Intel IB850 Manuel utilisateur

IB850

Socket 478 Pentium 4

Intel 875P Chipset

Full Size CPU Card

USER’S MANUAL

Version 1.0

ii IB850 User’s Manual

Acknowledgments

Award is a registered trademark of Award Software International,

Inc.

PS/2 is a trademark of International Business Machines

Corporation.

Intel and Pentium 4 are registered trademarks of Intel Corporation.

Microsoft Windows is a registered trademark of Microsoft

Corporation.

Winbond is a registered trademark of Winbond Electronics

Corporation.

All other product names or trademarks are properties of their

respective owners.

IB850 User’s Manual iii

Table of Contents

Introduction..............................................................1

Checklist........................................................................1

Product Description ........................................................2

Specifications .................................................................3

Board Dimensions...........................................................5

Installations..............................................................7

Installing the CPU...........................................................8

ATX Power Installation...................................................9

Installing the Memory......................................................9

Setting the Jumpers.......................................................10

Connectors on IB850 ....................................................18

BIOS Setup..............................................................33

Drivers Installation............................................56

Intel 875P Chipset Software Intallation Utility.................57

Realtek AC97 Codec Audio Driver Installation...............60

Intel PRO LAN Drivers Installation...............................61

ATI M7 VGA Driver Installation...................................62

ATI M9/M10 VGA Driver Installation ...........................64

iv IB850 User’s Manual

This page is intentionally left blank.

INTRODUCTION

IB850 User’s Manual 1

Introduction

Checklist

YourIB850 Pentium 4 CPU card package should include the items listed

below:

•The IB850 CPU Card

•This User’s Manual

•1 IDE Ribbon Cable

•1 Floppy Ribbon Connector

•SATA Power Cord

•SATA Cable

•2 Serial Port Ribbon Cable and 1 Parallel Port Attached to a

Mounting Bracket

•1 Y-Cable supporting a PS/2 Keyboard and a PS/2 Mouse

•1 CD containing the following:

•Chipset Drivers

•Flash Memory Utility

•Optional audio cable with bracket (Audio8K)

•Optional USB cable with bracket (USB2K-4)

•OptionalSecondaryCRTVGAcablewithbracket (VGA4K, for use

with IBA110)

•Optional TMDS cable with bracket (ID120P, for use with IBA110)

•Optional MicroAGP cards (IBA110)

INSTALLATIONS

2IB850 User’s Manual

Product Description

TheIB850 Pentium4CPUcard incorporatestheIntel 875P chipset that can

utilize asingle PGA478 processor of up to 3.2GHz or higher and supports

FSB frequency of 400/533/800Mhz (100Mhz, 133Mhz, and 200Mhz HCLK

respectively).

The 875P chipset comes with a Memory Controller Hub (MCH) designed

forusewiththePentium4processorwith512-KB L2 cache on 0.13 micron

process. The MCH component provides the CPU interface, DDR

interface, Hub Interface, and AGP8X graphics interface.

Aside from CRT support, the VGA function feature a Micro AGP slot for

optional daughter cards:

IBA110: with ATI M7CSP32, M9CSP64 / M10CSP64 chipset,

64MB/32MBframebuffer andsupportsdual channelLVDSinterface,

TMDS and CRT2 display function.

Two DDR memory sockets supportup to 2GBDDR 266/333/400

ECC/non-ECC SDRAM.

The board also has an Intel 82551 10/100MB fast Ethernet LAN and

optional Intel 82547EI Gigabit LAN as secondary LAN.

Other advanced features include twoSerial ATA ports, four USB 2.0

ports, IrDA interface and audio function.

INTRODUCTION

IB850 User’s Manual 3

Specifications

Product Name IB850

Form Factor PICMG (full size CPU card)

CPU Type Socket 478 (Intel Pentium 4)

CPU Voltage 0.8375V~1.6V (VRD10)

System Speed 2.0G~3.2GHz

CPU Frequency 400 MHz/533MHz/800MHz

Green /APM APM1.2

CPU Socket Socket 478

Chipset

Intel 875P Chipset

MCH: 82875P 932 pin FC-BGA

ICH5R: 82801ER460 pin MBGA

BIOS Award BIOS, support ACPI Function

Cache 128K/256K/512K Level 2 (CPU integrated)

VGA MicroAGP daughter card w/ATI Mobility M7/ M9 / M10

graphics controller, embedded 32/64MB Frame buffer

(DDR), AGP 4X, support CRT, LVDS, TV-out /2nd CRT.

Primary LAN Intel 82551QMLAN controller (10/100Mb)

Secondary LAN Intel 82547EI (10/100/1000Mb) Gigabit LAN(optional)

Audio ICH5RBuilt-inSound controller+AC97 CodecALC650, 2x6

12 pin header (Line-out, Line-in, MIC.). Supports 5.1

channels.

Memory type

2 x DDR 2.5V PC266/333/400 DDR SDRAM(support ECC

Function) DIMM Module, Max. capacity -2GB

LPC I/O Winbond 83627HF: IrDAx1 Parallel x1, COM1 (RS-232),

COM2 (RS-232/RS422/RS485), FDC 2.88MB (3 Mode

Support), Hardware monitoring

RTC/CMOS ICH5RBuilt-in

Battery Lithium Battery

PS2 KB/Mouse Controller built in Winbond 83627HF

Local bus IDE ICH5Rbuilt in, IDE1, IDE2 (Ultra DMA 33/66/100)

Serial ATA 2 ports

PCI to ISA

Bridge ITE 8888

ISA High drive Supported by SN74ABT16245

USB 4 ports,USB 2.0

IrDA Pin header

Disk On Chip Supports up to 288MB capacity

Watchdog

Timer Yes (256 segments: 0,1,2,...255 sec/min)

Expansion slots MicroAGP VGA socket for IBA110

D-type

connector PS/2 keyboard/mouse, VGA (CRT), RJ-45 x 2

Power

ATX 12V

INSTALLATIONS

4IB850 User’s Manual

Connector

System

Voltages +5V,+12V,-12V,5VSB

Board Size 122 x 338 mm

Other Features Modem Wakeup, LAN Wakeup

INTRODUCTION

IB850 User’s Manual 5

Board Dimensions

0.2" [5.08]

9.762"[247.95]

6.087"[154.61]

6.712"[170.48]

4.6"[116.84]

4.362" [110.79]

3.792" [96.32]

3.196" [81.18]

0.856" [21.74]

4.8"[121.92]

0" [0.00]

9.372"[238.05]

12.372" [314.25]

13.117" [333.17]

13.317" [338.25]

O0.16"[O4.06]

3.133" [79.58]

2.562" [65.07]

3.546" [90.07]

3.054" [77.57]

3.95" [100.33]

4.8" [121.92]

1.948" [49.48]

0"[0.00]

2.124" [53.95]

1.454"[36.93]

0.7"[17.78]

0.865" [21.97]

0.2" [5.08]

0.987" [25.07]

0"[0.00]

O0.16"[O4.06]

INSTALLATIONS

6IB850 User’s Manual
