HD IR Waterproof Network Dome Camera

User’s Manual

Version 4.2.0

Welcome

Thank you for purchasing our Network camera!

This user’s manual is designed to be a reference tool for your system.

Please read the following safeguard and warnings carefully before you use this series product!

Please keep this user’s manual well for future reference!

Important Safeguards and Warnings

1．Electrical safety

All installation and operation here should conform to your local electrical safety codes.

The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited

power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction)

Please note: Do not connect two power supplying sources to the device at the same time; it may

result in device damage!

We assume no liability or responsibility for all the fires or electrical shock caused by improper handling

or installation.

We are not liable for any problems caused by unauthorized modification or attempted repair.

2．Transportation security

Heavy stress, violent vibration or water splash are not allowed during transportation, storage and

installation.

3．Installation

Do not apply power to the camera before completing installation.

Please install the proper power cut-off device during the installation connection.

Always follow the instruction guide the manufacturer recommended.

4．Qualified engineers needed

All the examination and repair work should be done by the qualified service engineers.

We are not liable for any problems caused by unauthorized modifications or attempted repair.

5．Environment

This series network camera should be installed in a cool, dry place away from direct sunlight,

inflammable, explosive substances and etc.

Please keep it away from the electromagnetic radiation object and environment.

Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.

Otherwise it may result in CCD (CMOS) optical component damage.

Please keep the sound ventilation.

Do not allow the water and other liquid falling into the camera.

Thunder-proof device is recommended to be adopted to better prevent thunder.

The grounding studs of the product are recommended to be grounded to further enhance the reliability

of the camera.

6. Daily Maintenance

Please shut down the device and then unplug the power cable before you begin daily maintenance

work.

iii

Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens

surface.

Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to

dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the

device.

Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.

Dome enclosure is the optical component, do not touch the enclosure when you are installing the

device or clean the enclosure when you are doing maintenance work. Please use professional optical

clean method to clean the enclosure. Improper enclosure clean method (such as use cloth) may result

in poor IR effect of camera with IR function.

7. Accessories

Be sure to use all the accessories recommended by manufacturer.

Before installation, please open the package and check all the components are included.

Contact your local retailer ASAP if something is broken in your package.

Accessory Name

Amount

Network Camera Unit

Quick Start Guide

Installation Accessories Bag

Table of Contents

1General Introduction..............................................................................................................1

1.1 Overview ...................................................................................................................1

1.2 Features....................................................................................................................1

1.3 Specifications ...........................................................................................................2

2Structure .................................................................................................................................5

2.1 Components .............................................................................................................5

2.2 Framework and Dimension .....................................................................................5

3Device Installation .................................................................................................................7

3.1 Installation Steps......................................................................................................7

3.2 Restore Factory Default Setup Introduction ..........................................................9

4Quick Configuration Tool ....................................................................................................10

4.1 Overview.................................................................................................................10

4.2 Operation................................................................................................................10

5Web Operation.....................................................................................................................12

5.1 Network Connection...............................................................................................12

5.2 Login and Main Interface.......................................................................................12

6FAQ.......................................................................................................................................14

Appendix Toxic or Hazardous Materials or Elements.............................................................15

1General Introduction

1.1 Overview

This series network camera integrates the traditional camera and network video technology. It adopts

video data collection, transmission together. It can connect to the network directly without any auxiliary

device.

This series network camera uses standard H.264 video compression technology, which maximally

guarantees the video quality.

It supports the IR night vision function. In the night environments, the device can use the IR light to

highlight the object which is suitable for the surveillance function in the low illumination environments.

The waterproof design conforms to the IP 66 level. It has the sound waterproof function suitable for

use in the outdoor environments.

It can be used alone or used in a network area. When it is used lonely, you can connect it to the

network and then use a network client-end. Due to its multiple functions and various uses, this series

network camera is widely used in many environments such office, bank, road monitor and etc.

1.2 Features

User

Management

Different user rights for each group, one user belongs to one group.

The user right shall not exceed the group right.

Storage

Function

Support central server backup function in accordance with your configuration

and setup in alarm or schedule setting

Support record via Web and the recorded file are storage in the client-end

PC.

Support network storage function such as FTP.

Network

Monitor

Network camera supports one-channel video data transmit to network

terminal and then decode. Delaying time is within 270ms (network bandwidth

support needed)

Max supports 20 connections.

Adopt the following video transmission protocol: HTTP, TCP, UDP,

MULTICAST, RTP/RTCP, RTSP and etc.

Support web access.

Network

Management

Realize network camera configuration and management via Ethernet.

Support device management via web or client-end.

Power

External power adapter DC 12V.

Support PoE.

Warning！

Do not connect these two power supplying sources to the device at the

same time; it may result in device damage!

Assistant

Function

Log function

Support system resource information and running status real-time display.

Day/Night mode auto switch.

Support picture parameter setup such as electronic shutter and gain setup.

Support motion detect.

Backlight compensation: screen auto split to realize backlight compensation

to adjust the bright.

Support video watermark function to avoid vicious video modification.

Built-in IR light. Support IR night vision.

The enclosure conforms to the IP 66 protection. Has the waterproof function.

1.3 Specifications

Please refer to the following sheet for network camera performance specification.

Model

Parameter

ICIP D1300IR

System

Main Processor

TI Davinci high performance DSP

Embedded LINUX

System

Resources

Support real-time network, local record, and remote operation at the

same time.

User Interface

Remote operation interface such as WEB, DSS, PSS

System Status

Bit stream statistics, log, and software version.

Video Parameter

Image Sensor

1/3-inch CMOS

Pixel

1280(H)*960(V)

Day/night

Support IR-CUT switch

Gain Control

Fixed/Auto

White Balance

Manual/Auto

BLC

Off/BLC/WDR (1-100 adjustable)/HLC(anti-flicker is outdoor and is

valid only when exposure mode is auto with range 1-100)

Exposure Mode

Manual/Auto

It ranges from 1/3 to 1/10000

Video

Compression

Standard

H.264/H.264H/H.264B/MJPEG

Note: Some versions do not support H.264H.

Video Frame

Rate

PAL:

Main stream (1280*960@15fps),

extra stream ( 704*576@15fps)

Main stream (1280*720@25fps),

extra stream ( 704*576@25fps)

NTSC:

Main stream (1280*960@15fps),

extra stream ( 704*480@15fps)

Main stream (1280*720@30fps),

extra stream ( 704*480@30fps)

Video Bit Rate

H.264: 56Kbps-6144Kbps

MJPEG: adjustable and bit rate is adjustable.

Support customized setup.

Video Flip

Support mirror.

Support flip function.

Snapshot

Max 1f/s snapshot. File extension name is JPEG.

Privacy Mask

Supports max 4 privacy mask zones

Video Setup

Support parameter setup such as bright, contrast.

Video

Information

Channel title, time title, motion detect, camera masking.

Lens

2.8mm, 3.6mm, 6mm, 8mm. Fixed focus.

Lens Interface

M12. Lens is the default accessories

Video

Motion Detect

396 (18*22) detection zones; sensitivity level ranges from 0 to 100;

area threshold ranges from 0 to 100.

Activation event: video storage, image snapshot, log, email function

and etc.

cor

Record Priority

Manual >Video detect>Schedule

Network

Wire Network

1-ch 10/100 M Ethernet , RJ45 port

Network Protocol

HTTP, TCP/IP, ARP, RTSP, RTP,UDP, RTCP, SMTP, FTP, DHCP,

DNS, DDNS, PPPOE, IPv4/6, SNMP, UPNP, NTP

Remote

Operation

Monitor, system setup, file download, log information, maintenance ,

upgrade and etc

Restore Default

Setup

Built-in Reset button

IR light

IR light 15M.

General Parameter

Power

DC12V power and PoE.

Warning！

Do not connect these two power supplying sources to the device

at the same time; it may result in device damage!

Power

Consumption

4.5W MAX

Working

Temperature

-20℃~+60℃

Working

Humidify

≤95%

Dimensions(mm)

Φ113×86

Weight

280g (Excluding box)

Installation

Ceiling and wall mount

Model

Parameter

IP-73

System

Main Processor

High performance DSP

Embedded LINUX

System

Resources

Support real-time network, local record, and remote operation at the

same time.

User Interface

Remote operation interface such as WEB, DSS, PSS

System Status

Bit stream statistics, log, and software version.

Video Parameter

Image Sensor

1/3-inch CMOS

Pixel

1280(H)*960(V)

Day/night

Support day/night mode switch

Gain Control

Fixed/Auto

White Balance

Manual/Auto

BLC

On/Off

Exposure Mode

Manual/Low noise/Low motion blur/Auto

It ranges from 1/3 to 1/10000

Video

Compression

Standard

H.264/H.264H/MJPEG

Note: Some versions do not support H.264H.

Video Frame

Rate

PAL:

Main stream (1280*960@25fps),

extra stream ( 704*576@25fps)

NTSC:

Main stream (1280*960@30fps),

extra stream ( 704*480@30fps)

Video Bit Rate

H.264: 56Kbps-8192Kbps

MJPEG: adjustable and bit rate is adjustable.

Support customized setup.

Video Flip

Support mirror.

Support flip function.

Snapshot

Max 1f/s snapshot. File extension name is JPEG.

Privacy Mask

Supports max 4 privacy mask zones

Video Setup

Support parameter setup such as bright, contrast.

Video

Information

Channel title, time title, motion detect, camera masking.

Lens

3.6mm, 6mm, 2.8mm. Fixed focus.

Lens Interface

M12. Lens is the default accessories

Video

Motion Detect

396 (18*22) detection zones; sensitivity level ranges from 0 to 100;

area threshold ranges from 0 to 100.

Activation event: video storage, image snapshot, log, email function

and etc.

Record

Record Priority

Manual >Video detect>Schedule

Storage

Management

Network storage

Network

Wire Network

1-ch 10/100 Base-T Ethernet

Network Protocol

HTTP, TCP/IP, ARP,IGMP, ICMP, RTSP, RTP,UDP, RTCP, SMTP,

FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour, SNMP

Remote

Operation

Monitor, system setup, file download, log information, maintenance ,

upgrade and etc

Restore Default

Setup

Built-in Reset button

IR light

IR light 10~ 20M.

General Parameter

Power

DC12V power and PoE.

Warning！

Do not connect these two power supplying sources to the device

at the same time; it may result in device damage!

Power

Consumption

DC 12V

4W MAX

Working

Temperature

-30℃~+60℃

Working

Humidify

≤95%

Dimensions(mm)

Φ113×86

Weight

280g (Excluding box)

Installation

Ceiling and wall mount

2Structure

2.1 Components

You can refer to the following figure for multiple-function combination cable information. See Figure

2-1.

Figure 2-1 Multiple-function combination cable

Please refer to the following sheet for detailed information.

No.

Port

Name

Connector

Note

LAN

Network

port

Ethernet

To connect to standard

Ethernet.

DC12V

DC 12V

power

To connect to DC12V power

supply.

2.2 Framework and Dimension

Component

Component Name

Component 1

Device lens

Component 2

Dome body

Component 3

Dome enclosure

Autres manuels pour F Series

Table des matières

Autres manuels ICRealtime Caméra de sécurité

ICRealtime

ICRealtime ICIP-B2012VIR-B Manuel utilisateur

ICRealtime

ICRealtime PTZ-3660SIR Manuel utilisateur

ICRealtime

ICRealtime ICIPP3020HDIR Manuel utilisateur

ICRealtime

ICRealtime ICIP-P2300Y-IR Manuel utilisateur

ICRealtime

ICRealtime ICIP-B2001-IR Manuel utilisateur

ICRealtime

ICRealtime ICR540VD Manuel utilisateur

ICRealtime

ICRealtime ICIP-D1300 Manuel utilisateur

ICRealtime

ICRealtime ICIP B3000AF Manuel utilisateur

ICRealtime

ICRealtime ICIPD2730 Manuel utilisateur

ICRealtime

ICRealtime EL-2000 I-sniper Manuel utilisateur

ICRealtime

ICRealtime IPEL-M60F-IRW1 Manuel utilisateur

ICRealtime

ICRealtime IPEL-B2012X-IRW1 Manuel utilisateur

ICRealtime

ICRealtime HD Pinhole Manuel utilisateur

ICRealtime

ICRealtime ICIPD1300 Manuel utilisateur

ICRealtime

ICRealtime AVS-4MD4025-IR Manuel utilisateur

ICRealtime

ICRealtime ELIP-3000N Manuel utilisateur

ICRealtime

ICRealtime AVSD2218Z Manuel utilisateur

ICRealtime

ICRealtime EL9036 Manuel utilisateur

ICRealtime

ICRealtime ICHD-2000P20X Instructions d'utilisation d'origine

ICRealtime

ICRealtime IPFX-P4030X-IRW1 Manuel utilisateur

ICRealtime

ICRealtime ICIP-D3077P Manuel utilisateur

ICRealtime

ICRealtime AVS-D2110 Manuel utilisateur

ICRealtime

ICRealtime K6 Manuel utilisateur

ICRealtime

ICRealtime PTZ2300SIR Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
