Intel DBPXA210 Manuel technique

Intel®DBPXA250 and DBPXA210

Development Platform for Intel®

Personal Internet Client

Architecture

Specification Update

July 2002

Notice: The Intel®DBPXA250 andDBPXA210 Development Platform for Intel®Personal Internet

Client Architecture may contain design defects or errors known as errata which may cause the

product to deviate from published specifications. Current characterized errata are documented in

this specification update. Order Number: 278555-002

DBPXA250 and DBPXA210 Development Platforms Specification Update

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR IMPLIED, BY

ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN

INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS

ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES

RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER

INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving, or life sustaining applications.

Intel may make changes to specifications and product descriptions at any time, without notice.

The DBPXA250 and DBPXA210 Development Platform for Intel®Personal Internet Client Architecture may contain design defects or errors known as

errata which may cause the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature may be obtained by calling 1-800-

548-4725 or by visiting Intel’s website at http://www.intel.com.

AlertVIEW, i960, AnyPoint, AppChoice, BoardWatch, BunnyPeople, CablePort, Celeron, Chips, Commerce Cart, CT Connect, CT Media, Dialogic,

DM3, EtherExpress, ETOX, FlashFile, GatherRound, i386, i486, iCat, iCOMP, Insight960, InstantIP, Intel, Intel logo, Intel386, Intel486, Intel740,

IntelDX2, IntelDX4, IntelSX2, Intel ChatPad, Intel Create&Share, Intel Dot.Station, Intel GigaBlade, Intel InBusiness, Intel Inside, Intel Inside logo, Intel

NetBurst, Intel NetStructure, Intel Play, Intel Play logo, Intel Pocket Concert, Intel SingleDriver, Intel SpeedStep, Intel StrataFlash, Intel TeamStation,

Intel WebOutfitter, Intel Xeon, Intel XScale, Itanium, JobAnalyst, LANDesk, LanRover, MCS, MMX, MMX logo, NetPort, NetportExpress, Optimizer

logo, OverDrive, Paragon, PC Dads, PC Parents, Pentium, Pentium II Xeon, Pentium III Xeon, Performance at Your Command, ProShare,

RemoteExpress, Screamline, Shiva, SmartDie, Solutions960, Sound Mark, StorageExpress, The Computer Inside, The Journey Inside, This Way In,

TokenExpress, Trillium, Vivonic, and VTune are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and

other countries.

*Third-party brands and names are the property of their respective owners.

DBPXA250 and DBPXA210 Development Platforms Specification Update 3

Revision History............................................................................................................. 5

Preface.......................................................................................................................... 6

Affected Documents/Related Documents................................................................6

Nomenclature...........................................................................................................7

General Information .................................................................................................8

Summary of Changes.................................................................................................... 9

Codes Used in Summary Table...............................................................................9

Intel®BBPXA2xx Development Baseboard ................................................................ 12

Intel®DCPXA250 Processor Card.............................................................................. 16

Intel®DCPXA210 Processor Card............................................................................... 21

DBPXA250 and DBPXA210 Development Platforms Specification Update 5

Revision History

Date of

Revision Version Description

May 2002 -001 Public Release

July 2002 -002

Removed 1, 2, 3, 4, 5, 6, 7, 8, 9, from Intel® BBPXA2xx Development

Baseboard.

Removed 1, 2, 4, 5, 6, 11, 12 from Intel® DCPXA250 processor card.

Modified 12, 14 on the BBPXA2xx Development Baseboard.

Modified 7, 9, 10, and 13 on the DCPXA250 processor card.

Modified 1on the DCPXA210 processor card.

Added steppings matrix

6DBPXA250 and DBPXA210 Development Platforms Specification Update

Preface

This document is an update to the specifications contained in the Affected Documents/Related

Documents table below. This document is a compilation of device and documentation errata,

specification clarifications and changes. It is intended for hardware system manufacturers and

software developers of applications, operating systems, or tools.

We have endeavored to include all documented errata in the consolidation process; however, we

make no representations or warranties concerning the completeness of the Intel®DBPXA250 and

DBPXA210 Development Platforms for Intel®Personal Internet Client Architecture Specification

Update. This document may also contain information that was not previously published.

Information types defined in Nomenclature are consolidated into the specification update and are

no longer published in other documents.

This document may also contain information that was not previously published.

Affected Documents/Related Documents

Title Order

Intel®DBPXA250 Development Platform for Intel®PCA User’s Guide 278507

Intel® PXA250 and PXA210 Applications Processors Developer’s Manual 278522

Intel® PXA250 and PXA210 Applications Processors Design Guide 278523

Intel® PXA250 and PXA210 Applications Processors Specification Update 278534

DBPXA250 and DBPXA210 Development Platforms Specification Update 7

Preface

Nomenclature

Errata are design defects or errors. These may cause the Intel®DBPXA250 and DBPXA210

Development Platforms for Intel®PCA behavior to deviate from published specifications.

Hardware and software designed to be used with any given stepping must assume that all errata

documented for that stepping are present on all devices unless otherwise noted.

Documentation Changes include typos, errors, or omissions from the current published

specifications. These changes will be incorporated in the next release of the document.

Specification Clarifications describe a specification in greater detail or further highlight a

specification’s impact to a complex design situation. These clarifications will be incorporated in

any new release of the document.

Specification Changes are modifications to the current published specifications. These changes

will be incorporated in the next release of the document.

Note: Errata remain in the specification update throughout the product’s lifecycle, or until a particular

stepping is no longer commercially available. Under these circumstances, errata removed from the

specification update are archived and available upon request. Specification changes, specification

clarifications and documentation changes are removed from the specification update when the

appropriate changes are made to the appropriate product specification or user documentation

(datasheets, manuals, etc.).

8DBPXA250 and DBPXA210 Development Platforms Specification Update

Preface

General Information

Figure 1 and Figure 2 show the markings for the DCPXA250 and DCPXA210 processor cards.

DCPXA210

Figure 1. Intel®DCPXA250 Processor Card Markings

Figure 2. Intel®DCPXA210 Processor Card Markings

Intel

DCPXA250 32 Rev C/D

S/N

Intel Corp.

Austin, TX

Name of the card 32-Bit Processor Revision Letter (C/D) Card Serial Numbe

Intel

DCPXA210 16 Rev A

S/N

Intel Corp.

Austin, TX

Name of the card 16-Bit Processor Revision Letter (A) Card Serial Number

DBPXA250 and DBPXA210 Development Platforms Specification Update 9

Summary of Changes

The following tables indicates the errata, specification changes, specification clarifications, or

documentation changes which apply to the Intel®DBPXA250 and DBPXA210 Development

Platforms for Intel®PCA. This document covers these components of the development platform:

the Intel® BBPXA2xx development baseboard, the Intel®DCPXA250 processor card, and the

Intel®DCPXA210 processor card. Intel may fix some of the errata in a future stepping of the

component and account for the other outstanding issues through documentation or specification

changes as noted. This table uses the following notations:

Codes Used in Summary Table

X: Errata exists in the stepping indicated. Specification Change or

Clarification that applies to this stepping.

(No mark) or (Blank

box): This erratum is fixed in listed stepping or specification change does

not apply to listed stepping.

Plan Fix: This erratum may be fixed in a future stepping of the product.

Fixed: This erratum has been previously fixed.

No Fix: There are no plans to fix this erratum.

Doc: Intel intends to update the appropriate documentation in a future

revision.

Shaded: This item is either new or modified from the previous version of the

document.

10 DBPXA250 and DBPXA210 Development Platforms Specification Update

Summary of Changes

Note: Fixed refers to latest revision of the board and does not refer to earlier revisions. Some ECOs have

specific Intel®PXA250 and PXA210 applications processors stepping requirements.

Summary of BBPXA2xx Development Baseboard ECOs

ECO NO. Rev A Rev B Refer

to: Status ECO Description

1-9 These errata apply to a previously released stepping.

10 XX12 Fixed “UCB1400 Generates Interrupts Incorrectly”

11 XX12 Fixed “USB Cable Attach/Detach Detection Interrupt Is

Constantly Asserted”

12 X X 13 No Fix “100-MHz SDRAM Failure”

13 There is no ECO 13.

14 X13 Fixed “LCD Touch Screen Intermittently Fails”

15 X15 Fixed “New Philips UCB1400 Audio Codec on BBPXA2xx

Development Baseboard Requires Software

Change”

16 XX15 No Fix “Conditional ECO To Use 3.3-V PCMCIA Cards”

17 XX15 No Fix “Conditional ECO To Use The Expansion Port J26”

18 XX15 No Fix “Conditional ECO For USB “Soft Connect” Support”

Summary of DCPXA250 Processor Card ECOs

ECO NO. Rev C Rev D Refer

to: Status ECO Description

1-2 These errata apply to a previously released stepping.

3X16 Fixed “VCC_PLL And VCC_CORE Pin Voltage Must Be

Equal”

4-5 These errata apply to a previously released stepping.

6XFixed “50-MHz SDRAM Requires 0-ohm Resistors”

7X X 17 Fixed “For ARM* Multi-ICE* JTAG Use”

8X18 Fixed “Excessive Oscillator Output Voltage to PEXTAL Pin”

9X X 19 Fixed “Coin Cell Battery Issue”

10 X X 19 Plan Fix “Signal Integrity Problems On SDCLK”

11-12 These errata apply to a previously released stepping.

13 X X 20 Plan Fix “VCC Core Voltage Change”

Summary of DCPXA210 Processor Card ECOs (Sheet 1 of 2)

ECO NO. Rev A Refer to: Status ECO Description

1X21 No Fix “For Multi-ICE JTAG Use”

2X21 No Fix “MMC MMCLK Support”
