Linksys VoIP Manuel utilisateur

Discovering your Linksys box

Installation Guide

OVH.CO.UK

OVH LTD 3 Southwark Street LONDON SE1 1 RQ - Company Reg No. 5519821

Find out more: http://www.ovh.co.uk/telephony Contact us: Local callrate

020 7357 6616

OVH.CO.UK

OVH LTD 3 Southwark Street LONDON SE1 1 RQ - Company Reg No. 5519821 3

Find out more: http://www.ovh.co.uk/telephony Contact us: Local callrate

020 7357 6616

OVH.CO.UK

Summary

Contents

Check the contents of your Linksys package . . p 3

Installing

A.Assembly..........................p 4

B.Connectivity .......................p 4

C.Connecting ........................p 5

Detals of Linksys

Familiarise yourself with the box . . . . . . . . . . p 6

Networking

From traditional telephony to VoIP. . . . . . . . . p 7

Support

Customerservices......................p 8

Contents

Check the contents of your Linksys package

(1) VoIP box

(2) RJ-45 Ethernet cable

(3) Documentation CD

(4) Quick Installation Guide

(5) RJ-11 Telephone Cable

(6) 220V AC Adapter

(4)

(6)

(3)

(2)

(1)

(5)

OVH LTD 3 Southwark Street LONDON SE1 1 RQ - Company Reg No. 5519821

Find out more: http://www.ovh.co.uk/telephony Contact us: Local callrate

020 7357 6616

OVH.CO.UK

OVH LTD 3 Southwark Street LONDON SE1 1 RQ - Company Reg No. 5519821 5

Find out more: http://www.ovh.co.uk/telephony Contact us: Local callrate

020 7357 6616

OVH.CO.UK

Installing

A. Assembly

1. Connect the power cable (6) to the power port (4) and

connect it to an electrical socket.

3. Plug the telephone cable (5) to the RJ-11 “PHONE 1”

port (1) and connect it to your phone.

B. Connectivity

C. Connecting

(1) RJ-11 “PHONE 1”:to connect to your phone.

(2) RJ-11 “PHONE 2”:(optional) to connect to a second phone.

(3) RJ-45 ETHERNET PORT:for connecting your box to your

router.

(4) Power port:to connect the AC adapter (supplied).

Installing

(1) (2) (3) (4)

Assemble the power adapter (6).

2. Connect the Ethernet cable (2) to the RJ-45 Ethernet

port (3) and connect it to your ADSL box or router.

OVH LTD 3 Southwark Street LONDON SE1 1 RQ - Company Reg No. 5519821

Find out more: http://www.ovh.co.uk/telephony Contact us: Local callrate

020 7357 6616

OVH.CO.UK

OVH LTD 3 Southwark Street LONDON SE1 1 RQ - Company Reg No. 5519821 7

Find out more: http://www.ovh.co.uk/telephony Contact us: Local callrate

020 7357 6616

OVH.CO.UK

Detals of Linksys

Familiarise yourself with the box

(1) Indicates if a rst phone is connected.

(2) Indicates if a second phone is connected.

(3) Indicates whether the box is connected to the Internet.

(4) Indicates whether the box is powered by the AC adapter.

Networking

- Requirements :

an Internet connection.

 a DHCP server enabled on your network (by default

on the ADSL Box*).

* ADSL Box: modem / router that uses ADSL technology for connec-

ting to the Internet.

- A connection to the network:

 Connect the RJ-45 Ethernet cable to a free Ethernet

port on your router or ADSL box using the supplied

cable (2).

NB: To enjoy the advanced features, refer to the possible

congurations in the Customer Space (the OVH “Manager”).

For example, the IVR (Interactive Voice Response), number

portability, call in one click (Click2Call) etc.

For a complete list, refer to the following address:

http://www.ovh.co.uk/products/pap2t_telephone.xml

From traditional telephony to VoIP

The “Plug & Phone” solution means:

(1) (2) (3) (4)

The lights

OVH LTD 3 Southwark Street LONDON SE1 1 RQ - Company Reg No. 5519821

Find out more: http://www.ovh.co.uk/telephony Contact us: Local callrate

020 7357 6616

OVH.CO.UK Customer services

For further information, contact our hotline on:

Local call rate

020 7357 6616

Read our FAQ at the following address:

http://www.ovh.co.uk/telephony/faq
