Installation Instructions ADEMCO 5811

One Zone Door/Window Transmitter

The 5811 is a single zone Door/Window Transmitter, compatible with alarm systems that support 5800 series wireless

devices. 5811 has a unique serial number permanently assigned during manufacture, which must be entered into the control

panel upon installation.

NOTES

•Refer to the panel’s installation instructions for programming details.

•During programming of the control unit, 5811 transmitters should be treated as “RF” (i.e. supervised RF) Type.

Mounting

Choose a mounting location for the 5811 where the device is stationary and the magnet is mounted to the moving part of the

door or window. To verify adequate signal strength conduct the Go/No Go test (see control’s instructions) on the 5811 before

mounting permanently.

1. Install the Battery by inserting one edge of the battery under one of the two plastic battery retainer clips, then pressing

down firmly to snap it beneath both clips; see figure 1.

2. Mount the 5811 using double-faced tape (supplied) by affixing it to the back of the unit and mounting the unit in place.

Use screws (optional) if desired; see figure 2. Mount the magnet (supplied) near the alignment marks on the case (see

Diagram).

Replacing an existing unit: The back mounting plate must be replaced when replacing the 5811. Use

standard installation practices when removing the unit to avoid any damage to the mounting surface.

3. Engage the case tabs (see figure 2), then rotate the housing to close. Engage the latch with firm pressure to close and

lock.

Battery Removal

1. Open the housing by inserting a flat blade screwdriver into latch and twisting gently.

2. Remove the old battery cell using a small flat screwdriver into the latch and gently twisting it until the cover becomes

removable (see figure 3).

Figure 1: Battery Installation

Figure 2: Mounting

Figure 3: Battery Removal

Specifications

Dimensions:

2-1/8” (55mm) x 1-3/16" (30mm) x 1/4” (7mm)

Operating Conditions:

23° F (-5° C) to 120° F (50° C)

Relative Humidity 95%, (non-condensing)

Replacement Battery:

Panasonic/Sener CR2032 and Duracell DL2032

NOTE: The FCC ID and IC Certification number is on the back of the plastic case, or see the diagram in the “Figure 3:

Battery Removal” section for the alternate location.

FEDERAL COMMUNICATIONS COMMISSION STATEMENT

The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or

User Manual. Unauthorized changes or modifications could void the user's authority to operate the equipment

FCC/IC STATEMENT

This device complies with Part 15 of the FCC Rules,

and RSS-210 of Industry Canada (IC). Operation is

subject to the following two conditions: (1) This device

may not cause harmful interference (2) This device

must accept any interference received, including

interference that may cause undesired operation.

Cet appareil est conforme à la partie 15 des règles de la FCC &

de RSS 210 des

Industries Canada. Son fonctionnement est

soumis aux conditions suivantes: (1) Cet appareil ne doit pas

causer d' interferences nuisibles. (2) Cet appareil doit accepter

toute interference reçue y compris les interferences causant une

reception indésirable.

SUPPORT & WARRANTY

For the latest documentation and online support information, please go to:

www.MyWebTech.Honeywell.com

For the latest warranty information, please go to:

www.honeywell.com/security/hsc/resources/wa.

MyWebTech

Warranty

2 Corporate Center Drive, Suite 100

P.O. Box 9040, Melville, NY 11747

www.honeywell.com/security

Ê800-03928V2oŠ

800-03928V2 4/15 Rev. C
