NETGEAR Nighthawk CM2050V Manuel utilisateur

Quick Start

2.5 Gbps Ultra-High Speed

Cable Telephony Modem

Model CM2050V

Package contents

Cable modem

Ethernet

cable

Power

adapter

BEFORE RETURNING THIS PRODUCT TO THE STORE

FOR ANY REASON, call NETGEAR Technical Support at

1-866-534-9377 or visit

https://kb.netgear.com/000061156/How-can-I-troubleshoot-my-cable-modem.

Cable modem LEDs

LED Description

Power • Solid white. The cable modem is receiving power and is functioning

normally.

• Off. The cable modem is not receiving power.

• Solid red. The cable modem is too warm and might overheat.

Downstream • Solid amber. One downstream channel is locked.

• Solid white. Two or more downstream channels are locked.

• Blinking white. The cable modem is scanning for a downstream channel.

• Off. No downstream channel is locked.

Upstream • Solid amber. One upstream channel is locked.

• Solid white. Two or more upstream channels are locked.

• Blinking white. The cable modem is scanning for a upstream channel.

• Off. No upstream channel is locked.

Online • Solid white. The cable modem is online.

• Blinking white. The cable modem is synchronizing with the cable

provider’s cable modem termination system (CMTS).

• Off. The cable modem is ofine.

Multi-Gig

Ethernet

The LED color indicates the speed: blue for a 2.5 Gbps Ethernet

connection, white for a 1 Gbps Ethernet connection, and amber for a

100 Mbps Ethernet connection.

• Solid. A powered-on device is connected to the port.

• Blinking. The port is sending or receiving trafc.

• Off. No device is connected to this port.

Tel 1 and Tel 2 • Solid white. The Tel 1 or 2 port is online.

• Blinking white. The Tel 1 or 2 port is processing a call or the phone is off-

hook.

• Off. The Tel 1 or 2 port is not in use.

non-NETGEAR trademarks are used for reference purposes only.

Thank you for purchasing this NETGEAR product. You can visit

https://www.netgear.com/support to register your product, get help, access the

latest downloads and user manuals, and join our community. We recommend that

you use only ofcial NETGEAR support resources.

For regulatory compliance information, visit

https://www.netgear.com/about/regulatory/.

See the regulatory compliance document before connecting the power supply.

Some cable devices might not be compatible with certain cable networks. Check

with your cable Internet provider to conrm that this NETGEAR cable modem

router is allowed on your cable network.

If you are experiencing trouble installing your cable modem, contact NETGEAR at

1-866-874-8924.

Support

Phone

cable

Note to CATV system Installer- This reminder is provided to call the CATV systems

installer’s attention to Section 820-93 of the National Electrical Code, which

provides guidelines for proper grounding and in particular, species that coaxial

cable shield shall be connected to the grounding system of the building, as close

to the point of cable entry as practical.

1. Turn off and disconnect existing modems and routers.

If you are replacing a modem that is currently connected in your home,

unplug the modem and plug the new cable modem into the same outlet.

2. Use a coaxial cable to connect the cable port on the cable modem to a cable

wall outlet.

Make sure that the cable is tightly connected. We recommend that you

connect your cable modem directly to a cable wall outlet.

If you must share the connection, use a 3.5dB (1 to 2) splitter.

3. If you have Xnity Voice, connect your phone to the Tel 1 port

on the cable modem with the phone cable.

If you subscribed to two phone lines, connect the other phone to the Tel 2

port.

Note: The Tel 2 port only works for a two-phone line subscription.

4. Connect the power adapter to the cable modem and plug the power adapter

into an electrical outlet.

Coaxial cable

Start here

The cable modem might reset multiple times when it is powered on.

5. Wait for the Online LED to light solid white.

This process might take up to 10 minutes. When the cable modem comes

online, the Online LED stops blinking and lights solid white.

After 10 minutes, if the Online LED doesn’t light solid, make sure that the

cable outlet is working or call your Internet service provider (ISP) to make sure

you have service.

Note: When the Online LED lights solid, your cable modem is not connected

to the Internet yet. You must connect a router or computer to your cable

modem and then activate your cable modem with your cable Internet

provider.

6. Connect a router to your cable modem.

a. Connect the Ethernet port on the cable modem to the WAN or Internet

port on the router

b. Power on the router.

c. Connect your computer or mobile device to the router.

7. Collect this information about your Internet service and the cable modem:

• Your Xnity account number and the personal information associated with

your Xnity account (you need one of the following):

- Mobile phone number

- Xnity user name and password

• The following information from the cable modem label:

- Model number, which is CM2050V

- Serial number

90° 90°

WiFi router

Cable modem

NETGEAR, Inc.

350 East Plumeria Drive

San Jose, CA 95134, USA

NETGEAR INTERNATIONAL LTD

Floor 1, Building 3

University Technology Centre

Curraheen Road, Cork,

T12EF21, Ireland

April 2020

- MAC address

- MTA MAC address

8. Activate your Internet service:

a. Close all web browsers.

b. Launch a web browser.

You are redirected to the Xnity self-activation page. If you are not

redirected to the Xnity self-activation page, visit xnity.com/activate.

c. Provide your Xnity credentials and complete the self-activation process.

This process might take up to 10 minutes, during which the cable modem

reboots twice.

If you’re unable to activate your Xnity Internet service using the self-activation

page, call Xnity customer service at 1-800-XFINITY (1-800-934-6489).

Optional

phone
