Metrologic MS860 Manuel utilisateur

METROLOGIC INSTRUMENTS, INC.

MS860iMini-Slot™

Laser Bar Code Scanner

Installation and User’s Guide

MLPN 2202

Printedin USA

January 1999

Locations:

USA Corporate Headquarters Europe

Metrologic Instruments, Inc. Metrologic Instruments GmbH

90 Coles Road Dornierstrasse 2

Blackwood, NJ 08012 82178 Puchheim b.

Customer Service: 1-800-ID-METRO Munich, Germany

Tel: 609-228-8100 Tel: 49-89-89019-0

Fax: 609-228-6673 Fax: 49-89-89019-200

[email protected] [email protected]

www.metrologic.com

ASIA

South America Metrologic Asia (PTE) Ltd.

Metrologic Instruments 31, Kaki Bukit Road 3

Rua Flórida, 1.821-5°Andar-Brooklin #05-08 Techlink

CEP 04571-090, São Paulo-SP, Brasil Singapore 417818

Outside Brazil: Tel: 65-842-7155

Tel: 55-11-5505-6568

iii

Table of Contents

Introduction .................................................. 1

Unpacking List ................................................. 2

Scanner Connections to the Host ................................... 3

Configuration of the Scanner to the Host System ...................... 4

Cloning Feature ................................................ 5

Version 11 IBM 46XX Scanner ................................... 6

Configuring the MS860i-11 Scanner ........................ 7

Configuring the IBM 46XX ............................... 8

IBM 4683 and 4693 Terminals Driven by a 46XX Store

Controller Running 4680.OS or 4690.OS ............ 8

IBM 4684 and 4694 Systems .............................. 8

Version 17 Keyboard Wedge Scanner .............................. 9

Connection of a MS860i-17 Scanner to a PC ........................ 10

Installing the Scanner into a Counter .............................. 11

Attaching the Vertical Stand to the Work Surface .................... 12

MS860iFeatures .............................................. 13

Touch Plate ............................................... 14, 15

Visual Indicators ........................................... 16-19

Volume Settings ............................................... 20

Labels ...................................................... 21

Depth of Field ................................................ 22

Depth of Field and Symbol Specification ........................ 23, 24

Maintenance .................................................. 25

Applications and Protocols ..................................... 25

Appendix A

Specifications ...................................... 26, 27

Appendix B

Default Settings ..................................... 28-35

Appendix C

Pin Assignments .................................... 36-41

Appendix D

Warranty and Disclaimer ............................. 42, 43

Appendix E

Notices ........................................... 44, 45

Appendix F

Patents ............................................... 46

Volume Control Card ....................................... 47, 48

Index .................................................... 49, 50

Introduction

Metrologic's MS860iMini-Slot™ Laser Bar Code Scanner is a high-speed,

aggressive in-counter scanner. The MS860i unsurpassed scanning accuracy and

incorporates the most advanced laser technology in a smaller, yet rugged and

durable housing. Designed to be used where counter space is at a premium, the

MS860ican be used in a variety of applications.

The MS860iautodiscriminates all standard bar codes, eliminating the need to

"keyin" unprogrammed codes increasing productivity and efficiency. A code

correcting feature (MECCA)© enables the MS860ito decode damaged or

truncated codes on the first pass, making the MS860ian excellent choice for

reclamation and coupon redemption applications. Each version of the MS860i

provides three interface options, with full RS-232 protocol available on every

scanner. Three most popular protocols (RS-232, OCIA and Light Pen Emulation)

are consolidated into the standard model. For simple PC connectivity, a keyboard

wedge interface is also available. Metrologic also offers a patented Hand-Held

Option, which allows users to connect the MS941 Hand-Held Scanner to the

MS860i for greater scanning versatility.

The MS860iis easy to program via bar code menus from ScanSelect™ Scanner

Programming Guide or by using Metrologic's ScanSet™ IBM compatible

software program. Other key features of the MS860iare the auto-off/touch-on

plate and easily visible LED indicators mounted on the brushed stainless steel top

plate. An optional hardened glass window is also available. Universal adaptor

plates make it simple to replace older, larger flatbed scanners with the smaller

MS860i. Metrologic also provides a vertical mounting option, so customers can

use the MS860ias a projection scanner as well.

Most importantly, the MS860iis easy to afford. It offers a superior, versatile and

low cost alternative to larger, more expensive in-counter scanners.

Unpacking List

The shipping carton contains the following:

!Installation and User’s Guide (MLPN: 2202)

ScanSelect™ Scanner Programming Guide (MLPN: 2186)

Volume Control Card (MLPN: 2346)

!MS860iLaser Bar Code Projection Scanner

!Installation Plate (MLPN: 45471)

!Power Supply (optional)

!Communication cable with connection for power supply (optional) or

Communication Cable (optional)

!Adaptor Plate or Vertical Stand (optional)

If any item is missing or to order additional items, contact the dealer, distributor

or call Metrologic’s Customer Service Department at 1-800-ID-METRO or 1-

800-436-3876.

Scanner Connections to the Host

To maintain compliance with applicable standards, all circuits connected to the

scanner must meet the requirements for SELV (Safety Extra Low Voltage)

according to EN 60950. To avoid potential problems, do not power up the

scanner until the communication cable is secured to the host.

1. Turn off the host system.

2. Connect the 25-pin D-type connector on the scanner’s head cable to the

communication cable. Connect the other end of the communication cable

to the host device. (If the scanner will not receive power from a

transformer, skip to Step 5.)

3. If the scanner will receive power from an external power source, check the

AC input requirements of the transformer to make sure the voltage

matches the AC outlet. (A socket-outlet shall be installed near the

equipment and shall be easily accessible.)

4. Plug the transformer into the side of the female D-type connector located

on the communication cable. Plug the transformer into the AC outlet to

supply power to the scanner.

5. Power up the host system.

Note:When the scanner first receives power, the LEDs will flash and then

the scanner will beep once. After the scanner performs this start up

sequence, the green LED will remain on for a specified time

indicating that the laser is on.

Configuration of the Scanner to the Host System

The scanner is shipped from the factory programmed to a set of default conditions

noted in the Default Settings section of this guide and in the ScanSelect™

Scanner Programming Guide. The default settings in the ScanSelect guide have

an asterisk that appears before the brief definition

next to the bar code.

To communicate with the host system properly, it needs to be programmed to

meet specific scanning needs. Since each host system is unique, configure the

scanner to match the host system requirements. Configure the scanner by entering

program mode and scanning the appropriate bar codes that appear in the

ScanSelect Scanner Programming Guide. (When using ScanSet™, refer to the

ScanSet documentation for information on how to configure the scanner.)

1. Connect the scanner to the host system. (Refer to the Scanner

Connections to the Host section in this guide)

2. Enter program mode by scanning the ENTER/EXIT program mode bar

code as the first bar code after a power up cycle.

(The unit will beep three times.)

3. Scan the appropriate bar code(s) that appear in the ScanSelect Scanner

Programming Guide. (Reveal only one bar code to the scanner each time.

With your hand, cover the bar code that is not to be scanned.)

4. Exit program mode by scanning the ENTER/EXIT program mode bar

code again. (The new options will be saved and the scanner is ready for

normal operation.)

Note:Non-RS-232 interfaces chosen in Section B of the ScanSelect

Programming Guide do not match the default settings that are loaded

when the same interface is selected with ScanSet.

Cloning Feature

To program several scanners with the same settings, use the Cloning feature. This

is done by connecting the cloning cable (MLPN: #51544) between two scanners.

1. Turn off both scanners.

2. Connect the cloning cable between the two scanners.

3. Turn both scanners on by plugging in the transformers.

4. Once each scanner is ready, scan the cloning bar code with the scanner

that has the settings that need to be transferred to the other scanner.

Version 11 IBM 46XX Scanner

Output Format: IBM RS-485 serial input/output for the 4680 and 4690

(46XX) point-of-sale terminals

The Version 11 46XX interface can be used in several different ways. Both the

46XX terminal and the scanner must be configured to match each other.

Warning:Powerto the scanner and 46XX terminal should be turned off

before making physical connection.

The 4680 and 4690 series terminals have different types of physical ports for

connecting bar code scanners. Scanner ports include Port 5B, Port 17, and Port

9? (? = A, B, C, or E). A Port 9 type connector is present on all versions of the

46XX families of terminals. That is one reason why it is the normal point of

connection for Metrologic scanners. Another reason is that there is enough 12

volt power available to operate many Metrologic scanners. If your terminal

configuration requires the use of a different physical port for connecting bar code

scanners, contact Metrologic to get particular adaptor cable information.

All devices use a common communications bus inside the 46XX terminal, despite

what port that is in use for the physical connection. Each device has a different

address that it uses when it communicates. The terminal must be configured to

look for a device at a logical address.

The IBM 1520 mode/address was selected as a default because it was the first

IBM 46XX family scanner to support UPC/EAN, Code 39 and Interleaved 2 of

5(I 2 of 5). The Version 11 scanner formats Codabar, Code 128, and Code 93

using the Code 39 function code designation supported by the IBM device driver

for this scanner type. Other emulation modes currently available are the IBM

3687-2 Port 17 fixed scanner and the Port 9B IBM 4500 CCD hand-held bar

code reader. The use one of these other emulation modes may be needed

depending on which operating system (4680.OS, 4690.OS, POS/DOS or

DOS/RIPPS) is in use at your site.

Note:The IBM 4683 and IBM 4684 terminals have a good proven track

record of supplying power to Metrologic scanners. The IBM 4693 and

IBM 4694 terminals may be restricted from supplying power to certain

scanner models. Specifically, Metrologic currently recommends using

an external power supply for the scanner when connecting to an IBM

4694. Metrologic has no recommendations at this time for IBM 4693

terminals.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Metrologic Lecteur de codes-barres

Metrologic

Metrologic MS9500 Voyager Series Manuel utilisateur

Metrologic

Metrologic MS7320 InVista Series Manuel utilisateur

Metrologic

Metrologic MS7320 InVista Series Manuel utilisateur

Metrologic

Metrologic FocusE IS1650 Manuel utilisateur

Metrologic

Metrologic MS1633 FocusBT Manuel utilisateur

Metrologic

Metrologic IS1000 Series Manuel utilisateur

Metrologic

Metrologic S4800 microQuest Series Manuel utilisateur

Metrologic

Metrologic MS6720 Manuel utilisateur

Metrologic

Metrologic MS7120 Orbit Manuel utilisateur

Metrologic

Metrologic MS1890 Focus Manuel utilisateur

Metrologic

Metrologic MS860i Mini-Slot Manuel utilisateur

Metrologic

Metrologic IS421X ScanGlove Manuel utilisateur

Metrologic

Metrologic StratosS MS2220 Manuel utilisateur

Metrologic

Metrologic MLPN 2168 Manuel utilisateur

Metrologic

Metrologic MS6130 Manuel utilisateur

Metrologic

Metrologic MS1633 FocusBT Manuel utilisateur

Metrologic

Metrologic MS1633 FocusBT Manuel utilisateur

Metrologic

Metrologic IS1000 Series Manuel utilisateur

Metrologic

Metrologic QuantumT MS3580 Manuel utilisateur

Metrologic

Metrologic Hand-Held Scanner Manuel utilisateur

Metrologic

Metrologic 1070 Manuel utilisateur

Metrologic

Metrologic MS700i Manuel utilisateur

Metrologic

Metrologic MS7120 Orbit Manuel utilisateur

Metrologic

Metrologic FocusE IS1650 Manuel utilisateur

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Datalogic

Datalogic Heron HD3130 Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur
