Multitech MultiConnect microCell MTCM2-L6G1 Manuel utilisateur

MultiConnect®microCell

MTCM2-L6G1 User Guide

MULTICONNECT MICROCELL USER GUIDE

2 MultiConnect®microCell MTCM2-L6G1 User Guide

MultiConnect microCell User Guide

Model: MTCM2-L6G1

Part Number: S000752 1.1

This publication may not be reproduced, in whole or in part, without the specific and express prior written permission signed by an executive officer of

Multi-Tech Systems, Inc. makes no representations or warranties, whether express, implied or by estoppels, with respect to the content, information,

material and recommendations herein and specifically disclaims any implied warranties of merchantability, fitness for any particular purpose and non-

infringement.

Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of

Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes.

Trademarks

MultiTech®, the MultiTech logo, and MultiConnect are registered trademarks of Multi-Tech Systems, Inc. All other brand and product names are trademarks

or registered trademarks of their respective companies.

Legal Notices

The MultiTech products are not designed, manufactured or intended for use, and should not be used, or sold or re-sold for use, in connection with

applications requiring fail-safe performance or in applications where the failure of the products would reasonably be expected to result in personal injury or

death, significant property damage, or serious physical or environmental damage. Examples of such use include life support machines or other life

preserving medical devices or systems, air traffic control or aircraft navigation or communications systems, control equipment for nuclear facilities, or

missile, nuclear, biological or chemical weapons or other military applications (“Restricted Applications”). Use of the products in such Restricted

Applications is at the user’s sole risk and liability.

The MultiTech products and the final application of the MultiTech products should be thoroughly tested to ensure the functionality of the MultiTech

products as used in the final application. The designer, manufacturer and reseller has the sole responsibility of ensuring that any end user product into

which the MultiTech product is integrated operates as intended and meets its requirements or the requirements of its direct or indirect customers.

MultiTech has no responsibility whatsoever for the integration, configuration, testing, validation, verification, installation, upgrade, support or maintenance

of such end user product, or for any liabilities, damages, costs or expenses associated therewith, except to the extent agreed upon in a signed written

document. To the extent MultiTech provides any comments or suggested changes related to the application of its products, such comments or suggested

changes is performed only as a courtesy and without any representation or warranty whatsoever.

Contacting MultiTech

Knowledge Base

The Knowledge Base provides immediate access to support information and resolutions for all MultiTech products. Visit http://www.multitech.com/kb.go.

Support Portal

To create an account and submit a support case directly to our technical support team, visit: https://support.multitech.com.

Support

Business Hours: M-F, 8am to 5pm CT

Country By Email By Phone

Europe, Middle East, Africa: [email protected] +(44) 118 959 7774

U.S., Canada, all others: [email protected] (800) 972-2439 or (763) 717-5863

Warranty

To read the warranty statement for your product, visit https://www.multitech.com/legal/warranty. For other warranty options, visit

www.multitech.com/es.go.

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive, Mounds View, MN 55112

Phone: (800) 328-9717 or (763) 785-3500

Fax (763) 785-9874

CONTENTS

MultiConnect®microCell MTCM2-L6G1 User Guide 3

Contents

Chapter 1 – Product Overview ................................................................................................................................. 5

About the MultiConnect microCell Modem ................................................................................................................. 5

Documentation Overview ............................................................................................................................................. 5

Dimensions.................................................................................................................................................................... 6

MTCM2-L6G1 Specifications ......................................................................................................................................... 7

MTCM2-L6G1 Power Draw ........................................................................................................................................... 8

Side Panels and Connectors.......................................................................................................................................... 8

Side Panels ................................................................................................................................................................. 8

Connectors .................................................................................................................................................................. 8

LED Descriptions ........................................................................................................................................................... 9

Additional Signal LED Information ............................................................................................................................ 10

Chapter 2 – Safety Warnings.................................................................................................................................. 11

Radio Frequency (RF) Safety ....................................................................................................................................... 11

Sécurité relative aux appareils à radiofréquence (RF).............................................................................................. 11

Interference with Pacemakers and Other Medical Devices ...................................................................................... 12

Potential interference............................................................................................................................................... 12

Precautions for pacemaker wearers ........................................................................................................................ 12

Chapter 3 – Installing Drivers ................................................................................................................................. 13

Installing on Linux ....................................................................................................................................................... 13

Installing Windows Drivers ....................................................................................................................................... 13

Uninstall driver before installing update .................................................................................................................. 14

Chapter 4 – Installing the Device............................................................................................................................ 15

Installing a SIM Card ................................................................................................................................................... 15

Removing a SIM Card................................................................................................................................................ 15

Installing the Device.................................................................................................................................................... 15

Connecting to a CBRS Network................................................................................................................................... 15

Basic AT Commands.................................................................................................................................................. 15

Troubleshooting the Connection ............................................................................................................................. 16

Chapter 5 – Antenna Information .......................................................................................................................... 17

Antenna....................................................................................................................................................................... 17

Antenna System Devices............................................................................................................................................. 17

CBRS Antenna ............................................................................................................................................................. 17

Antenna Specifications.............................................................................................................................................. 17

Chapter 6 – Regulatory Information....................................................................................................................... 18

47 CFR Part 15 Regulation Class B Devices ................................................................................................................. 18

FCC Interference Notice.............................................................................................................................................. 18

Industry Canada Class B Notice................................................................................................................................... 18

CONTENTS

4 MultiConnect®microCell MTCM2-L6G1 User Guide

Waste Electrical and Electronic Equipment Statement .............................................................................................. 19

WEEE Directive.......................................................................................................................................................... 19

Instructions for Disposal of WEEE by Users in the European Union ........................................................................ 19

REACH Statement ....................................................................................................................................................... 19

Registration of Substances........................................................................................................................................ 19

Restriction of the Use of Hazardous Substances (RoHS) ............................................................................................ 20

Information on HS/TS Substances According to Chinese Standards ......................................................................... 21

Information on HS/TS Substances According to Chinese Standards (in Chinese) ...................................................... 22

PRODUCT OVERVIEW

MultiConnect®microCell MTCM2-L6G1 User Guide 5

Chapter 1 – Product Overview

About the MultiConnect microCell Modem

The MultiConnect microCell is a compact and simple communications platform that provides CBRS capabilities for

fixed and mobile applications. It is intended for use in settings such as vending, smart parking, medical, smart

inventory tracking equipment and commercial applications.

Documentation Overview

The following documents are available at https://www.multitech.com/brands/multiconnect-microcell. Select your

model to find the documents specific for that device.

Document Description Part Number

MultiConnect microCell MTCM2-

L6G1 User Guide

Hardware, regulatory, and getting started

information.

S000752

MultiConnect microCell MTCM2-

L6G1 Quick Start

Steps for getting started. Ships with the

device and is available online.

82105000L

Sequans Cassiopeia AT Commands

Manual

Lists AT Commands and parameters used

to communicate with your device.

N/A

Cassiopeia Module Use Cases with

AT Commands

Provides AT Command use cases N/A

PRODUCT OVERVIEW

6 MultiConnect®microCell MTCM2-L6G1 User Guide

Dimensions

PRODUCT OVERVIEW

MultiConnect®microCell MTCM2-L6G1 User Guide 7

MTCM2-L6G1 Specifications

Category Description

General

Standards 3GPP E-UTRA Release 10

USB Interface is CDC-ACM and CDC-ETHER compliant

TCP/IP Functions FTP, SMTP, SSL, UDP

Frequency Bands LTE: B42/B43

CBRS: B48

Speed

Data Speed LTE: Max 200Mbps (DL)/Max 15Mbps (UL)

Physical Description

Weight Device only 2.4 oz (66 g); With antennas 2.9 oz (83 g)

Dimensions Refer to Dimensions for dimensions.

Connectors

Antenna Connector 2 SMA connectors

SIM 1.8V and 3V SIM holder for micro-SIM (3FF) card

USB USB 2.0 with High Speed up to 480 Mbps

Environment

Operating Temperature -30° C to +60° C*

Storage Temperature -40° C to +85° C

Operating Humidity 10%-85% RH, non-condensing

Storage Humidity 5%-85% RH, non-condensing

Power Requirements

Operating Voltage USB Model: 5 VDC

SMS

SMS Point-to-Point messaging

Mobile-Terminated SMS

Mobile-Originated SMS

Certifications and Compliance

EMC and Radio

Compliance

FCC Part 15B

FCC Part 96.47

Safety Compliance UL/cUL 62368-1

*UL tested to ambient temperature of +60C.

PRODUCT OVERVIEW

8 MultiConnect®microCell MTCM2-L6G1 User Guide

MTCM2-L6G1 Power Draw

Note: MultiTech recommends that you incorporate a 10% buffer into your power source when determining

product load.

Radio Protocol 3G On/Off

Mode

Current or

Sleep

Mode

Live

Connection,

Idle Current

Average

Measured

Current at Max

Power1

TX Pulse

Amplitude

Current for

Peak Current 2

Total Inrush

Charge 3

Total Inrush

Duration

During

Power Up

5 Volts USB

LTE Band 43

(3700Mhz)

N/A N/A 477 mA 784 mA 0.135 mC 22.1 uS

LTE Band 42

(3500Mhz)

N/A N/A 482 mA 792 mA 0.135 mC 22.1 uS

LTE Band 48

(3625Mhz)

N/A 173 mA 473 mA 768 mA 0.135 mC 22.1 uS

Note:

1. Maximum Power: The continuous current during maximum data rate with the radio transmitter at

maximum power.

2. TX Pulse: The average peak current during an LTE connection.

3. Inrush Charge: The total inrush charge at power on.

Side Panels and Connectors

Side Panels

Connectors

The device has the following connectors:

USB 1 USB connector

SMA 2 female SMA connectors, labeled CELL and AUX

SIM 1 micro-SIM slot, between the SMA connectors

PRODUCT OVERVIEW

MultiConnect®microCell MTCM2-L6G1 User Guide 9

LED Descriptions

The MTCM2 has the following LEDs:

Note:

Slow is 1 second on 1 second off

Fast is 200 milliseconds on 200 milliseconds off

LED Status Description

Power On Device has power

Off Device does not have power

Link Status (LS) On Radio is not registered

Flash Slow Registered

Off Radio is turned off, in PSM mode, receiving a firmware

update, or SIM is not inserted.

LTE On LTE

Off SIM not inserted or radio technology unknown

SIM On Ready

Flash Slow Other

Off SIM not inserted

Signal Strength On Good

Flash Fast Fair

Flash Slow Poor

Off Too low for communication or SIM not inserted.

PRODUCT OVERVIEW

10 MultiConnect®microCell MTCM2-L6G1 User Guide

Additional Signal LED Information

Signal LED is based on +CESQ RSRP and RSRQ:

RSRP RSRQ

On -90 -10+

Fast -105 -11 to -15

Slow -120 -16 to -19

Off < -120 < -19

Table des matières

Autres manuels Multitech Modem

Multitech

Multitech MultiModem Cell MTCBA-E1 Manuel utilisateur

Multitech

Multitech MultiModemII MT5600BR-V92 Manuel utilisateur

Multitech

Multitech SocketModem Guide d'application

Multitech

Multitech MultiModem MT5634ZBA-V.92 Manuel utilisateur

Multitech

Multitech SocketModem Guide d'application

Multitech

Multitech MultiModem ZPX MT9234ZPX-PCIE-NV-CP Manuel utilisateur

Multitech

Multitech MultiModem Cell MTCBA-E1 Manuel utilisateur

Multitech

Multitech MTSMC-G2 Instructions d'installation

Multitech

Multitech BA-Series Manuel utilisateur

Multitech

Multitech Multimodem MTCBA-G-F1 Manuel utilisateur

Multitech

Multitech MultiModem SocketModem MT9234 Series Manuel d'installation

Multitech

Multitech SocketModem MTSMC-L Series Guide d'application

Multitech

Multitech MultiModem iCell MTCMR-E1 Manuel utilisateur

Multitech

Multitech MultiModem IND MT5634IND Manuel utilisateur

Multitech

Multitech CC1600-11L Manuel utilisateur

Multitech

Multitech etherFAX A2E Manuel utilisateur

Multitech

Multitech MTD-EV3 QuickCarrier Manuel utilisateur

Multitech

Multitech SocketModem Cell Cat M1 Guide d'application

Multitech

Multitech QuickCarrier USB-D MTD-MVW1 Manuel utilisateur

Multitech

Multitech MultiModem ZBA MT9234ZBA Manuel utilisateur

Multitech

Multitech MultiConnect Adapter Manuel utilisateur

Multitech

Multitech MT128STZLX Manuel de l'opérateur

Multitech

Multitech MTE-LAT6-B07 Manuel utilisateur

Multitech

Multitech MT5600BA Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
