HBM DMP41 Manuel utilisateur

Interface description and command set

English

DMP41

Digital precicion measuring device

Hottinger Baldwin Messtechnik GmbH

Im Tiefen See 45

D-64293 Darmstadt

Tel. +49 6151 803-0

Fax +49 6151 803-9100

[email protected]

www.hbm.com

Mat.: 7-0102.0003

DVS: A03474_04_E00_00 HBM: public

03.2020

EHottinger Baldwin Messtechnik GmbH.

Subject to modifications.

All product descriptions are for general information only.

They are not to be understood as a guarantee of quality or

durability.

Table of Contents

DMP41 A03474_04_E00_00 HBM: public 3

Table of Contents

1 Documentation overview 5...............................................................

1.1 How to work with this manual 5........................................................

1.1.1 Operation with PC 6..........................................................

1.1.2 Chapter and appendix overview 7...............................................

2 Interface comparison 9..................................................................

3 Communication with the DMP 11..........................................................

3.1 Ethernet interface 11..................................................................

3.1.1 Ports and addresses used 13...................................................

3.1.2 Setting the Ethernet interface 13.................................................

3.2 USB HOST interface 15...............................................................

3.3 RS‐232 interface 15...................................................................

3.3.1 Activation of the RS‐232 interface 16.............................................

3.3.2 Setting the interface 17.........................................................

4 Program creation 19......................................................................

4.1 Communication via the Ethernet interface / Test program 19................................

5 Command set of the HBM interpreter 23...................................................

5.1 Important agreements 23..............................................................

5.1.1 Command structure 24.........................................................

5.1.2 Command structure 25.........................................................

5.1.3 Data output structure 26........................................................

5.1.4 Individual command descriptions 27..............................................

5.1.5 Administrator rights 28.........................................................

5.2 Communication 30....................................................................

5.2.1 Addressing 30.................................................................

5.2.2 Computer-DMP41 communication 33.............................................

5.2.3 Error control, status register 37..................................................

Table of Contents

4A03474_04_E00_00 HBM: public DMP41

5.2.4 Identification 38...............................................................

5.3 Amplifier settings 39...................................................................

5.3.1 Amplifier input 39..............................................................

5.3.2 Filter setting 42................................................................

5.3.3 Measuring range 45............................................................

5.3.4 Taring 49.....................................................................

5.3.5 Transfer of amplifier settings and comments 52....................................

5.4 Amplifier functions 56..................................................................

5.4.1 Output format, measured value output 56.........................................

5.4.2 Display functions 66...........................................................

5.5 Multi‐Client 72........................................................................

5.6 Other 75.............................................................................

Glossary 81....................................................................................

Functional command overview 83................................................................

Index 87........................................................................................

Documentation overview

How to work with this manual

DMP41 A03474_04_E00_00 HBM: public 5

1 Documentation overview

The complete production documentation of the precision measuring devices

DMP41 (DMP41-T2; DMP41-T6) comprises the following publications:

SThe operating manual 'Digital precision measuring device DMP41-T2,

DMP41-T6' (A3463)

explains the manual operation of the device

SThe operating manual 'Digital precision measuring device DMP41

Interface description and command set (A3462) explains programming

and measurement via terminal or computer, including all HBM interpreter

commands

Important

You are currently reading the ’Interface description and command set’

operating manual.

For operation as a ’stand-alone device’, please use the general operating

manual ’Digital precision measuring device DMP41−T2, DMP41−T6’

(A3470)

1.1 How to work with this manual

Before putting the device into operation please note the following

information:

Important

Please comply with the safety instructions in the operating manual Digital

precision measuring device DMP41 (document number A3470).

This manual - Operation with computer or terminal - is intended to help you

operate the DMP device via a computer as rapidly as possible. It is both

suitable for beginners without PC experience and for experts with computer

experience.

Documentation overview

How to work with this manual

6A03474_04_E00_00 HBM: public DMP41

Various guides are available to help you:

SThe table of contents at the beginning of the manual provide an initial

overview.

SThe header shows you which chapter or sub‐chapter you are currently

reading.

SExample:

SThe footer displays the name of the manual (Operating with computer or

terminal, Operating manual, etc.)

SThe page numbers are coupled with capital letters according to the

chapter designations. Each chapter starts with Page 1.

SIf you are looking for individual commands, it is best to refer to the

command overview in Appendix IV or Appendix V.

SThe keyword index contains an index register to help you orientate

yourself rapidly in the manual.

1.1.1 Operation with PC

This manual explains the operation of your HBM device with a computer.

SYou can implement all device settings by sending an appropriate

command sequence from the computer. Automation of repetitive

measurement sequences is possible with a computer and the

corresponding programs.

In order to match up the signals output from or required by the various

devices (computer, plotter, printer, measuring device, etc.), the devices

must be connected together via interfaces.

Interfaces are standardized so that devices from various manufacturers can

be used.

The DMP device can be operated via the following standardized interfaces:

SEthernet interface

SUSB port for RS232

Administrator rights are required for all measurement‐relevant settings

(see also Page 28)

Documentation overview

How to work with this manual

DMP41 A03474_04_E00_00 HBM: public 7

Administrator rights belong to:

SThe person who entered the password

SThe person working directly (stand‐alone) on the DMP41 (default)

1.1.2 Chapter and appendix overview

Chapter A

Introduction

General information for using this manual. A documentation overview shows

you which documents are part of the DMP device.

Chapter B

Comparison of the Ethernet, RS‐232‐C

This shows which interfaces are included in the DMP device and what their

primary differences are.

Chapter C

Communication with the DMP device

This shows you how to activate the various interfaces and how to connect

the DMP device to your computer.

Chapter D

Program creation

This contains routines for programming interfaces to create your own

programs.

Chapter E

Command set of the HBM interpreter

Important agreements about command syntax, command structure and the

command notation are listed at the start of this chapter. The complete

command set of the HBM interpreter completes the chapter.

Appendix I

Glossary

The glossary describes the main technical terms used in this manual in

dictionary format.

Appendix II

Alphabetic command overview

Command overview sorted alphabetically for rapid orientation.

Documentation overview

How to work with this manual

8A03474_04_E00_00 HBM: public DMP41

Appendix hang III

Functional command overview

You can also search for commands sorted by function.

Appendix IV

Keyword index

Interface comparison

DMP41 A03474_04_E00_00 HBM: public 9

2 Interface comparison

The DMP41 has four different interfaces:

SEthernet

SUSB Host

SRS232 (external adapter on USB Host)

The device can be operated simultaneously via all interfaces, but can only

be parameterized over one connection at the same time.

The HBM Interpreter “translates" the command and corresponding

character string received from an interface into a code understood by the

DMP41.

You can call up the Interpreter via the above‐mentioned interfaces.

All HBM Interpreter commands are shown in Chapter

“5Command set of the HBM interpreter".

This chapter is to help you determine which interface to use. How the

interfaces function can be found in the corresponding Chapter.

Interface Connection

options

Cable Distance max. Transmission

speed

Comments

Ethernet Direct to PC,

network

Ethernet

(Cat-5 or higher) 100 m 10/100 Mbit/s Dependent on

USB HOST Keyboard, stick,

RS232 adapter USB 2.0 5 m 60 Mbyte/s

RS232 External adapter

on USB Host

3-wire cable for

transmission in

both directions

20 m 115200 baud Just one adapter

per device

Interface comparison

10 A03474_04_E00_00 HBM: public DMP41
