Huawei Mobile WiFi Manuel utilisateur

Inserting the SIM and Battery � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 2

Getting the SSID and Wi-Fi Key � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3

Windows Installation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4

Apple Mac OSX Installation � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 9

Changing the SSID � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �10

Changing the Wi-Fi Key � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �13

User Guide

ACN Mobile Wi-Fi™

Mobile Wi-Fi™

User Guide

Inserting the SIM and Battery

Note: Before inserting the battery and SIM note down the SSID and Wi-Fi Key

1. Press the button and hold at the

top of the modem – (a)

Pull the back cover o while still

holding the button – (b)

2. Insert the SIM with the ACN Logo

Facing you and the cut o corner

at the top left

3. Install the battery by inserting the

contact end rst – (a)

Then click the battery down – (b)

4. Replace the back cover onto the

Pocket Wi-Fi

Mobile Wi-Fi™

User Guide

Getting the SSID and Wi-Fi Key

1. Remove the back cover and the modem

2. Find and write down the SSID and WIFI key from the label.

3. Insert the SIM with the ACN Logo Facing you and the cut o corner at the top left

4. Insert the battery and replace the back cover.

5. Powering on the device by pressing and holding the power button.

Remember: It can take 10-15 seconds for the Modem to turn on and be ready to use.

6. Press the Wi-Fi/WPS Button

7. Scan for the SSID on your device found in step 2 and connect

8. Enter the WIFI Key found in step 2.

9. And you now should be online.

Mobile Wi-Fi™

User Guide

Windows Installation

• Please make sure the modem is powered on.

• After connecting the modem’s USB cable to your computer, information balloons will

appear from your System Tray (Located down the bottom right hand corner) and will

install necessary drivers and once nished, the nal balloon will notify that

“Your Device is Ready To Use”

• Then the Auto Play window will pop up and please click on Run Auto Run.exe

• For Windows Vista and Windows 7 from this point another window named User

Account Control might appear asking to Allow the Data Card Setup and please click

on Yes and then the Setup Software will run.

• If the software does not run automatically, go to “My Computer”, which should be

located on your Windows desktop.

• Browse to the disk drive labelled “Mobile Partner” and Double-click on

“Run AutoRun.exe”, to start the installation program.

1. Click the Next button to get things going.

Mobile Wi-Fi™

User Guide

2. Please read, and agree to, the Software Licence Agreement and leave the

installation directory unchanged. The software will start to install, and a progress

screen will be displayed.

3. Once the software and drivers have installed, click Finish

Mobile Wi-Fi™

User Guide

4. Your computer will now use the new software to properly configure your modem.

Please wait until the software tells you it is finished. An information balloon will

pop up from your System Tray area to advise you of this. This process may take

several minutes.

5. When the install is finished the Auto Play Window will pop up again and you will

need to click on Run Auto Run.exe and then Mobile Partner client connection

software will start.

If the software doesn’t start, double click the ‘Mobile Partner’ on the desktop.

6. Before connecting you will now need to setup the APN

• Click Tools > Options

Mobile Wi-Fi™

User Guide

• Click ‘Prole Management’

• Click ‘New’

• Enter Prole name as ‘ACN’

• APN > Select ‘Static’ and type the word ‘connect’

• Click ‘OK’

Mobile Wi-Fi™

User Guide

7. Now you can click the ‘connect’ button

Mobile Wi-Fi™

User Guide

Apple Mac OSX Installation

After connecting the USB Modem, the software on the modem will be loaded

automatically allowing you to start the software installation.

1. Double-click Wireless Broadband to begin the installation.

2. The installation application will open, Click Continue to proceed.

3. Please read the Software Licence Agreement and click Continue to proceed.

4. If you agree to the terms of the Software Licence Agreement, click Agree to proceed.

5. Click Install (recommended) performing a standard installation or Change Install

Location (advanced) if you wish to change the default installation directory.

6. You will be prompted for an administrator password to allow the software package

to be installed. In most cases this will simply be the password you use to log onto the

computer. Click OK to continue.

7. When you see the message “Install Succeeded”, click Close to nish.

8. Your computer will now start the ACN Mobile Partner software which is already

congured for the ACN Mobile network.

9. Click the Connect button to establish a connection.

Note: At this point you may receive a “New Network Interface” prompt. If so, click

Network Preferences, then click Apply and close the Network Preferences window.

10. You should now have a “Connection Successful!” message in the ACN Broadband

software. Click OK.

11. Open your preferred Internet Browser (e.g. Safari).

Mobile Wi-Fi™

User Guide

Changing the SSID

To personalise your Mobile Wi-Fi you can change the SSID to a name of your choice. To do

this you will need to follow the steps below.

Please ensure you are connected to the modem by Wi-Fi or USB cable before proceeding.

Once you are connected to the Mobile Wi-Fi;

• Open your browser, this can be Internet Explorer, Mozilla Firefox etc

• Enter the http://192.168.1.1 into the address bar and press enter

The following screen will be displayed, this is the modem interface.

• Enter the Password: admin (lower case)

• Click ‘Login’
