27" IPS-G Pro LED Monitor

User's Manual

CONTENTS

SAFETY GUIDELINES

FEATURES

PACKAGE CONTENTS

CONNECTIONS & CONTROLS

MONITOR STAND & BASE

VIEW ANGLE ADJUSTMENT

INSTALLATION

POWER

INPUT SELECTION

ON-SCREEN DISPLAY (OSD) MENU

BASIC MENU OPERATION

TROUBLESHOOTING

SPECIFICATIONS

PRESET DISPLAY MODES

----------------------------------------------------------------- 2

-------------------------------------------------------------------------------- 3

---------------------------------------------------------------- 3

----------------------------------------------------- 4

------------------------------------------------------------ 5

-------------------------------------------------------- 7

--------------------------------------------------------------------------- 7

------------------------------------------------------------------------------------- 8

--------------------------------------------------------------------- 8

--------------------------------------------- 8

----------------------------------------------------------- 9

----------------------------------------------------------------- 16

----------------------------------------------------------------------- 18

----------------------------------------------------------- 19

To avoid personal injury or damage to your equipment, please adhere to the

following safety guidelines:

1. Do not place the monitor on an unstable surface where it could fall and

cause personal injury or damage to the monitor or other equipment.

2. Do not expose the monitor to water or moisture of any kind. Do not place

objects filled with moisture such that they could tip over and spill onto the

monitor.

3. If the monitor is exposed to moisture, immediately unplug the power source

and allow it to completely dry out before reapplying power.

4. Do not block the ventilation holes on the monitor. Do not place the monitor

in an enclosed space where it cannot get adequate ventilation or cooling.

5. Do not place the monitor near a heat source, such as a fireplace, radiator,

heater vent, etc.

6. The power supply for this monitor uses a NEMA 5-15 grounded plug.

Ensure that your power source is properly grounded. Do not use a "cheater"

plug to bypass the ground pin.

7. The monitor can be powered by a wide voltage range, from 100 to 240 V

AC at 50 or 60 Hz, with an AC current at least 3.75A. Ensure that your power

source supplies voltage within this operating range. If your power source is

not within this operating range, please consult your local power company.

8. If the monitor will be unused for a long period of time, turn it off and unplug

it from the power source. This will help prevent damage in the event of a

lightning strike or excessive power surge.

9. Do not attempt to open the case or service the monitor yourself.

10. Clean only with a soft, dry cloth. Do not use solvents or chemical cleaners

on the screen or casing.

11. Do not leave a single image on the display for an extended length of time.

Doing so could cause burn-in of the image, that is visible on the screen mask.

It is recommended to use a variable desktop background and to use a screen

saver to prevent burn-in. Alternatively, ensure that the monitor is powered off

for at least 2 hours out of every 12.

SAFETY GUIDELINES

27" IPS monitor with LED backlighting

16:9 aspect ratio

2560 x 1440 @ 60Hz maximum resolution

Includes DisplayPort, VGA, HDMI, and Dual Link DVI-D input options

Angle adjustable stand +20 ~ -5 degrees

Built-in stereo speakers with 2 watt/channel amplifier

FEATURES

1x 27" IPS LED monitor

1x Stand base

1x AC power adapter

1x AC power cord

1x 3.5mm audio cable

1x Dual Link DVI-D cable

1x User's manual

PACKAGE CONTENTS

1 DP DisplayPort connector

CONNECTIONS & CONTROLS

2 VGA VGA port

3 DVI Dual Link DVI-D port

4 HDMI HDMI port

5 AUDIO 3.5mm stereo TRS audio jack

6 DC IN

AUTO

1234567

VOL+ VOL- UP DOWN MENU

DC power connector

1 AUTO

7 Power ON/OFF

2 VOL+ Increases the volume level

Moves the selection to the right in the menus

Exits the main menu/ Auto adjusts the image

Displays the source list

3 VOL- Decreases the volume level

Moves the selection to the left in the menus

4 UP Moves the selection up in the menus

Selectable Hotkey action

5 DOWN Moves the selection down in the menus

Selectable Hotkey action

MENU Displays the main menu

Edit highlighted menu item

VGA connector

DP connector

DVI connector HDMI connector

Audio connector

DC IN

The monitor stand comes already attached to the back of the monitor. To

install the base, perform the following steps:

1. Place a blanket or towel on a flat surface (such as a table or the floor).

2. Place the monitor face down on the blanket or towel.

3. Swivel the stand up so that there is sufficient vertical space to install the

base.

4. Fit the base on the bottom of the stand and press it until it clicks into place.

To remove the base, perform the following steps:

1. Place a blanket or towel on a flat surface (such as a table or the floor).

2. Place the monitor face down on the blanket or towel.

3. Squeeze the two plastic clips on the bottom of the base and pull the base

off the stand.

MONITOR STAND & BASE

Note that the stand can be removed from the back of the monitor so that the

monitor can be attached to a desk or wall mount. To remove the stand,

perform the following steps:

1. Place a blanket or towel on a flat surface (such as a table or the floor).

2. Place the monitor face down on the blanket or towel.

3. Remove the four screws attaching the stand to the back of the monitor.

To attach the monitor to a desk or wall mount, please refer to the instructions

for the mount.

Note: The monitor uses a VESA mounting size of 100x100.

100mm

If you are using the stand and base that comes with the monitor, you can

adjust the vertical angle of the monitor from -5 degrees (down) to +20

degrees (up). To adjust the angle, grasp the top and bottom edges of the

display, taking care not to touch the glass on the front. You can use clean

gloves or soft, dry cloths to aid in grasping the display edge without touching

the screen.

VIEW ANGLE ADJUSTMENT

1. Install the base or attach the monitor to a desk or wall mount, as desired.

(See MONITOR STAND & BASE)

2. Using the included video signal cables, connect video source devices to

the appropriate ports on the back of the monitor. You can have a different

video source device for each input.

3. Plug the DC power connector into the DC IN port on the back of the

monitor.

4. Plug the AC cord into the AC adapter, then plug the other end into a power

outlet.

INSTALLATION

5° 20°

Press the power button to turn the monitor ON. The LED indicates the power

state:

Blue - Power is ON

Orange - Standby mode

Off - No power to monitor

POWER

1. Press the AUTO button to display the list of inputs.

2. Press the UP or DOWN buttons to move the red highlight to the desired

input.

3. Press the MENU button to switch to the highlighted input.

ON-SCREEN DISPLAY (OSD) MENU

The built-in OSD menu system allows you to adjust the various settings

options on the monitor.

INPUT SELECTION
