MGate 5135/5435 Series

Quick Installation Guide

Version 1.0, September 2022

Technical Support Contact Information

www.moxa.com/support



- 2 -

Overview

The MGate 5135/5435 is an industrial Ethernet gateway for Modbus

RTU/ASCII/TCP and EtherNet/IP network communications.

Package Checklist

Before installing the MGate 5135/5435, verify that the package

contains the following items:

•1 MGate 5135 or MGate 5435 gateway

•Quick installation guide (printed)

•Warranty card

NOTE

Please notify your sales representative if any of the above

items are missing or damaged.

Optional Accessories (can be purchased separately)

•Mini DB9F-to-TB: DB9 female to terminal block connector

•WK-25: Wall-mounting kit, 2 plates, 4 screws, 25 x 43 x 2 mm

Hardware Introduction

LED Indicators

LED

Color

Description

PWR 1, PWR 2

Green

Power is on.

Off

Power is off.

Ready

Off

Power is off.

Green

Steady: Power is on, and the MGate is

functioning normally.

Blinking (1 sec.): The MGate has been located

by the MGate Manager’s Location function.

Red

Steady: Power is on, and the MGate is booting

up.

Blinking (0.5 sec.): Indicates an IP conflict, or

the DHCP or BOOTP server is not responding

properly.

Blinking (0.1 sec.): the microSD card failed.

EtherNet/IP

Adapter

Off

No connection has been established.

Green Steady: I/O data is being exchanged with all

of the connections.

Red

Steady: Rejects the connection due to

incorrect configurations.

Blinking (1 sec.): One or more connections

timed out.

Modbus

RTU/ASCII/TCP

Client

Off

No communication with Modbus device.

Green

Modbus communication in progress.

Red

Blinking (1 sec.):Communication error.

1. The Modbus

slave device returned an error

(exception).

2. Received a frame error (parity error,

checksum error).

3. Timeout (the slave device does not

respond).

- 3 -

LED

Color

Description

4. TCP connection failed (only for Modbus

TCP).

ETH 1, ETH 2

Green

Steady ON: Ethernet link on at 100Mbps.

Blinking: Data transmitting at 100Mbps.

Amber

Steady ON: Ethernet link on at 10Mbps.

Blinking: Data transmitting at 10Mbps.

Off

Ethernet is not connected.

Dimensions

MGate 5135

MGate 5435

Reset Button

Restore the MGate to factory default settings by using a pointed object

(such as a straightened paper clip) to hold the reset button down until

the Ready LED stops blinking (approx. five seconds).

- 4 -

Hardware Installation Procedure

1. Connect the power adapter. Connect the 12 to 48 VDC power line

or DIN-rail power supply to the terminal block of the MGate

5135/5435 device.

2. Use a Modbus serial cable to connect the MGate to a Modbus slave

device.

3. Use an Ethernet cable to connect the MGate to the EtherNet/IP

controller.

4. We designed the MGate 5135/5435 to attach to a DIN rail or

mounted on a wall. For DIN-rail mounting, push down the spring

and properly attach it to the DIN rail until it “snaps” into place. For

wall mounting, install the wall-mount kit (optional) first and then

screw the device onto the wall.

The following figure illustrates the two mounting options:

Wall- or Cabinet-mounting

We provide two metal plates for mounting the unit

on a wall or inside a cabinet. Attach the

plates to

the unit’s rear panel with screws. With the plates

attached, use screws to mount the unit on a wall.

The heads of the screws should be 5 to 7 mm in

diameter, the shafts should be 3 to 4 mm in

diameter, and the length of the screws should be

over 10.5 mm.

Software Installation Information

Please download the User Manual and Device Search Utility (DSU) from

Moxa’s website: www.moxa.com

Refer to the User’s Manual for additional details on using the DSU. The

MGate 5135/5435 also supports login via a web browser.

Default IP address: 192.168.127.254

Create your administration account and password when you log in the

first time.

- 5 -

Pin Assignments

Modbus Serial Port (Male DB9)

Pin RS-232

RS-422/

RS-485 (4W)

RS-485 (2W)

DCD

TxD-(A)

–

RXD

TxD+(B)

–

TXD

RxD+(B)

Data+(B)

DTR

RxD-(A)

Data-(A)

GND

DSR

–

RTS

–

CTS

–

*Signal ground

Ethernet Port (RJ45)

Signal

Tx+

Tx-

Rx+

Rx-

Power Input and Relay Output Pinouts

V2+ V2-

V1+ V1-

Power

Input 2

Power

Input 2

N.O. Common

N.C.

Power

Input 1

Power

Input 1

Specifications

Power Parameters

Power Input

12 to 48 VDC

Power Consumption

MGate 5135 Series: 455 mA max.

MGate 5435 Series: 455 mA max.

Relays

Contact Current Rating

Resistive load: 2 A @ 30 VDC

Environmental Limits

Operating

Temperature

Standard models: -10 to 60°C (14 to 140°F)

Wide temp. models: -40 to 75°C (-40 to 167°F)

Storage Temperature

(package included)

-40 to 85°C (-40 to 185°F)

Ambient Relative

Humidity

5 to 95% RH

Physical Characteristics

Dimensions

MGate 5135 Series:

25 x 90 x 129.6 mm (0.98 x 3.54 x 5.1 in)

MGate 5435 Series:

42 x 90 x 129.6 mm (1.65 x 3.54 x 5.1 in)

- 6 -

Weight

MGate 5135 Series: 294 g (0.65 lb)

MGate 5435 Series: 403 g (0.89 lb)

Reliability

Alert Tools

Built-in buzzer and RTC

MTBF MGate 5135 Series: 1,240,821 hrs.

MGate 5435 Series: 689,989 hrs.

ATTENTION

Power

terminal plug wiring size is 28-14 AWG, tighten to 1.7

in-lbs, wire Min. 80°C, Use copper conductors only.

Hot Surface Label.

Functional earth terminal.

ATTENTION

•

This device is an open-type equipment and intended to be

installed in a suitable enclosure.

•

If the equipment is used in a manner not specified by the

manufacturer, the protection provided by the equipment

may be impaired.

•

When installing, the assembler is responsible for the safety

of the system in which the equipment is incorporated.

NOTE

•This device is intended for use indoors and at altitudes up

to 2,000 meters.

•Pollution degree 2.

NOTE

Clean the device with a soft cloth, dry or with water.

NOTE

The power input specification complies with the requirements of

SELV (Safety Extra Low Voltage), and the power supply should

comply with UL 61010-1 and UL 61010-2-201.

For any repair or maintenance needs, please contact us.

Moxa Inc.

No. 1111, Heping Rd., Bade Dist., Taoyuan City 334004, Taiwan

+886-03-2737575
