Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/ 1

Quidway® S5600 Intelligent and Resilient Series

Switches Product Specification

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

Fixed port 24 10/100/1000Base-T

ports, 4 1000BASE-X SFP

(Combo) ports, and 2

dedicate high speed

stacking ports

48 10/100/1000Base-T, 4

1000BASE-X SFP

(Combo) ports, and 2

dedicate high speed

stacking ports

24 1000Base-X SFP

ports,

4 10/100/1000BASE-T

(Combo) , and 2 dedicate

high speed stacking ports

Extended slot 1 1 1 1 1

Extended module (1) 8 ports 1000Base-X SFP module

(2) 1 port Xenpak 10GE module

(3) 2 ports XFP 10GE module

Performance

Wire speed L2/L3

switching Port Switch capacity:

88Gbps

Throughput: 65.47Mpps

Port Switch capacity:

136Gbps

Throughput: 101.18Mpps

Port Switch capacity:

88Gbps

Throughput: 65 .47Mpps

Switching Fabric 192Gbps 240Gbps 192Gbps

Flash 16M 16M 16M 16M 16M

POE No Yes No Yes No

Switching mode Store and forward

Forwarding

Latency <40µs

SDRAM 128M

Layer 2 feature

MAC address

table Address self-learning

IEEE 802.1D standard

Up to 16K MAC addresses

Up to 1k static MAC addresses

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/ 2

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

VLAN 4k VLAN (IEEE802.1Q)

Voice VLAN

GVRP

Support Port-based VLAN

Protocol-based VLAN

Configure VLANs in batch

Stack IRF(DDM, DRR, DLA) Stack

up to 8 units in one stacking group

Up to 448GE or 384GE and 16 10GE in one stacking group

Stacking bandwidth 96Gbps

RMON on IRF

HGMP on IRF

Peer fabric port testing

Link aggregation Link aggregation through command lines

Dynamic link aggregation through LACP

Link aggregation across switches

Up to 8 GE or 4 10GE ports in each aggregation group

Up to 32 aggregation groups (each aggregation port must be of the same speed)

Manual link aggregation through command lines

Mirroring Many-to-one port mirroring (multiple monitored ports to one monitor port, N:1)

Traffic mirroring

STP/RSTP/MSTP IEEE 802.1D Spanning Tree Protocol (STP)

IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)

IEEE 802.1s Multiple Spanning Tree Protocol instances (MSTP)

QinQ BPDU Tunnel

Flow control IEEE 802.3x (full duplex)

Back-pressure based flow control (half duplex)

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/ 3

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

Broadcast /

Multicast /

Unicast storm

suppression

Port rate ratio(1% granularity) and PPS based on suppression

QinQ VLAN-VPN or double tag

Layer 3 feature

IP routing Static routing

16K IP Routes

RIPv1/v2 (Routing Information Protocol v1, v2)

OSPF v2 (Open Shortest Path First )

4 ECMP(Equal Cost Multi-Path)

RIP equivalent route

BGP4

Multicast IGMP (Internet Group Management Protocol) v1 and v2

IGMP (Internet Group Management Protocol) snooping

IGMP Group Limit on Interface

256 multicast groups

Adding multicast MAC addresses manually

Multicast source port suppression

MVR(Multicast VLAN Registration)1

PIM-DM

PIM-SM

MSDP(Multicast Source Discovery Protocol)

Network Protocol VRRP (Virtual redundancy routing protocol)

DHCP server

DHCP Snooping (Dynamic Host Configuration Protocol Snooping)

DHCP Relay (Dynamic Host Configuration Protocol Relay)

1For detail information, please refer to S5600 Series Switch System Description.

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/ 4

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

DHCP Client

DHCP option 60

ARP (Address Resolution Protocol)

NTP (Network Time Protocol)

BOOTP (Bootstrap Protocol)

UDP helper

Convergence

Quality of service

(QoS)/

Access control

list (ACL)

Support bi-directional port rate-limiting, Committed Access Rate (CAR), GE port with

granularity of 64 Kbps and 10GE port with the granularity of 1 Mbps

Eight output queues on each port

Time-based QoS

Packet redirection

Three scheduling algorithms that can be set based on port and queue at the same

time:

• SP (Strict Priority)

• WRR (Weighted Round Robin)

• SP + WRR

Packet tagging based on 802.1p or DSCP preference

L2~L4 Packet filter providing filtering based on source/destination MAC address,

source/destination IP address, port, protocol, VLAN, VLAN range, MAC address range,

or invalid frame

QoS profile management, allowing QoS service scheme customization

Mirroring remote ports (Support RSPAN)

Flow statistics for ACL rules defined using the deny keyword

Improvements made for the depth-first order of ACL matching

DSCP (differentiated services code point) refined when defining ACL rules

Delivering ACLs in RADIUS

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/ 5

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

Configuring synchronization for the queue schedule of aggregation ports

Protocol packet priority

Controlling Telnet users

Security

Network Login Support Centralized MAC address authentication

Support Disconnect unauthorized device (DUD) authentication

Support Port isolation

Support MAC address black hole

Support MAC Address Learning Limit

Prevent unauthorized access to the network by binding of MAC, IP and PORT

Support SSH(Secure Shell) V2 ( Automatic RSA public key configuring)

Support Port security

Support EAD (endpoint admission defense)

802.1X Support IEEE 802.1X user authentication

Version checking (802.1 X supplicant system)

Guest VLAN

Dynamic VLAN

802.1 X PEAP/EAP/TLS/TTLS

Performing 802.1 X authentication and MAC address-based authentication

simultaneously

802.1 X -trusted MAC address

802.1 X client checking

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/ 6

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

AAA&Radius Separated authentication, authorization, and accounting

Authenticated users need to be authenticated again when the device restarts

Delivering of trunk ports and hybrid ports in Tag VLAN is supported when performing

802.1x authentications

The tag authentication method field is added to RADIUS protocol

HWTACACS

Management/ Maintenance

System

Configuration

and Management

Support CLI (Command Line Interface) configuration mode

Support Configuration via the console port

Support Local/Remote configuration via Telnet

Support Remote configuration via modem dial-up

Support System configuration with SNMP v1, 2 and 3

Support SNMP Agent logging

Support HGMP V2

Support RMON (Remote Monitoring) v1, 1/2/3/9 groups of MIBs

Support Quidway network management system

Web-based network management

File system

management and

seven-segment

display

Upgrading all the units of a fabric using the App (or BootROM, Web) files of a unit

Setting an App file of a fabric or a unit of a fabric to be the primary/a secondary

configuration file

Specifying a fabric or a unit of a fabric to use the primary configuration file, a secondary

configuration file, or no configuration file to start.

Performing specific file-related operations for a fabric or a unit of a fabric, such as

deleting files stored in the storage devices of an Ethernet switch, displaying the

information about specified files or directories in the storage devices of an Ethernet

switch, and clearing the recycle bin.

Customizing the password for entering the BOOT menu

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

i.com/products/datacomm/ 7

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

Configuration file backup/recovery

Seven-segment display, which indicates the progress of loading software using

FTP/TFTP

System

Maintenance and

debugging

Detailed alarm/debug information output

Support Ping and Tracert

Support remote maintenance via Telnet Modems and SSH

Support HWping

Support System log

Hierarchical alarm management and alarm filtering

Support DLDP (Device Link Detection Protocol)

Saving debugging information into Flash

Displaying the information about all enabled types of debugging

Displaying the statistics of MAC addresses of a switch

Configuring Telnet users with specified source IP addresses/source ports

Setting the Daylight Saving Time

Loopback detection on ports

Support VCT(Virtual Cable Test)

Information

center Exporting switch synchronization information

Setting the format of time stamps to be sent to log hosts

Hardware configuration

Outline

dimension

(W×H×D) 440 mm ×43.6 mm ×420mm (17.32 in.×1.72 in. ×16.54 in.)

Weight 7.1Kg 7.4Kg 7.1Kg

Power

supply Power

module

PSL130-AD: 130 W system output, AC/DC input

PSL480-AD24P: 24-port PoE power module, 180 W system output + 300 W PoE

output (AC input); 180 W system output + 370 W PoE output (DC input)

PSL180-AD: 180 W system output, AC/DC input

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/ 8

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

PSL480-AD48P: 48-port PoE power module, 180 W system output + 300 W PoE

output (AC input); 180 W system output + 740 W PoE output (DC input)

Input

voltage AC:

Rated voltage: 100V to 240V, 50 Hz to 60Hz

Maximum tolerance:90V to 264V, 50 Hz to 60Hz

DC:

Rated voltage: -48V to -60V

Maximum tolerance: -36V to -72V

Input DC

voltage

of PoE

power

module

The S5624P-PWR/S5648P-PWR must use the external PoE PSU recommended by us

as its DC input, but not the -48VDC power supply generally available in the equipment

room. Otherwise, the device may be damaged

DC input of the PoE power module:

Rated voltage: –53.5 V

Max voltage range: –52 to–55 V

RPS

power Supported

Maximum power

consumption S5624P: 170 W

S5648P: 230 W

S5624F: 170 W

S5624P-PWR: 540 W

S5648P-PWR: 600 W

When with PoE power supply:

S5624P-PWR: 540 W (DC input), 560 W (AC input)

S5648P-PWR: 970 W (DC input), 640 W (AC input)

MTBF (Years) 32.30 32.30 23.99 23.99 23.89

Noise parameter S5624P: 50.8 dBA

S5648P: 51.4 dBA

S5624F: 54.6 dBA

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/ 9

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

S5624P-PWR: 51.8 dBA

S5648P-PWR: 52.2 dB

MTTR (hours) <2 <2 <2 <2 <2

Environment Operation temperature: 0°C ~ 45°C

Storage temperature: -40°C ~ 70°C

Operating humidity: 5% to 85% non-condensing

Relative humidity: 10% ~ 90%, non-condensing

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Huawei Changer

Huawei

Huawei Quidway S9300 Mode d’emploi

Huawei

Huawei S2700-EI Series Mode d’emploi

Huawei

Huawei S9700 Series Manuel utilisateur

Huawei

Huawei Quidway S2008-EI Manuel utilisateur

Huawei

Huawei B612 Manuel utilisateur

Huawei

Huawei S5700-HI Series Manuel utilisateur

Huawei

Huawei S5720I-6X-PWH-SI-AC Manuel utilisateur

Huawei

Huawei Quidway S3000-EI Series Manuel utilisateur

Huawei

Huawei Quidway S5600 Manuel utilisateur

Huawei

Huawei Quidway S3500 Series Manuel utilisateur

Huawei

Huawei Quidway S3000-EI Series Manuel utilisateur

Huawei

Huawei Quidway S3900 Series Manuel utilisateur

Huawei

Huawei Enterprise S2700 Series Manuel de l'opérateur

Huawei

Huawei MA5821 Manuel utilisateur

Huawei

Huawei Enterprise S2700 Series Manuel utilisateur

Huawei

Huawei CloudEngine 8800 Series Manuel utilisateur

Huawei

Huawei B890 Guide de référence

Huawei

Huawei Quidway S6506R Mode d’emploi

Huawei

Huawei S3700 Series Manuel utilisateur

Huawei

Huawei Enterprise S2700 Series Manuel utilisateur

Huawei

Huawei IdeaShare Key Manuel utilisateur

Huawei

Huawei quidway s7700 Manuel utilisateur

Huawei

Huawei S3700 Series Manuel utilisateur

Huawei

Huawei Quidway S5300 Series Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

D-Link

D-Link DES-1226G Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur
