Kramer TP-202 Manuel utilisateur

Kramer Electronics, Ltd.

USER MANUAL







Model:

TP-202

UXGA Line Transceiver / DA

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 1

Overview 3

3.1

About the TP-202 UXGA Line Receiver / DA 3

3.2

About the Power Connect Feature 3

3.3

Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP) 4

3.4

Recommendations for Achieving the Best Performance 4

Your TP-202 UXGA Line Transceiver / DA 5

Connecting the TP-202 7

5.1

Wiring the CAT5 LINE IN / LINE OUT RJ-45 Connectors 9

Technical Specifications 10

Figures

Figure 1: TP-202 UXGA Line Transceiver / DA 5

Figure 2: TP-202 (Underside Panel) 6

Figure 3: Connecting the TP-202 8

Figure 4: CAT5 PINOUT 9

Tables

Table 1: TP-202 UXGA Line Transceiver / DA Features 5

Table 2: TP-202 (Underside Panel) Features 6

Table 3: CAT5 PINOUT 9

Table 4: Technical Specifications of the TP-202 10

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

500-plus different models now appear in 8 Groups

, which are clearly defined

by function.

Congratulations on purchasing your Kramer TOOLS TP-202 UXGA Line

Transceiver / DA which is ideal for:

Presentation and multimedia applications

Long range graphics distribution for schools, hospitals, security, and

stores

The package includes the following:

TP-202

Power adapter (12V DC Input)

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

If necessary, set the polarity of the TP-202 using the underside switches

TP-202

Computer Graphics

Source

Display 2

Display 1

Display 2

Display 1

Overview

3 Overview

This section describes:

A summary of the TP-202, see section 3.1

The power connect feature, see section 3.2

Using shielded twisted pair (STP) / unshielded twisted pair (UTP), see

section 3.3

Recommendations for achieving the best performance, see section 3.4

3.1 About the TP-202 UXGA Line Receiver / DA

The Kramer TOOLS TP-202 receives a computer graphics

signal which is

transmitted via CAT5 cabling, and distributes it to two XGA outputs

simultaneously.

The TP-202 UXGA Line Transceiver / DA:

Has a transmission range of more than 150 ft. (more than 50 meters)

Can receive HD signals (high definition resolutions: 480p, 576p, 720p,

1080i and 1080p)

Includes two XGA outputs on HD15F connectors

Includes EQ. and LEVEL controls

Can change the polarity of decoding H and V Sync for UXGA graphics

Is 12VDC fed and can power or be powered by the receiver over the

same CAT5 cable (see section 3.2)

Features a CAT5 output for transmitting the signal to an additional

receiver

3.2 About the Power Connect Feature

The Power Connect feature lets you power a transmitter / receiver system by

connecting just one power adapter— to either the transmitter or the receiver.

The other unit is fed via the cable connecting between the transmitter/receiver.

The Power Connect feature applies as long as the cable can carry power. The

distance does not exceed 50 meters on standard CAT5 cable, for longer

distances, heavy gauge cable should be used

For a CAT5 cable exceeding a distance of 50 meters, separate power supplies

should be connected to the transmitter and to the receiver simultaneously.

1 The terminology XGA is used throughout this manual, where this implies any RGBHV signal on an HD15 connector

having a resolution from VGA up to UXGA

2 CAT5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3.3 Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP)

The decision whether to use shielded twisted pair (STP) cable or unshielded

twisted pair (UTP) cable depends on the nature of the application.

It is recommended that in applications with high interference, shielded twisted

pair (STP) cable is used. However, the shield itself does create a capacitance

that degrades the frequency response of the machines. For shorter distances, of

50m or so, shielded twisted pair (STP) cable is preferred because it provides

protection from interference (degradation is not apparent).

For long range applications, unshielded twisted pair (UTP) cable is preferred.

However, the unshielded twisted pair (UTP) cable should be installed far away from

electric cables, motors and so on, which are prone to create electrical interference.

3.4 Recommendations for Achieving the Best Performance

To achieve the best performance:

Connect only good quality connection cables, thus avoiding

interference, deterioration in signal quality due to poor matching,

and elevated noise- levels (often associated with low quality cables)

Avoid interference from neighboring electrical appliances and position

your TP-202 away from moisture, excessive sunlight and dust

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 For example: model number AD2512C, part number 2535-000251

Your TP-202 UXGA Line Transceiver / DA

4 Your TP-202 UXGA Line Transceiver / DA

Figure 1 and Table 1 define the TP-202:

Figure 1: TP-202 UXGA Line Transceiver / DA

Table 1: TP-202 UXGA Line Transceiver / DA Features

# Feature Function

1 12V DC +12V DC connector for powering the unit

2 LINE IN RJ-45 Connector Connect

to the LINE OUT RJ-45 connector on the transmitter

3 LINE OUT RJ-45 Connector Connect

to the LINE IN connector on an additional TP-202

4 EQ. Trimmer Adjust

the cable compensation equalization level

5 LEVEL Trimmer Adjust

the output signal level

6 XGA OUT 1 HD15F Connector Connect to the first XGA acceptor

7 XGA OUT 2 HD15F Connector Connect to the second XGA acceptor

8 ON LED Illuminates when receiving power

1 For example, the PT-110, as Figure 3 illustrates

2 Using a UTP CAT5 cable with RJ-45 connectors at both ends (the PINOUT is defined in Table 3 and Figure 4)

3 Insert a screwdriver into the small hole and carefully rotate it, to trim the appropriate level

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your TP-202 UXGA Line Transceiver / DA

Figure 2 and Table 2 define the TP-202 underside panel:

Figure 2: TP-202 (Underside Panel)

Table 2: TP-202 (Underside Panel) Features

# Feature Function

1 VS Switch Slide the switch to NORMAL to retain the polarity

Slide the switch to INVERT to invert the VS polarity

2 HS Switch Slide the switch to NORMAL to retain the polarity

Slide the switch to INVERT to invert the HS polarity

1 By default, both switches are set to NORMAL

Connecting the TP-202

5 Connecting the TP-202

You can use the TP-202 UXGA Line Transceiver / DA to configure a UXGA

DA system. This will let you transmit a computer graphics signal to two

displays via long line CAT5 UTP cabling

To connect the TP-202, as the example in Figure 3 illustrates, do the following:

1. Connect a transmitter (for example, the Kramer PT-110 XGA Line

Transmitter

) to the LINE IN RJ-45 connector via CAT5 cabling, see

section 5.1.

2. Set the VS and HS switches on the underside of the unit to NORMAL.

3. Connect the XGA OUT 1 HD15F connector to an XGA acceptor (for

example, Display 1).

4. Connect the XGA OUT 2 HD15F connector to an XGA acceptor (for

example, Display 2).

5. Check the image on the display. If it is not stable, set the VS and HS switches

to INVERT to obtain a stable image.

6. If required, connect the LINE OUT RJ-45 connector on the TP-202 to an

additional

TP-202.

7. If required, adjust

the video output signal level and/or cable compensation

equalization level.

8. If necessary, set the HS and VS switches on the TP-202 underside

9. Connect the 12V DC power adapter to the power socket and connect the

adapter to the mains electricity (not shown in Figure 3).

The signal from the UXGA source is transmitted via CAT5 cable to the

TP-202, decoded and converted at the XGA OUT 1 and XGA OUT 2 HD15F

connectors to the UXGA acceptors simultaneously.

1 By using two TP-202 units, you can transmit the signal to an additional TP-202

2 You can also connect an HD transmitter, such as the Kramer TP-219HD

3 Up to 10 units may be connected with minimal signal deterioration as long as the combined length between the first and the

last units does not exceed 100 meters

4 Use a screwdriver to carefully rotate the trimmer, adjusting the appropriate level

5 By default, both switches are set to normal (see Figure 2 and Table 2)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the TP-202

Display 2

Display 1

Display 2

Display 1

LongCAT5cable

Computer Graphics

Source

Figure 3: Connecting the TP-202
