Lantech IES-0208CA Manuel utilisateur

Lantech

IES-0208CA

8 10/100TX + 2 10/100/1000T/DUAL

Speed Combo Industrial Switch

User Manual

v1.00

APR 2014

FCC Warning

This Equipment has been tested and found to comply with the limits for a

Class-A digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy. It may cause harmful interference to radio

communications if the equipment is not installed and used in accordance

with the instructions. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

CE Mark Warning

This is a Class-A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

Content

Introduction.............................................................. 1

Features................................................................. 1

Package Contents.................................................. 2

Hardware Description.............................................. 3

Physical Dimension ................................................ 3

Front Panel............................................................. 3

Top View................................................................ 4

LED Indicators........................................................ 5

Ports....................................................................... 6

Cabling................................................................... 8

Wiring the Power Inputs.........................................12

Wiring the Fault Alarm Contact..............................13

Mounting Installation..............................................14

DIN-Rail Mounting.................................................14

Wall Mount Plate Mounting....................................16

Hardware Installation..............................................17

Installation Steps...................................................17

Network Application................................................18

Troubles shooting...................................................19

Technical Specification ..........................................20

Introduction

The 8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo Industrial Switch is a cost-

effective solution and meets the high reliability requirements demanded by industrial

applications. Using fiber port can extend the connection distance that increases the

network elasticity and performance.

Features

System Interface/Performance

RJ-45 ports support Auto MDI/MDI-X Function

SFP (mini-GBIC) supports 100/1000 Dual Mode

Store-and-Forward Switching Architecture

Back-plane (Switching Fabric): 5.6Gbps

1Mbits Packet Buffer

8K MAC Address Table

Supports Wide Operating Temperature (E Model, -40oC ~ 75oC)

Case/Installation

IP-30 Protection

DIN-Rail and Wall Mount Design

Power Supply

Wide Range Redundant Power Design

Power Polarity Reverse Protect

Overload Current Protection

Provides EFT protection 3,000 VDC for power line

Supports 6,000 VDC Ethernet ESD protection

Package Contents

Please refer to the package content list below to verify them against the checklist.

8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo Industrial Switch

Pluggable Terminal Block

User manual

2 wall mount plates with screws

One DIN-Rail (attached on the switch)

Compare the contents of the industrial switch with the standard checklist above. If any

item is damaged or missing, please contact the local dealer for service.

Hardware Description

In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling

information, and wiring installation.

Physical Dimension

8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo Industrial Switch dimension (W

x D x H) is 72mm x 105mm x 152mm

Front Panel

The front panel of the 8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo Industrial

Switch is shown as below:

Front Panel of the industrial switch

Top View

The top panel of the 8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo Industrial

Switch has one terminal block connector of two DC power inputs.

Top Panel of the industrial switch

LED Indicators

The diagnostic LEDs located on the front panel of the industrial switch provide real-time

information of system and optional status. The following table provides description of the

LED status and their meanings for the switch.

LED

Status

Meaning

PWR1

Green

Power 1 is active

Off

Power 1 is inactive

PWR2

Green

Power 2 is active

Off

Power 2 is inactive

Fault

Red

PWR1/PWR2 is inactive

Off

PWR1 & PWR2 are both active or no power

inputs

P1 ~ P8

Green

(Upper LED)

Connected to network

Blinking

(Upper LED)

Networking is active

Off

(Upper LED)

Not connected to network

Yellow

(Lower LED)

Ethernet port full duplex

Blinking

(Lower LED)

Collision of packets occurs

Off

(Lower LED)

Ethernet port half duplex or not connected to

network

P9 ~ P10

(10/100/1000T)

Green

(Upper LED)

Connected to network

Blinking

(Upper LED)

Networking is active

Off

(Upper LED)

Not connected to network

Green

(Lower LED)

The port is operating at speed of 1000M

Off

(Lower LED)

The port is disconnected or operates at speed

of 10/100M

P9 ~ P10

Link/Active

(100/1000 SFP)

Green

SFP port is connected to network

Blinking

Networking is active

Off

Not connected to network

Ports

RJ-45 ports

The UTP/STP ports will auto-sense for 10Base-T/100Base-TX connections (Fast

Ethernet) or 10Base-T, 100Base-TX, or 1000Base-T connections (Gigabit Ethernet).

Auto MDI/MDIX means that the switch can connect to another switch or workstation

without changing straight through or crossover cabling. See the figures below for straight

through and crossover cable schematic.

RJ-45 Pin Assignments

Pin Number

Assignment

Tx+

Tx-

Rx+

Rx-

Note

“+” and “-” signs represent the polarity of the wires that make up each wire

pair.

All ports on this industrial switch support automatic MDI/MDI-X operation, user can use

straight-through cables (See figure below) for all network connections to PCs or servers,

or to other switches or hubs. In straight-through cable, pins 1, 2, 3, and 6, at one end of

the cable, are connected straight through to pins 1, 2, 3 and 6 at the other end of the

cable. The table below shows the MDI and MDI-X port pin outs.

Pin MDI-X

Signal Name

MDI Signal Name

Receive Data plus (RD+)

Transmit Data plus (TD+)

Receive Data minus (RD-)

Transmit Data minus (TD-)

Transmit Data plus (TD+)

Receive Data plus (RD+)

Transmit Data minus (TD-)

Receive Data minus (RD-)

Straight Through Cable Schematic

Cross Over Cable Schematic

2 Gigabit Copper/SFP (Mini-GBIC) combo port:

The Industrial switch has two auto-detected Giga port—UTP/STP/Fiber combo ports.

The Gigabit Copper (10/100/1000T) ports should use Category 5e or above UTP/STP

Table des matières
