Lantech IPGS-5400-2P Manuel utilisateur

IPGS-5400-2P

IGS-5400-2P

4 Modular Slots Industrial L2+ Managed (PoE) Switch w/ITU

G.8032 Ring

User Manual (Hardware)

May. 2016

Recommendation for Shielded network cables

STP cables have additional shielding material that is used to reduce external interference.

The shield also reduces the emission at any point in the path of the cable. Our

recommendation is to deploy an STP network cable in demanding electrical environments.

Examples of demanding indoor environments are where the network cable is located in

parallel with electrical mains supply cables or where large inductive loads such as motors

or contactors are in close vicinity to the camera or its cable. It is also mandatory to use an

STP cable where the power device (like IP camera) is used outdoors or where the network

cable is routed outdoors.

Important Notice

Lantech Communications Global, Inc. reserves the right to modify the

equipment, its specification or this manual without prior notice, in the interest

of improving performance, reliability, or servicing. At the time of publication

all data is correct for the operation of the equipment at the voltage and/or

temperature referred to. Performance data indicates typical values related to

the particular product.

No part of this documentation or information supplied may be divulged to any

third party without the express written consent of Lantech Communications

Global Inc. Products offered may contain software which is proprietary to

Lantech Communications Global Inc. The offer or supply of these products

and services does not include or infer any transfer of ownership.

Interference Issues

This Equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC rules. These limits are

designed to provide reasonable protection against harmful interference in a

commercial or industrial installation. This equipment generates, uses, and

can radiate radio frequency energy. It may cause harmful interference to

radio communications if the equipment is not installed and used in

accordance with the instructions.

FCC Warning

This Equipment has been tested and found to comply with the limits for a

Class-A digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy. It may cause harmful interference to radio

communications if the equipment is not installed and used in accordance

with the instructions. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

CE Mark Warning

This is a Class-A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

Content

Chapter 1 Introduction.............................................5

Specification............................................................. 5

Chapter 2 Hardware Description ............................8

2.1 Physical Dimension........................................ 8

2.2 IP Protection................................................... 9

2.3 LED Indicators.............................................. 12

Chapter 3 Hardware Installation...........................13

Hardware installation ............................................. 13

3.1 Rack Mounting............................................. 14

3.2 Wiring the Power Inputs............................... 16

3.3 Wiring the Fault Alarm Contact.................... 19

3.4 Cabling......................................................... 20

3.5 USB Dongle ................................................. 23

Chapter 4 Network Application.............................24

ITU G.8032 Scheme.............................................. 24

Ring Coupling ........................................................... 24

Multiple Rings .......................................................... 25

Dual Homing ............................................................ 26

Chain....................................................................... 26

Chapter 5 Console Management ..........................28

5.1 Connecting to the Console Port................... 28

5.2 Login in the Console Interface..................... 29

Chapter 1 Introduction

Lantech IPGS/IGS-5400-2P is a high performance L2 + managed industrial switch which

provides L2 wire speed and advanced security function for network aggregation and

backbone deployment.

Specification

IEEE

Standards

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX Ethernet

IEEE 802.3ab 1000Base-TX Ethernet

IEEE 802.3z 1000Base-X Ethernet

IEEE 802.3x Flow Control Capability

ANSI/IEEE 802.3 Auto-negotiation

IEEE 802.1Q VLAN

IEEE 802.1p Class of Service

IEEE 802.1X Access Control

IEEE 802.1D Spanning Tree

IEEE 802.1w Rapid Spanning Tree

IEEE 802.1s Multiple Spanning Tree

IEEE 802.3ad Link Aggregation Control Protocol (LACP)

IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

IEEE 802.1x User Authentication (Radius)

IEEE 1588 Precision Time Protocol v2

IEEE 802.3at/af PoE (IPGS-5400-2P)

Switch

Architecture

Back-plane (Switching Fabric): 56Gbps

Packet throughput ability (Full-Duplex): 71.43Mpps

@64bytes

Transfer Rate

14,880pps for Ethernet port

148,800pps for Fast Ethernet port

1,488,000pps for Gigabit Ethernet port

CPU

Marvell 800Mhz

RAM

256M Byte

Flash

128M Byte

MAC Address

16K MAC address table

Jumbo frame

9KB on all ports

Connectors

Max. 28 10/100/1000T RJ-45 with auto MDI/MDI-X

function

Max 28 100M Mini-GBIC : SFP sockets

Max 28 1000M Mini-GBIC : SFP sockets

RS-232 console: Female DB-9

USB for automatic backup and edited restoration

configuration

Protocol

CSMA/CD

LED

Per unit: Power 1 (Green), Power 2 (Green), Alarm

(Red) ,R.M (Green)

Link/Activity (Green), Full duplex/collision(Yellow)), MINI

GBIC (Link/Activity )(Green)

Power Supply

IGS-5400-2P: 1 built-in power + 1 optional power

IPGS-5400-2P: 1 built-in power + 1 optional power + 1 PoE

power

VAC/VDC isolated 4000V

85V~265VAC/100~370VDC

VDC isolated 1600V 36~75VDC

12V~57VDC

PoE power input 45~57VDC (55V input is

recommended for 802.3at 30W applications)(IPGS-

5400-2P)

Power

Consumption

Full load: 30W/ Unload: 13W

PoE Budget

(IPGS-5400-

2P)

Max. 720W at rear side with dual 45~57VDC input

(55V input is recommended for 802.3at 30W applications)

Relay Alarm

Provides one relay output for port breakdown, power fail

and alarm.

Alarm Relay current carry ability: 1A @ DC24V

DI/DO

2 Digital Input (DI) :

Level 0: -30~2V / Level 1: 10~30V

Max. input current:8mA

2 Digital Output(DO): Open collector to 40 VDC, 200mA

Case

Dimension

19” Metal case,IP-30; 440mm(W)x325mm(D)x44mm(H)

Operating

Humidity

5%~95% (Non-condensing)

Operating

Temperature

-20°C ~60°C

Storage

Temperature

-40°C ~85°C

EMI

FCC Class A, CE EN61000-4-2 (ESD),

CE EN61000-4-3 (RS), CE EN-61000-4-4 (EFT),

CE EN61000-4-5 (Surge), CE EN61000-4-6 (CS),

CE EN61000-4-8, CE EN61000-4-11,

CE EN61000-4-12, CE EN55022 Class A, CE EN55024

MTBF

245,432hrs

Stability

Testing

IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock),

IEC60068-2-6 (Vibration)

Warranty

5 years

Chapter 2 Hardware Description

In this paragraph, it will describe the Industrial switch’s hardware spec, port, cabling

information, and wiring installation.

2.1 Physical Dimension

Metal case. IP-30,

440(W) x 325 (D) x 44 (H) mm

2.2 IP Protection

The IP Code, Ingress Protection Rating, sometimes also interpreted as International

Protection Rating, classifies and rates the degree of protection provided against the

intrusion (including body parts such as hands and fingers), dust, accidental contact, and

water in mechanical casings and with electrical enclosures. It is published by the

International Electrotechnical Commission (IEC)

Solid particle protection

The first digit indicates the level of protection that the enclosure provides against access

to hazardous parts (e.g., electrical conductors, moving parts) and the ingress of solid

foreign objects.

Level

Object size

protected against

Effective against

—

No protection against contact and ingress of objects

>50 mm

Any large surface of the body, such as the back of a

hand, but no protection against deliberate contact

with a body part

>12.5 mm

Fingers or similar objects

>2.5 mm

Tools, thick wires, etc.

>1 mm

Most wires, screws, etc.

Dust protected

Ingress of dust is not entirely prevented, but it must

not enter in sufficient quantity to interfere with the

satisfactory operation of the equipment; complete

protection against contact

Dust tight

No ingress of dust; complete protection against

contact
