Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 1
Quidway® S6500 Series High-end Multi-service
Switches Order Information
Table 1 Quidway® S6503 Host Configurations
Name Description Quantity Remark
Chassis configuration
LS-6503-AC-XG-PO
E-OVS
S6503 Ethernet Switch Assembly Chassis (AC
110/220V) with fan,1 AC power and document,
support PoE and XGBUS 1 Mandatory
LS-6503-DC-XG-PO
E-OVS
S6503 Ethernet Switch Assembly Chassis (DC
48V) with fan, 1 DC power and document ,support
PoE and XGBUS 1 Mandatory
Cabinet configuration
LS8M1B68 Assembly Cabinet for S6500 Ethernet Switch,
2.2M (optional) 0-1 Optional
Power Supply Configuration
LS8M4220 S6500 AC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M448 S6500 DC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M3POEPWR External PoE Power (220v-2500W, 110V-1250W)
Rack (with 1 PoE PSU) 0-1 PoE
Mandatory
LS8M1POEPWR PoE Power Supply Unit (220v-2500W,
110V-1250W) module 220V:0-1
110V:0-2 Optional
Main Control Unit
LS8M4SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module,Salience III Edge-96GE with 4
1000BASE-X interface,SFP Req. 1 Mandatory
LS8M1SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module,Salience III, with 4
1000BASE-X interface,SFP Req. 1 Mandatory
LS8M2SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module, Salience III Plus 1 Mandatory
Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 2
Table 2 Quidway® S6506 Host Configurations
Name Description Quantity Remark
Chassis configuration
LS-6506-AC-XG-PO
E-OVS
S6506 Ethernet Switch Assembly Chassis (AC
110/220V) with fan, 2 AC power and document,
support PoE and XGBUS, two power cord input 1 Mandatory
LS-6506-DC-XG-PO
E-OVS
S6506 Ethernet Switch Assembly Chassis (DC
48V) with fan, 2 DC power and document, support
PoE and XGBUS, two power cord input 1 Mandatory
Cabinet configuration
LS8M1B68 Assembly Cabinet for S6500 Ethernet Switch,
2.2M (optional) 0-1 Optional
Power Supply Configuration
LS8M4220 S6500 AC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M448 S6500 DC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M3POEPWR External PoE Power (220v-2500W, 110V-1250W)
Rack (with 1 PoE PSU) 0-1 PoE
Mandatory
LS8M1POEPWR PoE Power Supply Unit (220v-2500W,
110V-1250W) module 220V:0-1
110V:0-2 Optional
Main Control Unit
LS8M4SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module,Salience III Edge-96GE with 4
1000BASE-X interface,SFP Req. 1 Mandatory
LS8M1SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module,Salience III, with 4
1000BASE-X interface,SFP Req. 1 Mandatory
LS8M2SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module, Salience III Plus 1 Mandatory
System Software
LIS-S6506 S6506 VRP Network Operating System (host
software) 1 Mandatory
Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 3
Table 3 Quidway® S6506R Host Configurations
Name Description Quantity Remark
Chassis configuration
LS-6506R-AC-XG-P
OE-OVS
S6506R Ethernet Switch Assembly Chassis (AC
110/220V) with fan, 2 AC power and document,
support PoE and XGBUS, two power cord input 1 Mandatory
LS-6506R-DC-XG-P
OE-OVS
S6506R Ethernet Switch Assembly Chassis (DC
48V) with fan, 2 DC power and document,support
PoE and XGBUS, two power cord input 1 Mandatory
Cabinet configuration
LS8M1B68 Assembly Cabinet for S6500 Ethernet Switch,
2.2M (optional) 0-1 Optional
Power Supply Configuration
LS8M4220 S6500 AC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M448 S6500 DC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M3POEPWR External PoE Power (220v-2500W, 110V-1250W)
Rack (with 1 PoE PSU) 0-1 PoE
Mandatory
LS8M1POEPWR PoE Power Supply Unit (220v-2500W,
110V-1250W) module 220V:0-1
110V:0-2 Optional
Main Control Unit
LS8M4SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module,Salience III Edge-96GE with 4
1000BASE-X interface,SFP Req. 1-2 Mandatory
LS8M1SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module,Salience III, with 4
1000BASE-X interface,SFP Req. 1-2 Mandatory
LS8M2SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module, Salience III Plus 1-2 Mandatory
System Software
LIS-S6506R S6506R VRP Network Operating System (host
software) 1 Mandatory
Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 4
Table 4 Quidway® S6502 Host Configurations
Name Description Quantity Remark
Chassis configuration
LS-6502-XG-POE-O
VS
S6502 Ethernet Switch Chassis with fan and
documents, support PoE and XGBUS, 2 power
cord inputs, no power module, VRP incl. 1 Mandatory
Cabinet configuration
LS8M1B68 Assembly Cabinet for S6500 Ethernet Switch,
2.2M (optional) 0-1 Optional
Power Supply Configuration
LS8M7220PWR S6502 AC Power Supply Module, only for S6502 1-2 Mandatory
LS8M548PWR S6502 DC Power Supply Module, only for S6502 1-2 Mandatory
LS8M3POEPWR External PoE Power (220v-2500W, 110V-1250W)
Rack (with 1 PoE PSU) 0-1 PoE
Mandatory
LS8M1POEPWR PoE Power Supply Unit (220v-2500W,
110V-1250W) module 0-1 Optional
Main Control Unit
LS8M1T12PE S6502 Switch and Route Processing Module with
12-port 10/100/1000BASE-T RJ-45 and 4-port
1000BASE-X SFP 1 Mandatory
LS8M1P12TE S6502 Switch and Route Processing Module with
12-port 1000BASE-X SFP and 4-port
10/100/1000BASE-T RJ-45 1 Mandatory
LS8M1GP48-XG S6500 48-port 1000BASE-X Ethernet Optical
Interface Module with XGBUS uplink, SFP Req. 1 Mandatory
LS8M1GT48B-XG S6500 48-port 10/100/1000BASE-T Ethernet
Interface Module with XGBUS uplink, RJ45 1 Mandatory
LS8M1T16P-XG S6500 16-port 10/100/1000BASE-T RJ45 and
8-port 1000BASE-X SFP with XGBUS uplink 1 Mandatory
LS8M1T32P-XG S6500 32-port 10/100/1000BASE-T RJ45 and
16-port 1000BASE-X SFP with XGBUS uplink 1 Mandatory
LS8M1TGX2-XG S6500 2-port 10GE Interface Module with XGBUS
uplink, XFP Req. 1 Mandatory
LS8M1TGX4-XG S6500 4-port 10GE Interface Module with XGBUS
uplink, XFP Req. 1 Mandatory
Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 5
Table 5 Quidway® S6 500 Optional Interface Modules
Quantity
Name Description S6502 S6503 S6506 S6506R Remark
Standard Module
LS8M1FT48E 48-port 10/100BASE-TX Ethernet Electrical
Interface Module,RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1FP48 48-port 100M Ethernet Optical Interface
Module,SFP Req. 0-1 0-3 0-6 0-6 Optional
LS8M1GT20A Enhanced 20-port 10/100/1000BASE-T
Ethernet Electrical Interface Module,RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1GT48 48-port 10/100/1000BASE-T Enhanced
Ethernet Electrical Interface Module,RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1GP20A Enhanced 20-port 1000BASE-X Ethernet
Optical Interface enhansed Module,SFP
Req. 0-1 0-3 0-6 0-6 Optional
LS8M1GT8UE S6500 8-port 10/100/1000BASE-T Ethernet
Interface Module, RJ45 0-1 0-3 0-5 0-5 Optional
LS8M1GP8UB S6500 8-port 1000BASE-X Ethernet Optical
Interface Module, SFP Req. 0-1 0-3 0-5 0-5 Optional
LS8M1TGX1C Enhanced 1-port 10GBASE-R Ethernet
Interface Module,Xenpak Req. 0-1 0-3 0-6 0-6 Optional
LS8M1GT48A-Po
E 48-port 10/100/1000Bae-T Ethernet
Electrical Interface Module,PoE,RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1FT48F-Po
E 48-port 10/100BASE-TX Ethernet Electrical
Interface Module,PoE,RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1T12P
12-port 10/100/1000BASE-T,RJ45, Gigabit
Ethernet Electrical Interface+4-port
1000BASE-X Gigabit Ethernet Optical
Interface Module,SFP Req.
0-1 0-3 0-6 0-6 Optional
LS8M1P12T
12-port 1000BASE-X Gigabit Ethernet
Optical Interface+4-port
10/100/1000BASE-T,RJ45 Gigabit Ethernet
Electrical Interface Module,SFP Req.
0-1 0-3 0-6 0-6 Optional
LS8M1GP48-XG S6500 48-port 1000BASE-X Ethernet
Optical Interface Module with XGBUS
uplink, SFP Req. 0-1 0-3 0-6 0-6 Optional
LS8M1GT48B-X
G
S6500 48-port 10/100/1000BASE-T
Ethernet Interface Module with XGBUS
uplink, RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1T16P-XG S6500 16-port 10/100/1000BASE-T RJ45
and 8-port 1000BASE-X SFP with XGBUS
uplink 0-1 0-3 0-6 0-6 Optional
Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 6
Quantity
Name Description S6502 S6503 S6506 S6506R Remark
LS8M1T32P-XG S6500 32-port 10/100/1000BASE-T RJ45
and 16-port 1000BASE-X SFP with XGBUS
uplink 0-1 0-3 0-6 0-6 Optional
LS8M1TGX2-XG S6500 2-port 10GE Interface Module with
XGBUS uplink, XFP Req. 0-1 0-3 0-6 0-6 Optional
LS8M1TGX4-XG S6500 4-port 10GE Interface Module with
XGBUS uplink, XFP Req. 0-1 0-3 0-6 0-6 Optional
LS8M1VSNP S6500 Versatile Network Processing
Service Module (PBR/NAT/NetStream) with
XGBUS uplink 0-1 0-2 0-5 0-5 Optional
EPON OLT module
LS8M1PT8GB0 8-Port 1000BASE-PX10 Gigabit Passive
Optical Line Interface Module (20km, SFF) 0-1 0-3 0-5 0-5 Optional
LS8M1PT4GB0 4-Port 1000BASE-PX10 Gigabit Passive
Optical Line Interface Module (20km, SFF) 0-1 0-3 0-6 0-6 Optional
LS8M1PT8GA 8-Port 1000BASE-PX10 Gigabit Passive
Optical Line Interface Module (10km, SFF) 0-1 0-3 0-5 0-5 Optional
LS8M1PT4GA 4-Port 1000BASE-PX10 Gigabit Passive
Optical Line Interface Module (10km, SFF) 0-1 0-3 0-6 0-6 Optional
EPON upgrade package
LS8M1EPONSW
P
EPON Upgrade Package for Salience III
Series Switch and Route Processing
Module, with a 512M memory and
documents
0 1 1 1-2
EPON
mandatory
LS8M1EUP EPON Upgrade Package for S6502, with
Documents 1 0 0 0 EPON
mandatory
EPON splitter module
OC-1x32 Optical Splitter, 1x32, Single Mode,
1310nm&1520nm±40nm, SC/PC Splitter
ratio is
1:32
OC-1x2-5:95 Optical Splitter, 1x2/5:95 (Splitting Ratio),
Single Mode, 1310nm&1520nm±40nm,
SC/PC Splitter
ratio is
5:95
OC-1x2 Optical Splitter, 1x2, Single Mode,
1310nm&1520nm±40nm, SC/PC Splitter
ratio is 1:2
OC-1x4 Optical Splitter, 1x4, Single Mode,
1310nm&1520nm±40nm, SC/PC Splitter
ratio is 1:4
OC-1x16 Optical Splitter, 1x16, Single Mode,
1310nm&1520nm±40nm, SC/PC Splitter
ratio is
1:16
Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 7
Quantity
Name Description S6502 S6503 S6506 S6506R Remark
OC-1x32-U Optical Splitter, 1x32, Single Mode,
1310nm&1520nm±40nm, SC/PC, 1U Splitter
ratio is
1:32
OC-1x8 Optical Splitter, 1x8, Single Mode,
1310nm&1520nm±40nm, SC/PC Splitter
ratio is 1:8
Autres manuels pour Quidway S6506R
1
Ce manuel convient aux modèles suivants
2
Autres manuels Huawei Changer
Huawei
Huawei S5720I-6X-PWH-SI-AC Manuel utilisateur
Huawei
Huawei S2720 Series Mode d’emploi
Huawei
Huawei Quidway S5600 Manuel utilisateur
Huawei
Huawei Quidway S8500 Series Instructions d'installation
Huawei
Huawei Quidway S3900 Series Manuel utilisateur
Huawei
Huawei Quidway S1700-8-AC Manuel d'utilisation et d'entretien
Huawei
Huawei S5700-LI Series Manuel utilisateur
Huawei
Huawei S1700-8G-AC Manuel utilisateur
Huawei
Huawei Quidway S3000 Series Manuel utilisateur
Huawei
Huawei Quidway S2000-EI Series Manuel utilisateur
Huawei
Huawei CloudEngine 6850 Series Manuel utilisateur
Huawei
Huawei S5700-HI Series Manuel utilisateur
Huawei
Huawei Quidway S9300 Mode d’emploi
Huawei
Huawei MA5821 Manuel utilisateur
Huawei
Huawei Quidway S5300 Series Mode d’emploi
Huawei
Huawei Quidway S5000 Series Manuel utilisateur
Huawei
Huawei S1700 Series Manuel utilisateur
Huawei
Huawei CloudEngine 7800 Series Mode d’emploi
Huawei
Huawei S1720 Caractéristiques techniques
Huawei
Huawei S3700 Series Manuel utilisateur
