View

Instra

Broadband Series Test System

HP E1663A

SONET/SDH Electrical Interface

User’s Guide

SERIAL NUMBERS

This manual applies directly to instruments with serial numbers preﬁxed

3114U. For additional important information about serial numbers, see

Chapter 1.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

The information contained in this document is subject to change without notice.

HEWLETT-PACKARD MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE.

Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages

in connection with the furnishing, performance, or use of this material.

A copy of the specific warranty terms applicable to your product and replacement parts can be obtained

from your local Sales and Service Office.

The printing date will change when a new edition is printed. Minor changes may be made at reprint

without changing the printing date. Manual updates may be issued between editions to correct errors or

to document product changes. To ensure that you receive these updates or new editions, see your

Hewlett-Packard sales representative for details.

arranty

story

opyr

Hewlett-Packard Company

IDACOM Telecommunications Operation

11120 - 178 Street

Edmonton, Alberta

Canada T5S 1P2

We want to hear from you. If you have any

comments, questions, or suggestions about our

documentation, you may send them to the

following email address:

[email protected]

Call your local HP representative, or:

Tel: 1-800-661-3868 (In North America) Tel: 403-430-2770 (Outside North America)

Fax: 403-430-2601 Email: [email protected]

Product support

Printed in Australia

Manual Name: SONET/SDH Electrical Line Interface User’s Guide

Manual Part Number: E1663-90003

Product Part Number: E1663A

Edition Publication Date Application Version

Edition 1 January 1995 A.01.00

Edition 1A Rev. 1 July 1997 A.01.00

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

iii

Contents

1 Introduction

Overview 1-3

Module Identification 1-3

Control Panel at a Glance 1-4

Receiver 1-4

Front Panel at a Glance 1-5

Functional Features 1-6

Transmitter 1-6

Receiver 1-7

Monitor Point Access 1-7

Equalization 1-7

Clock Recovery and Decoding 1-7

ESD Precautions 1-8

Service 1-9

Exchange Program 1-9

Storage and Shipment 1-10

Packaging Requirements 1-10

2 Getting Started

Overview 2-2

Connecting to an Optical Line Interface 2-4

Connecting to the System Under Test 2-5

Starting a Test Session 2-6

3 C Function Reference

Electrical Interface Library 3-3

Library Initialization 3-3

Amplifier Gain Setup 3-3

4 Specifications

Electrical Specifications 4-3

Mechanical Specifications 4-6

Standards 4-7

Index

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Contents

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Figures

Figure 1.1 Typical Configuration 1-6

Figure 2.1 Module address settings 2-4

Figure 2.2 Interconnecting the modules 2-6

Figure 2.3 Connecting to the system under test 2-7

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Figures

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1-2

Introduction

This chapter provides an overview of the HP E1663A SONET/SDH Electrical

Interface. It covers:

• a general description of the Electrical Interface, including identiﬁcation and

accessories

• the Control panel

• the front panel indicators and connectors

• the functional features

• safety considerations

• ESD precautions

• service

• storage and shipment

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1-3

Overview

The HP E1663A SONET/SDH Electrical Interface is a member of the HP Broad-

band Series of modular VXI-based B-ISDN test instruments. The HP E1663A acts

as the interface between the HP Broadband Series Test System and the System

Under Test, transmitting and receiving 155.52 Mb/s or 52 Mb/s SONET/SDH trans-

mission signals.

The HP E1663A is used in conjunction with the HP E1697A 155 Mb/s Optical Line

Interface or the HP E1617A 52 Mb/s Optical Line Interface, and communication

between the modules is by SMA to SMB Radio Frequency (RF) adaptor cables.

See “Connecting to an Optical Line Interface”, page 2-4.

The Electrical Interface provides signal encoding at the appropriate levels and

format required by the System Under Test. Data is transmitted in the binary CMI

(Coded Mark Inversion) format at 155.52 Mb/s or 52 Mb/s.

The data stream received from the System Under Test is CMI at 155.52 Mb/s or 52

Mb/s. The clock is recovered from the incoming data, and automatic compensation

for cable loss and signal loss is provided.

Module Identiﬁcation

An identiﬁcation label is attached to the Electrical Interface clamshell enclosure.

The serial number is in the form “0000U00000'”. It is in two parts: the ﬁrst four

digits and the letter are the serial preﬁx, and the last ﬁve digits are the sufﬁx. The

preﬁx is the same for all identical modules and changes only when a change is

made to the module. The sufﬁx, however, is assigned sequentially and is unique to

each module. The contents of this manual apply to instruments with the serial

preﬁx(es) listed under SERIAL NUMBERS on the title page.

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
