Quidway® S2000-HI Series Intelligent Access Switches Product Specification

http://www.huawei.com/products/datacomm/ 1

Quidway® S2000-HI Series Intelligent Access

Switches Product Specification

Feature S2403H-HI S2016-HI S2008-HI

Fixed ports (1)24 10/100 BASE-TX

ports

(2) 1 console port

(1)16 10/100 BASE-TX

ports

(2) 1 console port

(1)8 10/100 BASE-TX

ports

(2) 1 console port

Extended Slot 2 2 1

Extended Module (1)1*10/100/1000BASE-T:max transmission distance: 100 m (328 ft)

(2)1*100BASE-SX: SC connector, 2 km (1.24 mi.)

(3)1*100BASE-LX: SC connector, 15 km (9.32 mi.)

(4)1*100BASE-LH40: SC connector, 40 km (24.86 mi.)

(5)1*1000BASE-SX: SC connector, 0.5km (0.31 mi.)

(6)1*1000BASE-LX: SC connector, 10 km (6.21 mi.)

(7)1*1000BASE-LH40: LC connector, 40 km (24.86 mi.)

(8)1*1000BASE-LH70: LC connector, 70 km (43.50 mi.)

(9)1*1000BASE-STACK (not supported by S2008-HI)

(10)1*100BASE-TX PD (Powered Device) (not supported by S2403-HI)

Performance

Switching

capacity 8.8 Gbps 7.2 Gbps 3.6 Gbps

Switching Fabric 19.2 Gbps 19.2 Gbps 19.2 Gbps

Throughput 6.55 Mpps 5.36 Mpps 2.68 Mpps

Stack(HGMP V2) Yes Yes No

Max stack

numbers 16 16 No

Stack bandwidth

(bps) 4G 4G No

POE (As PD) No Yes Yes

Latency <10µs

Layer 2 Switching

MAC Address Up to 8 K MAC addresses

1 K static MAC addresses

Adding of dynamic/static unicast MAC address, multicast MAC address, and

black hole MAC Address

Port Mirroring Many-to-one port mirroring (that is, multiple mirroring ports, and one monitor port)

Quidway® S2000-HI Series Intelligent Access Switches Product Specification

http://www.huawei.com/products/datacomm/ 2

Feature S2403H-HI S2016-HI S2008-HI

Remote switched port analyzer (RSPAN)

Port Features Port isolation

Port self-loop detection

Port loopback (internal/external test)

VLAN 4k VLANs (IEEE 802.1Q)

GVRP (GARP VLAN Registration Protocol)

Port-based VLAN

VLAN Tag Frame Extension

Link Aggregation Up to 3 maximum aggregation groups (2 FE groups and 1 GE group), each

containing up to 8FE/2GE

Traffic control IEEE 802.3x full-duplex flow control

Back-pressure based flow control (half duplex)

STP/RSTP/MSTP IEEE 802.1D Spanning Tree Protocol (STP)

IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)

IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)

Multicast MVR(Multicast VLAN Registration)

256 Multicast groups

IGMP (Internet Group Management Protocol) snooping on Layer 2 interfaces

Network protocol DHCP Snooping (Dynamic Host Configuration Protocol Snooping)

Support NTP (Network Time Protocol)

ARP

Convergence

QoS(Quality of

Service) Four output queues on each port

Support flexible queue scheduling algorithms:

• WRR (Weighted Round Robin)

• HQ+WRR (High-Priority Queuing + WRR)

Support bi-directional port rate-limiting with the granularity of 64kbit/s

Port bandwidth percentage-based Broadcast storm suppression

Drop of unknown multicast packets

Security

Various Security SSHv2

Guest VLAN

MAC Black Hole

DHCP Snooping

Centralized MAC Address Authentication

Network Login Hierarchical user management and password protection

Port-based and MAC-based 802.1X authentication

Local authentication server

Quidway® S2000-HI Series Intelligent Access Switches Product Specification

http://www.huawei.com/products/datacomm/ 3

Feature S2403H-HI S2016-HI S2008-HI

PEAP/TLS (Protected Extensible Authentication Protocol/Transport Layer

Security)

Management

System

Configuration and

Management

Support CLI (Command Line Interface) configuration mode

Support Configuration via the console port

Support Local/remote configuration via Telnet

Support System configuration with SNMP v1, 2, and 3

Support RMON (Remote Monitoring) v1 1, 2, 3 and 9 groups of MIB

Support Quidway and iManager N2000 network management system

Support WEB management system

Support Hierarchical alarms

Support System log

System

maintenance Debug information output

Ping, Traceroute, multicast Traceroute

Remote maintenance through Telnet

VCT (Virtual Cable Test)

Hardware configuration

Outline

dimensions (mm)

（H×W×D）

42 × 436 × 240 mm

(1.7 x 17.2 x 9.5 in) 42 × 436 × 200 mm

(1.7 x 17.2 x 7.9 in) 42 × 326 × 200 mm

(1.7 x 12.8 x 7.9 in)

Weight < 3kg (6.6 lb)

Fan No Fan

Maximum system

power

consumption 20 W 12 W 10 W

Input voltage Two models of switches are available, one supports AC input and the other

supports DC input

AC input:

Rated voltage range: 100V~240V, 50/60 Hz

Max voltage range: 90V~264V, 47~63 Hz

DC input:

Rated voltage range: –48V ~ –60V

Max voltage range: –36V ~–72 V

MTBF S2008-HI: 59.25 years( 519,030hours)

S2016-HI: 50.91 years (445,971hours)

S2403H-HI: 41.45 years (363,102hours)

Environment Working temperature: 0~45℃(32°F ~ 113°F)

Storage temperature: -40 ~ 70℃(-40°F to 158°F)

Relative humidity: 10%~90%, non-condensing

Quidway® S2000-HI Series Intelligent Access Switches Product Specification

http://www.huawei.com/products/datacomm/ 4

Feature S2403H-HI S2016-HI S2008-HI

Operating temperature: 0°C to 45°C (32°F to 113°F)
