Haier HDE5000AW Manuel utilisateur

User Manual and Installation Instructions

Gas & Electric Dryer

Sécheuses à chargement frontal à gaz et

électrique

Manual para el usuario e instrucciones

de instalación. Secadora a gas y eléctrica

Model #/ Modéle #/ Para Modelo de #

HDE/HDG5000AW ; HDE/HDG5300AW

Quality ■Innovation ■Style

(Picture for illustration purposes only. Actual model may vary per model purchased.)

Front Load Dryers

CHDE/HDG5000AW ; CHDE/HDG5300AW

English

PAGE

IMPORTANT SAFETY INSTRUCTIONS.......................................2-4

INSTALLATION INSTRUCTIONS..............................................5-24

Tools and Materials Required............................................................ 5

Electrical Requirements ..................................................................5-6

Unpacking Your Dryer ..................................................................... 6

Exhaust System Requirements ........................................................7-8

Gas Supply Requirements ................................................................ 9

Location of Your Dryer ...................................................................10

Location of Your Dryer in a Closet....................................................11

Manufactured (Mobile) Home Instruction .........................................12

Procedure for Reversing the Door............................................... 13-17

Changing the Drum Light ................................................................18

Electrical Installation ......................................................................19

3-Wire Cord Connections ..............................................................20

4-Wire Cord Connections ..............................................................21

Gas Connections ..........................................................................22

Replacement Parts .........................................................................24

OPERATING INSTRUCTIONS ............................................... 25-38

Understanding the Control Panel (HDE/HDG5300AW,CHDE/HDG5300AW) ....... 25-27

Understanding the Control Panel 27-29

Preparations before Drying .............................................................30

Load clothes into Dryer...................................................................31

Auto Dry Cycle .......................... 32-33

Auto Dry Cycle 34

Manual Dry Cycle 35

Manual Dry Cycle 36

Other Features...............................................................................37

Normal Operating Sounds..............................................................38

CARE AND CLEANING GUIDE.......................................................38

TROUBLESHOOTING..................................................................39

LIMITED WARRANTY .................................................................40

TABLE OF CONTENTS

(HDE/HDG5000AW,CHDE/CHDG5000AW)

.......

(HDE/HDG5300AW,CHDE/CHDG5300AW)

(HDE/HDG5000AW,CHDE/CHDG5000AW)

(HDE/HDG5300AW,CHDE/CHDG5300AW)

(HDE/HDG5300AW,CHDE/HDG5000AW) ..................................

..............................

English

WARNING - To reduce the risk of ﬁre, electric shock, or

injury to persons when using your appliance, follow the

basic precautions, including the following:

1. Read all of the instructions before using this appliance.

2. Don’t dry articles that have been previously cleaned in, washed in,

soaked in, or spotted with gasoline, dry clean solvents or other

ﬂammable explosive sub stains as they give off vapors which could

ignite or explode.

3. Do not allow children to play on or in the appliance. Close

supervision of children is necessary when the appliance is used near

children.

4. Before the appliance is removed from service or discarded, remove

the door to the drying compartment.

5. Do not reach into the appliance if the drum is moving.

6. Do not install or store this appliance where it will be exposed to

water and/or to the weather.

7. Do not tamper with controls.

8. Do not repair or replace any part of the appliance or attempt any

servicing unless speciﬁcally recommended in the user-repair

instructions that you understand and have skills to carry out.

9. Do not use fabric softeners or products to eliminate static unless

recommended by the manufacturers of the fabric softener or

product.

10. Do not use heat to dry articles or products to eliminate static unless

recommended by the manufacturers of the fabric softener or

product.

11. Clean lint screen before or after each load.

12. Keep area around the exhaust opening and adjacent surrounding

areas free from the accumulation of lint, dust and dirt.

13. Keep the dryer area clear and free from items that would obstruct

the ﬂow of combustion and ventilation air through the louvered panel

located on the rear of the dryer.

14. The interior of the appliance and the exhaust duct should be cleaned

periodically by qualiﬁed service personnel.

IMPORTANT SAFETY

INSTRUCTIONS

English

Thank you for using our Haier

product. This easy-to-use manual

will guide you in getting the best

use of your dryer.

Remember to record the model and

serial number. They are on a label

in back of the dryer.

Model number

Serial number

Date of purchase

Staple your receipt to your manual.

You will need it to obtain warranty service.

15. Do not place items exposed to cooking oils in your dryer. Items

contaminated with cooking oil may contribute to a chemical reaction

than could cause a load to catch ﬁre.

16. If material has been used with any ﬂammable liquids or solids, it

should not used in the dryer until all traces of ﬂammable liquids and

its fumes have been removed.

17. This dryer must be properly installed in accordance with the

installation instructions before it is used. See grounding instructions in

the installations sections.

18. Proper grounding must be ensured to reduce the risk of electric shock

and force. Check with a qualiﬁed electrician or service personnel if

you are in doubt as to whether the dryer is properly grounded.

19. Use the dryer only for its intended purpose: drying clothes.

20. Always disconnect dryer from electrical supply before attempting any

service. Disconnect power cord by grasping the plug, not the cord.

21. Replace worn power cord and/or loose plugs.

22. To reduce the risk of electric shock or ﬁre, do not use extension cords

or adapters to connect dryer electrical power source.

Risk of child entrapment. Before you throw away your old dryer,

take off the door so that children may not get trapped inside.

SAVE THESE

INSTRUCTIONS

DANGER

WARNING

Risk of Fire:

Tools and materials required

• Phillips-Head and ﬂathead screwdrivers

• Channel-lock adjustable pilers

• 1/2-inch open-end wrench

• Carpenter’s level

• Measuring tape (12ft. min.)

• Duct tape

• Pipe thread sealer (Gas)

• Rigid or ﬂexible metal 4 inch (102cm) duct

• Vent hood

Safety Warning:

1. Before starting installation, make sure that the gas shut off valve is in the

off position.

2. All old gas connectors and gas piping should be discarded.

ELECTRICAL REQUIREMENTS

Electric Dryer: (CHDE/HDE5000AW and CHDE/HDE5300AW)

Circuit

Individual 30 Amp branch circuit fused with 30 Amp time-delay fuses or circuit

breakers. Use seperately fused circuits for washers and dryers, and DO NOT

operate a washer and dryer on the same circuit.

INSTALLATION INSTRUCTIONS

English

1.Clothes dryer installation must be performed by a qualiﬁed installer.

2.Install the clothes dryer according to the manufacturer’s instructions

and local codes.

3.Do not install a clothes dryer with ﬂexible plastic venting materials.

If ﬂexible metal (foil type) duct is installed,it must be of a speciﬁc

type identiﬁed by the appliance manufacturer as suitable for use

with clothes dryers. Flexible venting materials are known to collapse,

be easily crushed,and trap lint.These conditions will obstruct clothes

dryer airﬂow and increase the risk of ﬁre.

4.To reduce the risk of severe injury or death, follow all installation

instructions.

SAVE THESE INSTRUCTIONS

English

Power Supply

3 or 4 wire, 120/240 Volt, 1 Phase, 60Hz, AC

(Canada - 120/240 Volt, 1 Phase, 60 Hz, AC)

Power Supply Cord Kit

(Not supplied when sold in US. Must be purchased to meet local electrical

codes.) The dryer MUST employ a 3-conductor power supply cord NEMA 10-30

Type SRDT rated at 240 Volt AC minimum, 30 Amp, with 3 open end spade lug

connectors with upturned ends or closed loop connectors and marked for use

with clothes dryers.

(When sold in Canada - 4-wire power supply cord provided and

attached on dryer)

Dryers being installed in a manufactured (mobile) home MUST employ a

4-wire power supply cord NEMA 14-30 type SRDT or ST (as required) rated

to 240 Volt AC minimum, 30 Amp, with 4 open-end spade lug connectors

with upturned ends or closed loop connectors and marked for use with clothes

dryers. See Electrical Connections for more information on a 4-wire system.

Outlet Receptacle

NEMA 10-30R receptacle should be located so the power supply cord is

accessible when the dryer is in the installed position. (Canada - NEMA 14-30R

receptacle)

ELECTRICAL REQUIREMENTS

Gas Dryer: (CHDG/HDG5000AW and CHDG/HDG5300AW)

Circuit

Individual 15 Amp branch circuit fused with 15-Amp maximum time delay fuse

or circuit breakers.

Power Supply

3 wire, 120 Volt, 1 Phase, 60Hz, AC

Power Supply Cord

The dryer is equipped with a 120 Volt 3-wire power supply cord.

NOTE: This dryer is equipped with a three-prong grounding plug for your

protection against shock hazard and should be plugged into a properly

grounded three-prong receptacle. Do not under any circumstance cut or

remove grounding prong from plug.

Unpacking Your Dryer

1. Remove all packaging material. This includes the foam base and all adhesive

tape holding the dryer accessories inside and outside.

2. Inspect and remove any remains of packaging, tape or printed materials

before using the dryer.

The following are speciﬁc requirements for

proper and safe operation of your dryer. Failure

to follow these instructions can create excessive

drying times and ﬁre hazards.

1. Do not use plastic ﬂexible duct to exhaust the dryer. Excessive lint can build up

inside exhaust system and create a ﬁre hazard and restrict air ﬂow. Restricted

air ﬂow will increase drying time. If your present system is made up of plastic

duct or metal foil duct, replace it with a rigid or ﬂexible metal duct. Ensure

present duct is free of any lint prior to installing dryer duct.

2. The dryer shall not be exhausted into a chimney, a wall, a ceiling, an attic, a

crawl space, or a concealed space of a building; The dryer exhaust system

MUST be exhausted to the outdoors. If the dryer is not exhausted

outdoors, some ﬁne lint will be expelled into the laundry area. An accumulation

of lint in any area of the home can create a health and ﬁre hazard.

3. Exceeding the length of duct pipe or number of elbows allowed in the

“Maximum Length” chart can cause an accumulation of lint in the exhaust

system. Plugging the system could create a ﬁre hazard, as well as increase

drying times.

4. Do not screen the exhaust ends of the vent system. Lint can become caught in

the screen, increasing drying time. Use an approved vent hood to terminate the

duct outdoors, and seal all joints with duct tape.

5. All male duct pipe ﬁttings must be installed downstream with the ﬂow of air.

6. The duct shall not be assembled with screws or other fastening means that extend

into the duct and catch lint.

7. Do not allow combustible material (clothing, draperies/curtains, paper, etc.) to

come in contact with exhaust system.

Explosion hazard:

Do not install the dryer where gasoline or other ﬂammables are kept or

stored. If the dryer is installed in a garage, it must be a minimum of 18

inches (45.7cm) above the ﬂoor. Failure to do so can result in death,

explosion, ﬁre or burns.

Exhaust Requirements:

Use only rigid or ﬂexible metal duct and approved vent hood which has a

swing-out damper hat open when the dryer is in operation. When the dryer

stops, the dampers automatically close to prevent drafts and the entrance of

insects and rodents. To avoid restricting the outlet,

WARNING

EXHAUST SYSTEM REQUIREMENTS

English

maintain a minimum of

clearance between the vent hood and the ground or

any other obstruction. The vent ﬂap should be able to move freely, although

vertical orientation of the exhaust system is acceptable. Certain extenuating

circumstances could affect the performance of the dryer:

1. Only rigid or ﬂexible metal duct work should be used.

2. Venting vertically through a roof may expose the exhaust system to down

drafts causing an increase in vent restriction.

3. Running the exhaust system through an uninsulatedarea may cause

condensation and faster accumulation of lint.

4. Compression of crimping of the exhaust system will cause an increase in

vent restriction.

The exhaust system should be inspected and cleaned a minimum of every 12

months with normal usage. The more the dryer is used the more often you

should check the exhaust system and vent hood for proper operation.

Side and Bottom Exhaust

For your convenience, your dryer can be exhausted through the side or the

bottom. If you need to change the exhaust on the dryer to the side or the

bottom of the cabinet, you will need to order the exhaust kit from your Haier

dealer or call 1- 800-313-8495

English

RECOMMENDED MAXIMUMM

Exhaust Hood Types

Recommended Use only for short

run installations

No. of 90º

elbows Rigid Metal Rigid Metal

0 90 ft. 60 ft.

1 60 ft. 45 ft.

2 45 ft. 35 ft.

3 35 ft. 25 ft.

12 inches (30.5cm)

The total length of ﬂexible metal duct shall not exceed 2.4 m.

5. In Canada, that only those foil-type ﬂexible ducts, if any, speciﬁcally identiﬁed

for use with the appliance by the manufacturer shall be used. In the United

States, that only those foil-type ﬂexible ducts, if any, speciﬁcally identiﬁed for

use with the appliance by the manufacturer and that comply with the UL Outline

for Clothes Dryer Transition Duct, Subject 2158A (2006), shall be used.

6. In Canada, that the exhaust duct shall be 102 mm in diameter. In the United

States, the required exhaust duct diameter.

GAS SUPPLY REQUIREMENTS

English English

WARNING

ADVERTENCIA

ADVERTISSMENT

PRECAUCIÓN

PRECAUCIÓN PRECAUCIÓN

ATTENTION

CAUTION

Replace copper connecting pipe that is not plastic

coated. Stainless steel or plastic-coated brass

MUST be used.

1.Installation MUST conform with local codes. In the absence of local codes,

installation must conform with the National Fuel Gas Code, ANSI Z223.1 (latest

edition) or in Canada, the current CAN/CGA B149.1

2. The gas supply line should be 1/2 inch (1.27cm) pipe.

3. If codes allow, flexible metal tubing may be used to connect your dryer to the

gas supply line. The tubing MUST be constructed of stainless steel or plastic-

coated brass.

4. The gas supply line MUST have an individual manual shutoff valve installed

within 6 feet (183cm) of the dryer in accordance with the National Fuel Gas

Code, ANSI Z223.1/NFPA 54.

In Canada, an individual manual shut-off valve MUST be installed in

accordance with the B149.1, Natural Gas and Propane Installation Code.

5. A 1/8 inch (0.32cm) N.P.T. plugged tapping, accessible for test gauge

connection, MUST be installed immediately upstream of the gas supply

connection to the dryer.

6. The dryer MUST be disconnected from the gas supply piping system during

any pressure testing of the gas supply piping system at test pressures in excess

of 1/2 psig (3.45kPa).

7. The dryer MUST be isolated from the gas supply piping system during any

pressure testing of the gas supply piping system at test pressures equal to or

less than 1/2 psig (3.45 kPa).

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Haier Séchoir

Haier

Haier HDY-D70-E Manuel utilisateur

Haier

Haier RDE350AW - 6.5 Cu. Ft. Electric Dryer Manuel utilisateur

Haier

Haier GE CleanSpeak WE04X20528 Guide de configuration

Haier

Haier HLTD500AGW Manuel utilisateur

Haier

Haier RDG350AW Manuel utilisateur

Haier

Haier GDZ3.5-61 Manuel utilisateur

Haier

Haier HDHP80AN1 Manuel utilisateur

Haier

Haier HLF11PC Manuel utilisateur

Haier

Haier HD90-A3Q979U1 Manuel utilisateur

Haier

Haier HD80-26A Manuel utilisateur

Haier

Haier HDV60E1 Manuel d'utilisation

Haier

Haier HDY-D70-E Manuel utilisateur

Haier

Haier Ginesis HLF103Q Manuel utilisateur

Haier

Haier HLP140E - 2.6 cu. Ft. Portable Vented Electric... Manuel utilisateur

Haier

Haier HD80-B636-F Manuel utilisateur

Haier

Haier HDY6-1 Manuel utilisateur

Haier

Haier HMS6-1 Manuel utilisateur

Haier

Haier Ginesis HLF103Q Manuel utilisateur

Haier

Haier GDZ3.5-1-HK Manuel utilisateur

Haier

Haier HD90-A3Q979SU1 Manuel utilisateur

Haier

Haier HDY-M60 Manuel utilisateur

Haier

Haier HLTD500AEW Manuel utilisateur

Haier

Haier CGDE450AW Manuel utilisateur

Haier

Haier Genesis CRDWE200AW Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Electrolux

Electrolux EW2H328R2 Manuel utilisateur

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

Electrolux

Electrolux TP5080TW Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur
