OVERVIEW
The HELTUN HE-TPS01 Advanced Programmable Touch Panel Switch “Solo” brings ‘Impossibly
Smart’ capabilities to your home lighting, electric outlets, door locks and valves. It replaces an
existing in-wall switch and brings over-the-Internet monitoring, control, and advanced
programmability to one connected device. Solo is ‘Impossibly Thin’ on the wall yet packed with
features to provide the ultimate in control and convenience.
Controls system with up to 5A load
Thanks to Solo’s independent relay channel input it allows control of systems with any power source needs or use of relay output as dry
contacts. The relay can be loaded up to 5 Amps.
Connects to Z-Wave lights and dimmers
Solo is an excellent choice for managing lighting systems. It allows connection to Z-Wave lights and dimmers controlling both On and O,
as well as smooth brighten (Up) and smooth dim (Down) states. Dimmer levels can be tied to Solo’s button backlight to provide feedback
of connected light state (On/O).
Controls devices
Solo can also be used to manage water valves, or window and door locks. It also allows association with relay switches to control
connected devices. If door/window sensors are installed, they may be associated with Solo backlight, enabling it to indicate device state
(Open/Closed).
Touch panel button has multiple functions
Solo has one high sensitivity capacitive touch button with two-color backlights (red/blue). 10 backlight brightness levels can be
congured manually or set to automatically adjust to ambient light conditions making it always easy to see.The button can be congured
to control relay output state in any of nine dierent modes.
Five ways to trigger programmed scenarios
An onboard Real Time Clock (RTC) enables Solo to trigger scenarios where connected device is set to a schedule. Another powerful feature
lets Solo trigger connected device scenarios when temperature, humidity, or light sensor values change. Solo button may also directly
trigger scenarios on controller — with each backlight indicating scene status.
Know how much energy you use
Solo can determine how much energy is used by connected device any particular day, week, or month. Just specify the consumption of
the load in watts for relay channel and the device logic will calculate total consumption relative to the time since the output was in the‘ON’
state.
Based on the latest Z-Wave platform
Solo integrates a Z-Wave Plus v2 700 platform module allowing it to be used with Z-Wave home automation systems. It supports Z-Wave
‘S0’and‘S2’security protocols, SmartStart technology, and can be connected (“associated”) to other Z-Wave devices, such as relays, motor
controllers, dimmers, etc.
5
TECHNICAL SPECIFICATIONS
Declaration of Conformity
Hereby, Heltun declares that the device is in compliance with directives:
EMC 2014/30/EU, LVD 2014/35/EU, RED 2014/53/EU, RoHS 2011/65/EU.
Front frame (on wall) dimensions: 89mm (H) х 89mm (W) х 9mm (D)
Rear electronics package dimensions: 53mm (H) х 53mm (W) х 28mm (D)
Materials: Tempered glass panel, Flame retardant plastic
5 frame colors: White, Gloss Black, Matte Black, Silver, Chrome
6 glass colors: White, Black, Yellow, Green, Red, Blue
1 capacitive-touch button
Red and Blue LED backlights for button
10 brightness levels (adjustable) for button backlight
Operating temperature: 0°С to +50°С
Operating humidity: 10% to 95% RH
Power supply: 85-265VAC 50Hz/60Hz or 24-48VDC
Power consumption: <1W
1 channel relay output with resistive load up to 5A
Independent relay input (dry contact)
Relay switching with zero-cross technology
Relay life time: 100.000 switches
Internal ambient light sensor
Internal temperature sensor
- Measurement range: –30°C to +80°C
- Accuracy: ±0.5°C
Internal humidity sensor
- Measurement range: 0% to 80% RH
- Accuracy: ±3.0% RH
Software energy consumption logic
IP class: IP21
Z-Wave Plus V2 SDK: V7.11
Z-Wave 700 module: ZGM130S
Requires mounting to ush electrical junction box:
round, square or rectangular type – min. depth 40mm
Placement of the HE-TPS01 is of utmost importance for proper operation and must be away from sunlight and sources of direct heat.
We recommend installing the HE-TPS01 approximately 1.5 meters above the oor.
Remove the touch panel unit and backplate of the HE-TPS01 from the packaging.
FIRST ENSURE THE POWER IS OFF at the main circuit breaker, and then test the wires with a probe or multimeter to verify. Insert the
wires to the correct HE-TPS01 terminals by inserting a small Phillips-head screwdriver into the slot beneath each terminal and unscrew
to open.
Follow connection diagrams on Figure 1 or 2 and the instructions below:
• Power wires: For AC power (85-265VAC) connect Line & Neutral lead wires to L & N terminals labeled “POWER”. For DC power
(24-48VDC) connect “+” wire to terminal L and“–”wire to terminal N.
• Source wire: Connect the required power source for relay to the terminal labeled“IN 1-3”.
• Load: Connect the required load to the relay output terminal labeled“OUT-1”.
Note: HELTUN recommends installing cord terminals (electric wire ferrules) on the ends of wires before connecting them to the
HE-TPS01 (various colors terminals are included).
Note: Zero-Cross technology is unavailable if the device uses DC voltage (24-48VDC).
Tighten wires using Phillips screwdriver in slot beneath each wire.
Making sure the HE-TPS01 backplate is oriented on the wall with the word“TOP”pointed upwards, secure the backplate to the electrical
junction box using the four provided screws (do not overtighten).
Once the backplate is secured onto the wall, assemble the HE-TPS01 touch panel unit onto the backplate by rst carefully aligning the
two top snap connectors, and then gently pushing the entire panel unit until it‘snaps’into position all the way around.
Next, switch On the main power at the circuit breaker. The HE-TPS01 will start up showing the original default factory settings.
Remove the clear protective lm from the touch panel unit by pulling on the top right-hand tab.
1.
2.
3.
4.
5.
6.
INSTALLATION
The HELTUN HE-TPS01 Touch Panel Switch ‘Solo’must be installed by a licensed electrician in a manner that conforms to local regulations
and building codes. Provide these instructions to the licensed electrician who is installing the HE-TPS01.
WARNING: Electrical power must be switched o during installation.
Note: The device security code (DSK) and SmartStart QR code are printed on the HE-TPS01 back panel plus on the included Security Card
(see Figures 7 & 8).
Z-WAVE NETWORK
The HE-TPS01 may be operated in any Z-Wave network with other Z-Wave certied devices from other manufacturers. The HELTUN
HE-TPS01 will act as a‘repeater’ for other devices regardless of manufacturer or brand to increase the reliability of the overall network.
Security
S0, S2 unauthorized, and S2 authorized Inclusion Modes are supported. If you use the S2 authorized Inclusion Mode the security key
should be used during the inclusion process. The Security Key is printed on a card located with this quick start guide and also on the
HE-TPS01 backplate (see Figures 7 & 8).
Note: Be sure to save this key. Without the key, it is impossible to perform an Inclusion in S2 authorized mode.
SmartStart
SmartStart-enabled products can be added to a Z-Wave network by scanning the Z-Wave QR Code shown on the product with
gateways/controllers that provide for SmartStart inclusion. In this case, no further action will be required and the SmartStart product will
be added automatically within ten minutes of being turned on in the vicinity of a network.
To add the HE-TPS01 to the Z-Wave network using SmartStart:
1.
2.
3.
To disassemble, ENSURE POWER IS SWITCHED OFF at the main circuit breaker AND THE LCD SCREEN IS BLANK.
To remove the HE-TPS01 touch panel unit grasp rmly at the bottom and pull backwards while tilting outwards until all tabs disconnect.
Remove screws from backplate and disconnect the wires by inserting a small Phillips-head screwdriver into the slot beneath each wire
and unscrewing to release.
DISASSEMBLY
1.
2.
3.
4.
5.
Set the main controller in Security S2 Authenticated“Add Mode”.
Input the Touch Panel Switch‘Solo’DSK to the controller (or scan the QR code).
Power on the device.
Wait for the adding process to complete.
Successful adding will be conrmed by a message on the Z-Wave controller.
