NETGEAR EX6150 AC1200 Manuel utilisateur

Quick Start

AC1200 WiFi Range Extender

Model EX6150

Getting Started

The NETGEAR WiFi Range Extender increases the distance of a WiFi

network by boosting the existing WiFi signal and enhancing the overall

signal quality over long distances. An extender repeats the signals from an

existing WiFi router or access point.

WiFi Range

Extender

Boosts the range

of your existing

WiFi and creates

a stronger signal

in hard-to-reach

areas

Existing WiFi

Sometimes your

router does not

provide the WiFi

coverage you need

Meet Your Extender

Before you install your extender, familiarize yourself with its LEDs,

buttons, and port.

Front Panel and Side Panel

Router Arrow LED

Client Arrow LED

Router Link LED Client Link LED

Power LED

WPS LED

Ethernet port

Access Point/Extender switch

Power On/O button

Factory Reset button

WPS button

LED Descriptions

Router Link

LED

This LED indicates the connection between the extender and

the router or access point.

Solid green. Best connection.

Solid amber. Good connection.

Solid red. Poor connection.

O. No connection.

Client Link LED This LED indicates the connection between the extender and

a computer or WiFi device.

Solid green. Best connection.

Solid amber. Good connection.

Solid red. Poor connection.

O. No connection.

Power LED Solid amber. The extender is booting.

Solid green. The extender is powered on.

O. The extender is powered o.

WPS LED Solid green. WiFi security is enabled (WPA or WPA2).

Blinking green. A WPS connection is in progress.

O. WiFi security is not enabled.

Note: If the Router Arrow LED or Client Arrow LED

blinks, see Find the Best Location on page 11. If no arrow LEDs light, the

extender is in a good location.

Use the Extender in Extender Mode

Set the Access Point/Extender switch, place the extender, apply power,

and connect it to your WiFi network.

Set the Access Point/Extender Switch

To use the extender in extender mode, set the Access Point/Extender

switch to Extender .

Place the Extender and Apply Power

1. Place your extender in the same room as your WiFi router.

Proximity to the WiFi router is required only during the initial setup

process.

2. Plug the extender into an electrical outlet.

Wait for the Power LED to light green. If the Power LED

does not light, press the Power On/Off button on the side of the

extender.

Connect to an Existing WiFi Network

To extend the range of your WiFi network, you must connect the extender

to your existing WiFi network. You can do this in one of two ways:

• Connect with WPS. For more information, see Connect with WPS on

page 6.

• Connect with web browser setup. For more information, see

Connect with Web Browser Setup on page 8.

Connect with WPS

Wi-Fi Protected Setup (WPS) lets you join a secure WiFi network without

typing the network name and password.

Note: WPS does not support WEP network security. If you are using WEP

security, follow the instructions in Connect with Web Browser Setup on

page 8.

1. Press the WPS button on the side panel of the extender.

The WPS LED blinks.

2. Within two minutes, press the WPS button on your router or access

point.

The WPS LED on the extender lights solid green, the Router Link LED

lights, and the extender connects to your existing WiFi network.

If the Router Link LED does not light, try again. If it still does not light,

see Connect with Web Browser Setup on page 8.

3. If your WiFi router supports the 5 GHz band, repeat Steps 1 and 2 to

connect the extender to the 5 GHz band.

4. Find the new extended WiFi network name on your computer or WiFi

device.

The extender creates two new extended WiFi networks. The

extender’s new WiFi network names are based on your existing WiFi

network name, with _2GEXT and _5GEXT at the end of the name.

For example:

• Existing WiFi network name. MyNetworkName

• New extended WiFi network names. MyNetworkName_2GEXT

and MyNetworkName_5GEXT

5. Connect your computer or WiFi device to the new extended WiFi

network.

Use the same WiFi password that you use for your WiFi router.

6. Unplug the extender and move it to a new location closer to the area

with a poor WiFi signal.

The location that you choose must be within the range of your

existing WiFi router network.

7. Plug the extender into an electrical outlet.

Wait for the Power LED to light green. If the Power LED does

not light, press the Power On/Off button.

8. Use the Router Link LED on the front panel to help you choose a spot

where the extender-to-router connection is optimal.

Connect with Web Browser Setup

1. Use a WiFi network manager on a computer or WiFi device to find and

connect to the NETGEAR_EXT (SSID) WiFi network.

After the connection with the computer or WiFi device is established,

the Client Link LED lights.

2. Launch a web browser.

3. Enter www.mywiﬁext.net in the address ﬁeld of the browser.

The New Extender Setup screen displays.

4. Click the NEW EXTENDER SETUP button.

The Extender Setup screen displays.

5. Complete the fields on the Extender Setup screen and click the NEXT

button.

6. Verify that the Access Point/Extender switch is set to Extender

and click the CONTINUE button.

7. Select a WiFi network to extend and click the NEXT button.

If you do not want to extend both WiFi bands, clear the 2.4GHz WiFi

Networks or the 5GHz WiFi Networks checkbox.

8. In the Password (network key) field, type the existing WiFi network

password (also called passphrase or security key) and click the NEXT

button.

9. Set the network name (SSID) and password for your extender and

click the NEXT button.

10. Use a WiFi network manager on the computer or WiFi device to

connect to the new extended WiFi network.

Repeat this step for all of your computers and WiFi devices.

11. Select the check box at the bottom of the screen and click the NEXT

button.

A message displays confirming that the extender is connected to the

WiFi network.

12. Click the Next button.

The registration screen displays.

13. Complete the registration fields and click the Finish button to

complete the setup.

The Status screen displays.

If you do not want to register your extender, click the Skip

Registration link.

Note that you must register your extender before you can use

NETGEAR telephone support.

14. Unplug the extender and move it to a new location closer to the area

with a poor WiFi signal.

The location that you choose must be within the range of your

existing WiFi router network.

15. Plug the extender into an electrical outlet.

Wait for the Power LED to light green. If the Power LED does

not light, press the Power On/Off button.

Use the Router Link LED to help you choose a spot where the

extender-to-router connection is optimal.
