SPA400 Internet Telephony Gateway

with 4 FXO Ports

Guide v1.0

Administration and Configuration

SPA400 Internet Telephony Gateway with 4 FXO Ports

Administration and Configuration Guide v1.0

SPA400 Internet Telephony Gateway with 4 FXO Ports – Administration and Configuration Guide v1.0

Using the SPA400

The SPA400 features the ability to connect up to four (4) standard analog telephones

lines to a Linksys Voice System (LVS) VoIP network and includes the additional

benefit of a voicemail application. A total of 4 SPA400 devices can be configured per

SPA9000 utilizing up to 16 analog phone lines and automatically routing calls to and

from your existing PSTN telephone service.

Designed to be implemented only with a SPA9000, the SPA400 enables cost-

conscience business users to utilize the high value features on the LVS that are

typically found on much more expensive voice communications systems. The

SPA400 includes an integrated voicemail application supporting up to 32 voicemail

accounts with customized greetings, providing LVS users the ability to receive and

playback voicemail messages.

This section provides all the necessary steps to make the SPA400 operational with

the SPA9000 IP Telephony System. Refer to the other Chapters within this guide for

information about configuring the SPA9000.

Understanding How the SPA400 Interacts with the SPA9000

The SPA400 provides the SPA9000 access to the PSTN by connecting the FXO

ports to analog lines. There are specific “Line” settings on the SPA9000 that are

configured to recognize a SPA400 as a service enabling calls from an IP Phone on a

LVS network to be routed out to the PSTN and vice versa. The SPA400 sets up and

tears down calls between the PSTN and IP Phones offering seamless telephone

service with Linksys VoIP equipment.

Using the SPA9000 Setup Wizard

It is highly recommended that the SPA9000 Setup Wizard is used to install and

configure the SPA400 Telephony Gateway on a LVS network. Version 1.1.0.3 (or

higher) of the SPA9000 Setup Wizard supports the SPA400 for the initial or an

existing LVS installation.

Connect the SPA400 to the network via the Ethernet port before running the

SPA9000 Setup Wizard.

The latest version of the SPA9000 Setup Wizard can be downloaded from

http://www.linksys.com.

SPA400 Internet Telephony Gateway with 4 FXO Ports

Administration and Configuration Guide v1.0

SPA400 Internet Telephony Gateway with 4 FXO Ports – Administration and Configuration Guide v1.0

Configuring the SPA400

The SPA400 and the SPA9000 have corresponding fields that must be properly

configured for a successful installation. If the SPA9000 Setup Wizard is not used,

the SPA400 can alternatively be configured using the web-based configuration utility.

To access the Web-based configuration utility, launch a browser application and

enter the IP address of the SPA400. By default, the SPA400 is configured to obtain

an IP Address via DHCP. Running the SPA9000 Setup Wizard will automatically

detect the IP Address of the SPA400 to simplify installation.

Accessing the Web-base Configuration Utility

Upon entering the IP Address of the SPA400 into the browser, a password request

page will appear. The default User Name is Admin. Leave the password field blank

(no password). Click the OK button to access the configuration utility.

Using a password to access the SPA400 prevents unauthorized users from changing

the settings of the device. A new password can be entered by selecting the

Administration Tab and then clicking on the Management menu item.

Configuring the SPA400 with the associated SPA9000 settings

The following section provides the principal steps to configure a SPA400 on a LVS

network with a SPA9000. The example configuration assumes that a SPA9000 will be

configured to access the PSTN only and therefore the SPA400 is configured in the “Line

1” tab on the SPA9000. However, if a VoIP Service Provider is also to be defined, then

a SPA400 can be configured in any of the available Lines (1-4) tabs in the SPA9000

configuration utility.

A complete listing of all SPA400 menu items can be found towards the end of this guide

that provides additional information on the SPA400 parameters and settings using the

web-based configuration utility.

From the SPA400 configuration utility, click the Setup tab and select the SPA9000

Interface menu item.

User ID:

Enter the User ID of the SPA9000 in the User ID field. The User ID setting must be

identical to the User ID configured in the associated field in the Line # on the

SPA9000.

SPA400 Internet Telephony Gateway with 4 FXO Ports

Administration and Configuration Guide v1.0

SPA400 Internet Telephony Gateway with 4 FXO Ports – Administration and Configuration Guide v1.0

Discover Automatically:

The Discover Automatically radio button enables the SPA400 to learn the IP address

and the UDP port of the SPA9000 the from the SIP Registration packets sent by

SPA9000.

Static Address:

It is preferred that the SPA400 is configured with a static IP address. Enter the IP

address and the UDP port of the SPA9000 to enable the SPA400 to listen for the SIP

Registration request from the SPA9000

If the SPA9000 obtains an IP address from a DHCP server, it is preferred that the

“Discover Automatically” option is selected to avoid registration failure due to

SPA9000 IP address changes.

Figure 1 and Figure 2 reflect the web-based configuration utility for the SPA400 and

SPA9000. In the configuration example below, the SPA400 is listed as the Line 1

service, permitting PSTN access for the SPA9000. The two User ID fields are

referenced below with the identical “SPA9000” User ID entered on each

configuration utility.

Figure 1: SPA400 Configuration Utility,

Setup / SPA9000 Interface Page

Figure 2: SPA9000 Configuration Utility,

Voice / Line 1 Page

(SPA400 IP Address)

SPA400 Internet Telephony Gateway with 4 FXO Ports

Administration and Configuration Guide v1.0

SPA400 Internet Telephony Gateway with 4 FXO Ports – Administration and Configuration Guide v1.0

Click Save Settings at the bottom of the page and then the Restart button on the

SPA400 configuration utility. The SPA400 device will reboot. Continue to

Configuring the SPA9000 to register the SPA400.

Configuring the SPA9000 to register the SPA400

There are three setting that must be configured on the SPA9000 to complete the

SPA400 installation. Select the appropriate Line tab from the SPA9000 configuration

utility (Line 1 is used in the example in Figure 2). From this configuration page, the

following fields must match the settings entered in the SPA400 configuration:

SIP Settings: SIP Port = 5060 (SPA400 Port)

Subscriber Information: User ID = SPA9000 (SPA400 User ID)

Proxy and Registration: Proxy = 192.168.15.107 (SPA400 IP Address)

Click the Submit All Changes button on the SPA9000 configuration utility. The

SPA9000 device will reboot.

The SPA9000 is now configured to access the PSTN allowing calls to be routed to

and from the analog line(s) connected to the SPA400.

SPA400 Internet Telephony Gateway with 4 FXO Ports

Administration and Configuration Guide v1.0

SPA400 Internet Telephony Gateway with 4 FXO Ports – Administration and Configuration Guide v1.0

Using the Integrated Voicemail Application Server - Optional

The SPA400 includes a USB Adapter with an integrated voicemail application,

providing an essential voicemail service for users (or extensions) configured on a

SPA9000. The integrated voicemail application server supports 32 configurable

voicemail accounts enabling users to leave and play back voice messages.

(Although a SPA9000 can be configured with up to 4 SPA400 devices, only 1

SPA400 can be configured with the voicemail application).

The SPA9000 can be configured with up to four SPA400 devices, the voice mail

service can either concentrate with one SPA400 or distribute among the four

SPA400. However, an IP Phone can only subscribe to one mailbox from one

SPA400..

Configuring the SPA400 Voicemail Server

The SPA400 and the SPA9000 have corresponding fields that must be properly

configured for a successful installation. If the SPA9000 Setup Wizard is not used,

the SPA400 can alternatively be configured using the web-based configuration utility.

Refer to Accessing the Web-base Configuration Utility in the section above.

From the SPA400 configuration utility, click the Setup tab and select the Voicemail

Server menu item.

Server Port:

Enter the UDP port over which the Voicemail Server will listen for signaling between

the SPA400 and the SPA9000. Note: This port number must be different from the

UDP port configured in the SPA9000 Interface menu.

SPA9000 User ID:

Enter the User ID that the SPA9000 will use to register the SPA400 Voicemail

Server. This setting must be identical to the User ID configured in the SPA9000

Interface menu.

SPA9000 Subscriber ID:

Enter a Subscriber ID that the SPA9000 uses to subscribe to the SPA400 Voicemail

Server for obtaining notification.

Mailbox Deposit Number:

Enter the associated telephone number that the SPA9000 uses to deposit voicemail.

Mailbox Access Number:

Enter the associated telephone number that the SPA9000 uses to access voicemail.

SPA400 Internet Telephony Gateway with 4 FXO Ports

Administration and Configuration Guide v1.0

SPA400 Internet Telephony Gateway with 4 FXO Ports – Administration and Configuration Guide v1.0

Click Save Settings at the bottom of the page and then the Restart button on the

SPA400 configuration utility. The SPA400 device will reboot. Continue to

Configuring the SPA9000 Voicemail Settings.

Figure 3: SPA400 Configuration Utility,

Setup / Voicemail Server Page

Figure 4: SPA9000 Configuration Utility,

Voice / Line 1 Page

Configuring the SPA9000 Voicemail Settings

The parameters entered in the SPA400 Voicemail Server fields must also match in

the SPA9000 configuration utility under the associated Line # used for the SPA400

Voicemail Server.

The example in Figure 4 assumes the SPA9000 is configured to use Line 1. The

configuration and installation of the SPA400 and the integrated voicemail application

server can be configured on the same SPA9000 Line tab. It is not a requirement to

configure the SPA400 and Voicemail Server using separate SPA9000 Line tabs.

Three settings (URL) must be configured to enable the SPA9000 users to subscribe,

access, deposit, and manage their voicemail services. The settings are entered in

their respective fields on the SPA9000 in the following format:

<service_id#>@<spa400_ip_address>:<port>

Where service_id# and port must match the setting entered in the SPA400

Voicemail Server menu defined in Figure 3.

(SPA400 IP Address)

SPA400 Internet Telephony Gateway with 4 FXO Ports

Administration and Configuration Guide v1.0

SPA400 Internet Telephony Gateway with 4 FXO Ports – Administration and Configuration Guide v1.0

From the SPA9000 Line 1 tab, the following fields must match the settings entered in the

SPA400 Voicemail Server page. From the example above, the settings would be as

follows:

Subscriber Information: User ID = SPA9000 (SPA9000 User ID)

Proxy and Registration: Mailbox Deposit URL= [email protected]:5090 (Mailbox Deposit Number)

Proxy and Registration: Mailbox Manage URL= [email protected]:5090 (Mailbox Manage Number)

Proxy and Registration: Mailbox Subscribe URL= [email protected]:5090 (SPA9000 Subscriber ID)

Click the Submit All Changes button on the SPA9000 configuration utility. The SPA9000

device will reboot. The SPA400 and the SPA9000 are now configured to use the

integrated voicemail application server.

SPA400 Internet Telephony Gateway with 4 FXO Ports

Administration and Configuration Guide v1.0

SPA400 Internet Telephony Gateway with 4 FXO Ports – Administration and Configuration Guide v1.0

Configuring SPA400 Voicemail Accounts

The SPA400 supports up to 32 voicemail accounts providing LVS Users the ability to

receive and playback voicemail messages. Creating a voicemail account for an LVS

User requires entering a Mailbox ID in the configuration of their SPA IP Phone and then

associating it to a SPA400 Voicemail User ID.

A Voicemail User ID is defined as a valid SPA IP Phone extension that has been

configured in the SPA9000. Voicemail User IDs and passwords may be added or

changed from the SPA400 configuration utility.

From the SPA400 configuration utility, click the Setup tab and select the Voicemail Users

menu item. If the installation and configuration of the SPA400 was initially performed

using the SPA9000 Setup Wizard, each extensions configured for voicemail will be

populated in the SPA400 Voicemail Users page. By default, a user’s voicemail account

will be active with the password to access the voicemail account being identical to their

extension (i.e., ext.=100 password=100).

Figure 5: SPA400 Configuration Utility,

Setup / Voicemail Users Page

Figure 6: SPA IP Phone Configuration Utility,

Ext 1 Page

Click Save Settings at the bottom of the page and then the Restart button on the

SPA400 configuration utility. The SPA400 device will reboot. Continue to

Configuring a SPA IP Phone for Voicemail Service.

(SPA9000 IP Address)

SPA400 Internet Telephony Gateway with 4 FXO Ports

Administration and Configuration Guide v1.0

SPA400 Internet Telephony Gateway with 4 FXO Ports – Administration and Configuration Guide v1.0

Configuring a SPA IP Phone for Voicemail Service

Each valid SPA IP Phone extension configured in the SPA9000 may be configured

for voicemail service. The SPA IP Phone configuration page (Figure 6) can be

accessed by either clicking on the PBX Status link in the upper right location of the

SPA9000 configuration utility or by entering the SPA IP Phone IP address into the

browser.

From the SPA IP Phone configuration utility, click the Ext 1 tab. The voicemail setting

is entered in the Mailbox ID field in the following format:

<line#><User ID>

Where <line#> refers to the SPA9000 Line (1–4) of the SPA400 configuration and

<User ID> must match the setting entered in the SPA400 Voicemail Users menu.

From the example in Figure 5 and Figure 6, the setting is as follows:

Call Feature Settings: Mailbox ID = 1100

The IP address reflected in the Voice Mail Server field on the SPA IP Phone Ext 1

page (Figure 6) is correctly configured as the IP address of the SPA9000. The

SPA9000 acts as a proxy to the SPA400 voicemail server.

Click the Submit All Changes button on the SPA IP Phone configuration utility. The

SPA IP Phone will reboot. The SP IP Phone has now been configured to access the

voicemail service.

LVS Voicemail Users may refer to the SPA IP Phone Voicemail Quick Reference

Card for details on using the voicemail service.

Autres manuels pour SPA400

Table des matières

Autres manuels Linksys Porte

Linksys

Linksys AG241 Manuel d'utilisation

Linksys

Linksys SPA3102 Instructions d'utilisation d'origine

Linksys

Linksys WAG354G (EU) Manuel utilisateur

Linksys

Linksys BEFCMUH4 Manuel utilisateur

Linksys

Linksys SPA3102 Manuel utilisateur

Linksys

Linksys CG2P2WB Manuel d'utilisation

Linksys

Linksys AG041 Manuel utilisateur

Linksys

Linksys WAG325N Manuel utilisateur

Linksys

Linksys Mediatrix 440 series Manuel utilisateur

Linksys

Linksys Wireless-N ADSL2+ Gateway WAG160N Manuel utilisateur

Linksys

Linksys WCG200 - Wireless-G Cable Gateway Wireless... Manuel utilisateur

Linksys

Linksys SPA400 Manuel d'utilisation

Linksys

Linksys WAG54G - Wireless-G ADSL Gateway Wireless... Manuel utilisateur

Linksys

Linksys WPG11 Instructions d'utilisation d'origine

Linksys

Linksys WAG200G Manuel utilisateur

Linksys

Linksys WAG54G - Wireless-G ADSL Gateway Wireless... Instructions d'utilisation d'origine

Linksys

Linksys SPA8000 Manuel d'utilisation

Linksys

Linksys BEFDSR41W - ADSL Modem + Router Manuel utilisateur

Linksys

Linksys WCG200 - Wireless-G Cable Gateway Wireless... Instructions d'utilisation d'origine

Linksys

Linksys AG300 Manuel utilisateur

Linksys

Linksys SPA3102 Manuel utilisateur

Linksys

Linksys BEFCMUH4 Manuel utilisateur

Linksys

Linksys SPA3102 Manuel d'utilisation

Linksys

Linksys SPA8000 Instructions d'utilisation d'origine

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur
