Interlogix TruVision TVW-2401 Feuille d'instructions

TruVision HD-TVI 1080P

Wedge Camera

Configuration Manual

P/N 1073184-EN • REV A • ISS 23JUN16

Interlogix is part of UTC Climate, Controls & Security, a

unit of United

Technologies Corporation.

Trademarks and

patents

he TruVision and Interlogix names and logos are trademarks of

United Technologies.

Other trade names used in this document may be trademarks or

registered trademarks of the manufacturers

or vendors of the

respective products

Contact information

For contact information

, see www.interlogix.com or

www.utcfssecurityproducts.eu

Customer suppor

For contact information, see www.interlogix.com or

www.utcfssecurityproducts.eu

TruVision HD-TVI 1080P Wedge Camera Configuration Manual 1

Content

Introduction 2

HD-TVI 1080P Wedge Cameras 2

Programming 2

Call up the camera OSD menu 2

Menu tree 3

Configuration 3

Format 3

Languages 3

Main Menu 4

AE (Auto Exposure) 4

WB (White Balance) 4

Day/Night 5

Video Setting 6

Reset 6

Save & Exit 6

2 TruVision HD-TVI 1080P Wedge Camera Configuration Manual

Introduction

This is the configuration manual for following camera models:

HD-TVI 1080P Wedge Cameras

TVW-2401 (1080P TVI Wedge Camera, Fixed Lens, IR, PAL)

TVW-4401 (1080P TVI Wedge Camera, Fixed Lens, IR, NTSC)

Programming

Once the camera has been installed, the camera can be configured using the

built-in OSD (On Screen Display) button or the menu of a TVI DVR .

When you configure the camera settings via a DVR, select the PTZ protocol

TruVision Coax and click the menu button to call up the menu.

Call up the camera OSD menu

To set up the camera:

1. Set up the camera hardware as described in the Installation Guide.

2. In Camera Settings of the DVR, access the PTZ menu and set the protocol to

TruVision-Coax for the TruVision HD-TVI camera.

3. In live view of the desired camera, click the PTZ Control icon on the live view

toolbar to access the PTZ control panel.

4. To call up the camera setup menu:

From the camera, press the Menu button.

— or —

From the camera OSD of the DVR, select Menu.

— or —

From the DVR, select Iris+.

The camera setup menu appears (see “Menu tree” on page 3 for the menu

structure).

5. Select the menu options:

From the DVR: To select an OSD item, click the directional buttons up/down.

To adjust the value of a selected item, click the directional buttons left/right.

From the camera: To select an OSD item, push the Menu button up/down.

To adjust the value of a selected item, push the Menu button left/right.

6. Click Iris+ to enter the submenu or to confirm the selected item.

7. When the setup is complete, select Exit and click Iris+ to exit the camera

OSD.

TruVision HD-TVI 1080P Wedge Camera Configuration Manual 3

Note: You cannot exit the camera setup menu using the Menu button on the

camera.

Menu tree

The menu tree for the TruVision 1080P TVI wedge camera is shown below.

Configuration

This section describes how to set up the menu settings.

Format

Select PAL or NTSC.

Languages

Select one of the languages available: English or Chinese.

4 TruVision HD-TVI 1080P Wedge Camera Configuration Manual

Main Menu

AE (Auto Exposure)

AE describes the brightness-related parameters. You can adjust the image

brightness by using BRIGHTNESS, EXPOSURE MODE, and GAIN in different

light conditions.

Select the following options under the AE menu:

BRIGHTNESS Brightness refers to the brightness of the image. You can set the

brightness value from 1 to 10 to darken or brighten the image.

The higher the value is, the brighter the image.

EXPOSURE MODE You can set AE mode as GLOBAL, BLC, or WDR.

GLOBAL

GLOBAL refers to the normal exposure mode that is used to

adjust the situations including unusual lighting distribution,

variations, non-standard processing, or other conditions of under

exposure to get an optimum image.

BLC (Backlight Compensation)

BLC compensates light to the object in the front to make it clear.

However, this causes the over-exposure of the background when

light is strong.

When BLC is selected as the exposure mode, the BLC level can

be adjusted from 0 to 8.

WDR (Wide Dynamic Range)

The WDR function helps the camera provide clear images even

under backlight conditions. WDR balances the brightness level of

the whole image and provides clear images with details.

GAIN It optimizes the clarity of image in poor light scene. The

GAIN level can be set to HIGH, MIDDLE, and LOW. Select OFF

to disable the GAIN function.

Note: Noise will be amplified if the GAIN is on.

WB (White Balance)

WB is the white rendition function of the camera to adjust the color temperature

according to the environment. It can remove the unrealistic color casts in the

image. You can set the WB mode to ATW or MWB.

Select the following options under the WB menu:

TruVision HD-TVI 1080P Wedge Camera Configuration Manual 5

ATW In ATW mode, white balance is being adjusted automatically

according to the color temperature of the scene illumination.

MWB You can set the R GAIN/B GAIN value from 0 to 255 to adjust the

shades of red/blue color of the image.

Day/Night

You can select Color, B/W, and SMART for DAY and NIGHT switches.

Select the following options under the DAY/NIGHT menu:

COLOR The image is always in color in day mode.

B/W The image is always in black and white. The IR LED turns on in low-

light conditions.

SMART Select OPEN/CLOSE to turn on/off INFRARED and set the value of

SMART IR in this menu.

INFRARED

Select it to turn on/off the IR LED to respond to the requirements of

different lighting conditions.

SMART IR

Use the Smart IR function to adjust the light to the desired intensity

and to prevent the image from over exposing. The SMART IR value

can be adjusted from 0 to 3. The higher the value, the more obvious

effects are. The image is not bright and it is disabled when the value

is 0.

Day to Night

Set the sensitivity/threshold of the Day/Night switch. The higher the

value, the higher the lux value required to switch from day to night.

Night to Day

Set the sensitivity/threshold of the Day/Night switch. The higher the

value, the higher lux value required to switch from night to day.

6 TruVision HD-TVI 1080P Wedge Camera Configuration Manual

Video Setting

Move the cursor to VIDEO SETTING and press the confirm button to enter the

submenu. CONTRAST, SHARPNESS, COLOR GAIN, DNR and MIRROR are

adjustable.

Select the following options under the video setting menu:

CONTRAST This feature enhances the difference in color and light between

parts of an image. You can set the CONTRAST value from 1 to 10.

SHARPNESS Sharpness determines the amount of detail an imaging system can

reproduce. You can set the SHARPNESS value from 1 to 10.

COLOR GAIN Adjust this feature to change the saturation of the color. The value

ranges from 1 to 10.

DNR (Digital Noise

Reduction) The DNR function can decrease the noise effect, especially when

capturing moving images in low light conditions and delivering more

accurate and sharp image quality. You can set the DNR value from

1 to 10.

MIRROR DEFAULT, H, V, and HV are selectable for the mirror function.

DEFAULT: The mirror function is disabled.

H: The image flips 180 degrees horizontally.

V: The image flips 180 degrees vertically.

HV: The image flips 180 degrees both horizontally and vertically.

Reset

Reset all settings back to default.

Save & Exit

Press OK to save the settings and exit the menu.
