Duo/Trio Oce Bike

Owner’s Manual

Welcome

Congratulations on choosing to enhance your productivity and wellness with

LifeSpan. You’ve made a healthy decision, as the need for increased amounts

of daily activity has never been higher. Per the President’s Council on Fitness,

fewer than 5 percent of adults achieve the suggested 30 minutes of daily

exercise, while oce-working professionals are inactive for an average of 10

hours per day. Your new Oce Bike provides health-inspiring exercise during

studying, screen time, or professional work, perfect for improving your mental

and physical wellbeing.

Ideal for any atmosphere, each LifeSpan Oce Bike has been designed to

feature sophisticated aesthetics, modest footprints, and smooth, distraction-

free pedaling. To ensure zero additional costs and easy placement anywhere,

your bike operates without electricity or batteries. Just sit and pedal!

Before you assemble or operate your product, please read this manual

thoroughly. Important information, including safety precautions, assembly

instructions, and proper operation information are included. After assembly

is complete, review the Final Inspection section to ensure safe, ergonomic use.

Should you need to contact LifeSpan customer service, please visit the

customer service section of www.LifeSpanFitness.com. All service requests

will be responded to within one business day. Consumers in the United States

and Canada can also dial (877) 654-3837, option 4.

Neither LifeSpan nor its representatives can accept responsibility for any damages or

injury incurred as a result of information presented in this manual except under the terms

of the product warranty.

Table of Contents

Welcome

Getting Started

Warranty

Safety

Children and Pets

Transportation

Storage

Specications

Oce Bike Assembly

Assembly Instructions

Oce Bike Operations

Seat Adjustment

Final Inspection

Troubleshooting

Table Assembly

Assembly Instructions

Getting Started

Warranty

Your LifeSpan Oce Bike comes with the following limited warranty valid in

North America.

LifeSpan warrants the equipment it manufactures is free from defects in

materials and workmanship under normal use and services. The periods above

are based on the date of purchase. During these periods, LifeSpan will replace

defective parts. Should your Oce Bike need service or assistance during the

warranty period, do not return it to the store that it was purchased. Instead,

please visit our website at www.LifeSpanFitness.com, click on“Customer

Service” and complete the form to request assistance or call 877.654.3837

option 4 for a customer service agent. To get assistance you will need the

unique product serial number located on the underside of the frame.

LifeSpan reserves the right to make changes and improvements to our products

without incurring any obligations to similarly alter any product purchased.

In order to insure our product warranty and to ensure the safe and ecient

operation of your LifeSpan product, only authorized parts can be used. The

warranty is void if any parts other than those provided by LifeSpan are used.

Exclusions and Limitations:

• This warranty does not apply to any defects caused by negligence, misuse,

improper assembly, or maintenance, accident, or “act of God.”

• This warranty does not apply to discoloration of paints or plastics.

• LifeSpan shall not be responsible for incidental or consequential damages.

• This warranty is non-transferable form the original owner.

Registration

Should you need to process a warranty claim make sure you retain your

purchase receipt to verify the date of purchase and register your LifeSpan

product online. To complete the registration go to www.LifeSpanFitness.com

and select “Product Registration”.

Warranty

Frame

Parts

Oce Bike

3 Years

1 Year

Table

3 Years

Warranty

Frame (Excludes tabletop)

Safety

When using your Oce Bike, basic precautions should always be followed,

including:

• Never operate this Oce Bike if it has been damaged.

• Do not use outdoors or in areas of high humidity or extreme

temperature changes.

• Use this product for its intended use as described in this

Owner’s Manual.

• Do not use attachments that are not recommended by

LifeSpan.

• Always keep a clear path around this product for access to,

passage around and emergency dismount. At a minimum

there should be a clear path on at least one side and front

or back of the product. Minimum clearances are specied

below.

• Holding the Oce Bike as you sit down will help prevent

the bike from rolling away from you.

Getting Started

20" (.5 m)

20" (.5 m)20" (.5 m)

20" (.5 m)

Safety Clearance

Children and Pets

• Keep children under 10 years of age away from playing on

or using your Oce Bike at all times.

• When in use, keep others away from moving parts

including the pedals and cranks.

• This Oce Bike can be used by children 10 years of age and

older and those with reduced physical ability or sensory

capacity under supervision and instruction concerning

proper use in a safe manner.

• Although the Oce Bike is not intended for serious

exercise, always consult a physician before beginning

an exercise program. If you experience chest pains,

nausea, dizziness or shortness of breath, stop exercising

immediately and consult your physical before continuing.

• Keep the product on a solid and level surface at all times.

• Wear shoes with high traction rubber sole during use.

Transportation

The Oce Bike comes with

integrated transport wheels,

located on the back of the bike’s

frame. To safely transport the

Oce Bike, lift the front and roll

to desired location.

Getting Started

Storage

When storing your Oce Bike, keep it in a clean, dry environment. To

prevent dust and dirt build up, cover the product with a clean, non-

abrasive cover.

Speciciations

Oce Bike

Seat Adjustable; Polyurethane Foam

Pedaling Bi-Directional; Forward and Backward

Max User Weight 400 lb (181.4 kg)

Net Weight 45.2 lb (20.5 kg)

Power None

Assembled Size 39L x 24W x 39H in / 99L x 61W x 99H cm

Frame Welded Steel Frame Construction

Getting Started

Oce Bike Assembly Instructions

At LifeSpan we strive to make our equipment easy to assemble and start

using. Parts that can be pre-assembled are always assembled and tested on

the product line.

Prior to starting the assembly process, take all the parts out of the box,

remove plastic bags and lay everything out on the oor to become familiar

with the components.

It is recommended that you use two people during assembly and follow these

assembly instructions to reduce any problems that may occur.

5mm Allen

Wrench

Multi-Wrench

13, 14, 15,

19 mm

Socket

Oce Bike Assembly Instructions

Hardware Included

Item# Part Description Item# Part Description

1 Seat Slide Frame 6 Right Pedal

2 Rear Base Foot 7 Seat Back

3 Drive System 8 Seat

4 Seat Slide Frame Base Cover 9A Front Base Foot with Wheels

5 Left Pedal 9B Front Base Foot with Pegs

All Hardware is Pre-Installed

Step # Item # Qty. Part Description

1 10 2 M8x45L Bolt, Lock Washers,

Flat Washers

2 11 2 M8X50L Bolt, Lock Washer,

Flat Washer, Nut

2 12 4 Phillips Head Screw

3 13 2 M8x45L Screw, Lock Washer,

Flat Washer

5 14 6 M8x15L Screw, Washer

6 15 4 M8x15L Screw, Washer

STEP 2

Phillip Head

Screws (x4)

STEP 2

M8 x 50L Bolt

(x2)

STEP 5

M8 x 15L Bolt

(x6)

STEP 6

M8 x 15L Bolt

(x4)

STEP 3

M8 x 45L Screw

(x2)

STEP 1

M8 x 45L Screw

(x2)

Oce Bike Assembly Instructions

Step 1: Attach Base Foot to Seat Slide Frame

A. Position Seat Slide Frame(1) on oor as shown in gure 1.

B. Remove the two pre-installed M8X45L Bolts, Lock Washers and Flat

Washers(10) from Seat Slide Frame(1).

C. Connect the Rear Base Foot(2) to the Seat Slide Frame(1) with the two

M8x15L Bolts, Lock Washers and Flat Washers (10). Fully tighten all

hardware.

Flat Washer

Lock Washer

M8X45L Bolts

5mm Allen

Wrench

PRE-INSTALLED

M8 x 45L Screw

(x2)
