iMarc™FLEX 9123

Installation Instructions

Document Number 9123-A2-GN10-50

May 2003

Contents

Product Documentation Online ..................................................................... 2

Upgrading a Unit to the Advanced SLM Feature Set .................................... 2

Package Checklist ........................................................................................ 2

Preparation ................................................................................................... 3

Cables You May Need to Order .................................................................... 3

Safety Instructions ........................................................................................ 4

Installing the Power Supply and Cord ........................................................... 4

Connecting to an Asynchronous Terminal or PC .......................................... 5

Verifying that Self-Test Passed ..................................................................... 5

Menu Hierarchy ............................................................................................ 6

A Quick Guide to Configuration .................................................................... 9

Full Installation and Setup ............................................................................ 10

About the Installation Procedures ................................................................. 10

Minimal Installation for Service Providers (Leased Line Mode) .................... 12

Setting Up Local Management at the Central Site ........................................ 14

Automatic Configuration ............................................................................... 14

Connecting to the Network ........................................................................... 15

Configuring SNMP Trap Managers and Traps .............................................. 16

Verifying the End-to-End Path ...................................................................... 16

Connecting to the Ethernet ........................................................................... 17

Connecting to the DTE (Router or FRAD) .................................................... 18

Verifying That Data is Being Received ......................................................... 19

Checking PVC Connections ......................................................................... 19

Important Safety Instructions ....................................................................... 20

EMI Notices .................................................................................................. 21

Government Requirements ........................................................................... 21

Warranty, Sales, Service, and Training Information ...................................... 24

Document Feedback ..................................................................................... 24

Trademarks ................................................................................................... 24

Patent Notification ......................................................................................... 24

NOTE: The FrameSaver®

product line has been

renamed to iMarc.

Product Documentation Online

Complete documentation for this product is available at www.paradyne.com.

Select Support →Technical Manuals → iMarc IP/Frame Relay Devices.

Select the following documents:

iMarc SLV Technical Description (9000-A2-GB30)

iMarc SLV Configuration Reference (9000-A2-GB31)

iMarc SLV SNMP Reference (9000-A2-GB32)

iMarc SLV Operations Guide (9000-A2-GB33)

To order a paper copy of a Paradyne document, or to speak with a sales representative,

please call 1-727-530-2000.

Upgrading a Unit to the Advanced SLM Feature Set

Full Service Level Management (SLM) capability can be activated in units that have the

basic diagnostic feature set at any time. This is an optional feature that adds real-time

and historical network performance monitoring and SLA (Service Level Agreement)

reporting capabilities to your iMarc unit and network. Simply order a Feature Activation

Certificate and provide the model to be activated, your OpenLane®SLM system license

key number, and the number of iMarc units to be activated to SLM capability. You can

order the certificate for a single unit or for many units.

OpenLane SLM Release 5.3 or above is required to schedule activation of SLM features

in units, and to manage the number of activations remaining on the certificate.

OpenLane also provides a Certificate Summary Report to assist you in the management

of the certificate.

When the Feature Activation Certificate arrives, add the Activation Certificate Number to

your OpenLane SLM application’s database. Activations can occur at any time, for as

many units as desired, until no activations remain for the certificate. When ready to

activate units, simply select the units to be activated and schedule the activations. The

activations occur when scheduled, and OpenLane updates the certificate information.

Contact your sales representative for additional information.

Package Checklist

Verify that your package contains the following:

❑iMarc™FLEX unit

❑Power cord with a wall-mount 120 VAC power transformer

❑Self-mounting tie wrap for power cord strain relief

❑RJ48C modular cable for U.S. network access

Be sure to register your warranty at www.paradyne.com/warranty.

Preparation

Make sure you have:

❑A dedicated, grounded power outlet that is protected by a circuit breaker within

6 feet of the iMarc unit

❑A clean, well-lit, and ventilated site that is free from environmental extremes

❑One-to-two feet of clearance for cable connections

❑A physical connection to the frame relay T1 network

❑An asynchronous terminal or PC (personal computer)

❑If desired, an operable Ethernet LAN (Local Area Network) connection for access

by an NMS (Network Management System)

❑Configuration information for the iMarc unit being installed or replaced

❑Appropriate cables (see Cables You May Need to Order, below)

For additional information, see the iMarc SLV Technical Description (9000-A2-GB30).

Cables You May Need to Order

Contact your sales representative to order cables.

If connecting to . . . Order a . . .

Feature

Number Part Number

T1 line interface/

connector

For use in Canada.

T1 line interface cable,

RJ48C-to-CA81A

(20 feet / 6.1 meters)

3100-F1-510 035-0221-2031

Equipment with

V.35 interfaces,

MS34 connectors

V.35 DTE adapter,

EIA-530A-to-V.35

3100-F1-570 035-0244-0031

Asynchronous

terminal or PC with an

8-pin modular

interface/connector

Standard EIA-232

straight-through cable,

8-pin modular-to-DB25

(14 feet / 4.3 meters)

3100-F2-540 035-0314-1431

PC with a D-Sub9

interface/connector

Standard EIA-232

straight-through cable,

D-Sub9-to-DB25

(14 feet / 4.3 meters)

3100-F2-550 035-0313-1431

External device

(e.g., a modem)

Standard EIA-232-D

crossover cable

(14 feet / 4.3 meters)

9008-F1-550 035-0336-1431

Safety Instructions

Please refer to the Important Safety Instructions on page 20.

Installing the Power Supply and Cord

Procedure

1. Insert the power cord’s plug into the POWER jack.

2. Plug the power supply into the grounded power outlet and check the LEDs.

If any LEDs light, you have power. If not, refer to Troubleshooting in the iMarc SLV

Operations Guide (9000-A2-GB33) for possible explanations.

3. Insert the self-mounting tie wrap in the leftmost hole (hole with a dark circle around

it) until it snaps securely into place. The tie wrap provides strain relief for the power

cord.

4. Loop the tie wrap around the power cord, thread it through the hole at the base of

the wrap, and pull it snugly around the cord.

00-16684

Grounded

Power

Outlet

ALM

TEST

SIG

OOF

ALM

NetworkSystem Por t

FrameSaverTM SLV

FrameSaver

®FLEX

9123-C

ALM

System

COM NET

POWER

ETHERNET

Connecting to an Asynchronous Terminal or PC

A VT100-compatible asynchronous terminal or a PC providing VT100 terminal

emulation must be used to set up access to and management of the unit.

Procedure

1. Configure the terminal or PC so it is compatible with the iMarc unit:

— Baud Rate set to 19.2 kbps.

— Character length set to 8 data bits.

— Parity set to none.

— Stop bit set to 1.

— Flow Control set to None.

2. Insert the DB25 end of the EIA-232 cable into the iMarc unit’s COM port.

3. Insert the other end of the cable into the terminal or PC.

4. Tighten the screws on each side of the connector to secure the cable.

5. Press Enter on the keyboard to display the Main Menu.

If the Main Menu does not appear, recheck the terminal or PC settings (see Step 1),

or press the Enter key. Refer to Troubleshooting in the iMarc SLV Operations Guide

(9000-A2-GB33) for other possible explanations.

Verifying that Self-Test Passed

To verify that the unit passed its self-test, go to the System and Test Status screen.

Main Menu →Status →System and Test Status

The results of the self-test appear directly under the screen title.

If any failure messages appear, reset the unit by disconnecting, then reconnecting the

power cord. The unit will perform the self-test again. If the failure reappears, call your

service representative for assistance.

COM NET

POWER

ETHERNET

COM

Port

00-16685

Menu Hierarchy

The Menu Hierarchy shows the organization of the iMarc unit’s screens.

S t a t u s System and Test

Status

Self-Test Results

Last System Reset

Health and Status

Test Status

LMI Reported

DLCIs

DLCI

Status

CIR (bps)

IP Path

ConnectionStatus

Device Name

IP Address

Status

Discovery Source

PVC Connection

Status

Source Link, DLCI, EDLCI

Primary Destination Status

Timeslot

Assignment Status

Network Timeslot Status

I P R o u t i n g T a b l e Destination

Mask

Gateway

Hop

Type

Interface

TTL

Performance

Statistics

Service Level Verification

DLCI

Frame Relay

ESF Line

Ethernet

Clear All Statistics

T r a p E v e n t L o g Number of Trap Events

Time of Day

Event

Display LEDs and

Control Leads

I d e n t i t y System

NAM

Test NetworkPVCTests PVC Loopback

Send Pattern

Monitor Pattern

Connectivity

Data Port PVC

Tests

PVC Loopback

Send Pattern

Monitor Pattern

Network Physical

Tests

Local Line Loopback

Local Payload Loopback

Remote Line Loopback

Send Pattern

Monitor Pattern

Data Port Physical

Tests

DTE Loopback

IP Ping

Lamp Test

Abort All Tests

Configuration System Frame Relay and LMI

Class of Service Definitions

Service Level Verification

General

Network Physical

Frame Relay

DLCI Records

Data Ports Physical

Frame Relay

DLCI Records

Time Slot

Assignments

Link Layer Network Assignments

Clear Assignments

PVC Connections Source Link, DLCI, EDLCI

Primary Destination Link, DLCI, EDLCI

IP Path List Add and Display Static Paths

Management and

Communication

Options

Node IP

Management PVCs

General SNMP Management

Telnet and FTP Sessions

SNMP NMS Security

SNMP Traps

Ethernet Management

Communication Port

External Modem (on COM Port)

Auto-

Configuration

Frame Relay Discovery Mode

Automatic Circuit Removal

Control System

Information

Device Name

System Name, Location, Contact

Date

Time

Administer Logins Login ID

Password

Access Level

Change Operating

Mode

Back-to-Back Mode

Standard Mode

Select Software

Release

Current Release

Alternate Release

Switch & Reset

LMI Packet

Capture Utility

Capture Interface

Packet Capture Start/Stop

Status

Packets in Buffer

Display LMI Trace Log

Reset Device

Easy Install Service Type

Node IP Address

Node Subnet Mask

TS Access

Create Dedicated Network Mgmt Link

Ethernet Management Options Screen

Time Slot Assignment Screen

Network 1 Line Framing Format

Network 1 Line Coding Format

Network 1 Line Build Out

DS0 Base Rate

A Quick Guide to Configuration

The iMarc unit should operate using the default (factory-set) configuration options, with

exception to the changes specified in these installation instructions. Refer to the

following table for help in navigating through the menus.

As an example, follow these steps to go to the Configuration Edit/Display menu so you

can start setting up the unit.

To load a configuration for editing:

1. From the Main Menu, press the down arrow key twice so the cursor is on

Configuration.

2. Press Enter to display the Configuration menu. The Load Configuration From menu

appears.

3. Press Enter to select Current Configuration (the cursor is already on this selection).

The Configuration Edit/Display menu appears.

This sequence of steps would be shown as the menu selection sequence:

Main Menu → Configuration

To save a configuration option change:

1. Press Ctrl-a to switch to the function keys area at the bottom of the screen.

2. Type sor S(Save) and press Enter. The Save Configuration To menu appears.

3. Press Enter again to save your changes to the Current Configuration.

4. Press Esc until the Configuration Edit/Display menu reappears to continue

configuring the unit.

Press Ctrl-a, type m(MainMenu), and press Enter to return to the Main Menu.

In the sections that follow, only the minimum option changes required are included so

you will have a quick and trouble-free installation. See the iMarc SLV Configuration

Reference (9000-A2-GB31) for more information.

Press the . . . To . . .

Esc key Go back one screen or menu level. To see a visual

representation of the menu levels, see Menu Hierarchy on

page 6.

Tab key, or

Up (↑), Down (↓),

Left (←) and Right (→)

Arrow keys

Move the cursor from one menu item to the next.

Enter or Return key Complete the menu or option selection.

Spacebar Display the next available setting when changing a

configuration option. All the available settings for an option

appears at the bottom of the screen.

Full Installation and Setup

An Easy Install screen is provided to simplify installation and setup. The Easy Install

feature can be used when one person installs and sets up the iMarc unit from beginning

to end.

Procedure

1. Select the Easy Install feature.

Main Menu →Easy Install

About the Installation Procedures

There are two methods for installing and setting up the FrameSaver unit.

One person can install and set up the unit. If this is the case, see Full Installation

and Setup.

An installer can physically install and set up access to the unit in leased line mode,

and the network operation center (NOC) can switch the unit to frame relay mode

and complete the setup. If this is the case, see

An installer can physically install and set up access to the unit, and the network

operation center (NOC) can complete the setup. If this is the case, see Minimal

Installation for Service Providers (Leased Line Mode) on page 12.

Certain procedures are common to both the full installation and minimal methods. These

procedures (starting with Setting Up Local Management at the Central Site on page 14)

are referenced in the full and minimal installation instructions. Refer to them, as needed.

Easy Install Screen Example

2. Enter the Node IP Address and Subnet Mask.

3. If the Ethernet port will be used, select the Ethernet Port Options Screen, and

configure the following:

— Enable Interface Status. If the NMS will be on a different subnet than the unit,

enter Yes at the Would you like to set the Node’s Default IP

Destination to Ethernet? prompt. Otherwise, enter No.

— If the IP Address and Subnet Mask are unique to the interface, enter them for

the port; otherwise, the Node IP Address and Subnet Mask will be used.

— Enter the Default Gateway Address; the IP Address that will be used for

packets without a route.

— Enable Proxy ARP if the unit will proxy for downstream iMarc units learned via

the proprietary RIP (Routing Information Protocol) feature.

— Press the Esc key to return to the Easy Install screen.

main/easy_install 9123

Device Name: Node A 12/27/2002 10:32

EASY INSTALL

Service Type: Frame Relay

Node IP Address: 000.000.000.000 Clear

Node Subnet Mask: 000.000.000.000 Clear

TS Access: DLCI 980

Create a Dedicated Network Management Link

Ethernet Port Options Screen

Time Slot Assignment Screen

Network 1 Line Framing Format: ESF

Network 1 Line Build Out (LBO): 0.0

Network 1 Line Coding Forma B8ZS

DS0 Base Rate (Kbps): Nx64

-----------------------------------------------------------------------------

Ctrl-a to access these functions, ESC for previous menu MainMenu Exit

Save

Table des matières

Autres manuels Paradyne Matériel réseau

Paradyne

Paradyne Application Module 9109 OCU-DP Manuel utilisateur

Paradyne

Paradyne Compshere 3000 Series Manuel d'exploitation et d'entretien

Paradyne

Paradyne COMSPHERE 3610 Manuel utilisateur

Paradyne

Paradyne Hotwire 6210 Manuel utilisateur

Paradyne

Paradyne COMSPHERE 6700 Series Manuel utilisateur

Paradyne

Paradyne ACCULINK 3160 Manuel utilisateur

Paradyne

Paradyne Hotwire 8784 Manuel utilisateur

Paradyne

Paradyne Hotwire 5216 Manuel utilisateur

Paradyne

Paradyne COMSPHERE 3610 Guide de l'utilisateur

Paradyne

Paradyne COMSPHERE 6700 Series Manuel utilisateur

Paradyne

Paradyne COMSPHERE 3610 Manuel d'exploitation et d'entretien

Paradyne

Paradyne 8540 Manuel utilisateur

Paradyne

Paradyne FrameSaver NP 100 Manuel utilisateur

Paradyne

Paradyne JetFusion Integrated Access Device Manuel utilisateur

Paradyne

Paradyne 7112 Manuel utilisateur

Paradyne

Paradyne 4300 Manuel utilisateur

Paradyne

Paradyne 5030 Manuel utilisateur

Paradyne

Paradyne T1 Access Mux 916x Manuel d'utilisation et d'entretien

Paradyne

Paradyne COMSPHERE 3610 Manuel d'exploitation et d'entretien

Paradyne

Paradyne FrameSaver 9120 Manuel du propriétaire

Paradyne

Paradyne COMSPHERE 3610 Manuel de la liste des pièces

Paradyne

Paradyne 4929 DSLAM Manuel utilisateur

Paradyne

Paradyne 3163 Manuel utilisateur

Paradyne

Paradyne COMSPHERE 3610 Manuel d'exploitation et d'entretien

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur

Paradyne iMarc FLEX 9123 Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques
