Lantech

2204 Series

(IES-2204F, IPES-2204F, IGS-2204DSFP, IPGS-2204DSFP)

User Manual

V2.02

Mar. 2014

Table of Content

Chapter 1 Introduction ........................................... 1

1.1 Package Contents......................................... 4

Chapter 2 Hardware Description............................ 5

2.1 Bottom View.................................................. 5

2.2LED Indicators.............................................. 6

Chapter 3 Hardware Installation ............................ 8

3.1 Installation Steps........................................... 8

3.2 DIN-Rail Mounting......................................... 9

3.3 Wall Mount Plate Mounting ..........................11

3.4 Wiring the Power Inputs...............................12

3.5 Wiring the Fault Alarm Contact ....................13

3.6 Cabling ........................................................14

Chapter 4 Console Management.......................... 18

4.1 Connecting to the Console Port....................18

4.2 Pin Assignment............................................18

4.3 Login in the Console Interface......................19

4.4 CLI Management .........................................20

Chapter 5 Web-Based Management.................... 21

5.1 About Web-based Management...................21

5.2 Preparing for Web Management ..................21

5.3 System Login...............................................22

5.4 System.........................................................23

5.5 Time - SNTP................................................25

5.6 Account - Admin...........................................28

5.7 IP Addressing –IPV4...................................29

5.8 Syslog..........................................................31

Syslog Configuration...................................................... 31

5.9 SNMP Configuration....................................32

SNMP - Agent................................................................ 32

6.20.1 SNMP Trap Configuration............................. 34

5.10 System Alert - Relay Alarm..........................35

6.8.1 System Alert - SMTP....................................... 35

6.8.2 System Alert - Event ....................................... 37

5.11 DHCP Server...............................................39

6.6.1 DHCP Server - Server configuration............... 39

6.6.2 Client Table ..................................................... 40

6.6.3 IP Bindings ...................................................... 40

5.12 Port - Configuration......................................42

5.13 Port Status...................................................43

5.14 Port Statistics...............................................44

5.15 Port –Port Alert ...........................................46

5.16 Rate Control –Rate Limit..............................47

5.17 Aggregation - Configuration .........................49

6.17.1 Configuration................................................. 50

6.17.2 Aggregator –Status ...................................... 52

5.18 Spanning Tree.............................................53

6.18.1 RSTP Setting................................................. 53

6.18.2 RSTP Information............................................... 55

5.19 Pro-Ring II S................................................56

5.20 Multicast Support.........................................58

5.21 LLDP ...........................................................61

6.22.1 LLDP Neighbors .........................................62

6.23 Filtering Database........................................63

6.24 VLAN...........................................................65

6.24.1. VLAN Configuration...................................... 65

6.24.2 Switch Status................................................. 68

6.25 QoS.............................................................69

6.25.1 Global Settings.............................................. 69

6.25.2 Port Priority................................................. 70

6.25.3 COS Mapping to Queue................................ 71

6.25.4 DSCP mapping to queue .............................. 72

6.26. Power over Ethernet..................................74

6.27. Port Mirroring ............................................79

6.28. Security.....................................................80

6.26.1 IP Source Guard - Configuration................... 80

6.26.2 IP Source Guard –Static Table .................... 81

6.26.3 802.1X/Radius............................................... 82

6.26.4 MAC Filtering...................................................... 85

6.26.5 Port Security.................................................. 86

You can block the un-authorized MAC by oer port in

this function...............................................................86

6.29. Maintenance..............................................87

6.27.1 Save Configuration .....................................87

Troubles shooting.................................................. 92

Appendix A—RJ-45 Pin Assignment..................... 93

RJ-45 Pin Assignments .........................................93

RJ-45 Pin Assignment of PoE................................96

Appendix B—Command Sets................................ 98

Switch Setting Commands Set...................................... 98

Admin Password Commands Set.................................. 99

IP Setting Commands Set ............................................. 99

SNTP Commands Set ................................................. 100

LLDP Commands Set.................................................. 101

Backup & Restore Commands Set.............................. 102

Upgrade Firmware Commands Set............................. 102

DHCP Server Commands Set..................................... 102

Port Control Commands Set........................................ 104

Port Status Commands Set......................................... 106

Rate Limit Commands Set........................................... 106

Trunk Commands Set.................................................. 107

PRO-RING IIS Commands Set ................................... 109

RSTP Commands Set ................................................. 109

VLAN Commands Set ................................................. 111

SNMP Commands Set ................................................ 114

Traffic Prioritization Commands Set............................ 115

IGMP Commands Set.................................................. 116

Multicast Static Filtering Table Commands Set .......... 117

IP Security Commands Set ......................................... 118

Port Security Commands Set...................................... 119

MAC Blacklist Commands Set..................................... 119

802.1x Commands Set................................................ 120

Fault Alarm Commands Set ........................................ 122

System Warning Commands Set ................................ 122

Mac Address Table Commands Set............................ 125

Port Statistics Commands Set..................................... 126

Port Monitoring Commands Set .................................. 126

System Event Log Commands Set ............................. 127

Ping Commands Set.................................................... 127

SFP Monitor Commands Set....................................... 127

Loading Average Commands Set ............................... 127

Save Configuration Commands Set............................ 130

Factory Default Commands Set .................................. 130

System Reboot Commands Set.................................. 130

Logout Commands Set................................................ 130

FCC Warning

This Equipment has been tested and found to comply with the limits for a

Class-A digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy. It may cause harmful interference to radio

communications if the equipment is not installed and used in accordance

with the instructions. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

CE Mark Warning

This is a Class-A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

Chapter 1 Introduction

Management

SNMP v1 v2c, v3/ Web/Telnet/CLI

SNMP MIB

RFC 1215 Trap, RFC1213 MIBII, RFC 1157 SNMP MIB, RFC 1493

Bridge MIB, RFC 2674 VLAN MIB, RFC 1643 , RFC 1757, RSTP MIB,

Private MIB, LLDP MIB

VLAN

Port Based VLAN

IEEE 802.1Q Tag VLAN (256 entries)/ VLAN ID (Up to 4K,

VLAN ID can be assigned from 1 to 4094.)

GVRP (256 Groups)

Port Trunk with

LACP

LACP Port Trunk: 4 Trunk groups/Maximum 4 trunk

members

LLDP

Supports LLDP allowing switch to advertise its identification

and capability on the LAN

Spanning tree

IEEE802.1d spanning tree

IEEE802.1w rapid spanning tree.

Pro-Ring2s

Supports Pro-Ring2s. Provides redundant backup feature

and the recovery time below 20ms

Quality of Service

The quality of service determined by port, Tag and IPv4

Type of service, IPv4 Different Service

Class of Service

Supports IEEE802.1p class of service, per port provides 4

priority queues

Port Security

Supports 100 entries of MAC address for static MAC and

another 100 for MAC filter

Port Mirror

Supports 3 mirroring types: “RX, TX and Both packet”.

IGMP

Supports IGMP snooping v1,v2

256 multicast groups and IGMP query

IP Security

Supports 10 IP addresses that have permission to access

the switch management and to prevent unauthorized

intruder.

Supports IEEE802.1X Authentication/RADIUS

Bandwidth

Control

Support ingress packet filter and egress packet limit

The egress rate control supports all of packet type and the

limit rates are 100K~102400Kbps(10/100),

100K~256000Kbps(1000)

Ingress filter packet type combination rules are

Broadcast/Multicast/Unknown Unicast packet,

Broadcast/Multicast packet, Broadcast packet only and all

of packet. The packet filter rate can be set from

100K~102400Kbps(10/100), 100K~256000Kbps(1000)

Flow Control

Supports Flow Control for Full-duplex and Back Pressure

for Half-duplex

System Log

Supports System log record and remote system log server

SMTP

Supports SMTP Server and 6 e-mail accounts for receiving

event alert

Relay Alarm

Provides one relay output for port breakdown, power fail

Alarm Relay current carry ability: 1A @ DC24V

SNMP Trap

1. Topology Change

2. Power Trap

3. MAC-Violation

DHCP

Provides DHCP Client/ DHCP Server/ Port and IP Binding

DNS

Provides DNS client feature and supports Primary and

Secondary DNS server

SNTP

Supports SNTP to synchronize system clock in Internet

Firmware Update

Supports TFTP firmware update, TFTP backup and restore.

Configuration

Upload/Download

Supports binary format configuration file for system quick

installation

ifAlias

Each port allows importing 128bits of alphabetic string of

word on SNMP and CLI interface

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Lantech Changer

Lantech

Lantech IPES-0208 Series Manuel utilisateur

Lantech

Lantech 5 10/100TX w/ 4 PoE Injector Industrial... Manuel utilisateur

Lantech

Lantech IPES-5408T Manuel utilisateur

Lantech

Lantech IPGS-0204DSFP Manuel utilisateur

Lantech

Lantech IPES-5408T-43 Manuel utilisateur

Lantech

Lantech IES-2208C Manuel utilisateur

Lantech

Lantech IES-2208CA-DNV Manuel utilisateur

Lantech

Lantech IGS-0208GSFP Manuel utilisateur

Lantech

Lantech IES-2208CA Manuel utilisateur

Lantech

Lantech TGS-R6616XFT Manuel utilisateur

Lantech

Lantech IPES-3408 Series Manuel utilisateur

Lantech

Lantech IPGS-0005T-4 Manuel utilisateur

Lantech

Lantech IGS-0008A Manuel utilisateur

Lantech

Lantech LGS-2404 Manuel utilisateur

Lantech

Lantech IPES-0008B Series Manuel utilisateur

Lantech

Lantech LGS-1104 Manuel utilisateur

Lantech

Lantech IPES/IES-0008B Series Manuel utilisateur

Lantech

Lantech IPES-5408T-X-IGN Series Manuel utilisateur

Lantech

Lantech IPES-2208CA Manuel utilisateur

Lantech

Lantech IES-0005B Series Manuel utilisateur

Lantech

Lantech TPGS-L6216XT Manuel utilisateur

Lantech

Lantech IPES-0008A Series Manuel utilisateur

Lantech

Lantech IPGS-5008T Series Manuel utilisateur

Lantech

Lantech IPGS-3 Series Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
