CALIBRATION PROCEDURE

NI 9246/9247

This document contains the verification and adjustment procedures for the NI 9246 and NI 9247.

For more information about calibration solutions, visit ni.com/calibration.

Contents

Software.................................................................................................................................... 1

Documentation.......................................................................................................................... 2

Test Equipment......................................................................................................................... 3

Test Conditions......................................................................................................................... 3

Initial Setup............................................................................................................................... 3

Verification ............................................................................................................................... 4

Accuracy Verification....................................................................................................... 4

Adjustments .............................................................................................................................. 6

Accuracy Adjustment ....................................................................................................... 6

EEPROM Update ..................................................................................................................... 6

Reverification ........................................................................................................................... 7

Worldwide Support and Services ............................................................................................. 7

Software

Calibrating the NI 9247 requires the installation of NI-DAQmx 15.1 or later on the calibration

system. You can download NI-DAQmx from ni.com/downloads. NI-DAQmx supports

LabVIEW, LabWindows™/CVI™, C/C++, C#, and Visual Basic .NET. When you install

NI-DAQmx you only need to install support for the application software that you intend to use.

2|ni.com |NI 9246/9247 Calibration Procedure

Documentation

Consult the following documents for information about the NI 9246/9247, NI-DAQmx, and

your application software. All documents are available on ni.com and help files install with the

software.

NI cDAQ-9174/9178 USB Chassis Quick Start

NI-DAQmx installation and hardware setup.

NI 9246 Getting Started Guide

NI 9246 specific information.

NI 9246 Datasheet

NI 9246 specifications and calibration interval.

NI 9247 Getting Started Guide

NI 9247 specific information.

NI 9247 Datasheet

NI 9247 specifications and calibration interval.

NI DAQmx Readme

Operating system and application software support.

LabVIEW Help

LabVIEW programming concepts and reference information about NI-DAQmx

VIs and functions.

NI-DAQmx C Reference Help

Reference information for NI-DAQmx C functions and NI-DAQmx C properties.

NI-DAQmx .NET Help Support for Visual Studio

Reference information for NI-DAQmx .NET methods and NI-DAQmx .NET

properties, key concepts, and a C enum to .NET enum mapping table.

NI 9246/9247 Calibration Procedure |© National Instruments |3

Test Equipment

Table 1 lists the equipment recommended for the performance verification and adjustment

procedures. If the recommended equipment is not available, select a substitute using the

requirements listed in Table 1.

Test Conditions

The following setup and environmental conditions are required to ensure the NI 9246/9247

meets published specifications.

• Keep connections to the device as short as possible. Long cables and wires act as antennas,

picking up extra noise that can affect measurements.

• Verify that all connections to the device are secure.

• Use shielded copper wire for all cable connections to the device. Use twisted-pairs wire to

eliminate noise and thermal offsets.

• Maintain an ambient temperature of 23 °C ± 5 °C. The device temperature will be greater

than the ambient temperature.

• Keep relative humidity below 80%.

• Allow a warm-up time of at least 10 minutes to ensure that the NI 9246/9247 measurement

circuitry is at a stable operating temperature.

Initial Setup

Complete the following steps to set up the NI 9246/9247.

1. Install NI-DAQmx.

2. Make sure the NI cDAQ-9178 power source is not connected to the chassis.

3. Connect the NI cDAQ-9178 chassis to the system safety ground.

a. Attach a ring lug to a 14 AWG (1.6 mm) wire.

b. Connect the ring lug to the ground terminal on the side of the NI cDAQ-9178 chassis

using the ground screw.

c. Attach the other end of the wire to the system safety ground.

4. Install the module in slot 8 of the NI cDAQ-9178 chassis. Leave slots 1 through 7 of the

NI cDAQ-9178 chassis empty.

Table 1. Recommended Equipment

Equipment

Recommended

Model

Parameter

Measured Requirements

Source Fluke 5522A Accuracy,

Adjustment

Use a high-precision current

source with an accuracy

≤650 ppm

cDAQ Chassis NI cDAQ-9178 All —

4|ni.com |NI 9246/9247 Calibration Procedure

5. Connect the NI cDAQ-9178 chassis to your host computer.

6. Connect the power source to the NI cDAQ-9178 chassis.

7. Launch Measurement & Automation Explorer (MAX).

8. Right-click the device name and select Self-Test to ensure that the module is working

properly.

Verification

The following performance verification procedures describe the sequence of operation and test

points required to verify the NI 9246/9247 and assumes that adequate traceable uncertainties are

available for the calibration references.

Accuracy Verification

Complete the following procedure to determine the As-Found status of the NI 9246/9247.

1. Set the calibrator to Standby mode (STBY).

2. Connect the NI 9246/9247 to the calibrator as shown in Figure 1.

Figure 1. Accuracy Verification Connections

3. Set the calibrator current to a Test Point Value indicated in Table 4.

4. Set the calibrator to Operate mode (OPR).

5. Wait at least 45 seconds for the signal to settle.

6. Acquire samples from each channel.

a. Create and configure an AI current task on the NI 9246/9247 according to Table 2.

Table 2. NI 9246/9247Configuration for Accuracy Verification

Min Max Scaled Units Physical Channels

NI 9246 -31.25 31.25 Current AI0:2

NI 9247 -147 147 Current AI0:2

NI 9246/9247

Calibrator

AI1

–

AI0

–

AI2

–

NI 9246/9247 Calibration Procedure |© National Instruments |5

b. Configure the AI current task according to Table 3.

c. Start the task.

d. For the maximum Test Point calculate and record the AC magnitude for each channel

on the NI 9246/9247. NI recommends using the Extract Single Tone Information VI

to calculate the magnitude. For the minimum test point average the value and record

the result.

Note The output magnitude of the Extract Single Tone Information is in Apk. To

convert to RMS, use the following equation:

e. Stop and clear the task.

7. Compare the average for each channel to the limits in Table 4.

Note The test limits listed in Table 4 should be used for calibration verification

only. These values only apply under the specific calibration conditions described in

this document, and are not to be construed as general operational specification of the

NI 9246/9247. For operation specification, refer to the most recent NI 9246

Datasheet and NI 9247 Datasheet at ni.com/manual.

8. Set the calibrator to Standby mode (STBY).

9. Repeat steps 3 through 7 for each test point listed in Table 4.

10. Disconnect the calibrator from the device.

Table 3. NI 9246/9247 Timing Configuration

Sample Mode Samples Per Channel Sample Rate (kS/s)

Finite Samples 50,000 50

Table 4. NI 9246/9247 Verification Test Limits for Accuracy

Test Point 1-Year Limits

Location Value

Frequency

(Hz) Lower Limit Upper Limit

NI 9246

Max 2 Arms 55 1.9913 Arms 2.0087 Arms

Min 0.00 Adc 0.00 -0.023 Adc 0.023 Adc

NI 9247

Max 2 Arms 55 1.9925 Arms 2.0075 Arms

Min 0.00 Adc 0.00 -0.133 Adc 0.133 Adc

Arms Apk() 2()÷=

6|ni.com |NI 9246/9247 Calibration Procedure

Adjustments

The following performance adjustment procedure describes the sequence of operation required

to adjust the NI 9246/9247.

Accuracy Adjustment

Complete the following procedure to adjust the accuracy performance of the NI 9246/9247.

1. Set the calibrator to Standby mode (STBY).

2. Connect the NI 9246/9247 to the calibrator as shown in Figure 1.

3. Adjust the NI 9246/9247.

a. Initialize a calibration session on the NI 9246/9247. The default password is NI.

b. Input the external temperature in degrees Celsius.

c. Call the NI 9246/9247 DAQmx Get C Series Calibration Adjustment Points function

to obtain an array of recommended calibration current for the NI 9246/9247.

d. Set the calibrator to a reference value determined by the array of recommended

calibration currents.

e. Set the calibrator’s output frequency to 55 Hz.

f. Set the calibrator to Operate mode (OPR).

g. Wait at least 45 seconds for the signal to settle.

h. Call and configure the NI 9246/9247 adjustment function according to Table 5.

Note To adjust all channels in parallel, use ‘ai0:2’ as the channel name.

i. Set the calibrator to Standby mode (STBY).

j. Close and commit the calibration session.

4. Disconnect the NI 9246/9247 from the calibrator.

EEPROM Update

When an adjustment procedure is completed, the NI 9246/9247 internal calibration memory

(EEPROM) is immediately updated.

If you do not want to perform an adjustment, you can update the calibration date and onboard

calibration temperature without making any adjustments by initializing an external calibration,

setting the C Series calibration temperature, and closing the external calibration.

Table 5. Adjustment Configuration

Physical Channel Reference Value

cDAQMod8/aixThe reference value from the array of adjustment points

375305A-01 Aug16

Refer to the NI Trademarks and Logo Guidelines at ni.com/trademarks for more information on National Instruments trademarks. Other

product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National

Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the

National Instruments Patents Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and third-party

legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance

for the National Instruments global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data. NI MAKES

NO EXPRESS OR IMPLIED WARRANTIES AS TO THE ACCURACY OF THE INFORMATION CONTAINED HEREIN AND SHALL NOT BE LIABLE FOR

ANY ERRORS. U.S. Government Customers: The data contained in this manual was developed at private expense and is subject to the applicable

limited rights and restricted data rights as set forth in FAR 52.227-14, DFAR 252.227-7014, and DFAR 252.227-7015.

Reverification

Repeat the Verification section to determine the As-Left status of the device.

Note If any test fails Reverification after performing an adjustment, verify that you

have met the Test Conditions before returning your device to NI. Refer to Worldwide

Support and Services for assistance in returning the device to NI.

Worldwide Support and Services

The NI website is your complete resource for technical support. At ni.com/support you have

access to everything from troubleshooting and application development self-help resources to

email and phone assistance from NI Application Engineers.

Visit ni.com/services for NI Factory Installation Services, repairs, extended warranty, and

other services.

Visit ni.com/register to register your NI product. Product registration facilitates technical

support and ensures that you receive important information updates from NI.

A Declaration of Conformity (DoC) is our claim of compliance with the Council of the European

Communities using the manufacturer’s declaration of conformity. This system affords the user

protection for electromagnetic compatibility (EMC) and product safety. You can obtain the DoC

for your product by visiting ni.com/certification. If your product supports calibration,

you can obtain the calibration certificate for your product at ni.com/calibration.

NI corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas,

78759-3504. NI also has offices located around the world. For telephone support in the United

States, create your service request at ni.com/support or dial 1 866 ASK MYNI (275 6964).

For telephone support outside the United States, visit the Worldwide Offices section of

ni.com/niglobal to access the branch office websites, which provide up-to-date contact

information, support phone numbers, email addresses, and current events.

Autres manuels pour NI 9246

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels National Instruments Unité de contrôle

National Instruments

National Instruments NI-9208 Manuel utilisateur

National Instruments

National Instruments NI PXI-2585 Manuel utilisateur

National Instruments

National Instruments 9756 Manuel utilisateur

National Instruments

National Instruments NI 9870 Manuel utilisateur

National Instruments

National Instruments NI 9264 Manuel utilisateur

National Instruments

National Instruments PXIe-4310 Manuel utilisateur

National Instruments

National Instruments FBUS-HSE/H1 LD Manuel utilisateur

National Instruments

National Instruments SCXI-1120/D Manuel

National Instruments

National Instruments LabVIEW Robotics Module Manuel utilisateur

National Instruments

National Instruments NI 9207E Manuel utilisateur

National Instruments

National Instruments NI-9361 Manuel

National Instruments

National Instruments SCXI-1104 Manuel utilisateur

National Instruments

National Instruments NI 9251 Manuel utilisateur

National Instruments

National Instruments BNC-208X Series Manuel utilisateur

National Instruments

National Instruments NI PXI-665 Series Manuel utilisateur

National Instruments

National Instruments NI 9425 Manuel utilisateur

National Instruments

National Instruments SCXI-1521 Manuel utilisateur

National Instruments

National Instruments FlexRIO PXIe-79 R Series Manuel utilisateur

National Instruments

National Instruments Relay Module SCC-RLY01 Manuel utilisateur

National Instruments

National Instruments SCXI-1000 Manuel utilisateur

National Instruments

National Instruments PXIe-4302 Manuel utilisateur

National Instruments

National Instruments PXIe-6674T Manuel utilisateur

National Instruments

National Instruments PXIe-8830mc Manuel utilisateur

National Instruments

National Instruments NI 9516 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
