NETGEAR ANT24BNA Manuel utilisateur

Installation Guide

500mW Bi-directional Booster

ANT24BNA

Power Injector

ANT24BDC

Introduction

This section introduces the NETGEAR ANT24BNA 500 mW Bi-directional Booster and the

NETGEAR ANT24BDC 6 VDC, 1.5A Power Injector and related components.

The 500-milliwatt bi-directional power booster for the NETGEAR ME103 802.11b ProSafe

Wireless Access Point increases the transmission signal from an average 50 mW to 500 mW

and amplifies the signal by 10 dB (10 times) in receive mode. Use this when you want to

maintain a single access point device to cover a larger area.

The ANT24BDC enables locating an antenna and a NETGEAR ANT24BNA booster more

than 30 feet away from the wireless unit in a remote area where electrical power is not available.

DC power is supplied to the booster through the antenna cable by means of the power injector.

This eliminates the need to install extra wires. Moreover, unlike power over Ethernet devices,

this configuration never needs to be reset.

The booster and power injector are part of a wireless system, including the access point, cables

and antennas. According to FCC regulations, the booster can only be used with the wireless

access point that is provided with it. Check http://www.NETGEAR.com/go/antennas_fcc for a

list of approved devices.

500 mW Booster Package Contents

The package should contain

• NETGEAR 500mW Bi-directional Booster for 802.11b ANT24BNA

• NETGEAR PWR-10015-01 DC power adapter

• Ceiling/wall mount bracket and hardware

• Installation guide

• Warranty card

• Support information card

Installation Guide,

Warranty card and

Support information card

500 mW Bi-directional booster

ANT24BNA

Wall and ceiling

mount bracket

and hardware

Power adapter

–Use a NETGEAR antenna cable of no more than 3 m between the Power Injector and

the access point.

–For optimal performance, the combined length of both NETGEAR antenna

cables should not exceed 13 m. If the length exceeds 13 m, the overall performance

will decrease.

Antenna cables have intrinsic loss at 2.4 GHz which can decrease range performance. The

longer the cable, the higher its loss. To achieve optimal performance, use the shortest antenna

cable you can from the antenna to the ANT24BNA booster. Cable loss between the booster

ANT24BNA and antenna in the transmit and receive functions cannot be compensated.

However, the NETGEAR antenna cable between the ANT24BNA booster and the wireless

access point can be as long as 10 m without performance reduction. By the same token, a 3 m

NETGEAR antenna cable between the optional injector and wireless access point can be added

without performance reduction.

In receive mode, the booster amplifies the signal by 10 dB with a low noise amplifier. This

amplification can compensate for cable loss up to 10 dB (booster to wireless node only). In

transmit mode, the booster accepts the 802.11b input signal as low as 5 dBm and amplifies it to 27

dBm (variable power amplifier). The typical output power of an 802.11b wireless node is 15dBm

or more. So, there is a 10 dB margin to fully compensate for cable loss. The loss in the cable

between the booster and the wireless node only can be completely compensated in transmit and

receive mode up to 10 dB loss without any reduction of performance.

Installing the Booster

Turn off your ME103 Wireless Access Point and connect your wireless accessories according to

the illustration. After attaching your new antenna, reconnect your wireless device to the network

and turn it on.

Power Injector Package Contents

The package should contain

•NETGEAR 6 VDC 1.5A Power Injector ANT24BDC for bi-directional booster ANT24BNA

•Installation Guide

•Warranty card

•Support information card

If any of the parts are incorrect, missing, or damaged, contact your NETGEAR dealer. Keep the

carton, including the original packing materials, in case you need to return the product for repair.

NOTE: To obtain optimal results in extending wireless range with antenna installations, it is

recommended that a qualified professional installer service is consulted for site survey and

proper installation.

Placement and Other Important Considerations

Observe the following guidelines when configuring your Booster for 802.11b. In order to comply

with FCC regulations you must use NETGEAR antenna cables (ACC-10314-01, 02, 03 or 04)

with these products. These antenna cables are low loss and are ideally suited for the NETGEAR

booster, power injector and antennas. Performance (range) can be drastically reduced if longer or

higher loss antenna cables are used.

•Place the ANT24BNA booster as close as possible to the antenna with a short NETGEAR

antenna cable. The shortest FCC approved antenna cable is the NETGEAR 1.5 m (ACC-

10314-01) cable.

•Place the longer NETGEAR cable (up to 10 meters) between the ANT24BNA booster and

the access point. The overall performance will decrease if the length exceeds 10m.

•If you use a ANT24BDC Power Injector to power the booster remotely, follow these

guidelines:

–Use the longer NETGEAR antenna cable (up to 10 m) between the booster and the

power injector.

Installation Guide,

Warranty card and

Support information card

Power Injector ANT24BDC

Two Antenna Ports,Two Boosters and Two AntennasOne Antenna Port, One Booster and One Antenna

Two Antenna Ports, One Booster and Two Antennas

Antenna

e. g. NETGEAR

ANT24O5

Antenna

e. g. NETGEAR

ANT24O5

ETHERNET

RESET

5-12V DC

Wireless unit

SecondaryPrimary

NETGEAR Antenna cable

(short, medium or long)

Connect

Antenna

cable

500 mW Booster ANT24BNA

NETGEAR

Antenna

cable (short)

Connect

Antenna

cable

Connect

cable

Connect

Antenna

cable

Connect

Antenna

cable

DC Block

NETGEAR Antenna cable

(short, medium or long)

Connect

Antenna

cable

500 mW Booster ANT24BNA

NETGEAR

Antenna

cable (short)

Connect

Antenna

cable

Connect

cable

DC Block

Antenna

e. g. NETGEAR

ANT24O5

ETHERNET

RESET

5-12V DC

Wireless unit

NETGEAR Antenna cable

(short, medium or long)

Connect

Antenna

cable

500 mW Booster ANT24BNA

NETGEAR

Antenna

cable (short)

Connect

Antenna

cable

Connect

cable

Connect

Antenna

cable

DC Block

Antenna

e. g. NETGEAR

ANT24O5

ETHERNET

RESET

5-12V DC

Wireless unit

NETGEAR Antenna cable

(short, medium or long)

Connect

Antenna

cable

500 mW Booster ANT24BNA

NETGEAR

Antenna

cable (short)

Connect

Antenna

cable

Connect

cable

Connect

Antenna

cable

DC Block

SecondaryPrimary

Current antenna

Do NOT remove

SpecificationsInstalling the Booster with the

Optional Power Injector

Note: As noted in the illustration below, be sure to disconnect the DC power adapter from the

ANT24BNA Booster for 802.11b, and connect it to the NETGEAR ANT24BDC Power Injector.

Description

26.5 dBm minimum

Frequency Range

Operating Mode

DC Surge Protection

Current Drain (TDD Mode)

Transmit Power

+ 5 dBm minimum

Transmit Input Power

2400 to 2500 MHz

TDD Burst Mode

600 Watts TVS @ 6VDC

700 mA type. @ 6VDC

NETGEAR 500mW Bi-directional

Booster for 802.11b, with Two

Female Reverse SMA Connectors

3 µs maximum

Transmit Ramp Up Time

10 dB typical

Receiver Gain

±1 dB over operating range

Receiver Frequency Response

5 dB maximum

Receiver Noise Figure

3 µs maximum

Receiver Ramp Down Time

ABS

Material

White

Color

130 x 75 x 37 mm (5.1 x 3.0 x 1.5 in)

Device Size (l x w x h)

5.0 g/1.1 lbs (including DC adapter)

Weight

SMA female reverse (2x), 1 for connection to antenna,

1 for connection to ME103 wireless access point

RF Connector Type

50 ± 5 Ohms

RF Connector Impedance

750 VRMS maximum

RF Connector Dielectric

Withstanding Voltage

0.2 dB

RF Connector Insertion Loss

ETHERNET

RESET

5-12V DC

Wireless unit

NETGEAR Antenna

cable (medium or long)

NETGEAR

Antenna cable

(short or medium)

Connect

Antenna

cable

500 mW Booster ANT24BNA

NETGEAR

Antenna

cable (short)

Antenna

e. g. NETGEAR

ANT24O5

Connect

Antenna

cable

Connect

Antenna

cable

Do NOT connect

DC cable

Connect

Antenna

cable

SecondaryPrimary

Current antenna

Do NOT remove

DC Block NETGEAR

Connect

DC cable

Connect

Antenna

cable

Injector NETGEAR

ANT24BDC

Description

30 A-Peak for 115 VAC

50 A-Peak for 230 VAC

Full Load, 25°C, Cold Start

AC Input Voltage

AC Input Frequency

AC Input Current

AC Inrush Current

90 to 264 VAC

50 to 60 Hz

0.4 Arms for 115 VAC

0.2 Arms for 230 VAC

NETGEAR PWR-10015-01 DC

Adapter Specifications

+6 V

Output Voltage

±5%Total Regulation

0 A / 2.5 A

Min/Max Load Current

60 mVPPRipple And Noise

15 WTotal Output Power

65% minimum @115 VAC, 60 Hz, Full Load

Efficiency

100 ms maximumRise Time

PVC + STEELMaterial

0 to 40°C (32 to 104°F)

Operating Temperature

-40 to 70°C (-40 to 158°F)Storage Temperature

UL, CSA, TUVDesigned To Meet Standards

0.25 mA maximumLeakage Current

Short Circuit ProtectionOver Current Protection

10% to 90%Humidity

Description

Brass per JIS H3250 C3604 BD, Gold Plated per

MIL-G-45204

RF Connector Recommended

Coupling Nut Torque

RF Connector Coupling Nut

Retention Force

RF Connector Contact

Captivation Axial

RF Connector Body

0.45 to 0.99 Nm (4.0 to 8.8 in.lb.)

22.7 kg (50 lb) min.

2.27 kg (5 lb) min.

NETGEAR 500mW Bi-directional

Booster for 802.11b, with Two

Female Reverse SMA Connectors

Beryllium Copper per QQ-C-530, Gold Plated per

MIL-G-45204

RF Connector Contact

0 to 70°C (32 to 158°F)

Operating Temperature

-30 to 80°C (-22 to 176°F)

Storage Temperature

10% to 90%

Humidity

1 year

Warranty

Specifications

Description

PTC Fuse 2.5 A / 30 V

Frequency Range

PTC Fuse

Insertion Loss

Short Circuit Protection

2400 to 2500 MHz

2.5 A / 30 V

1.5 dB maximum @ 2.4 to 2.5 GHz

ANT24BDC Power Injector for the

ANT24BNA Booster with Two

Female Reverse SMA Connectors

750 VRMS maximum

0.2 dBRF Connector Insertion Loss

.45 to .99 Nm (4.0 to 8.8 in.lb.)

RF Connector Recommended

coupling nut Torque

22.68 kg (50 lbs.) minimum

RF Connector Coupling nut

retention force

2.27 kg (5 lbs.) minimum

RF Connector Contact

captivation axial

Brass per JIS H3250 C3604 BD, Gold Plated

per MIL-G-45204

RF Connector Body

Beryllium Copper per QQ-C-530, Gold Plated per

MIL-G-45204

RF Connector Contact

DC Supply Voltage

RF Connector Type

DC, 5 V to 12 V

SMA female reverse (2x), 1 for connection to antenna, 1

for connection to ME103

50 ± 5 Ohms

RF Connector Impedance

RF Connector Dielectric

Withstanding Voltage

Aluminum AlloyMaterial

WhiteColor

Description

88.2 x 58.9 x 33.4 mm (3.48 x 2.32 x 1.32 in)

Operation Temperature

Storage Temperature

Humidity

Device Size (l x w x h)

0 to 70°C (32 to 158°F)

-10 to 80°C (14 to 176°F)

10% to 90%

ANT24BDC Power Injector for the

ANT24BNA Booster with Two

Female Reverse SMA Connectors

Weight 220 g (7.76 oz)

1 year

Warranty

Statement of Conditions

In the internal function, and/or reliability, NETGEAR reserves the right to make changes to the products described in

this document without notice. NETGEAR does not assume any liability that may occur due to the use or application

of the product(s) or circuit layout(s) described herein.

Federal Communications Commission (FCC) Compliance Notice:

Radio Frequency Notice

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the

receiving antenna, (2) Increase the separation between the equipment and receiver, (3) Connect the equipment into an

outlet on a circuit different from that to which the receiver is connected, (4) Consult the dealer or an experienced

radio/TV technician for help.

Federal Communications Commission (FCC) Radiation Exposure Statement

To ensure the compliance with the FCC RF exposure requirement for safety, make sure that the antenna is installed

with separation distance of at least 25 cm (10 in) from a person. The antenna shall not be colocated with other

transmitting devices.

Note: To meet FCC regulations, the system must be installed as shown in the diagrams. Substitution of cables and

access point provided and/or any modification to any of the components of this system will void the user's right to

operate it.

Check http://www.NETGEAR.com/go/antennas_fcc for a list of FCC approved devices.

Use of this booster with any other devices is strictly prohibited by the FCC.

To ensure compliance with the FCC's RF Exposure requirements for safety, all omni- directional antennas must 

be installed to provide a separation distance of at least 20cm from a person. 

The panel antennas (Netgear part numbers ANT24D12 and ANT24D18) must be fixed mounted on a permananet 

structure to ensure a separation distance of at least 50cm from all persons. The panel antennas can only be used 

for point-to-point applications and may not be used for point-to-multipoint applications.

The antennas shall not be co-located with other transmitting devices.

Note: To meet FCC regulations, the system must be installed as shown in the diagrams. Substitution of cables and 

access point provided and/or any modification to any of the components of this system will void the user's right to 

operate it.

Check http://www.NETGEAR.com/go/antennas_fcc for a list of FCC approved-antennas.

Use of this booster with any other devices is strictly prohibited by the FCC.

Technical Support

PLEASE REFER TO THE SUPPORT INFORMATION CARD THAT SHIPPED WITH

YOUR PRODUCT.

By registering your product at www.NETGEAR.com/register, we can provide you with faster

expert technical support and timely notices of product and software upgrades.

NETGEAR, INC.

Support Information

Phone: 1-888-NETGEAR (For US & Canada only) - 24x7 phone support

See Support Information card for other countries.

E-mail: [email protected] (24x7 online support)

www.NETGEAR.com

Everybody's Connecting are trademarks or registered trademarks of Netgear, Inc. in the United

States and/or other countries. Microsoft and Windows are registered trademarks of Microsoft

Corporation in the United States and/or other countries. Other brand and product names are

trademarks or registered trademarks of their respective holders. Information is subject to change

August 2003

*M-10082-04*

M-10082-04

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels NETGEAR Matériel réseau

NETGEAR

NETGEAR SRX5308 - ProSafe® Quad WAN Gigabit SSL VPN... Manuel utilisateur

NETGEAR

NETGEAR AF711F Manuel utilisateur

NETGEAR

NETGEAR Stora Manuel utilisateur

NETGEAR

NETGEAR STM150 - ProSecure Web And Email Threat Management... Manuel utilisateur

NETGEAR

NETGEAR RN12P0610 - ReadyNAS 3200 Manuel utilisateur

NETGEAR

NETGEAR UTM10 - ProSecure Unified Threat Management... Instructions d'installation et d'utilisation

NETGEAR

NETGEAR UTM25 - ProSecure Unified Threat Management... Manuel utilisateur

NETGEAR

NETGEAR ReadyNAS RN312 Manuel utilisateur

NETGEAR

NETGEAR M6100 Series Guide de l'utilisateur

NETGEAR

NETGEAR RNDP6310 - ReadyNAS Pro NAS Server Manuel utilisateur

NETGEAR

NETGEAR ReadyDATA 5200 Manuel utilisateur

NETGEAR

NETGEAR AX742 - ProSafe 24 Gigabit Stacking Manuel utilisateur

NETGEAR

NETGEAR M4100 Series ProSAFE Manuel utilisateur

NETGEAR

NETGEAR ProSafe ANT2409 Manuel utilisateur

NETGEAR

NETGEAR ReadyNAS 2120 Manuel utilisateur

NETGEAR

NETGEAR ReadyNAS OS 6 Desktop Storage Systems Manuel utilisateur

NETGEAR

NETGEAR SSL312-100NAS - ProSafe SSL312 SSL VPN Concentrator... Manuel utilisateur

NETGEAR

NETGEAR AirCard Manuel utilisateur

NETGEAR

NETGEAR PLP1200 Manuel utilisateur

NETGEAR

NETGEAR WMS5316 - ProSafe 16-AP Wireless Management... Manuel utilisateur

NETGEAR

NETGEAR Sprint Spark Fiche technique

NETGEAR

NETGEAR AXM752 - ProSafe XFP Transceiver Module Manuel utilisateur

NETGEAR

NETGEAR Orbi Pro WiFi 6 Mini router Manuel utilisateur

NETGEAR

NETGEAR UTM25-100NAS - Prosecure Utm Appliance 25U No Sub... Manuel utilisateur

Manuels Matériel réseau populaires d'autres marques

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Manuel utilisateur

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Manuel utilisateur

Yudor

Yudor YDS-16 Manuel utilisateur

D-Link

D-Link ShareCenter DNS-320L Manuel utilisateur

Samsung

Samsung ES1642dc Instructions d'utilisation

Honeywell Home

Honeywell Home LTEM-PV Instructions de montage

evertz

evertz 7700 Series Manuel utilisateur

D-Link

D-Link ShareCenter DNS-343 Manuel utilisateur

Asante

Asante AsanteBridge 1012 Manuel utilisateur

FireBrick

FireBrick FB2700 Manuel utilisateur

Audiovox Electronics

Audiovox Electronics ARWH2T Manuel utilisateur

ADC

ADC DSX-1 Manuel

NetComm

NetComm NF2 Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 5620 Manuel utilisateur

Dell EMC

Dell EMC XC6420 Series Manuel utilisateur

Lanner

Lanner NCA-1020A Manuel utilisateur

Allied Telesis

Allied Telesis AT-TN121-A Manuel utilisateur

Arista

Arista CCA-ETM-Q12 Manuel utilisateur
