HBM FS22 SI Manuel utilisateur

User Manual

English

FS22 SI

Industrial BraggMETER SI

Hottinger Baldwin Messtechnik GmbH

Im Tiefen See 45

D-64239 Darmstadt

Tel. +49 6151 803-0

Fax +49 6151 803-9100

[email protected]

www.hbm.com

HBM FiberSensing, S.A.

Optical Business

Rua Vasconcelos Costa, 277

4470-640 Maia

Portugal

Tel. +351 229 613 010

Fax +351 229 613 020

[email protected]

www.hbm.com/fs

Mat.: 7-2002.4249

DVS: A4249-8.0 HBM: public

10.2017

Interrogator version: v3.0

SW version: v2.4

EHottinger Baldwin Messtechnik GmbH.

Subject to modifications.

All product descriptions are for general information only.

They are not to be understood as a guarantee of quality or

durability.

FS22 SI A4249-8.0 HBM: public 3

English

1 Technical Details 6.........................................

1.1 General Information 6........................................

1.2 System Components 7.......................................

1.3 Technical Data 8............................................

2 Regulatory and Certification Considerations 11................

2.1 Environment Considerations 11.................................

2.1.1 Disposal of your Old Appliance 11...............................

2.2 Laser Safety 12..............................................

2.2.1 Symbols 12..................................................

2.2.2 Class 1 Laser 12..............................................

2.2.3 General Precautions Considerations 13..........................

2.2.4 Certification 14...............................................

3 Operation 15................................................

3.1 Connectors 15................................................

3.1.1 Standard 15..................................................

3.1.2 Rack-Mountable 16...........................................

3.2 Setting Up 17................................................

3.2.1 Power Supply 17.............................................

3.2.2 Optical Connectors 17.........................................

3.2.3 Ethernet Connection 17........................................

3.3 Switching On 18..............................................

3.4 Switching OFF 19.............................................

3.5 Operating the Interrogator 20...................................

3.5.1 Network Properties 20.........................................

3.5.2 Resetting the IP Address of the Interrogator 24...................

3.5.3 Synchronization 25............................................

3.5.4 Operation 28.................................................

4 Measuring 36................................................

4.1 Typical Configuration 36.......................................

4A4249-8.0 HBM: public FS22 SI

4.1.1 HBM FS Wavelengths 37......................................

4.2 Definitions 38................................................

4.2.1 Wavelength 38...............................................

4.2.2 Power 39....................................................

4.3 Measurement Methods 39.....................................

4.3.1 Conventional 40..............................................

4.3.2 Smart Peak Detection (SPD) 41................................

4.4 Common Measuring Difficulties 43..............................

4.4.1 Dirty Connector 43............................................

4.4.2 Broken Connector 46..........................................

4.4.3 Reflective Fiber Ending 46.....................................

4.4.4 Cut Fiber 47.................................................

4.4.5 Fuse Failure 49...............................................

5 Remote Communications 51..................................

5.1 Communication Protocol Syntax 51.............................

5.1.1 Command Syntax 51..........................................

5.1.2 Common Commands 54.......................................

5.1.3 System Commands 55........................................

5.1.4 Status Commands 57.........................................

5.1.5 Acquisition Commands 57.....................................

5.1.6 Memory Commands 73........................................

6 BraggMONITOR SI Software Details 75........................

6.1 Software Version 75...........................................

6.2 Install and Uninstall Software 76................................

6.2.1 System Requirements 76......................................

6.2.2 Software Installation 77........................................

6.2.3 Software Uninstall 78..........................................

6.3 Running the Software 79.......................................

6.3.1 Network Properties 79.........................................

6.3.2 Regional Settings 79..........................................

FS22 SI A4249-8.0 HBM: public 5

6.3.3 Run as Administrator 80.......................................

7 BraggMONITOR SI User Interface 82..........................

7.1 General Bar 82...............................................

7.1.1 Date and Time 83.............................................

7.1.2 Connecting to the Interrogator 86...............................

7.1.3 Acquisition 88................................................

7.1.4 Software and Interrogator Information 94.........................

7.1.5 Exit Application 94............................................

7.2 Graphical Area 94............................................

7.2.1 Graphical View 95............................................

7.2.2 Numerical View 97............................................

7.2.3 Spectral View 98..............................................

7.2.4 Configuration 107..............................................

7.2.5 SCPI Interface 114.............................................

Technical Details

6A4249-8.0 HBM: public FS22 SI

1 Technical Details

1.1 General Information

The FS22 - Industrial BraggMETER SI with real time

embedded Smart Peak Detection (SPD) is a continuous

swept laser scanning interrogator specifically designed to

interrogate Fiber Bragg Grating (FBG) based sensors in

industrial environments.

BraggMETER interrogators include a NIST traceable

wavelength reference that provides continuous calibra

tion to ensure system accuracy over long term operation.

The high dynamic range and high output power com

bined with the Smart Peak Detection (SPD) allow high

resolution to be attained even for long fiber leads and

lossy connections.

Multiple sensors can be connected in series in each opti

cal fiber, in combination with one, four or eight optical

channels with parallel acquisition. The FS22 - Industrial

BraggMETER SI is particularly suitable for large scale

sensing networks acquiring a large number of sensors

simultaneously and providing 1 S/s acquisition rates with

sub picometer resolution.

The BraggMETER is available either in Standard and

Rack-mountable formats. This Manual applies to the fol

lowing equipment:

Standard

K-FS22-01-010-120 FS22 – Industrial BraggMETER SI Single channel

K-FS22-03-010-120 FS22 – Industrial BraggMETER SI Single channel

K-FS22-01-010-420 FS22 – Industrial BraggMETER SI Quad channel

K-FS22-03-010-420 FS22 – Industrial BraggMETER SI Quad channel

Technical Details

FS22 SI A4249-8.0 HBM: public 7

K-FS22-01-010-820 FS22 – Industrial BraggMETER SI Octo channel

K-FS22-03-010-820 FS22 – Industrial BraggMETER SI Octo channel

Rack-Mountable

K-FS22-11-010-120 FS22 – Industrial BraggMETER SI Single channel

K-FS22-13-010-120 FS22 – Industrial BraggMETER SI Single channel

K-FS22-11-010-420 FS22 – Industrial BraggMETER SI Quad channel

K-FS22-13-010-420 FS22 – Industrial BraggMETER SI Quad channel

K-FS22-11-010-820 FS22 – Industrial BraggMETER SI Octo channel

K-FS22-13-010-820 FS22 – Industrial BraggMETER SI Octo channel

HBM FiberSensing interrogators are compatible with

catman software, a powerful tool for data acquisition and

processing.

1.2 System Components

The FS22 - Industrial BraggMETER SI set includes:

Standard format Rack-mountable format

- Interrogator

- Power cord

- Power adapter

- Ethernet cable (L ~2 m)

- Mounting blocks with M6

screws

- Connector protection caps

- Quick guide

- Digital support material

- Calibration certificate

- Interrogator

- Power cord

- Ethernet cable (L ~2 m)

- Connector protection caps

- Quick guide

- Digital support material

- Calibration certificate

Technical Details

8A4249-8.0 HBM: public FS22 SI

1.3 Technical Data

Wavelength Measurement

Range 100 nm (1500 to 1600 nm)

Resolution/Repeatability1) <0.5 pm

Stability/Reproducibility1) 1 pm

Optical channels2) 1, 4 or 8

Maximum sensors Operation mode Conventional With SPD

Per OC 125 125

Total 500 1000

Sample rate 1 S/s

Optical detection Logarithmic

Dynamic range3) > 50 dB

Laser Source

Optical output power4)

Single 0 dBm

Quad -3 dBm

Octo -6 dBm

Linewidth < 500 MHz

Connectors

Optical FC/APC and SC/APC

Electrical Standard: Weidmüller Terminal Block

SLDF 5.08 2-way supplied with 100-230 V power

adapter and Type F plug cable5)

Rack-Mountable: C14 (IEC/EN 60320-1) supplied

with Type F plug cable5)

Communication RJ45 Ethernet

Control

Interface Ethernet (TCP/IP)

Commands SCPI (ASCII textual strings)6)

Synchronization NTP

Technical Details

FS22 SI A4249-8.0 HBM: public 9

Features

OSA trace Continuous (wavelength, absolute power)7)

Sleep mode Yes

Local data logging Yes

Storage capacity8) 2 GB

Environmental

Operation temperature 10 to 40 ºC

Operation humidity < 90% at 40 ºC

Storage temperature -20 to 70 ºC

Storage humidity <95% (non-condensing)

Shock Resistance 20 g; 11 ms (EN60068-2-27)

Vibration Resistance9) 2.5 g (EN60068-2-6)

Mechanical

Dimensions (w x h x d) Standard: 155 x 125 x 275 mm

Rack-Mountable: 483 x 88 x 400 mm

Mounting Standard: 6 screws M6

Rack-Mountable: 19" rack mountable (2U)

Enclosure Aluminum

Weight Standard: 4.5 kg (without mounting brackets)

Rack-Mountable: 7 kg

Power

Voltage Standard: 11-36 VDC

Rack-Mountable: 100-240 VAC 50-60 Hz

Consumption4)

Nominal10) 17.5 W

Technical Details

10 A4249-8.0 HBM: public FS22 SI

Stand by 0.4 W

Sleep mode 0.4 W

1) As per NIST Technical Note 1297: Repeatability [§D.1.1.2], σ of measurements carried out under

the same conditions; Reproducibility [§D.1.1.3], σ of measurements carried out under the full

operation conditions (temperature and power cycles). Above mentioned measurements accuracy

[§D.1.1.1] carried out using calibrated instrument against a NIST traceable gas cell. Further details

on HBM FiberSensing technical notes

2) With simultaneous acquisition

3) Considered as the ratio between the optical power emitted at an optical channel and the minimum

detectable optical power reflected by a fiber Bragg grating

4) Typical values

5) Different plug formats can be added upon request

6) Standard Commands for Programmable Instruments

7) Full spectrum trace with 20001 points acquired over the 100 nm range (sampled every 5 pm)

8) Up to 6000 hours of data storage, considering 100 sensors

9) Sinusoidal vibration

10) Peak consumption may reach 38 W (during startup)

Table des matières

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
