Lectrosonics UM700 Manuel utilisateur

UM700

DIGITAL FREQUENCY-AGILE

UHF BELT-PACKTRANSMITTER

LECTROSONICS, INC.

Rio Rancho, NM

www.lectrosonics.com

OPERATING INSTRUCTIONS

and trouble-shooting guide

TABLE OF CONTENTS

The UM200C transmitter is FCC type accepted under Part 74: 470-608MHz and 614-802MHz

INTRODUCTION.................................................................................................. 3

GENERAL TECHNICAL DESCRIPTION ............................................................ 4

CONTROLS AND FUNCTIONS .......................................................................... 6

BATTERY INSTALLATION ................................................................................... 8

OPERATING INSTRUCTIONS ............................................................................ 8

OPERATING NOTES ........................................................................................... 9

ADJUSTING THE TRANSMITTER FREQUENCY.............................................. 9

MICROPHONE CORD TERMINATION ............................................................. 10

5-PIN INPUT JACK WIRING ............................................................................. 11

A6U UHF ANTENNA.......................................................................................... 13

TROUBLESHOOTING ....................................................................................... 14

SPECIFICATIONS AND FEATURES................................................................. 15

SERVICE AND REPAIR..................................................................................... 16

RETURNING UNITS FOR REPAIR................................................................... 16

WARRANTY .........................................................................................Back cover

Frequency Agile UHF Belt-PackTransmitter

Rio Rancho, NM – USA

INTRODUCTION

The 700 Series wireless system was designed to take advantage of the superior

audio performance provided by DSP audio signal processing and the security

provided by proprietary digital and encrypted digital radio operation.

Several advantages are provided by a digital wireless system and DSP technology:

• A digital radio system provides outstanding signal to noise ratio

• The signal to noise ratio of a digital radio system does not vary with the RF signal

strength arriving at the receiver.

• DSP audio signal processing provides a superior limiter

• Eavesdropping is difficult and secure encryption techniques can be implemented

The UM700 is a rugged, machined aluminum package in a belt-pack configuration

with a removable, spring loaded belt clip. A 5-pin input jack provides taps for any

microphone or line level signal. The unit is powered by a single 9 Volt alkaline or

lithium battery, or from external DC using an optional battery eliminator. The an-

tenna is a detachable, locking 1/4 wavelength flexible bronze alloy cable that con-

nects to a 50 Ohm SMA port on the control panel.

Only the UM700 transmitter is covered in this manual.Companion receivers are

covered in separate manuals. The UM700 will operate with any 700 Series Lec-

trosonics receiver in the same frequency block.

UM700

Block Diagram

Freq

Switches

Shunt

Limiter From

DSP

Roll-Off

Preamp and

Supersonic

Filter Audio

Gain

+5V Bias

Supply

Mic

Jack Buffer and

Lo Freq

Filter

Analog to Digital

Converter Digital Signal

Processor

To uP

Modulator

Drive

Amp Power

Amp

1/4 Wave

Antenna

Audio

Level

Oscillator

Filter

Synthesizer

EEProm

Multicolor

Audio Level

LEDs

Multicolor

Battery Status

LED

Switching

Pwr Supply

Delay Control

from uP

Polarity

Protection

Diode Power

Switch 4V Main

Pwr Supply

Isolator

GENERAL TECHNICAL DESCRIPTION

GENERAL

The 700 Series wireless system uses digital modulation for an extremely high signal to noise ratio and freedom from

distortion and compandor artifacts. The input preamplifier uses an ultra low noise op amp for an excellent signal to

noise ratio. A dual-envelope limiter is implemented by the DSP firmware to cleanly limit input signal peaks up to

30dB above full modulation. The transmitter circuits are all regulated to allow full output power from the beginning (9

Volts) to the end (5.5 Volts) of battery life.

The UM700 transmitter is comprised of a number of functional sub-systems as shown in the block diagram below.

DIGITAL MODULATION

Digital modulation is used to eliminate compandor artifacts and provide an extremely high signal to noise ratio. A

proprietary compression algorithm is used to contain the RF energy into a narrower bandwidth than other digital

systems to allow the 700 Series system to utilize frequencies in FCC Part 74 for broadcast and motion picture

production. For applications that require secure operation that prevent eavesdropping, encryption can easily be

implemented.

AUDIO PROCESSING

The input circuitry includes an adjustable low frequency roll-off filter ahead of the limiter and gain stage to customize

the low frequency response for varying conditions. In controlled environments with minimal low frequency ambient

noise, such as a film production set, the frequency response can be extended to 30 Hz. For applications with

excessive low frequency energy, such as in a moving vehicle or rooms with HVAC noise, the low end can be rolled

off as high as 150 Hz to reduce the effects of the noise.

A “dual-envelope”limiter with 30 dB of range is next in the signal chain. This special limiter is software controlled,

being driven by the DSP to minimize “overshoot”and slow attack times that can occur in other types of limiter circuits.

The compressor works with two different time constants to cleanly handle a wide variety of dynamics. A fast peak

limiter prevents overload distortion from sharp, infrequent transients in the audio signal, and an averaging limiter with

longer time constants prevents “pumping”(gain modulation) that can occur with repeated peaks that are closely

spaced. Supersonic filtering is provided to prevent excessive high frequency energy from entering the A/D converter.

Frequency Agile UHF Belt-PackTransmitter

Rio Rancho, NM – USA

A/D CONVERTER AND DSP PROCESSOR

The processed audio signal enters the A/D converter to generate a digital signal for the modulator. A proprietary

algorithm is used for sampling and compression to minimize noise and distortion, and provide a wide, flat frequency

response. The signal then enters the modulator to generate a digitally modulated radio signal.

OUTPUT SECTION

Intermodulation (IM) occurs in the final amplifier stages of conventional transmitters when the transmitters are within

a few feet of each other. This can create serious problems in multi-channel wireless systems when an IM signal falls

on the carriers, IF frequencies, etc.of the systems being operated. To eliminate this problem in the UM700, the

modulated radio signal passes through a circular isolator before entering the antenna. The circular isolator functions

like a “one-way check valve”to allow the RF signal to pass through to the antenna, but not to pass backwards into

the amplifier stage. RF signals from other nearby transmitters cannot reach the output amplifier in the UM700. This

provides excellent stability and eliminates IM in the output stage of the transmitter.

LONG BATTERY LIFE

High efficiency circuits and switching power supplies throughout the design allow over 4.5 hours of operation using a

single 9 Volt alkaline battery. (A 9V lithium battery will provide over 14 hours of operation.) The battery compartment

is a unique mechanical design which automatically adjusts to fit any brand of battery. The battery contacts are spring

loaded to prevent “rattle”as the unit is handled.

FREQUENCY AGILITY

700 Series wireless systems are available on eight different “blocks”of 256 frequencies, from 537.600 to 767.900

MHz. Each of these blocks provides 256 selectable frequencies in 100 kHz steps over a 25.6 MHz bandwidth. This

wide variety of selectable frequencies alleviates carrier interference problems in mobile or traveling applications. Two

16-position rotary switches on the side panel of the unit are used to select the frequency.

The UM700 transmitter section uses a synthesized, frequency selectable main oscillator The frequency is extremely

stable over a wide temperature range and over time.

ANTENNA

At UHF frequencies, where wavelengths and antennas are shorter than at VHF frequencies, a resonant length wire is

preferred over using the microphone cable as the antenna. The antenna on the UM700 consists of a flexible 1/4

wavelength bronze cable, detachable via an SMA connector. The impedance of this connector is 50 Ohms.

FREQUENCY

1.6MHz 100kHz

BLK 20 (BK)

512.0 - 537.5

SN:

XXXX

35 150

75 Hz

LF ROLL OFF

FCCID:DBZUM700

Lectrosonics, Inc.

Made in U.S.A.

LECTROSONICS

UM700

OFF ON

LEVEL

AUDIO

ANTENNA

CONTROLS AND FUNCTIONS

INPUT JACK

The input jack on the UM700 is a Switchcraft TA5M connector that accommodates virtually every lavalier, hand-held

or shotgun microphone available, with positive or negative bias. The input will also cleanly handle line level signals

up to 300 mV before limiting. Use a Switchcraft TA5F connector on the microphone cable or input adapter cord .

See the separate sheet titled “Transmitter 5-Pin Input JackWiring” regarding the correct connections for

various microphones, and other sources.

ON/OFF SWITCH

Turns the battery power on and off. Even when the switch is turned off or on abruptly, the digital muting prevents

“thumps”or transients from occurring.

“ON” LAMP

Glows brightly when the battery is good and the ON/OFF switch is ON. This tri-color LED will indicate the condition

of the battery in the transmitter as follows:

Green - battery good

Yellow - battery getting low

Red - battery very low - change now

Blinking Red - battery critical - failure imminent

FREQUENCY ADJUST (located under the sliding door)

These two rotary switches adjust the center frequency of the carrier. The 1.6M is a coarse adjustment and the 100K

is the fine adjustment. Each transmitter is factory aligned at the center of its operating range. The default position of

the frequency select switches is in the center of the transmitter’s range.

Since the internal circuits are all tightly regulated and the RF output stage is powered by a regulated supply, the

transmitter will continue to operate perfectly to a battery voltage of 5.5Volts.

Please note that a weak battery will sometimes light the POWER LED

immediately after turn on, but will soon discharge to the point where the

LED will indicate a weak battery, just like a flashlight with “dead” batteries.

The combination of an accurate battery condition indicator and regulation of all

internal circuits provides much longer battery life, as well as consistent perfor-

mance over the life of the battery.

Frequency Agile UHF Belt-PackTransmitter

Rio Rancho, NM – USA

AUDIO LEVEL CONTROL

Used to adjust the audio input level for proper modulation.

AUDIO LEVEL LEDS

Indicate the proper setting of the MIC LEVEL control.

The two audio level LED’s are bi-colored (red/.green) and indicate 5 levels -

Off - Off no audio modulation

Green - Off low audio

Green - Green moderate audio

Yellow -Yellow full audio

Red - Red limiting

ANTENNA

The flexible wire antenna supplied with the transmitter is cut to 1/4 wavelength of the center of the frequency block

(the frequency range) of the transmitter. It is removable via an SMA connector. The SMA connector is a 50 Ohm RF

port which can also be connected directly to test equipment. Replacement antennas are available in pre-cut lengths

for specific frequency blocks, or as a kit with instructions to cut the antenna for any frequency block.

ADJUSTABLE LOW FREQUENCY ROLL-OFF

A 18dB per octave low frequency roll-off is provided in the audio section, with the -3dB point adjustable from 35Hz to

150Hz. The actual roll-off frequency will vary somewhat according to the low frequency response of the mic capsule

being used.

The low frequency roll-off control is used to reduce the undesirable effects of very low frequency audio often pro-

duced by air conditioning systems, automobile traffic and other sources. Excessive low frequency content in the

audio input can cause overload of the program audio in recording applications. In sound reinforcement systems,

excessive low frequency content can cause excessive power amplifier drain or even damage to loudspeaker sys-

tems. A common example is wind blowing across a microphone, causing very high levels of low frequency audio

(“wind noise”). By rotating the roll-off control clockwise, the hinge point of the roll-off is increased to reduce the level

of low frequencies. In low noise situations, such as a motion picture production set indoors where environmental

noise is minimal, the control can be rotated counter-clockwise to permit low frequency audio to be captured.

THE BELT CLIP

The belt clip may be removed for special applications by removing one screw.

USE ONLYTHE SCREWTHAT IS SUPPLIED

The circuitry is tightly packed into this unit. A longer screw will permanently damage the transmitter! Use only

Lectrosonics PN:28528 which is a Phillips head, 4-40 x 3/16", FL100 screw.

BATTERY INSTALLATION

The transmitter is powered by a standard alkaline or lithium 9 Volt battery. It is important that you use ONLY an

ALKALINE or LITHIUM battery for longest life. Standard zinc-carbon batteries marked “heavy-duty” or “long-

lasting” are not adequate. Ni-cad rechargeable batteries will only provide 1.5 hours of operation, or less, and will

run down quite abruptly. Unless it is cold, alkaline batteries provide over 4.5 hours of operation. Lithium batteries

can be used to provide up to 14 hours. Care should be taken not to leave a fully discharged lithium battery in the

transmitter, as swelling of the battery can make it difficult to remove from the compartment. The battery status

circuitry is designed for the voltage drop over the life of alkaline batteries.

To open the battery compartment, press outward on the cover door in the direction of the arrow as shown in the

drawing. Only firm, sliding pressure is needed to open and close the battery door. Swing the door open and take

note of the polarity marked inside showing the location of the positive (+) and negative (-) terminals. You can see the

large and small contact holes inside the battery compartment with the door open.

Insert the battery correctly and close the cover by pressing the door closed and across, reversing the opening

procedure illustrated above. If the battery is inserted incorrectly, the door will not close. Do not force the door

closed.

OPERATING INSTRUCTIONS

1) Install a fresh battery according to the instructions above.

2) Insert the microphone plug into the input jack, aligning the pins;be sure that the connector locks in.

3) Attach the antenna to the SMA connector on the top of the transmitter.

4) Mute the sound system.

5) Turn the transmitter power switch to the “ON”position.

6) Position the microphone in the location you will use in actual operation.

7) While speaking or singing at the same voice level that will actually be used, observe the MODULATION LEDs.

Adjust the AUDIO LEVEL control knob until the LEDs begin to light. Start at a low setting where neither LED

lights as you speak.

Swing the

door open

Press outward on the

battery door in this

direction

Frequency Agile UHF Belt-PackTransmitter

Rio Rancho, NM – USA

OPERATING NOTES

The AUDIO LEVEL control knob should not be used to control the volume of your sound system or recorder levels.

This gain adjustment matches the transmitter gain with the user’s voice level and microphone positioning.

If the audio level is too high —both LEDs will be Red frequently or stay Red. This condition may reduce the dynamic

range of the audio signal.

If the audio level is too low —neither LED will light, or only one LED will flicker Green. This condition will reduce the

signal to noise ratio of the system.

The input limiter will handle peaks up to 30dB above full modulation. Occasional limiting is desirable, indicating that

the gain is correctly set and the transmitter is fully modulated for optimum signal to noise ratio.

Different voices will usually require different settings of the AUDIO LEVEL control, so check this adjustment as each

new person uses the system. If several different people will be using the transmitter and there is not time to make

the adjustment for each individual, adjust it for the loudest voice.

ADJUSTING THE TRANSMITTER FREQUENCY

If you are experiencing interference from another signal on your frequency, you may want to change the operating

frequency of your system. The left switch changes the operating frequency by 1.6 MHz per step and the right switch

changes it 100 kHz per step. If you are experiencing interference, change the operating frequency in 100 kHz steps

to find a clear channel. If it is not possible to find a clear channel using the 100 kHz switch, return it to its original

position and change the 1.6 MHz switch by one click then try the 100 kHz switch again.

To gain access to these switches, slide the access door sideways with a fingerrnail.

The UDR700 receiver front panel will indicate the correct switch settings to match the receiver frequency.

MICROPHONE CORD TERMINATION

VIEW FROM SOLDER

SIDE OF PINS

0.3"

0.15" Heatshrink

Tubing

TA5F Connector Assembly

Mic Cord Stripping Instructions

Caution!

Do not allow the shield wire to touch any

metal part of the connector shell.

The shield wire is the antenna on VHF

models and poor operating range will result.

Shield Wire

Crimp

Tabs

Rubber

Insulation

Crimp

Tabs

Rubber

Insulation

Autres manuels pour UM700

Table des matières

Autres manuels Lectrosonics Émetteur

Lectrosonics

Lectrosonics M175 Manuel utilisateur

Lectrosonics

Lectrosonics M185 Manuel utilisateur

Lectrosonics

Lectrosonics HMa Manuel utilisateur

Lectrosonics

Lectrosonics LMb Manuel utilisateur

Lectrosonics

Lectrosonics SMQV Manuel utilisateur

Lectrosonics

Lectrosonics SSM Manuel utilisateur

Lectrosonics

Lectrosonics HMA-941 Series Manuel utilisateur

Lectrosonics

Lectrosonics UT195 Manuel utilisateur

Lectrosonics

Lectrosonics WM/E02 Manuel utilisateur

Lectrosonics

Lectrosonics M2T/E01 Non Dante Manuel utilisateur

Lectrosonics

Lectrosonics UM400a Manuel utilisateur

Lectrosonics

Lectrosonics UM400E Manuel utilisateur

Lectrosonics

Lectrosonics H187 Manuel utilisateur

Lectrosonics

Lectrosonics HM/E01 Manuel utilisateur

Lectrosonics

Lectrosonics UH400 Manuel utilisateur

Lectrosonics

Lectrosonics HMa Manuel utilisateur

Lectrosonics

Lectrosonics SMDB/E01 Series Manuel utilisateur

Lectrosonics

Lectrosonics HHa-941 Manuel utilisateur

Lectrosonics

Lectrosonics duet DCHT Manuel utilisateur

Lectrosonics

Lectrosonics M175 Manuel utilisateur

Lectrosonics

Lectrosonics MM400B Manuel utilisateur

Lectrosonics

Lectrosonics UM 200C Manuel utilisateur

Lectrosonics

Lectrosonics Digital Hybrid Wireless SSM Manuel utilisateur

Lectrosonics

Lectrosonics UM400 Manuel utilisateur

Manuels Émetteur populaires d'autres marques

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuel du propriétaire

Honeywell

Honeywell 5816WMBR Manuel utilisateur

Kamstrup

Kamstrup READy MTU Mode d'emploi

Omega

Omega ZW Series Manuel utilisateur

ABB

ABB Field 264H Mode d’emploi

Alinco

Alinco DJ-V17T Manuel utilisateur

Dejero

Dejero EnGo 3x Manuel utilisateur

Rosemount

Rosemount 4600 Manuel utilisateur

Speaka Professional

Speaka Professional 2342740 Manuel utilisateur

trubomat

trubomat GAB 1000 Manuel utilisateur

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuel utilisateur

Rondish

Rondish UT-11 Manuel utilisateur

MG 10JRE Manuel utilisateur

Burkert

Burkert 8177 Manuel utilisateur

Firetide

Firetide HotPort 3203 Manuel

Tele Radio

Tele Radio T9-02 Manuel utilisateur

Rotronic

Rotronic HygroFlex HF3 Series Manuel utilisateur

Jamara

Jamara FCX6 Pro Tel Manuel utilisateur
