a] to Lower Support
Pillar [02b]
Note: There are three choices for
height adjustment. You can choose
your desired height position while
connecting the upper support pillar
[02a] to lower support pillar [02b]
The First Choice
The Second Choice
The Third Choice
The Second Choice The Third ChoiceThe First Choice
02a
02b
E
I
①
②
01 02 03 04 05 06 07 08 09 10 11
You may need
assistance with this
step.
Step 3 Assemble the TV Plate
GI
H
06
I
EE
FI
04
05
FrontFront
01 02 03 04 05 06 07 08 09 10 11
Please Note: The provided TV bolts meet most of today's TVs design. However,
some TVs require special bolts which may not be in the hardware bag. In this case
we offer our “PSUHP" Universal Hardware Kit which provides a large selection of
bolts that can meet the demand of older and unique applications.
Please Note: When using the spacers it is important to note that they can be used
in multi-layers (meaning stacked). If you have any difficulty understanding how to
install the TV bolts or spacers, please contact customer service at
Step 4 Secure the TV Brackets to a TV
CAUTION: Ensure the
TV bracket [07] is
EQUALLY CENTERED on
your TV and securely
fastened in place.
Please note: The bolt
hole locations on your TV
may vary in accordance
of the manufacturers
design of the TV. We are
only illustrating possible
locations of the bolt
holes.
Option A (For Flat Back TV)
TV6
TV8
TV1/TV3
07
TV7TV7
(if needed)
08
(Optional)(Optional)
Note: The spacers
must be used with
steel washers [TV7] to
stop the spacers from
falling down.
07
Select TV Bolts
Only one bolt size fits your TV.
M6 M8
Bolt length: Verify adequate thread engagement with
bolt or bolt/spacer combination. We recommend
thread engagement by at least 5 turns.
-Too short will not hold the TV.
-Too long will damage the TV.
Too Short Too Long
Correct Correct
UP Note: To avoid any injuries
caused by dumping, it is
recommended to use the
tipping restraint belts [08]
to attach the TV stand
against the wall.
01 02 03 04 05 06 07 08 09 10 11
Option B (For Round Back TV)
Alternate Spacer Setups
Note: The spacers must be used
with steel washers [TV7] to stop
the spacers from falling down.
Note: The spacers must be used
with steel washers [TV7] to stop
the spacers from falling down.
Alternate Spacer Setups
Option D
For cable interference or inset holes, use
spacers [TV8], [TV9] and [TV10] to create
extra space between the TV and TV brackets
Spacers may be necessary for 2 holes ONLY.
Option C (For TV with A “Bump”)
TV6
TV7
TV8(if needed)
TV1/TV3
07
Alternate Spacer Setups
Note: The spacers must be
used with steel washers
[TV7] to stop the spacers
from falling down.
TV6
TV2/TV4/TV5
07
TV7TV7
TV8/TV9/TV10TV8/TV9/TV10
TV6
TV2/TV4/TV5
07
TV7TV7
TV8/TV9/TV10TV8/TV9/TV10
08
(Optional)(Optional)
08
(Optional)(Optional)
07
08
TV2/TV4/TV5
TV6
TV10TV7
TV8/TV9
TV10
TV8/TV9
TV10
(Optional)
(Optional)
01 02 03 04 05 06 07 08 09 10 11
