Panasonic PAN4620 Manuel utilisateur

PAN4620

IEEE®802.15.4 and Bluetooth®Low Energy Module

Quick Start Guide

Rev. 0.1

Wireless Modules

PAN4620

Quick Start Guide Rev. 0.1 Page 2

Overview

The PAN4620 is Panasonic’s Internet of Things

dual mode module comprising NXP®’s Kinetis®

MKW41Z512CAT4 SoC –a 2.4 GHz 802.15.4 and

Bluetooth Low Energy (LE) wireless radio

microcontroller based on an ARM®Cortex®-M0+

core.

Features

•UART, SPI, I²C, TSI, ADC, and DAC

•Same form factor and compatible pinout for

VCC, GND, Reset, UART, I²C, and SWD as

PAN1026, PAN1760, PAN1760A, and PAN1761

•Single and concurrent operation of IEEE

802.15.4 and Bluetooth LE

•Open to various known application layers or

proprietary solutions

•Surface Mount Type dimensions:

15.6 mm x 8.7 mm x 1.9 mm

•On module 32 MHz and 32 kHz crystal

•SoC: NXP Kinetis KW41Z –2.4 GHz 802.15.4

and Bluetooth LE 4.2 Wireless Radio

Microcontroller

•Core: Up to 48 MHz 32 bit ARM Cortex-M0+

•Memory: 512 kB of flash and 128 kB of SRAM

•Voltage range: 1.8 V to 4.2 V

•Temperature range: -40 °C to 85 °C

Characteristics

•Transceiver frequency range 2 360 MHz to

2 483.5 MHz

•Programmable transmitter output power:

-30 dBm to 3 dBm

•Receiver sensitivity (Bluetooth LE): -93 dBm

•Receiver sensitivity typical for IEEE Standard

802.15.4: -98 dBm

•Typical receiver current consumption (3.6 V

supply): 8.5 mA

•Transmitter current consumption (3.6 V supply,

0 dBm): 7.6 mA

Bluetooth

•Bluetooth LE 4.2 compliant implementation

certified by Bluetooth SIG

•Supporting software consisting of Bluetooth LE

host stack and profiles and IPv6

over Bluetooth LE

•Bluetooth Developer Studio Plug-In

IEEE 802.15.4

•IEEE standard 802.15.4 compliant

•Supporting software consisting of 802.15.4

MAC/PHY implementation, Simple Media Access

Controller (SMAC), and NXP’s certified Thread®

and Zigbee®stacks are available.

Block Diagram

Chip

Antenna



NXP

KW41Z

GPIOs

SPI

Reset



VCC 1.8 V - 4.2 V



PAN4620

IEEE 802.15.4 and

Bluetooth Low Energy 4.2 Module



Crystal

32 MHz



Crystal

32.768 kHz



Flash

512 kB



SRAM

128 kB



UART

TSI



I²C

ADC

DAC

SWD

PAN4620

Quick Start Guide Rev. 0.1 Page 3

By purchase of any of the products described in this document the customer accepts the document's

validity and declares their agreement and understanding of its contents and recommendations. Panasonic

Industrial Devices Europe GmbH (Panasonic) reserves the right to make changes as required at any time

without notification.

This document is copyrighted. Reproduction of this document is permissible only if reproduction is without

alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Do not

disclose it to a third party.

This Quick Start Guide does not lodge the claim to be complete and free of mistakes.

The information contained herein is presented only as guidance for Product use. No responsibility is

assumed by Panasonic for any infringement of patents or any other intellectual property rights of third

parties that may result from the use of Product. No license to any intellectual property right is granted by

this document, whether express or implied, by estoppel or otherwise.

Description of hardware, software, and other information in this document is only intended to illustrate the

functionality of the referred Panasonic product. It should not be construed as guaranteeing specific

functionality of the product as described or suitable for a particular application.

Any provided (source) code shall not be used or incorporated into any products or systems whose

manufacture, use or sale is prohibited under any applicable laws or regulations.

Any outlined or referenced (source) code within this document is provided on an “as is” basis without any

right to technical support or updates and without warranty of any kind on a free of charge basis according

to § 516 German Civil Law (BGB) including without limitation, any warranties or conditions of title, non-

infringement, merchantability, or fitness for a particular purpose. Customer acknowledges that (source)

code may bear defects and errors.

The third-party tools mentioned in this document are offered by independent third-party providers who are

solely responsible for these products. Panasonic has no responsibility whatsoever for the performance,

product descriptions, specifications, referenced content, or any and all claims or representations of these

third-party providers. Panasonic makes no warranty whatsoever, neither express nor implied, with respect

to the goods, the referenced contents, or any and all claims or representations of the third-party providers.

To the maximum extent allowable by Law Panasonic assumes no liability whatsoever including without

limitation, indirect, consequential, special, or incidental damages or loss, including without limitation loss of

profits, loss of opportunities, business interruption, and loss of data.

PAN4620

Quick Start Guide Rev. 0.1 Page 4

Table of Contents

1About This Document.........................................................................................................................5

1.1 Purpose and Audience ..............................................................................................................5

1.2 Revision History.........................................................................................................................5

1.3 Use of Symbols .........................................................................................................................5

1.4 Related Documents...................................................................................................................6

2Overview..............................................................................................................................................7

3PAN4620 USB Evaluation-Board Overview ......................................................................................8

3.1 Building Block Overview............................................................................................................8

3.2 Architecture Overview................................................................................................................8

3.3 Breakout Pins............................................................................................................................9

3.4 Configuration Settings ...............................................................................................................9

4Getting Started..................................................................................................................................11

4.1 Jumper Start up Configuration.................................................................................................11

4.2 Device Drivers.........................................................................................................................12

4.3 Using Initial Bluetooth Heart Rate Example on PAN4620 USB...............................................13

4.4 Getting NXP MCUXpresso IDE for PAN4620 Module .............................................................14

4.5 Getting NXP SDK for PAN4620 Module..................................................................................15

4.6 Using SDK in MCUXpresso IDE..............................................................................................16

5Restricted Use...................................................................................................................................24

5.1 Life Support Policy...................................................................................................................24

5.2 Restricted End Use..................................................................................................................24

6Appendix ...........................................................................................................................................25

6.1 Ordering Information................................................................................................................25

6.2 Contact Details........................................................................................................................25

PAN4620

1 About This Document

Quick Start Guide Rev. 0.1 Page 5

1 About This Document

1.1 Purpose and Audience

This Quick Start Guide applies to the IEEE 802.15.4 and Bluetooth Low Energy development

platform PAN4620 USB. The intention is to enable our customers to easily integrate our module

PAN4620 in their product. This guide describes the needed software and gives useful hints.

The product is referred to as “The PAN4620” or “the module” within this document.

1.2 Revision History

Revision

Date

Modifications/Remarks

0.1

2019-02-20

1st version

1.3 Use of Symbols

Symbol

Description

Note

Indicates important information for the proper use of the product.

Non-observance can lead to errors.

Attention

Indicates important notes that, if not observed, can put the product’s functionality

at risk.

Tip

Indicates useful information designed to facilitate working with the PAN4620.

[chapter number]

[chapter title]

Cross reference

Indicates cross references within the document.

Example:

Description of the symbols used in this document 1.3 Use of Symbols.



Requirement

Indicates a requirement that must be met before the corresponding tasks can be

completed.



Result

Indicates the result of a task or the result of a series of tasks.

This font

GUI text

Indicates fixed terms and text of the graphical user interface.

Example:

Click Save.

PAN4620

1 About This Document

Quick Start Guide Rev. 0.1 Page 6

Symbol

Description

Menu > Menu item

Path

Indicates a path, e.g. to access a dialog.

Example:

In the menu, select File > Setup page.

This font

File names, messages, user input

Indicates file names or messages and information displayed on the screen or to

be selected or entered by the user.

Examples:

pan1760.c contains the actual module initialization.

The message Failed to save your data is displayed.

Enter the value Product 123.

[ Key ]

Key

Indicates a key on the keyboard, e.g. [ F10 ].

1.4 Related Documents

Please refer to the Panasonic website for more information as well as related documents

6.2.2 Product Information.

PAN4620

2 Overview

Quick Start Guide Rev. 0.1 Page 7

2 Overview

The PAN4620 USB is a development platform for the PAN4620 IEEE 802.15.4 and Bluetooth

Low Energy module to implement Bluetooth and IEEE 802.15.4 functionality into various

electronic devices.

This guide will describe how to start up the Evaluation Board, get all needed software sources,

execute example code and build own implementations.

Please refer to the Panasonic website for related documents 6.2.2 Product Information.

Further information on the variants and versions 6.1 Ordering Information.

PAN4620

3 PAN4620 USB Evaluation-Board Overview

Quick Start Guide Rev. 0.1 Page 8

3 PAN4620 USB Evaluation-Board Overview

3.1 Building Block Overview

3.2 Architecture Overview



PAN4620 USB Development Board



PAN4620

USB USB-Hub

J-Link

SWD

FTDI

UART

Breakout

PIN header

PAN4620

3 PAN4620 USB Evaluation-Board Overview

Quick Start Guide Rev. 0.1 Page 9

3.3 Breakout Pins

3.4 Configuration Settings

Jumper

Topview

Description

Detail

5 V from USB

connected

5 V power option, to power the board from USB

or the 5 V pin. The 5 V from USB can also be

used to power the sensor board.

5 V from or to breakout

pin connected

Module reset connected

If there is no firmware on the module, the reset

will be pulled low. This has to be considered

when the module is sharing a common reset

with other components.

Module reset

disconnected

PAN4620

3 PAN4620 USB Evaluation-Board Overview

Quick Start Guide Rev. 0.1 Page 10

Jumper

Topview

Description

Detail

SWD connected

Access to module and programmer SWD.

SWD disconnected

Module UART

connected

Access to module UART RX and TX.

Module UART

disconnected

Module VCC connected

Module VCC connection and GND pin. The

module VCC jumper can be removed for current

measurements.

J7, J10

FTDI connected to

module UART

Option for module UART to breakout pin or

FTDI. Place jumpers either on J7 or J10.

Breakout pin connected

to module UART

J11

3.3 V are supplied to

the breakout pin

Option to power an external sensor board

sensor with 3.3 V. Do not place this jumper, if

an external 3.3 V source is present.

3.3 V are not supplied

to the breakout pin

R32, R48

These 0 Ω resistors can be removed, to

disconnect the LEDs in case the IOs PTB0,

PTC1, PTA18, and PTA19 shall be used for

other purposes.

SW2, SW3

If you want to use PTC4 and PTC5 for other

purposes, do not push the buttons.

After each different configuration the reset button needs to be pressed.

Autres manuels pour PAN4620

Table des matières

Autres manuels Panasonic Unité de contrôle

Panasonic

Panasonic Photovoltaic Module HIT VBHN SJ25 Series Manuel utilisateur

Panasonic

Panasonic AG-EC4G Manuel utilisateur

Panasonic

Panasonic FP-XH M8N16PD Manuel utilisateur

Panasonic

Panasonic INDUSTRY PAN9028 Manuel utilisateur

Panasonic

Panasonic SF4D Series Manuel utilisateur

Panasonic

Panasonic S-LINK V SL-VMC1 Manuel utilisateur

Panasonic

Panasonic UJ20 Series Mode d'emploi

Panasonic

Panasonic GP-KS162CUDE Manuel utilisateur

Panasonic

Panasonic HIT VBHN340SA17E Manuel utilisateur

Panasonic

Panasonic INDUSTRY PAN9028 Guide de configuration rapide

Panasonic

Panasonic EBL512 G3 5000 Manuel technique

Panasonic

Panasonic GP-US932CSAE Manuel utilisateur

Panasonic

Panasonic AK-UCU500P Manuel utilisateur

Panasonic

Panasonic AK-UCU600P Manuel utilisateur

Panasonic

Panasonic AWRC600P - REMOTE CONTROL UNIT Manuel utilisateur

Panasonic

Panasonic BMED500 - CAMERA CONTROL UNIT Manuel utilisateur

Panasonic

Panasonic CF-BAC02GU Manuel utilisateur

Panasonic

Panasonic PAN1322-SPP Manuel utilisateur

Panasonic

Panasonic Aquarea PAW-HPM1 Mode d’emploi

Panasonic

Panasonic AJ-EC3P Manuel utilisateur

Panasonic

Panasonic WX-CC411BP Manuel utilisateur

Panasonic

Panasonic GPKS162CUD - CONTROL UNIT Manuel utilisateur

Panasonic

Panasonic WVPS104C - CAMERA DRIVE UNIT Manuel utilisateur

Panasonic

Panasonic CF-BAW0512U Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
