Huawei WiMAX Guide de référence

Huawei Proprietary and Confidential

Welcome to use Huawei WiMAX USB Modem!

Online Help

Issue 03

Date 2009-03-10

Part Number 00496193

Huawei Proprietary and Confidential

No part of this document may be reproduced or transmitted in any form or by any means

without prior written consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of Huawei

Technologies Co., Ltd and possible licensors. Customers shall not in any manner

reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer,

lease, assign, or sublicense the said software, unless such restrictions are prohibited by

applicable laws or such actions are approved by respective copyright holders under

licenses.

Trademarks and Permissions

, HUAWEI, and

are trademarks or registered trademarks of Huawei

Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the property of

their respective owners.

Notice

Some features of the product and its accessories described herein rely on the software

installed, capacities and settings of local network, and may not be activated or may be

limited by local network operators or network service providers, thus the descriptions

herein may not exactly match the product or its accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify any information or

specifications contained in this manual without prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS". EXCEPT AS

REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR

CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE

SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL,

INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS,

BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and will

obtain all necessary governmental permits and licenses in order to export, re-export or

import the product mentioned in this manual including the software and technical data

therein.

Huawei Proprietary and Confidential

Safety Precautions

General Requirements:

zBefore you install and use the device, read these safety precautions carefully and

observe them during operation.

zKeep the device dry during storage, transportation, and operation of the device.

zPrevent collision of the device during storage, transportation, and operation of the

device.

zDo not attempt to dismantle the device by yourself. In case of any fault, contact the

appointed maintenance center for assistance or repair.

zWithout prior written consent, no organization or individual is permitted to make any

change to the structure or safety and performance design of the device.

zWhile using the device, observe all applicable laws, directives and regulations, and

respect the legal rights of other people.

Environmental Requirements:

zPlace the device in a well-ventilated place. Do not expose the device to direct sunlight.

zKeep the device clean, free of dust and stain.

zDo not place the device near a water source or in a damp area.

zDo not place any object on the top of the device.

zDo not place the device on or near inflammable materials such as foam.

zKeep the device away from heat source or fire, such as an electric heater or a candle.

zKeep the device far away from any household appliance with strong magnetic field or

electromagnetic field, such as a microwave oven, a refrigerator or a satellite dish

antenna.

Operating Requirements:

zDo not allow children to play with the device or accessories. Swallowing the

accessories may be fatal.

zUse the accessories provided or authorized only by the manufacturer.

zMake sure that the device does not get wet. If water gets into the device, switch off the

power supply immediately, and contact the appointed maintenance center.

zThe power supply of the device must meet the requirements of the input voltage of the

device.

zBefore plugging or unplugging any cable, shut down the device.

zWhile plugging or unplugging any cable, make sure that your hands are dry.

zDo not step on, pull, or bend any cable. Otherwise, the cable may be damaged, leading

to malfunction of the device.

zDo not use old or damaged cables. In any of the following cases, stop using the device,

disconnect it from the power supply and unplug the power plug immediately: there is

smoke emitted from the device, or there is some abnormal noise or smell. Contact the

specified maintenance center for repair.

Huawei Proprietary and Confidential

zDo not scratch or abrade the shell of the device. This may lead to malfunctions of the

device, such as short circuit. The shed painting material may also lead to skin allergy.

zDo not use the device during lightning, and unplug it from the computer, to prevent

damage to the device and the computer.

zIf the device is not used for a long time, unplug the device from the computer.

Cleaning Requirements:

zBefore cleaning the device, stop using it and unplug it from the computer.

zDo not clean the device shell with any cleaning solution or cleanser spray. Use a piece

of soft cloth to clean the device shell.

Usage Requirements of Wireless Product

zKeep the device away from magnetic storage devices (e.g., a magnetic card or a floppy

disk), to prevent loss of the stored information.

zUnplug the device from the computer and turn off the computer in situations where a

wireless device is prohibited or using of a wireless device will lead to interference.

zUnplug the device from the computer and turn off the computer kept close to an

electronic high-precision controlled device, such as an audiphone, a pacemaker, fire

alarm or an automatic gate. Otherwise, this will lead to malfunction of the electronic

device.

zThe user who uses an electronic assistant medical-treatment device needs to confirm

with the service center regarding the effects of the radio wave on this device.

zDo not take the device to the operation theater, Intensive Care Unit (ICU) or the

Coronary Care Unit (CCU).

zWhen you are driving a car or traveling by plane, unplug the device from the computer

and turn off the computer, to avoid interference arising from radio signal of the device.

zWhen using the device maintain distance of 3 cm between your body and the antenna

of the device.

zIn the area with inflammable or explosive materials, turn off your wireless device, and

follow the relevant instructions given in the label, to prevent explosion or fire.

zProtect the wireless device and its accessories, and use it in a clean and dust-free

environment. Make sure that the wireless device does not come in contact with flame or

a cigarette that is lit.

zMake sure that the wireless device and its accessories are dry.

zDo not drop, throw or try to bend your wireless device.

zDo not place the wireless device and its accessories in high or low temperature areas.

zThis device uses radio signal for transmission. The network connection may not be

available in all the situations. In an emergency, you should not rely solely on this

wireless device for essential communications.

Online Help Contents

Issue 03 (2009-03-10) Huawei Proprietary and Confidential

Contents

1 Getting to Know Your USB Modem..................................................................1-1

1.1 Functions and Features................................................................................................1-1

1.2 Connecting the External Antenna................................................................................1-1

1.3 Requirements on PC Configuration.............................................................................1-2

2 Installing the USB Modem .................................................................................2-1

2.1 Connecting the USB Modem.......................................................................................2-1

2.2 Removing the USB Modem ........................................................................................ 2-2

2.3 Installing the Cela.C.M ...............................................................................................2-2

2.4 Uninstalling the Cela.C.M...........................................................................................2-2

2.5 Introduction to the Icons..............................................................................................2-3

3 Maintaining the USB Modem............................................................................3-1

3.1 Connecting and Disconnecting Network.....................................................................3-1

3.2 Upgrading the USB Modem Software.........................................................................3-1

3.3 Managing the Configuration File ................................................................................3-2

3.4 Switching the Cela.C.M User......................................................................................3-2

3.5 Switching the Cela.C.M Language..............................................................................3-2

4 Viewing Information of the USB Modem........................................................4-1

4.1 Viewing the Device Information.................................................................................4-1

4.2 Viewing the Connection Information..........................................................................4-1

5 FAQ .........................................................................................................................5-1

6 Acronyms and Abbreviations.............................................................................6-1

Online Help 1 Getting to Know Your USB Modem

Issue 03 (2009-03-10) Huawei Proprietary and Confidential

1 Getting to Know Your USB Modem

1.1 Functions and Features

EchoLife WiMAX USB Modem (hereinafter referred to as the USB Modem) is

applicable to the Worldwide Interoperability for Microwave Access (WiMAX) network.

In areas covered by the network, you can enjoy the high-performance broadband

network services anywhere and anytime. You can wirelessly surf the Internet with brand

new experiences.

High Speed

zSupporting the IEEE802.16e-2005 WiMAX air interface.

zSupporting downlink throughput rate of up to 15 Mbit/s and uplink throughput rate

of up to 5 Mbit/s.

Portable and Fashionable Design

zProviding user-friendly user interface.

zSupporting upgrading of the device driver.

zSupporting plug and play.

zProviding fashionable and elegant appearance.

1.2 Connecting the External Antenna

If you need to connect the external antenna to your USB Modem, do as follows:

Step 1 Power off the USB Modem.

Step 2 Pull out the plastic plug on the side of the USB Modem and connect the external antenna

to the USB Modem.

Step 3 Put the external antenna in an open space without any surrounding obstacles, so that the

network signals are not affected.

----End

1 Getting to Know Your USB Modem Online Help

1-2 Huawei Proprietary and Confidential

zDo not place the external antenna outdoors.

zIt is preferred to connect the external antenna to the antenna interface not close to the USB

port.

zDuring lightning weather, stop using the external antenna, and disconnect it from the USB

Modem.

1.3 Requirements on PC Configuration

Your PC must meet the following configuration requirements for using the USB Modem.

If the configuration of your PC cannot meet the requirements, the operating performance

of the USB Modem may be degraded.

Item Configuration

Memory 128 MB RAM or above

Free hard disk space 50 MB or above

Operating system zWindows XP (with Service Pack 2 or a patch of later

version)

zWindows Vista

USB interface USB 2.0 full speed

Display resolution 800 × 600 or above. 1024 × 768 is recommended.

Online Help 2 Installing the USB Modem

Issue 03 (2009-03-10) Huawei Proprietary and Confidential

2 Installing the USB Modem

2.1 Connecting the USB Modem

zEnsure that the PC is powered on when you connect the USB Modem to the PC.

Otherwise, the USB Modem cannot be used normally.

zUse the delivery-attached cable. A USB extension cable or an extra-long USB cable

may cause shortage of power supply, thus making the device unserviceable.

zDuring lightning weather, power off the USB modem and disconnect it from the

computer.

Figure 2-1 Connecting the USB Modem

To connect the USB Modem to the PC, do as follows:

Step 1 Power on the PC.

Step 2 Use a USB cable to connect the USB Modem to the PC. See Figure 2-1 for the

connection details.

If the USB Modem is used for the first time, the system prompts you to install the

Cela.C.M . For details, see section 2.3 "Installing the Cela.C.M." After the USB Modem

is connected to the PC, if the USB Modem accesses the network normally, it displays

on the system tray, indicating that network connection is established. If the USB

Modem cannot access the network normally, it displays on the system tray,

indicating that network connection is not established.

----End

2 Installing the USB Modem Online Help

2-2 Huawei Proprietary and Confidential

You need to enable the function to show icon in notification area when connected in the Local

Area Connection Properties window.

2.2 Removing the USB Modem

Do as follows to remove the USB Modem from the PC. Otherwise, the operating system

of your PC may be damaged even in standby mode.

zIf is not displayed on the system tray, perform the following steps:

Step 1 Quit the Cela.C.M.

Step 2 Disconnect the USB Modem or the connector of the USB cable from the PC.

----End

zIf is displayed on the system tray, perform the following steps:

Step 1 Double-click on the system tray. The system prompts "Safely remove hardware."

Step 2 Stop running the corresponding hardware of the USB Modem on the device manager.

Step 3 Disconnect the USB Modem or the connector of the USB cable from the PC after the

system prompts that you can remove the hardware safely.

----End

2.3 Installing the Cela.C.M

The Cela.C.M is the program used to configure the USB Modem parameters. Take the

Windows XP operating system as an example, to install the Cela.C.M, do as follows:

Step 1 Power on the PC.

Step 2 Use a USB cable to connect the USB Modem to the PC.

Step 3 The system prompts that new hardware is found and prompts you to install the Cela.C.M.

Step 4 Install the Cela.C.M according to the prompts.

Step 5 When you finish installing the Cela.C.M, it displays on the system tray.

----End

2.4 Uninstalling the Cela.C.M

You can uninstall the Cela.C.M by two methods:

Online Help 2 Installing the USB Modem

Issue 03 (2009-03-10) Huawei Proprietary and Confidential

From the Program

Step 1 Quit the Cela.C.M.

Step 2 Choose Start > All programs.

Step 3 Find the Cela.C.M, select Uninstall.

Step 4 Uninstall the Cela.C.M according to the prompts.

----End

From the Control Panel

Step 1 Quit the Cela.C.M.

Step 2 Choose Start > Control Panel > Add/Remove Programs.

Step 3 Click Change/Remove Programs.

Step 4 Find the Cela.C.M, click Change/Remove.

Step 5 Uninstall the Cela.C.M according to the prompts.

----End

After the Cela.C.M is uninstalled, restart the PC to ensure complete removing of the Cela.C.M

from the PC.

2.5 Introduction to the Icons

Icon Description

Information such as the base station identifier (BSID), the

carrier-to-interference-and-noise ratio (CINR), the connecting time,

the data information, and the IP address information.

Enter the user name and password to connect the network for the

first time. Switch the Cela.C.M user.

Information such as the device name, the S/N, the MAC address, the

device software version, and the device state.

Importing and exporting the configuration file, and upgrading the

software.

Information about the Libyamax C.M information.

Indicating the network signal strength.

Table des matières

Autres manuels Huawei Modem

Huawei

Huawei E353S-6 Manuel utilisateur

Huawei

Huawei E5830 Manuel utilisateur

Huawei

Huawei EC1705 Manuel utilisateur

Huawei

Huawei E392 Manuel utilisateur

Huawei

Huawei Mobile Broadband USB Modem Stick Lite Manuel utilisateur

Huawei

Huawei LTE E8372 Manuel utilisateur

Huawei

Huawei HiLink K3773 Manuel utilisateur

Huawei

Huawei E169 Feuille d'instructions

Huawei

Huawei e3276 Manuel utilisateur

Huawei

Huawei E220 Guide de l'utilisateur

Huawei

Huawei K3565 Manuel utilisateur

Huawei

Huawei H352-381 Manuel utilisateur

Huawei

Huawei E270 Manuel utilisateur

Huawei

Huawei EchoLife BM325 Manuel utilisateur

Huawei

Huawei Vodafone USB 4G Manuel d'installation et d'exploitation

Huawei

Huawei E3372 Manuel utilisateur

Huawei

Huawei E156B Manuel utilisateur

Huawei

Huawei E1612 Manuel utilisateur

Huawei

Huawei E3372 Caractéristiques techniques

Huawei

Huawei EC1260 Manuel utilisateur

Huawei

Huawei USB 3G Manuel d'installation et d'exploitation

Huawei

Huawei E272 Manuel utilisateur

Huawei

Huawei HiLink E3131 Caractéristiques techniques

Huawei

Huawei E173 Caractéristiques techniques

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
