Three-Beam Magnetic Torpedo Laser Dot

Model No. 40-6184

Instruction Manual

Congratulations on your choice of this Magnetic Torpedo Laser Dot.

We suggest you read this instruction manual thoroughly before using

the instrument. Save this instruction manual for future use.

This is a Class IIIa laser tool and is manufactured to comply

with CFR 21, parts 1040.10 and 1040.11 as well as international

safety rule IEC 285.

7722H_Manuals 1/17/14 8:02 AM Page 1

Table of Contents

1. Kit Contents

2. Features and Functions

3. Safety Instructions

4. ocation/Content

of Warning abels

5. ocation of Parts/Components

6. Operating Instructions

7. Using the Product

8. Self-Check and Calibration

9. Technical Specifications

10. Application Demonstrations

11. Care and Handling

12. Product Warranty

13. Product Registration

14. Accessories

1. Kit Contents

Description Qty.

Magnetic Torpedo aser Dot 1

“AA” Alkaline Batteries 3

eveling Bracket 1

Instruction Manual with Warranty Card 1

Soft-Sided Pouch 1

2. Features and Functions

• Simultaneously projects three beams for level, plumb and

square applications

• eveling vials are in four directions: 45º, 90º, 180º and cross check

• Magnetic base attaches onto any ferrous surfaces

• Able to work with a 1/4" - 20 tripod

• Removable base plate can make horizontal leveling

more convenient

• V-groove aligns unit with pipes.

7722H_Manuals 1/17/14 8:02 AM Page 2

3. Safety Instructions

Please read and understand all of the following instructions, prior

to using this tool. Failure to do so, may void the warranty.

DANGER!

Class IIIa aser Product

Max. Power Output: ≤5mW

Wavelength: 640-660nm

THIS T L EMITS LASER RADIATI N.

D N T STARE INT BEAM.

AV ID DIRECT EYE EXP SURE.

ATTENTION IMPORTANT

• Read all instructions prior to operating this laser tool. Do not remove any labels from tool.

• Do not stare directly at the laser beam.

• Do not project the laser beam directly into the eyes of others.

• Do not set up laser tool at eye level or operate the tool near a reflective surface as

the laser beam could be projected into your eyes or into the eyes of others.

• Do not place the laser tool in a manner that may cause someone to unintentionally

look into the laser beam. Serious eye injury may result.

• Do not operate the tool in explosive environments, i.e. in the presence of gases or

flammable liquids.

• Keep the laser tool out of the reach of children and other untrained persons.

• Do not attempt to view the laser beam through optical tools such as telescopes as

serious eye injury may result.

• Always turn the laser tool off when not in use or left unattended for a period of time.

• Remove the batteries when storing the tool for an extended time (more than 3 months)

to avoid damage to the tool should the batteries deteriorate.

• Do not attempt to repair or disassemble the laser tool. If unqualified persons attempt

to repair this tool, warranty will be void.

• Use only original Johnson®parts and accessories purchased from your Johnson®

authorized dealer. Use of non-Johnson®parts and accessories will void warranty.

7722H_Manuals 1/17/14 8:02 AM Page 3

4. Location/Content of Warning Labels

7722H_Manuals 1/17/14 8:02 AM Page 4

5. Location of Part/Components

Precision vials

3 beams: plumb,

level & square

aser output windows

Strap raceway (strap

not included)

Magnetic base

On/off switch

Battery

door

1/4" Screw hole aser reference edge

V-groove

Leveling Bracket Adjustable support feet

1/4" bolt

7722H_Manuals 1/17/14 8:02 AM Page 5

V-Groove:

Use the V-groove to align on pipes up to 10" (254 mm) in diameter.

1/4"-20 Tripod Mount:

Use the threaded hole in the base to mount to a camera tripod.

Strap Raceways:

Use straps (not included) to fasten to pipes, studs, etc.

Magnetic Base:

Use the magnetic base to attach to metal studs or pipes.

7722H_Manuals 1/17/14 8:02 AM Page 6

6. perating Instructions

IMP RTANT: It is the responsibility of the user to verify the

calibration of the instrument before each use.

Battery Installation

Turn on/off button in the counter-clock-

wise direction and completely unscrew

the switch. This will provide you access

to the battery compartment. Insert all

three batteries by following the polarity on the outside of the unit.

Return the switch to the original position.

Note: Used (discharged) batteries are hazardous waste and should be

disposed of properly.

7. Using the Product

With the press of the red power-on/off

button, the laser will simultaneously project

3 laser dots through the laser output

windows, and with one more press of the

power-on/off button, the laser dots will turn off. When the laser dot

appears dim, it is time to replace the batteries.

aser output mode is shown as

follows:

7722H_Manuals 1/17/14 8:02 AM Page 7

Horizontal Usage with Base

Connect the laser level with the leveling bracket

Center the bubble by adjusting the support feet

Adjust the support feet to center the bubble. The laser is now level in

the horizontal plane.

Project horizontal laser dot

3/4" from reference surface

to laser dot.

7722H_Manuals 1/17/14 8:02 AM Page 8

Vertical Usage

Center the plumb vial as shown in the illustration

Angle Usage

Center the 45º vial as shown in the illustration.

Magnetic base usage

Attached on any ferrous surface

7722H_Manuals 1/17/14 8:02 AM Page 9

8. Self-Check and Calibration

Horizontal bubble vial check

Put the laser on a smooth and horizontal plane, and then check

according to steps as follows:

Step 2 Rotate unit 180 degrees.

If the laser level is in horizontal, the bubble vial position should be as follows:

Step 1

Step 3

7722H_Manuals 1/17/14 8:02 AM Page 10
