Model 5SSA

Sausage Stuffer

Designed exclusively for use with all

KitchenAid®Household Stand Mixers.

WORSTVULAPPARAAT

INSTRUCTIES EN RECEPTEN

SAUSAGE STUFFER

INSTRUCTIONS AND RECIPES

ACCESSOIRE POUR FARCIR LES SAUCISSES

MODE D’EMPLOI ET RECETTES

WURSTFÜLLHORN

BEDIENUNGSANLEITUNG UND REZEPTE

SET PER INSACCARE

ISTRUZIONI PER L’USO E RICETTE

EMBUTIDOR DE SALCHICHAS

INSTRUCCIONES Y RECETAS

KORVHORN

INSTRUKTIONER OCH RECEPT

PØLSEHORN

BRUKSANVISNING OG OPPSKRIFTIR

MAKKARAN-TÄYTTÖPUTKILO

KÄYTTÖOHJEET JA RESEPTIT

PØLSEHORN

INSTRUKTIONER OG OPSKRIFTER

FUNIL PARA SALSICHAS

INSTRUÇÕES E RECEITAS

KRANSAKÖKU-OG PYLSUGERÐASTÚTAR

LEIÐBEININGAR OG UPPSKRIFTIR

EΞAPTHMA ΠAPAΣKEYHΣ ΛOYKANIKΩN

OΔHΓΙEΣ KAI ΣYNTAΓEΣ

English

Table of Contents

Stand Mixer Attachment Safety....................................................................................... 1

Important Safeguards ..................................................................................................... 1

To Attach Stand Mixer Attachment ................................................................................. 2

Before Attaching Stand Mixer Attachment............................................................... 2

Food Grinder* Attachment ............................................................................................. 2

To Assemble Food Grinder Attachment.................................................................... 2

To Use Food Grinder Attachment............................................................................. 3

To Clean Food Grinder Attachment.......................................................................... 3

Sausage Stuffer Attachment ........................................................................................... 4

To Assemble Sausage Stuffer Attachment................................................................ 4

To Use Sausage Stuffer Attachment......................................................................... 4

To Form Smaller Links .............................................................................................. 5

To Clean Sausage Stuffer Attachment...................................................................... 5

Mild Breakfast Sausage................................................................................................... 5

KitchenAid®Household Stand Mixer Attachment Warranty ............................................. 6

Service Centers................................................................................................................ 6

Customer Service ............................................................................................................ 6

* Food Grinder Attachment sold separately.

English

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed

including the following:

1. Read all instructions.

2. To protect against risk of electrical shock, do not put mixer in water or other liquid.

3. The appliance is not intended for use by young children or infirm persons

without supervision.

4. Unplug from outlet when not in use, before putting on or taking off parts, and

before cleaning.

5. Avoid contacting moving parts. Keep fingers out of discharge opening.

6. Do not operate the mixer with a damaged cord or plug or after the mixer

malfunctions, or is dropped or damaged in any manner. Return the mixer to the

nearest Authorized Service Center for examination, repair or electrical or mechanical

adjustment.

7. The use of attachments not recommended or sold by KitchenAid may cause fire,

electric shock or injury.

8. Do not use the mixer outdoors.

9. Do not let the cord hang over the edge of table or counter.

10. Never feed food by hand. Always use combination food pusher/wrench.

11. Blades are sharp. Handle carefully.

12. This product is designed for household use only.

SAVE THESE INSTRUCTIONS

Stand Mixer Attachment Safety

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your

appliance. Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt

you and others.

All safety messages will follow the safety alert symbol and either

the word “DANGER” or “WARNING.” These words mean:

You can be killed or seriously

injured if you don’t immediately

follow instructions.

You can be killed or seriously injured

if you don’t follow instructions.

All safety messages will tell you what the potential hazard is, tell you how to

reduce the chance of injury, and tell you what can happen if the instructions are

not followed.

WARNING

DANGER

WARNING

English

Before Attaching

Stand Mixer Attachment

1. Turn Stand Mixer speed control to

“0” (OFF).

2. Unplug mixer or disconnect power.

3. Depending on which type of hub you

have, either flip up hinged cover or

loosen the attachment knob (A) by

turning it counterclockwise and remove

attachment hub cover.

4. Insert the attachment shaft housing (B)

into the attachment hub (C) making

certain that attachment power shaft

fits into square hub socket.

5. It may be necessary to rotate the

attachment back and forth. When the

attachment is in proper position, the

pin on the attachment housing will fit

into the notch on the hub rim.

6. Tighten the attachment knob by turning

it clockwise until the attachment is

completely secured to mixer.

To Attach Stand Mixer Attachment

Food Grinder* Attachment

To Assemble Food Grinder Attachment

1. Insert the grind worm (A) into the grinder body (B).

2. Place the knife (C) over the square shank at the exposed end of the grind worm.

3. Place grinding plate (D) over the knife, matching the tabs of the plate with the

notches of the grinder body.

4. Place ring (E) on grinder body, turning by hand until secured but not tightened.

NOTE: The combination food pusher/wrench (F) is used for removal of ring (E) only.

Do not use it to tighten ring (E).

NOTE: Use Sausage Stuffer (model SSA) with Food Grinder (model FGA).

Fine

Coarse

* Food Grinder Attachment sold separately.

English

To Use Food Grinder Attachment

1. Cut food into small strips or pieces and

feed them into hopper. Meat should be

cut into long narrow strips.

2. Turn mixer to Speed 4 and feed food

into hopper using combination food

pusher/wrench.

NOTE: Liquid may appear in hopper when

processing large amounts of high moisture

foods such as tomatoes or grapes. To

drain liquid, continue to operate mixer.

To avoid damage to mixer, do not process

additional food until liquid has drained

from hopper.

Coarse Plate – Use for

grinding raw or cooked meats,

firm vegetables, dried fruits

and cheese.

Fine Plate – Use for grinding

raw meat, cooked meats for

spreads and breadcrumbs.

Grinding Meat – For better mix and

more tender results, grind beef twice. Best

texture results from grinding very cold or

partially frozen meat. Fatty meats should

be ground only once.

Grinding Bread – To grind bread for

crumbs, be sure that bread is either oven

dried thoroughly to remove all moisture,

or not dried at all. Partially dried bread

may jam the Food Grinder.

NOTE: Very hard, dense foods such as

totally dried homemade bread should

not be ground in the Food Grinder.

Homemade bread should be ground fresh

and then oven or air-dried.

To Loosen Ring – If ring is too tight to

remove by hand, slip the combination

food pusher/wrench over the grooves and

turn counterclockwise.

NOTE: To avoid damage to the food

grinder attachment, do not use

combination food pusher/wrench to

tighten ring to grinder body.

To Clean Food Grinder Attachment

First completely disassemble food grinder

attachment.

The following parts are dishwasher safe:

• Grinder body

• Grinder worm

• Ring

• Combination food pusher/wrench

The following parts should be hand

washed in warm, sudsy water and

dried thoroughly:

• Knife

• Grinding plates

Food Grinder* Attachment

* Food Grinder Attachment sold separately.

English

Sausage Stuffer Attachment

To Assemble Sausage Stuffer Attachment:

1. Insert grind worm (A) into the grinder body (B).

2. Place the retainer bar (C) over the square shank at the exposed end of the grind worm.

3. Insert desired Sausage Stuffer tube (D) or (E) in ring (F) and then screw onto grinder

body, turning by hand until finger tight, but not over tightened.

NOTE: The combination food pusher/wrench (G) is used for removal of ring (F) only.

Do not use it to tighten ring (F).

NOTE: Use Sausage Stuffer (model SSA) with Food Grinder (model FGA).

To Use Sausage Stuffer Attachment

Use the small Sausage Stuffer tube (E) to

make breakfast sausage with casings and

the large Sausage Stuffer tube (D) to prepare

Bratwurst, Italian or Polish sausage with

casings or breakfast sausage without casings.

1. If using natural casings, it’s

recommended to first soak them in

cold water for 30 minutes to remove

excess salt, then rinse several times by

running cold water through the entire

length of casing.

2. Grease stuffer tube with shortening

and slide, 3 to 4 feet (91 to 122 cm) of

casing onto stuffer tube.

3. Tie the end of the casing with string

to seal.

4. Turn mixer to Speed 4 and slowly feed

ground meat mixture into hopper using

the combination food pusher/wrench.

5. Hold the tied end of the casing in

one hand and guide meat mixture as

it fills casing.

NOTE: Do not pack meat mixture too

tightly into casing; allow enough room

to twist sausage into smaller links and for

expansion during cooking. If an air pocket

develops, pierce with a toothpick or skewer.

To complete a recipe using several pounds

of meat, it may be necessary to repack the

Sausage Stuffer with casing several times to

use all of the ground meat mixture.

English

3 pounds (1.5 kg) pork

shoulder cut into

1-inch (2.5-cm) strips

1⁄4cup (60 g) minced

onion

4 teaspoons (20 g) sage

1⁄2teaspoon (3 g) savory

4 teaspoons (20 g) salt

1 teaspoon (5 g) pepper

1⁄3cup (80 g) chopped

parsley

1⁄2teaspoon (3 g) chervil

1⁄3teaspoon (2 g)

marjoram

Dash allspice

2 tablespoons (30 ml)

water

1 egg, beaten

1 tablespoon (15 g)

shortening

Natural or synthetic

casings

Place pork on metal baking sheet and freeze 20 minutes.

Combine onion, sage, savory, salt, pepper, parsley, chervil,

marjoram, and allspice. Sprinkle mixture over pork.

Assemble and attach Food Grinder using coarse grinding

plate. Turn to Speed 4 and grind pork into bowl. Add

water and egg. Attach bowl and flat beater. Turn to Stir

Speed and mix 1 minute.

Remove knife and coarse grinding plate from Food

Grinder. Assemble and attach Sausage Stuffer. Grease

Stuffer with shortening and slide casing on tightly.

Tie off end of casing. Turn to Speed 4 and stuff pork

mixture into casings. Twist sausage into smaller links and

refrigerate or freeze until ready to use.

Yield: 3 pounds (1.5 kg) sausage.

Mild Breakfast Sausage

Sausage Stuffer Attachment

To Form Smaller Links

To form smaller links, lay the entire length

of sausage on a flat surface and twist filled

casing several times at regular intervals. Fresh

sausage may be stored 1 to 2 days in the

refrigerator or up to 1 month in the freezer.

To Clean Sausage Stuffer Attachment

First completely disassemble sausage

stuffer attachment.

The following parts are dishwasher safe:

• Retainer bar

• Sausage Stuffer tubes

• Grinder body

• Grinder worm

• Ring

• Combination food pusher/wrench

English

Length of

Warranty:

Europe & Australia:

Two Year Full Warranty

from date of purchase.

Other:

One Year Full Warranty

from date of purchase.

KitchenAid

Will Pay For:

Replacement parts and

repair labor costs to

correct defects in materials

or workmanship. Service

must be provided by an

Authorized KitchenAid

Service Center.

KitchenAid

Will Not Pay For:

A. Repairs when Sausage

Stuffer is used for

operations other than

normal household food

preparation.

B. Damage resulting from

accident, alterations,

misuse, abuse, or

installation/operation

not in accordance with

local electrical codes.

KITCHENAID DOES NOT ASSUME ANY RESPONSIBILITY FOR

INDIRECT DAMAGES.

KitchenAid®Household

Stand Mixer Attachment Warranty

Service Centers

All service should be handled locally by

an Authorized KitchenAid Service Center.

Contact the dealer from whom the unit was

purchased to obtain the name of the nearest

Authorized KitchenAid Service Center.

In the U.K.:

Call: 0845 6011 287

In Ireland:

M.X. ELECTRIC

Service Department

25 Alymer Crescent

Kilcock, CO.KILDARE

Call: 1 679 2398/87 2581574

Fax: 1 628 4368

In Australia:

Call: 1800 990 990

In New Zealand:

Call: 0800 881 200

Customer Service

In U.K. & Ireland: Tollfree number 00800 38104026

Address: KitchenAid Europa, Inc.

PO BOX 19

B-2018 ANTWERP 11

BELGIUM

www.KitchenAid.com

www.KitchenAid.co.uk

English

® Registered Trademark of KitchenAid, U.S.A.

TM Trademark of KitchenAid, U.S.A.

The shape of the stand mixer is a trademark of KitchenAid, U.S.A.

Specifications subject to change without notice.

9709872A (5181dZw407)

Table des matières

Autres manuels KitchenAid Appareils de cuisine

KitchenAid

KitchenAid KSM5SSB Manuel utilisateur

KitchenAid

KitchenAid 5KSM1APC Manuel utilisateur

KitchenAid

KitchenAid K42049 Manuel utilisateur

KitchenAid

KitchenAid KHB3581 Instructions de montage

KitchenAid

KitchenAid 5KSS1121CA/4 Manuel utilisateur

KitchenAid

KitchenAid Professional 600 RKP26M1XBY Manuel utilisateur

KitchenAid

KitchenAid KSM45 Series Manuel utilisateur

KitchenAid

KitchenAid K5-A Mode d'emploi

KitchenAid

KitchenAid 5KPM5 Manuel utilisateur

KitchenAid

KitchenAid ARTISAN KEA28AMANA Manuel utilisateur

KitchenAid

KitchenAid 5KGM Manuel utilisateur

KitchenAid

KitchenAid EPS-10 Manuel utilisateur

KitchenAid

KitchenAid KHBBV53 Manuel utilisateur

KitchenAid

KitchenAid 5KSM1CB Manuel utilisateur

KitchenAid

KitchenAid KGM Manuel utilisateur

KitchenAid

KitchenAid KSM3300 Series Manuel utilisateur

KitchenAid

KitchenAid KSM1CB Manuel utilisateur

KitchenAid

KitchenAid KSM45-KSM200 Series Manuel utilisateur

KitchenAid

KitchenAid 5KMC4241 Manuel utilisateur

KitchenAid

KitchenAid KSBC1B2CU Manuel utilisateur

KitchenAid

KitchenAid KMC4244 Manuel utilisateur

KitchenAid

KitchenAid 5KSS1121 Manuel utilisateur

KitchenAid

KitchenAid KI795BIONA Manuel utilisateur

KitchenAid

KitchenAid 790-0007A Fiche d'information produit

Manuels Appareils de cuisine populaires d'autres marques

Tayama

Tayama TYG-35AF Manuel utilisateur

AEG

AEG 43172V-MN Manuel utilisateur

REBER

REBER Professional 40 Guide de l'utilisateur

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuel utilisateur

Presto

Presto fountain popper Manuel utilisateur

Westmark

Westmark 1035 2260 Manuel utilisateur

Zanussi

Zanussi ZCG64396XA Manuel utilisateur

HOFFEN

HOFFEN SM-9302M Manuel utilisateur

Philips

Philips HD3133 Manuel utilisateur

Ronco

Ronco Beef Jerky Manuel utilisateur

Hendi

Hendi 470411 Manuel utilisateur

Livoo

Livoo MEN386 Manuel utilisateur

Vogue

Vogue D446 Manuel utilisateur

croydon

croydon WR-10313-700 Manuel utilisateur

ADE

ADE AUTOMATIC-L Manuel utilisateur

Chefman

Chefman RJ43-SQ Series Manuel utilisateur

Vacmaster

Vacmaster VP680 Manuel utilisateur

Jetmaster

Jetmaster 900HG Manuel utilisateur
