KANE457

Quick Reference Guide

ON / OFF

Turns the analyser ON / OFF

BACKLIGHT

Switches backlight & torch light ON /

OFF

PUMP

Turns the pump ON / OFF

Hold button to zero pressure

SEND / ENTER

Send readings to printer

(Press button for 1 second.)

Send readings to memory

(Hold button down for 2+ secs.)

Stock No. 19294-2 July 2014

Battery charger

connection

Flue Gas Inlet

Watertrap Drain

with Red Screw

Plug

Flue probe temperature (T1)

Inlet temperature (T2)

Pressure connection

P2 (differential)

Fit Spigot to Hose before

connecting to Analyser

1. BEFORE USING ANALYSER CHECK THE FOLLOWING:

Particle filter is not dirty or wet.

Water trap and flue probe hose are empty of water

Water trap and red screw plug are fitted correctly to the analyser

Flue probe hose is connected properly to the flue gas inlet

Flue probe temperature plug is connected into T1 temperature connection

Please read the Safety Warnings in the User Manual

2. FRESH AIR PURGE

Position the flue probe in fresh air, then press the “On/Off” button. The analyser auto-

calibrates for approximately 90 seconds. When complete…

Select “Ratio” on the dial. In fresh air the CO reading = 0ppm

Select “O2/Eff” on the dial. In fresh air the O2 reading = 20.9%

Select “Status” on the dial to view the following…

STATUS display

BAT

11 : 46 : 29

15 / 05 / 13

CAL 283

- Battery status.If less than 1 bar recharge or replace, (see section 10)

- Current time. Can be set via the “Menu”, (see section 11)

- Current date. Can be set via the “Menu”, (see section 11)

- Number of days until re- calibration is required

Note: Boiler inlet air temperature can either be…

a) Set automatically by the flue probe during the fresh air purge, or

b) Continuously measured if a thermocouple is plugged into the T2 socket

3. COMBUSTION TESTS

Select “Ratio” on the dial to check that the analyser is set for the correct fuel. To change

fuel select MENU / SETUP / SET FUEL then use scroll and enter, (see section 11).

Position the flue probe as per the boiler manufacturer’s instructions; typically the tip of

the flue probe is inserted to the centre of the flue. The readings will stabilise after 60

seconds assuming the boiler conditions are stable.

The rotary switch can be used to display the following information…

RATIO display

NAT GAS

R 0.0001

COP 12

CO2% 8.8

- Fuel type can be changed via “Menu”, (see section 11)

- CO/CO2 ratio

- Carbon Monoxide, (ppm)

- Carbon Dioxide, (%)

Press SEND to print a full combustion test. (Also sends to PC if Bluetooth fitted).

Hold SEND for 2+ seconds to log a full combustion report.

O2/EFF display

O2% 5.4

TFC 55.1

TIC 17.2

EfC% 98.3

- Oxygen left after combustion. Should be 20.9% in fresh air.

- Flue temperature, (C)

- Inlet temperature. Normally set by flue probe during fresh air purge.

- Condensing boiler efficiency (EfC). Can be changed via “Menu”

Press SEND to print a full combustion test. (Also sends to PC if Bluetooth fitted).

Hold SEND for 2+ seconds to log a full combustion report.

AUX display: a user defined display

O2% 20.9

COP 00

11 : 55 : 02

BAT 59

- The default AUX (auxiliary) display is shown

The parameters on lines 1, 2, 3 and 4 can be set independently

To customise the AUX display select MENU / SCREEN / AUX.

They remain the AUX parameters until changed again by the user.

Press SEND to print a full combustion test. (Also sends to PC if Bluetooth fitted).

Hold SEND for 2+ seconds to log a full combustion report.

4. PRESSURE TEST (Also see section 9)

Select “Prs”. The pump stops. Press the PUMP button to auto-zero the pressure

sensor. Using the black connectors and manometer hose connect to P1 for single

pressure or P1 and P2 for differential pressure.

PRS display

PRESSURE

P -0.04

mbar

12 : 56 : 29

- Defaults to smoothing ‘off’ on start-up. Can be changed via “Menu”.

- Defaults to ‘low’ resolution on start-up. Can be changed via “Menu”.

- Pressure units can be changed via “Menu”.

- Displays time to enable manually timed tests.

Press SEND to print a pressure test. (Also sends to PC if Bluetooth fitted).

Hold SEND for 2+ seconds to log a pressure report.

5. LET-BY and TIGHTNESS TESTING (Also see section 9)

Select “Tightness”. The pump stops. Press the PUMP button to auto-zero the pressure

sensor. Select “yes” or “no” for the let-by test by using  or , then press . Connect

from the test point to P1 using a black connector and manometer hose. Adjust the gas

pressure as you would with a “U” tube manometer. Press to start either the let-by

test or the stabilisation period…

LET BY

P1 10.35

P2 10.35

TIME 59

- Let-by test display.

- Pressure at the start of the let-by test

- Real time pressure reading

- Let-by default time is 1 minute. Can be changed via “Menu”.

When complete adjust the gas pressure if necessary then press to start the

stabilisation period…

STABIL’N

P1 20.00

mbar

TIME 59

- Stabilisation display.

- Real time pressure reading

- Stabilisation default time is 1 minute. Can be changed via “Menu”.

When complete adjust the gas pressure if necessary then press to start the tightness

test…

TIGHTN’S

P1 20.33

P2 20.33

TIME 119

- Tightness test display.

- Pressure at start of tightness test

- Real time pressure reading

- Tightness default time is 2 minute. Can be changed via “Menu”.

When complete the display will show…

LOG 06

P1 20.33

P2 20.26

PRINT 

- Let-by and tightness test are automatically stored as a log number

- Pressure at start of tightness test

- Pressure at end of tightness test

- The test can be printed immediately or later from the memory

Note: The analyser’s memory can store up to 20 tightness tests. Tightness tests are logged

automatically therefore the tightness section of the memory will be full after the 20th

tightness test is complete. Before the 21st tightness test can be performed the

tightness section of the memory must be cleared. To do this select MENU / REPORT /

TIGHTN’S / DEL ALL / YES then press .

6. DIFFERENTIAL TEMPERATURE

Select “Diff Temp” to measure flow, return and differential temperatures

DIFF TEMP display

TEMP

T1C 60.1

T2C 47.0

TC 13.1

- Pump automatically switches off when dial is moved to Diff Temp

- Use the T1 connection for the flow temperature sensor

- Use the T2 connection for the return temperature sensor

- Real time temperature difference

Press SEND to print a differential temperature test. (Also sends to PC if Bluetooth fitted).

Hold SEND for 2+ seconds to log a differential temperature report.

7. AMBIENT TESTS

ROOM AIR TESTING

Select “Room Test” for CO and CO2 investigations. Tests can be 15 or 30 minutes and

can be stopped at any time by pressing the PUMP key. Please refer to user manual.

ROOM AIR display

COp 02

CO2P 600

TEST 14

LOG 01

- Real time CO reading (ppm)

- Real time CO2 reading, (ppm)

- Test 00 = start. To stop the Room CO test press the PUMP button

- The complete Room CO test is automatically stored as a log number

Ambient CO2 & CO ideal for 'walk around' testing.

COp 8

CO2P 900

COx 14

CO2x 985

- Real time CO reading, (ppm)

- Real time CO2 reading, (ppm)

- Maximum CO reading (ppm)

- Maximum CO2 reading (ppm)

Timed LOG

Select logging period from 4 to 24 hours to take 240 sets of readings

COp 9

CO2P 800

COv 11

CO2v 950

- Real time CO reading, (ppm)

- Real time CO2 reading, (ppm)

- Average CO reading (ppm)

- Average CO2 reading (ppm)

ZERO

Follow the instructions on the screen. 60 second ambient zero is followed by a true zero.

ZEROING

CO2p 0

TIME 59

60 second countdown

8. OTHER DISPLAY CODES

-PO- = Pump Off

-OC- = Open Circuit on temperature input

9. FOR BEST PRESSURE SENSOR ACCURACY

1) Switch the analyser on for 5 minutes to let the temperature stabilise.

2) Zero the pressure sensor when the analyser in the exact position that it will be

used.

10. MANO-MODE

A limited mode for pressure and temperature only that avoids the 90 second countdown

With the KANE457 switched off, press and hold down / and then press

and release / . Release / after MANO_MOD is displayed on

top line.

The KANE457 will now operate as a fixed display thermometer/pressure meter with the

pump off and inhibited. The readings can be printed but not stored.

11. TO FULLY CHARGE NiMH RECHARGEABLE BATTERIES

1) The analyser must be switched on.

2) Connect the charger and switched it on; charging indicator illuminates.

3) Switch the analyser off; the display will show “BATTERY CHARGING”.

12. USING THE MENUS

Select “Menu” on the rotary switch and navigate using the function buttons…

 = Scroll up  = Scroll down

= Enter

COMBUSTION MENU

MAIN MENU SUB MENU OPTIONS / COMMENTS

SETUP SET FUEL NAT GAS, L OIL (28/35 sec), PROPANE, BUTANE, LPG, PELLETS

(Wood)

N  C  G EfN = nett efficiency, EfG = gross efficiency, EfC = condensing efficiency

SET TIME Uses Military time. 7am = 07:00, 7pm = 19:00

SET DATE Uses DD-MM-YY format

OUTPUT KMIRP1 or KMIRP2 or BLUETOOTH or XML DATA

PASSKEY 1111

REPORT COMB’N Stored combustion tests, VIEW, DEL ALL or EXIT (max = 99 tests)

SCREEN CONTRAST Factory setting is 04

AUX Enables users to customise the parameters on the AUX display

User can set any parameter on lines 1, 2, 3 and 4

HEADER Sets printout header, 2 lines, 20 characters per line

SERVICE CODE Password protected for authorised service agents. Leave set to 0000.

To EXIT each Sub MENU select EXIT.

To EXIT the MENU move the rotary switch to any position other than “Menu”.

Any changes that have not been “entered” will be ignored.

TEMP + PRESS. MENU

SETUP PASSKEY 1 1 1 1

SET TIME Uses Military time. 7am = 07:00, 7pm = 19:00

SET DATE Uses DD-MM-YY format

EXIT

MAIN MENU

SUB

MENU OPTIONS / COMMENTS

PRESSURE SMOOTH OFF = normal response.

ON = slower (damped) response

RESOLVE LOW = e.g. 0.01mBar resolution.

HIGH = displays to an extra decimal place

PS UNITS mBar, mmH2O, Pa, kPa, PSI, mmHg, hPa, InH2O

TIME

LET BY = Set duration of let-by test in minutes.

Default = 1 minute

STABIL’N = Set duration of stabilisation in minutes.

Default = 1 minute

TIGHTN’S = Set duration of tightness test in minutes.

Default = 2 minute

EXIT

REPORT PRESSURE

Stored pressure tests, VIEW, DEL ALL or EXIT

(max = 20 tests)

TIGHTN’S Stored let-

by and tightness tests, VIEW, DEL ALL or EXIT,

(20 tests)

TEMP

Stored differential temperature tests, VIEW, DEL ALL or EXIT

(20 tests)

SCREEN CONTRAST

Factory setting is 04

AUX

Enables users to customise the parameters on the AUX

display

User can set any parameter on lines 1, 2, 3 and 4

HEADER Sets printout header, 2 lines, 20 characters per line

SERVICE CODE Password protected for authorised service agents.

Leave set to 0000.

AMBIENT MENU

SETUP PASSKEY 1 1 1 1

SET TIME Uses Military time. 7am = 07:00, 7pm = 19:00

SET DATE Uses DD-MM-YY format

EXIT

REPORT ROOM AIR Stored Room AIR tests, VIEW, DEL ALL or EXIT

(max = 20 tests)

AMBIENT Stored Amb CO2 & CO tests, VIEW, DEL ALL or EXIT,

(20 tests)

TIMED Stored Timed Logs, VIEW, DEL ALL or EXIT (20 tests)

SCREEN CONTRAST

Factory setting is 04

AUX Enables users to customise the parameters on the AUX display

User can set any parameter on lines 1, 2, 3 and 4

HEADER Sets printout header, 2 lines, 20 characters per line

SERVICE CODE Password protected for authorised service agents.

Leave set to 0000.

Autres manuels pour 457

Table des matières

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
