Honeywell HJ0CESWK7 Manuel utilisateur

Model:

HJ0CESWK7/

HJ2CESWK8/

HJ4CESWK9/

HJ5CESWK0

Portable Air Conditioner

User Manual

Read and save these instructions before use

Customer Support:

Web: www.jmatek.com

USA: 1-800-474-2147 | [email protected]

CANADA^: [email protected]

^ Canada Customer Support service available for models sold in Canada only.

•

Basic safety precautions should always be followed when

using electrical appliances.

Electrical equipment and installations regulated by national

legislation must be followed.

The appliance should be transported upright or on its side.

Do not turn on the appliance for at least one hour before

starting it.

DO NOT operate the unit with a damaged plug or loose wall

outlet. If the supply cord is damaged, it must be replaced

by the manufacturer, its service agent or similarly qualiﬁed

persons in order to avoid a hazard.

DO NOT cover the air intake and exhaust when in use.

DO NOT place objects, especially heavy or hot objects, on

top of unit. DO NOT sit on the unit.

Always turn off and unplug the unit when cleaning or

servicing.

DO NOT use the appliance if it is damaged.

Do not modify this appliance in any way to avoid danger.

If service is needed contact an authorized service agent.

Repairs must only be undertaken by authorized service

centres of the manufacturer. Failure to comply may be

dangerous.

Unplug the unit when stored or not in use.

DO NOT pull or carry the appliance by the power cord.

DO NOT pinch the power cord in the door and DO NOT pull

it along edges or sharp corners.

SAFETY

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY AND

KEEP FOR FUTURE REFERENCE. IN CASE THERE IS ANY

INCONSISTENCY OR CONFLICT BETWEEN THE ENGLISH

VERSION AND ANY OTHER LANGUAGE VERSION OF THE

CONTENT OF THIS MATERIAL, THE ENGLISH VERSION

SHALL PREVAIL.

WARNING:

SAFETY (CONTINUED)

Do not pierce or burn the unit.

It is essential that the appliance is connected to an efﬁcient

earth system checked by a qualiﬁed electrician.

Refrigerant gas may be odorless.

Stagnation of possible leaks of refrigerant gas in

unventilated rooms could lead to ﬁre or an explosion hazard

should the refrigerant come in contact with electric heaters,

stoves or other sources of ignition.

Use care when storing the appliance to prevent mechanical

faults.

Only persons authorized by an accredited agency certifying

their competence to handle refrigerants in compliance with

sector legislation should work on refrigerant circuits.

Maintenance and repairs requiring the assistance of

other qualiﬁed personnel must be carried out under

the supervision of specialists in the use of inﬂammable

refrigerants.

DO NOT use means to accelerate the defrosting process

or to clean, other than those recommended by the

manufacturer.

DO NOT run the power cord under carpeting and rugs.

Use caution to prevent tripping on cord.

DO NOT use the device in the following cases:

- in a room with continously operating sources of ignition

(eg. open ﬂames, an operating gas appliance or an

operating electrical heaters.

- In areas where gasoline, sulphur, oil, paint or other

ﬂammable goods are stored.

- In an area where the water can be projected.

DO NOT touch the plug or the device with wet hands.

Flammable substances or pressurized containers (eg.

aerosol cans) should be kept a minimum of 50cms away.

This appliance has been manufactured for use in domestic

environments and should not be used for other purposes.

•

SAFETY (CONTINUED)

Use only implements recommended by the manufacturer

for defrosting or cleaning.

Only use the installation kit provided to install this unit.

DO NOT attempt to extend the hose or install this unit

using other methods other than that shown in this

manual. Improper installation will void any existing

warranties.

DO NOT use an extension cord with this unit.

This appliance can be used by children aged from 8 years

and above, and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning

use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by

children without supervision.

Never insert your ﬁngers or rods into the air outlet. Take

special care to warn children of these dangers.

The manufacturer is not liable for injury caused to

persons or property damage due to non-compliance

with maintenance instructions and improper use of the

appliance.

The appliance shall be installed in accordance with national

wiring regulations.

The appliance is not to be used by persons (including

children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction.

DO NOT operate your air conditioner in a wet room such as

a bathroom or laundry room.

This appliance should be used in a room that allows for

good ventilation between the unit and any walls/furniture or

other objects. The room size should correspond to the room

area as speciﬁed for operation by the manufacturer and

the appliance should be well kept to prevent mechanical

damage.

•

SAFETY (CONTINUED)

A warning to keep ventilation openings clear of obstruction.

Do not pierce or burn the refrigerants.

Be aware that refrigerants may not contain an odor.

•

THANK YOU

Congratulations on your purchase of this Honeywell Portable Air Conditioner.

Regarding the information pertaining to the installation, handling, servicing, cleaning and disposal

of the appliance, please refer to the below paragraph of the manual.

USER TIPS

Portable Air Conditioners are ideal for spot cooling. The compressor, condenser and evaporator

are housed in a compact unit. The air is dehumidiﬁed and cooled while a ﬂexible hose sends heat

outside. The Portable Air Conditioner includes a window venting kit.

No permanent installation is needed. The unit is easy to move from room to room and offers a truly

ﬂexible air conditioning solution.

Auto Evaporation System - The unit automatically evaporates the condensate through the hose.

There is no need to empty the drainage tank except in humid conditions. Read and follow the

instructions carefully.

To ensure optimal efﬁciency of the product, keep doors and windows closed when it is used as an air

conditioner or dehumidiﬁer. If the product is being used with the fan function only, an open window

could improve air circulation.

Important:

Before installing the unit, place it UPRIGHT for 1 hour before use to allow the refrigerant to stabilize.

Air outlet automatically opens when the unit is turned on, and automatically closes when the unit is

turned off. Manually adjust the air vent located at the top of the unit to adjust the direction of air ﬂow.

Follow installation instructions to set up the unit.

Plug the unit into a properly grounded circuit. DO NOT plug into an extension cord.

•

Cooling and Dehumidifying

Operation Fan Operation

PARTS DESCRIPTION

1) Control Panel 9) Upper Rubber Drain Plug

(Dehumidifying Mode)

2) Air Outlet 10) Lower Dust Filter

3) Handle 11) Drain Tube

(For Continuous Drain)

4) Casters 12) Drain Plug Cap

5) Remote Control 13) Lower Rubber Drain Plug

(Air Conditioning Mode)

6) Hose Connector 14) Power Supply Cord

7) Cord Winder

8) Upper Dust Filter

3EN

INSTALLATION

It is important that the installation instructions below are followed for successful installation of this

Portable Air Conditioner. Please call Customer Support if you have any difﬁculties or queries

regarding these installation procedures.

Installation Kit:

Installation Steps:

Exhaust Hose Connector, Exhaust Hose and window bracket panel adapter are pre-assembled

inside the package.

1. Window Bracket Kit (1 Set) 4. Exhaust Hose (1 Piece)

2. Window Bracket Panel Adapter (1 Piece) 5. Drain Tube (1 Piece)

3. Exhaust Hose Connector

LOCKUNLOCK

UNLOCKLOCK

4 5

1 3

x1 x1

Hose:

Length: 10.23'' to 47'' (26cm to 120cm)

4EN

INSTALLATION (CONTINUED)

2. Connect the hose to the rear exhaust outlet on the back of the unit. Slide-in the hose connector

then rotate clockwise until it is locked in place.

Note: After setting the window bracket to the size of your window, please remove it from the window

and follow the instructions below.

Hose:

Dia.5.9'' (15cm)

Length: 10.23'' to 47'' (26cm to 120cm)

Window Bracket Kit:

This window kit is designed to ﬁt most standard sliding windows. If your window is outside of the

size parameters as outlined above, the window bracket can be cut shorter to ﬁt by bringing it to a

nearby hardware store.

Horizontal Sliding Window Vertical Sliding Window

Part A:

Min. Length 19.7" (50 cm)

Part A + B:

Min. Length 19.7" (50 cm)

Max. Length 38.2" (97 cm)

Part B

+ =

5EN

INSTALLATION (CONTINUED)

Horizontal Sliding Window Vertical Sliding Window

5. The Portable Air Conditioner is now ready to use.

4. Connect the window bracket to the window.

3. Connect the window bracket to the window bracket panel adapter. Ensure that all connections are

tight and installed properly.
