06/03 34-ST-99-22 (Addendum to 33-ST-25-14B) 1 of 8

ST 3000 Smart Transmitter,

Release 300 and Smart Field

Communicator Model STS103

Transmitter Models:

STD110, STD120, STD130, STD170, STD924,

STD930, STD974

34-ST-99-22

06/03

Addendum

(to User’s Manual

34-ST-25-14B)

Overview Replacement Meterbody and Heads

The ST 3000 Pressure Transmitter, Models:

·STD110, STD120, STD130, STD170, and STD974

·STD924 and STD930 with Tantalum and Monel diaphragms

is now being shipped with newly designed meter body and process heads. If a

replacement meter body is needed, it should be ordered from the Model Number stated

on the meter body nameplate. This meter body replacement number will start with

STD110S-xxx...

This new transmitter is functionally identical to previous models in that the working

ranges (Lower Range Limit to Upper Range Limit) and intended applications have not

changed. However, the specifications for the maximum Pressure Rating and for the

Overpressure Rating have been enhanced in all models except the draft range

transmitter. A summary of specifications is given in Table 6.

The new versions, which will continue as Models STD110, STD120, STD130,

STD170, STD924, STD930, and STD974, differ only in the physical size and form of

the meter body, process head, and associated components.

With exceptions noted in this addendum, information given in User’s Manual

34-ST-25-14B applies also to this newer design.

Installation, operation, maintenance, calibration, and troubleshooting tasks remain

virtually the same as for the previous version. Differences appear primarily in torque

specifications when replacing meter bodies, and in part numbering and part

recognition when replacing components or assemblies.

Publications

This addendum provides details for parts replacement that span a variety of

applications of the Models STD110, STD120, STD130, STD170, STD924, STD930,

and STD974.

For Series 100 Models ST 3000 Smart Pressure Transmitter

Series 100 Differential Pressure Models

Specification and Model Selection Guide

34-ST-03-60

For Series 900 Models ST 3000 Smart Pressure Transmitter

Series 900 Differential Pressure Models

Specification and Model Selection Guide

34-ST-03-65

2 of 8 34-ST-99-22 (Addendum to 33-ST-25-14B) 06/03

Additions to the

User Manual The additions and changes to User Manual 34-ST-25-14B that relate to the newly

designed meter body and process heads are given in Table 1 of this addendum.

Use the information in Table 1 to reference and annotate your User Manual.

Table 1 Additions/Changes to the User Manual

Page # in User

Manual

Sub-Section Description of Change

21 3.3 Considerations for ST 3000

Transmitter

Table 6 Transmitter

Overpressure Ratings

The Maximum Working Pressure Rating and the

Overpressure Rating has been enhanced for all

models included in this addendum except for the

draft range transmitter.

For more information, refer to Table 6 in this

Addendum.

41 4.3 Piping ST3000 Transmitter

Table 15 Installing Flange

Adapter

In Step 5, do not use the torque specification of 47.5

to 54 N∙m(35 to 40 lb-ft).

Instead, torque Flange Adapter bolts evenly to

47,5 N·m +/- 2,4 N·m (35 Lb-Ft +/- 1.8 Lb-Ft).

174 9.3 Inspecting and Cleaning

Barrier Diaphragms

Table 54 Process Head Bolt

Torque Ratings

In Step 8, do not use specifications for head bolt

torque given in Table 54.

Instead, torque head bolts/nuts to the specifications

given in Table 2 of this addendum.

179/180 9.5 Replacing Meter Body

Table 56 Replacing Meter Body

Only

In Step 9, the reference to Table 48 for applying

torque to head bolts/nuts should be as given in

Table 2 of this addendum.

214-217 12.1 Replacement Parts

Figure 57 and Table 71

Figure 57 illustrates the replacement parts available

for the previous design of meter body and process

heads, and Table 71 provides part numbers and

descriptions for the parts called out in Figure 57.

For the newly designed meter body and process

heads, use Figure 1 of this addendum to locate

replacement parts, and use Table 3 of this

addendum for part numbers and descriptions.

For applicability of parts, refer to the appropriate

Manuals, following.

ST 3000 Smart Transmitter

Series 100 Differential Pressure Models

Specification and Model Selection Guide

34-ST-03-60

ST 3000 Smart Pressure Transmitter

Series 900 Differential Pressure Models

Specification and Model Selection Guide

34-ST-03-65

06/03 34-ST-99-22 (Addendum to 33-ST-25-14B) 3 of 8

Table 2 Torque Table - Process Head Bolts/Nuts

Bolt Type

Meterbody Type 51452557-001

(Carbon Steel)

5142557-002 and -003

(NACE and Non-NACE

Stainless Steel)

51452557-004

(B7M Alloy Steel)

51451864XXXX, NOT

XX5

(All Transmitter except

Draft Range)

67,8 N•M +/- 3,4 N•M

(50.0 Lb-Ft +/- 2.5 Lb-

Ft)

56,9 N•M +/- 2,8 N•M

(42.0 Lb-Ft +/- 2.1 Lb-Ft)

48,8 N•M +/- 2,4 N•M

(36.0 Lb-Ft +/- 1.8 Lb-Ft)

51451864XX5

(Draft Range Transmitter

only)

20,3 N•M +/- 1,0 N•M

(15.0 Lb-Ft +/- 0.8 Lb-

Ft)

20,3 N•M +/- 1,0 N•M

(15.0 Lb-Ft +/- 0.8 Lb-Ft)

20,3 N•M +/- 1,0 N•M

(15.0 Lb-Ft +/- 0.8 Lb-Ft)

Figure 1 ST 3000 Model STD110, STD120, STD130, STD170, STD924, STD930, STD974

(Rev S or greater)

4 of 8 34-ST-99-22 (Addendum to 33-ST-25-14B) 06/03

Table 3 Parts Identification for Callouts in Figure 1

Key

No.

Part Number Description Qty/

Unit

1Specify complete

model number from

nameplate plus R300

Series 100 replacement meter body without heads 1

Specify complete

model number from

nameplate plus R300

Series 900 replacement meter body without heads 1

51452866-001

51452866-002

51452866-003

51452866-004

································

Bolts and Nuts Kit, Carbon Steel

Bolts A286 SS (NACE) and Nuts, 304 SS (NACE) Kit

Bolts 316 SS (non-NACE) and Nuts 304 SS (NACE) Kit

Bolts B7M and Nuts 7M Kit

Each Bolts and Nuts Kit includes:

Bolt, Hex head, 7/16-20 UNF, 1.50 Inches long (Flange Adapter)········

Nut, Hex, 7/16 UNC (Process Head)····················································

Bolt, Hex Head, 7/16 UNC X 3.25 inches long (Process Head)············

30753785-001

30753787-001

30753786-001

································

Drain and Plug Kit, stainless steel

Drain and Plug Kit, Monel

Drain and Plug Kit, Hastelloy C

Each Drain and Plug Kit includes:

Pipe Plug ····················································································

Vent Plug ·····························································································

Vent Bushing ·······················································································

51452865-001

51452865-002

·································

Meterbody Gasket Kit (PTFE Material); Kit includes:

Meterbody Gasket Kit (Viton Material); Kit includes:

Gasket, Process Head ·········································································

Gasket, Flange Adapter ·······································································

O-Ring, Meterbody to Electronics Housing ··········································

51452868-001

51452868-002

Gasket only, Process Head (12 PTFE Gaskets/pack)

Gasket only, Process Head (6 Viton Head O-Rings)

51452868-004

51452868-005

Gasket only, Flange Adapter, 6 PTFE Adapter Gaskets

Gasket only, Flange Adapter, 6 VITON Adapter O-Rings

06/03 34-ST-99-22 (Addendum to 33-ST-25-14B) 5 of 8

Table 4 Flange Adapter Kits

Key

No.

Part Number Description Quantity

Per Unit

51452867-110

51452867-210

51452867-310

51452867-410

51452867-150

51452867-350

51452867-130

51452867-330

···································

Flange Adapter Kit, with:

SS Flange Adapters and with carbon steel bolts

SS Flange Adapters and with A286 SS (NACE) bolts

SS Flange Adapters and with 316 SS (non-NACE) bolts

SS Flange Adapters and with B7M alloy steel bolts

Monel Flange Adapters and with carbon steel bolts

Monel Flange Adapters and with 316 SS (non-NACE) bolts

Hastelloy C Flange Adapters and with carbon steel bolts

Hastelloy C Flange Adapters and with 316 SS (non-NACE) bolts

Each 1/2-inch NPT Flange Adapter Kit includes:

Gasket, Flange Adapter ································································

1/2-inch NPT Flange Adapter ·························································

Bolt, hex head, 7/16-20 UNF, 1.50 inches long, Flange Adapter ··

51452867-100

51452867-200

51452867-300

51452867-400

···································

SS Blind Flange Adapter Kit, with Carbon Steel bolts

SS Blind Flange Adapter Kit, with A286 SS (NACE) bolts

SS Blind Flange Adapter Kit, with 316 SS (non-NACE) bolts

SS Blind Flange Adapters and B7M alloy steel bolts

Each Blind Flange Adapter Kit includes:

Gasket, Flange Adapter ································································

Blind Flange Adapter ······································································

Bolt, hex head, 7/16-20 UNF, 1.50 inches long, Flange Adapter ··

6 of 8 34-ST-99-22 (Addendum to 33-ST-25-14B) 06/03

Table 5 Process Head Assembly Kits

Key

Part Number Description Quantity

Per Unit

51452864-010

51452864-012

51452864-020

51452864-022

51452864-030

51452864-032

51452864-040

51452864-042

51452864-110

51452864-112

51452864-120

51452864-122

51452864-130

51452864-132

51452864-140

51452864-142

···································

Process Head Assembly Kit, with PTFE Gasket and with:

Carbon steel head without side vent/drain

Carbon steel head with side vent/drain

Stainless steel head without side vent/drain

Stainless steel head with side vent/drain

Hastelloy C head without side vent/drain

Hastelloy C head with side vent/drain

Monel head without side vent/drain

Monel head with side vent/drain

Process Head Assembly Kit, with VITON Gasket and with:

Carbon steel head without side vent/drain

Carbon steel head with side vent/drain

Stainless steel head without side vent/drain

Stainless steel head with side vent/drain

Hastelloy C head without side vent/drain

Hastelloy C head with side vent/drain

Monel head without side vent/drain

Monel head with side vent/drain

Each Process head Assembly Kit includes:

Pipe Plug (See Note.)···································································

Vent Plug (See Note.)············· ·····················································

Vent Bushing (See Note.)·····························································

Process Head ··············································································

Gasket (PTFE), Process Head ····················································

Gasket (PTFE), Flange Adapter···················································

NOTE: This item is made of the same material as the

Process Heads, except for Kits with carbon steel Process

Heads, which include stainless steel Pipe Plug, Vent Plug,

and Vent Bushing.

06/03 34-ST-99-22 (Addendum to 33-ST-25-14B) 7 of 8

Table 6 Pressure Specification and Ratings Summary Comparisons

Maximum Working

Pressure Rating

(Note 1)

Overpressure Rating

(Note 1)

Transmitter

Model

Upper Range

Limit

Previous New Design Previous New Design

STD110 10 inches H2O

(25 mbar)

50 psi

(3.5 bar)

(Same as

previous)

50 psi

(3.5 bar)

(Same as

previous)

STD120,

STD924

400 inches H2O

(1 bar)

3000 psi

(207bar)

4500 psi

(310 bar)

3000 psi

(207 bar)

4500 psi

(310 bar)

STD130,

STD930

100 psi

(7 bar) """"

STD170,

STD974

3000 psi

(207 bar) ""'" "

Note 1 Maximum Working Pressure Rating and Overpressure Rating vary with materials of construction;

for more specific information refer to the appropriate Product Specification Guide.

8 of 8 34-ST-99-22 (Addendum to 33-ST-25-14B) 06/03

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Honeywell Émetteur

Honeywell

Honeywell ADEMCO 5805-6 Manuel utilisateur

Honeywell

Honeywell ZR530 Manuel utilisateur

Honeywell

Honeywell ADEMCO 5878 Instructions de montage

Honeywell

Honeywell ST 800 Series Manuel utilisateur

Honeywell

Honeywell KEGS5000 Manuel utilisateur

Honeywell

Honeywell SmartLine SLG 700 Manuel utilisateur

Honeywell

Honeywell ADEMCO 5869 Manuel utilisateur

Honeywell

Honeywell XNX-AM Series Manuel utilisateur

Honeywell

Honeywell ADEMCO 5878 Instructions de montage

Honeywell

Honeywell Midas-M Manuel utilisateur

Honeywell

Honeywell ADEMCO 5816AP Instructions de montage

Honeywell

Honeywell ST 3000 Instructions d'installation et d'utilisation

Honeywell

Honeywell PEHA 450 FU-HS128 Manuel utilisateur

Honeywell

Honeywell SMV 3000 Manuel utilisateur

Honeywell

Honeywell RESCU 406AFN Guide de configuration

Honeywell

Honeywell XNX Manuel utilisateur

Honeywell

Honeywell SLN 700 Manuel utilisateur

Honeywell

Honeywell 5822T Manuel utilisateur

Honeywell

Honeywell 5894PI - Ademco Wireless PIR Motion Sensor Manuel utilisateur

Honeywell

Honeywell oneWireless XYR 6000 Manuel utilisateur

Honeywell

Honeywell 5834-4 Series Instructions de montage

Honeywell

Honeywell XNX Manuel utilisateur

Honeywell

Honeywell Ademco 5804AP Manuel utilisateur

Honeywell

Honeywell ADEMCO 5811 Manuel utilisateur

Manuels Émetteur populaires d'autres marques

NIVELCO

NIVELCO EasyTREK SCA-300 Series Manuel du propriétaire

Kamstrup

Kamstrup READy MTU Mode d'emploi

Omega

Omega ZW Series Manuel utilisateur

ABB

ABB Field 264H Mode d’emploi

Alinco

Alinco DJ-V17T Manuel utilisateur

Dejero

Dejero EnGo 3x Manuel utilisateur

Rosemount

Rosemount 4600 Manuel utilisateur

Speaka Professional

Speaka Professional 2342740 Manuel utilisateur

trubomat

trubomat GAB 1000 Manuel utilisateur

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Manuel utilisateur

Rondish

Rondish UT-11 Manuel utilisateur

MG 10JRE Manuel utilisateur

Burkert

Burkert 8177 Manuel utilisateur

Firetide

Firetide HotPort 3203 Manuel

Tele Radio

Tele Radio T9-02 Manuel utilisateur

Rotronic

Rotronic HygroFlex HF3 Series Manuel utilisateur

Jamara

Jamara FCX6 Pro Tel Manuel utilisateur

Excalibur

Excalibur SoundMaster FM Transmitter 144 Manuel utilisateur
