IBASE Technology MI888 Manuel utilisateur

MI888

Intel®Pineview-M/ Pineview-D +ICH8M

Luna-Pier / Luna-Pier Refresh Platform

Mini-ITX Motherboard

USER’S MANUAL

Version 1.0

MI888 User’s Manual

Acknowledgments

AMI BIOS is a trademark of American Megatrends Inc.

PS/2 is a trademark of International Business Machines

Corporation.

Intel and Luna-Pier are registered trademarks of Intel

Corporation.

Microsoft Windows is a registered trademark of Microsoft

Corporation.

Winbond is a registered trademark of Winbond Electronics

Corporation.

All other product names or trademarks are properties of their

respective owners.

MI888 User’s Manual iii

Table of Contents

Introduction .......................................................5

Checklist ......................................................................................6

MI888 Specifications...................................................................7

Board Dimensions........................................................................8

Installations .......................................................9

Installing the Memory................................................................10

Setting the Jumpers....................................................................11

Connectors on MI888 ................................................................15

BIOS SETUP ....................................................23

Drivers Installation ......................................43

Intel Chipset Software Installation Utility.................................44

Intel Pineview Chipset Family Graphics Driver Installation.....46

Realtek High Definition Codec Audio Driver Installation ........48

Realtek RTL8111DL LAN Drivers Installation ........................49

Appendix ...........................................................51

A. I/O Port Address Map ...........................................................51

B. Interrupt Request Lines (IRQ)...............................................52

C. Watchdog Timer Configuration ............................................53

D. Digital I/O Sample Code.......................................................58

MI888 User’s Manual

This page is intentionally left blank.

INTRODUCTION

Introduction

MI888 Mini ITX Motherboard

MI888 Edge Connectors

MI888 User’s Manual 5

INTRODUCTION

MI888 User’s Manual

Checklist

Your MI888 package should include the items listed below.

•The MI888 Intel®Luna-Pier Mini-ITX motherboard

•This User’s Manual

•1 CD containing chipset drivers and flash memory utility

•Cable kit (USB, Serial port, Serial ATA)

INTRODUCTION

MI888 User’s Manual 7

MI888 Specifications

Form Factor MiniITX

CPU Type Intel® Pineview-M & Pineview-D Microprocessor (45nm

Technology)

CPU Speed Atom SC N450 1.66 GHz/ 512KB L2 cache (MI888)

Atom DC D510 1.66GHz / 1MB L2 cache (MI888-D5)

Green /APM APM1.2

BIOS AMI BIOS, support ACPI Function

Chipset Intel® Luna-Pier / Luna-Pier Refresh platform

Pineview-M : 22mm x 22mm, Micro-FCBGA8 (5.5W)

or Pineview-D : 22mm x 22mm, Micro-FCBGA8 ( 13W for DC)

ICH8M: 31mm x 31mm, 676-pin T-PBGA (2.4W)

Memory DDR2 667MHz

N450 supports SO-DIMM x 1 (w/o ECC), Max. 2GB , Single

channel

D510 supports SO-DIMM x 1 (w/o ECC), Max. 2GB , Single

channel

VGA Intel® Integrated Graphics Controller

Luna Pier supports DirectX 9 Graphic (200MHz)

Luna Pier Refresh supports DirectX 9 Graphic (400MHz)

OpenGL 1.4

LVDS 18-bit one channels LVDS interface w/DF13 socket x1

LAN Realtek 8111DL x 1

USB ICH8M built-in USB 2.0 host controller, support 8 ports

Serial ATA Ports ICH8M built-in SATA controller, supports 2 ports

Parallel IDE ICH8M built-in one channel Ultra DMA 33/66/100, for CF Type II

(Component side)

Audio Intel ICH8M built-in audio controller w/ Realtek ALC662 Codec

Supports 5.1 CH audio (Line-out, Line-in & MIC )

LPC I/O Winbond W83627UHG :

COM1 (RS232/422/485), COM2(RS232), COM3 (RS232), COM4

(RS232), with pin-9 with power for 4 ports (500 mA for each port)

Hardware monitor (2 thermal inputs, 4 voltage monitor inputs,

VID0-4 & 1 x Fan Header)

Digital IO 4 in & 4 out

KB/Mouse

Connector

Yes

Expansion Slots Mini PCI-express socket x 1 for Wireless LAN or other module

PCI + PCI-Express(1x) slot x1

Edge Connector PS/2 KBMS connector x 1

DB15 + DB9 Stack connector x1 for VGA+COM 1

Dual DB9 Stack connector x 1 for COM2,3

RJ45 + Dual USB stack connector x1 for LAN 1 + USB 1,2

Dual USB stack connector x 1 for USB 3, 4

Audio 3-port connector x 1 (Line-out, Line-in, MIC)

On Board

Header/Connecto

2x4 pins header x 2 for 4 USB ports

LVDS ( DF13 X 1 )

Mini PCI-e connector x 1

12 pins header x1 for front audio

DF11-10 pins box header x 1 for COM4

CF type II connector x 1

2x5 pin header x 1 for Digital I/O

Watchdog Timer Yes (256 segments, 0, 1, 2…255 sec/min)

Power Connector ATX (20-pin)

Board Size 170mm x 170mm

INTRODUCTION

Board Dimensions

MI888 User’s Manual

INSTALLATIONS

MI888 User’s Manual 9

Installations

This section provides information on how to use the jumpers and

connectors on the MI888 in order to set up a workable system. The

topics covered are:

Installing the Memory ......................................................................... 10

Setting the Jumpers.............................................................................. 11

Connectors on MI888.......................................................................... 15

INSTALLATIONS

Installing the Memory

The MI888 board supports one DDR667 DDR2 memory.

Remarks:

N450 supports SO-DIMM x 1 (w/o ECC), Max. 2GB , Single channel

D510 supports SO-DIMM x 1 (w/o ECC), Max. 2GB , Single channel

Installing and Removing Memory Modules

To install the DDR2 modules, locate the memory slot on the board and

perform the following steps:

1. Hold the DDR2 module so that the key of the DDR2 module aligns

with that on the memory slot. Insert the module into the socket at a

slight angle (approximately 30 degrees). Note that the socket and

module are both keyed, which means that the module can be installed

only in one direction.

2. To seat the memory module into the socket, apply firm and even

pressure to each end of the module until you feel it slip down into the

socket.

3. With the module properly seated in the socket, rotate the module

downward. Continue pressing downward until the clips at each end

lock into position.

4. To remove the DDR2 module, press the clips with both hands.

MI888 User’s Manual
