ICRealtime ICIPS1300WDR Manuel utilisateur

Megapixel Indoor Network Camera User’s Manual

Version 4.1.1

Welcome

Thank you for purchasing our network camera!

This user’s manual is designed to be a reference tool for your system.

Please read the following safeguard and warnings carefully before you use this series product!

Please keep this user’s manual well for future reference!

Important Safeguards and Warnings

1．Electrical safety

All installation and operation here should conform to your local electrical safety codes.

The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited

power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction) Please

note: Do not connect two power supplying sources to the device at the same time; it may result

in device damage! The product must be grounded to reduce the risk of electronic shock.

We assume no liability or responsibility for all the fires or electrical shock caused by improper handling

or installation.

We are not liable for any problems caused by unauthorized modification or attempted repair.

2．Transportation security

Heavy stress, violent vibration or water splash are not allowed during transportation, storage and

installation.

3．Installation

Do not apply power to the camera before completing installation.

Please install the proper power cut-off device during the installation connection.

Always follow the instruction guide the manufacturer recommended.

4．Qualified engineers needed

All the examination and repair work should be done by the qualified service engineers.

We are not liable for any problems caused by unauthorized modifications or attempted repair.

5．Environment

This series network camera should be installed in a cool, dry place away from direct sunlight,

inflammable, explosive substances and etc.

Please keep it away from the electromagnetic radiation object and environment.

Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.

Otherwise it may result in CCD (CMOS) optical component damage.

Please keep the sound ventilation.

Do not allow the water and other liquid falling into the camera.

Thunder-proof device is recommended to be adopted to better prevent thunder.

The grounding studs of the product are recommended to be grounded to further enhance the reliability

of the camera.

6. Daily Maintenance

iii

Please shut down the device and then unplug the power cable before you begin daily maintenance

work.

Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens

surface.

Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to

dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the

device.

Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.

Dome enclosure is the optical component, do not touch the enclosure when you are installing the

device or clean the enclosure when you are doing maintenance work. Please use professional optical

clean method to clean the enclosure. Improper enclosure clean method (such as use cloth) may result

in poor IR effect of camera with IR function.

7. Accessories

Be sure to use all the accessories recommended by manufacturer.

Before installation, please open the package and check all the components are included.

Contact your local retailer ASAP if something is broken in your package.

Accessory Name Amount

Network Camera Unit 1

C/CS Adapter ring 1

Quick Start Guide 1

CD 1

Table of Contents

1General Introduction ..................................................................................................................1

1.1 Overview........................................................................................................................1

1.2 Feature...........................................................................................................................1

1.3 Specifications................................................................................................................2

1.3.1 Performance...........................................................................................................2

2Framework...................................................................................................................................5

2.1 Rear Panel.....................................................................................................................5

2.2 Side Panel .....................................................................................................................9

2.3 Front Panel....................................................................................................................9

2.4 Bidirectional talk..........................................................................................................10

2.4.1 Device-end to PC-end........................................................................................10

2.4.2 PC-end to the Device-end..................................................................................10

2.5 Alarm Setup.................................................................................................................10

2.5.1 Alarm Input and Output Connection.................................................................11

2.5.2 IR Light Connection.............................................................................................12

3Installation..................................................................................................................................13

3.1 Lens Installation..........................................................................................................13

3.1.1 Auto Aperture Lens.............................................................................................13

3.1.2 Manual Lens.........................................................................................................13

3.1.3 Remove Lens.......................................................................................................14

3.2 SD Card .......................................................................................................................14

3.2.1 Installation.............................................................................................................14

3.2.2 Remove.................................................................................................................15

3.3 3G Card........................................................................................................................16

3.3.1 Installation.............................................................................................................16

3.3.2 Remove.................................................................................................................16

3.4 3G/WIFI Antenna........................................................................................................17

3.4.1 Installation.............................................................................................................17

3.4.2 Remove.................................................................................................................18

3.5 I/O Port.........................................................................................................................19

4Quick Configuration Tool.........................................................................................................20

4.1 Overview......................................................................................................................20

4.2 Operation .....................................................................................................................20

5Web Operation..........................................................................................................................22

5.1 Network Connection...................................................................................................22

5.2 Login and Main Interface...........................................................................................22

6FAQ ............................................................................................................................................24

Appendix Toxic or Hazardous Materials or Elements ...............................................................25

1General Introduction

1.1 Overview

This series network camera integrates the traditional camera and network video technology. It

adopts audio video data collection, transmission, storage together. It can connect to the network

directly without any auxiliary device.

This series network camera uses standard H.264 video compression technology and PCM,

G.711a/u audio compression technology, which maximally guarantees the audio and video

quality.

This series network camera has mega pixel resolution and supports 12V DC/24V AC power. It

supports the wireless network application, bidirectional talk, digital water mark and etc.

It can be used alone or used in a network area. When it is used lonely, you can connect it to the

network and then use a network client-end. Due to its high definition, multiple functions and

various applications, this series network camera is widely used in many indoor environments and

other important area surveillance.

1.2 Feature

User

Management

Different user rights for each group, one user belongs to one group.

The user right can not exceed the group right.

Data

Transmission

Support cable network data transmission via Ethernet

Wireless device supports WIFI/3G wireless data transmission.

Storage

Function

Support central server backup function in accordance with your configuration and

setup in alarm or schedule setting

Support record via Web and the recorded file are storage in the client-end PC.

Support local SD card hot swap. Support short-time storage when encounter

disconnection.

Support network storage such as FTP.

Alarm

Function

Real-time respond to external on-off alarm input, and video detect as user pre-

defined activation setup and generate corresponding message in screen and audio

prompt(allow user to pre-record audio file)

Real-time video detect: motion detect, camera masking.

Network

Monitor

Network camera supports one-channel audio/video data transmit to network

terminal and then decode. Delay is within 270ms (network bandwidth support

needed)

Max supports 20 connections.

Adopt the following audio and video transmission protocol: HTTP, TCP, UDP,

MULTICAST, RTP/RTCP, RTSP and etc.

Support web access.

Network

Management

Realize network camera configuration and management via Ethernet.

Support device management via web.

Support various network protocols.

Peripheral

Equipment

Support peripheral equipment connection via the RS232 port, each peripheral

equipment control protocol and interface can be set freely.

Support serial port (RS232/RS485) transparent data transmission.

Support the on-off alarm device to alarm via the sound or the light.

Power External power adapter. Support DC 12V/AC 24V power supply.

Warning！

Do not connect two power supplying sources to the device at the same time; it

may result in device damage!

PoE

Support Power over Ethernet (PoE). Conform to the IEEE802.3af standard.

Connect the device to the switcher or the router that supports the PoE function to

realize the network power supply.

To guarantee proper performance, please make sure the power sourcing device

can supply at least 10W power.

Usually, do not use the PoE for the WIFI/3G device.

Assistant

Function

Day/Night mode auto switch (ICR switch.)

Backlight compensation: screen auto split to realize backlight compensation to

adjust the bright.

Support system resource information and running status real-time display. Support

log function.

Support video watermark function to avoid vicious video modification.

Support auto aperture.

Support picture parameter setup such as electronic shutter and gain setup.

Support dual-stream, ACF(Active frame control )

1.3 Specifications

1.3.1 Performance

Please refer to the following sheet for network camera performance specification.

Model

Parameter ICIP S1300WDR

System

Main

Processor TI Davinci high performance DSP

OS Embedded LINUX

System

Resources Support real-time network, local record, and remote operation at the same

time.

User Interface Remote operation interface such as WEB, DSS, PSS

System Status SD card status, bit stream statistics, log, and software version.

Video Parameter

Image Sensor 1/3-inch CMOS

Pixel 1280(H)×960(V)

Day/Night

Mode Support day/night mode switch and IR-CUT at the same time.

Auto Aperture Optional

Gain Control Fixed/Auto

White Balance Manual/Auto

BLC Off/BLC/WDR (1-100 adjustable)/HLC(anti-flicker is outdoor and is valid only

when exposure mode is auto with range 1-100)

Electronic

Shutter Manual/Auto

It ranges from 1/3 to 1/10000.

Video

Compression

Standard

H.264/ H.264H/H.264B/MJPEG

Note: Some versions do not support H.264H.

Video Frame

Rate

PAL:

Main stream (1280*960@25fps)

Extra stream (704*576@25fps)

Main stream (1280*720@25fps)

Extra stream (704*576@25fps)

NTSC:

Main stream (1280*960@30fps)

Extra stream (704*480@30fps)

Support AC24V/DC12V power and PoE.

T Ethernet

Main stream (1280*720@30fps)

Extra stream (704*480@30fps)

Video Bit Rate

H.264:56Kbps-8192Kbps, H.264H 16Kbps-8192Kbps, H.264B 56Kbps-

8192Kbps.

MJPEG is adjustable and bit rate is adjustable.

Support customized setup.

Flip Support

Mirror Support

Snapshot Max 1f/s snapshot. File extension name is JPEG

Privacy Mask Each channel supports max 4 privacy mask zones

Video Setup Support parameter setup such as bright, contrast.

Video

Information Channel title, time title, motion detect, tampering.

Lens Optional

Lens Interface C/CS optional

Audio Input 1-channel，3.5mm JACK LINE IN

Audio

Audio Output 1-channel，3.5mm JACK SPEAK OUT

Bidirectional

Talk Input Reuse the first audio input channel

Audio Bit Rate 16kbps 16bit

Audio

Compression

Standard G.711A/G.711Mu

Video

Motion Detect

396 (18*22) detection zones; sensitivity level ranges from 0 to 100; area

threshold ranges from 0 to 100.

Activation event, alarm device, audio/video storage, image snapshot, log,

email function and etc.

Camera

Masking Activation event, alarm device, audio/video storage, image snapshot, log,

email SMTP function and etc.

Alarm Input 1-channel input，1-channel output

Record and

Backup

Record

Priority

Manual>External alarm >Video detect>Schedule

Storage

Management Support SD card storage, NAS storage

Network

Wire Network 1-channel wire Ethernet port, 10/100 Base-T Ethernet

Network

Protocol HTTP,TCP,ARP,RTSP,RTP,UDP,RTCP,SMTP,FTP,DHCP,DNS,DDNS,PPPo

E,IPv4/v6,SNMP,QoS,UPnP,NTP, HTTPS, 802.1x, Bonjour

Protocol PSIA(optional), ONVIF

Remote

Operation Monitor, PTZ control, system setup, file download, log information,

maintenance , upgrade and etc

AUX Interface

Video Output 1-channel analog video output，BNC port

Network

Interface 1-channel Ethernet, 10/100 Base-

3G Port Support 3G SIM card, TD/EVDO/WCDMA function. (For 3G series product

only.)

Antenna Port Support to receive the wireless signal (This function is for 3G and WIFI series

product only.)

RS485 port PTZ control interface. Support various protocols.

Power

Consumption <10W (For WIFI and 3G device, it is below 12W.)

Working

Temperature -20℃~+60℃

Working

Humidify ≤95%

Dimensions 70*63.2*149.5

Weight 650g

Installation Support various installation modes(Enclosure and bracket are optional)

Table des matières

Autres manuels ICRealtime Caméra de sécurité

ICRealtime

ICRealtime F Series Manuel utilisateur

ICRealtime

ICRealtime AVS-D2118VF Manuel utilisateur

ICRealtime

ICRealtime ICR300H3B Manuel utilisateur

ICRealtime

ICRealtime AVS-B2100 Manuel utilisateur

ICRealtime

ICRealtime ICIPD4002IR28 Manuel utilisateur

ICRealtime

ICRealtime EL700 Manuel utilisateur

ICRealtime

ICRealtime F Series Manuel utilisateur

ICRealtime

ICRealtime Full HD(HD-SDI) CCTV Box Camera Manuel utilisateur

ICRealtime

ICRealtime ICIP-D2360 Manuel utilisateur

ICRealtime

ICRealtime IPEL-M60F-IRW1 Manuel utilisateur

ICRealtime

ICRealtime ICIPP3020HDIR Manuel utilisateur

ICRealtime

ICRealtime EL-2000 I-sniper Manuel utilisateur

ICRealtime

ICRealtime ICIP-D2000-VIR Manuel utilisateur

ICRealtime

ICRealtime IPEL-B2012X-IRW1 Manuel utilisateur

ICRealtime

ICRealtime AVS-A4112S Manuel utilisateur

ICRealtime

ICRealtime EL-3000 Manuel utilisateur

ICRealtime

ICRealtime IPMX Series Manuel utilisateur

ICRealtime

ICRealtime EL9036 Manuel utilisateur

ICRealtime

ICRealtime ICR540IN Manuel utilisateur

ICRealtime

ICRealtime AVS-4KD8021-IR Manuel utilisateur

ICRealtime

ICRealtime ICIP D3000AVIR-M Manuel utilisateur

ICRealtime

ICRealtime AVSD2208VF Manuel utilisateur

ICRealtime

ICRealtime I-Sniper EL-750W Manuel utilisateur

ICRealtime

ICRealtime AVS-B2712SL Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
