Interlogix TruVision TVT-2202 Manuel utilisateur

TruVision IR

Turret Camera

TVT

-2202/TVT-4202

Installation

Guide

P/N

1072921 • REV A • ISS 10FEB15

Installation Guide 1

Contents

Product overview 2

Camera description 3

Installation 4

Programming 6

Specifications 7

Setup menu 8

Regulatory information 9

2 Installation Guide

Product overview

This is the TruVision IR Turret Camera Installation

Guide for models TVT-2202/TVT-4202. This guide

describes a standard installation.

Package contents:

Camera with power

and video output

cables

4 M4 screws (4 x

25 mm) and 4 dry

wall anchors (Ø7.5

x 24.5 mm) for wall

or ceiling

installation

Template

Hex wrench

Installation Guide 3

•WEEE and Battery

Disposal

Installation Guide

CD

Camera description

1. Camera

2. Enclosure

3. Mounting base

4. Video cable

5. Power cable

6. Lock screw

7. Zoom and focus

4 Installation Guide

Installation

To install the camera:

1. Using the template, place it level against the

mounting surface and mark the position of the

mounting holes.

2. Following all local codes, drill and prepare the

mounting holes.

3. Loosen the lock screw and release the clip

plate to release the camera from the mounting

base.

Installation Guide 5

4. Fix the mounting base to the mounting surface.

5. Route the cables to the cable hole and connect

the corresponding cables.

Connect a 75 ohm coaxial video cable to the

video cable, and connect a 12 VDC power

supply to the power cable..

6. Adjust the camera according to the figure

below to get an optimum angle.

Clip Plate

0~360°

0~75°

0~360°

6 Installation Guide

7. Secure the camera to the mounting base by

tightening the lock screw.

8. Use a screwdriver to adjust the ZOOM screw

and the FOCUS screw until you get the

optimum image.

Programming

Once the camera hardware has been installed, the

camera can then be configured by using a TVS-

C200 controller (purchase separately).

Clip

Plate

Installation Guide 7

The Setup menu provides access to the camera

configuration options. See page 8 for an overview of

the menu. Please refer to the configuration manual

for further information on setting up the camera.

Program the camera by attaching a standard video

monitor to the system.

Specifications

Power supply

12 VDC

Current Max. 420 mA

Power

consumption

Max. 5W

Weight (net) 1.76 lb. (800 g)

Dimensions

Ø 5.28 × 4.88 × 3.48 in.

(Ø 134.2 × 123.9 × 88.1

mm)

8 Installation Guide

Setup menu
