INSTRUCTIONS

SDMM8 Manual Meter and

SDMP8 Preset Meter

For metered dispense of petroleum-based lubricants, oils and 50:50 antifreeze/water mix

fluids only.

For professional use only.

Maximum Working Pressure: 1500 psi (10 MPa, 103 bar)

List of Models page 2

Important Safety Instructions

Read all warnings and instructions in this

manual. Save these instructions.

Models

2333492G

Models

SDMM8 Manual Bare Meters

Bare manual meters do not include a nozzle or extension. Model packages that include a nozzle and extension are

provided below.

SDMM8 Manual Meters with Nozzle and Extension Packages

The following packages include Bare Meter Model 24U959 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U960 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U961 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U956 and the nozzle and extension kits indicated in the table

below.

Model Number Model Description Inlet

24U959* 4/16 Quart NPT

24U960* 4/16 Quart BSPT

24U961* 4/16 Quart BSPP

24U956* 4/16 Liter NPT

24U957* 4/16 Liter BSPT

24U958* 4/16 Liter BSPP

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V034 4/16 Quart NPT Flex 255853 255459

24V037 4/16 Quart NPT Rigid 255852 255459

24V040 4/16 Quart NPT Gear Lube 255854 255470

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V035 4/16 Quart BSPT Flex 255853 255459

24V038 4/16 Quart BSPT Rigid 255852 255459

24V041 4/16 Quart BSPT Gear Lube 255854 255470

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V036 4/16 Quart BSPP Flex 255853 255459

24V039 4/16 Quart BSPP Rigid 255852 255459

24V042 4/16 Quart BSPP Gear Lube 255854 255470

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V043 4/16 Liter NPT Flex 255853 255459

24V046 4/16 Liter NPT Rigid 255852 255459

24V049 4/16 Liter NPT Gear Lube 255854 255470

Models

333492G 3

The following packages include Bare Meter Model 24U957 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U958 and the nozzle and extension kits indicated in the table

below.

See Nozzle and Extension Kits, page 27

† See Nozzle Parts, page 28.

SDMP8 Preset Meters

Bare preset meters do not include a nozzle or extension. Model packages that include a nozzle and extension are

provided on page 4.

*This meter can be used for antifreeze applications with antifreeze nozzle 255855 or 24W306. See page 27 for infor-

mation about these nozzles.

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V044 4/16 Liter BSPT Flex 255853 255459

24V047 4/16 Liter BSPT Rigid 255852 255459

24V050 4/16 Liter BSPT Gear Lube 255854 255470

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V045 4/16 Liter BSPP Flex 255853 255459

24V048 4/16 Liter BSPP Rigid 255852 255459

24V051 4/16 Liter BSPP Gear Lube 255854 255470

Model Number Model Description Inlet

24U947* 60 Quart NPT

24U948* 60 Quart BSPT

24U949* 60 Quart BSPP

24U950* 60 Gallon NPT

24U951* 60 Gallon BSPT

24U952* 60 Gallon BSPP

24U953* 60 Liter NPT

24U954* 60 Liter BSPT

24U955* 60 Liter BSPP

Models

4333492G

SDMP8 Preset Meters with Nozzle and Extension Packages

The following packages include Bare Meter Model 24U947 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U948 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U949 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U950 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U951 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U952 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U953 and the nozzle and extension kits indicated in the table

below.

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V052 60 Quart NPT Rigid 24W641 255459

24Z125 60 Quart NPT Rigid 255852 255459

24Z126 60 Quart NPT Flex 255853 255459

24Z127 60 Quart NPT Rigid 255854 255470

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V053 60 Quart BSPT Rigid 24W641 255459

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V054 60 Quart BSPP Rigid 24W641 255459

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V055 60 Gallon NPT Rigid 24W641 255459

24Z128 60 Gallon NPT Rigid 255852 255459

24Z129 60 Gallon NPT Flex 255853 255459

24Z130 60 Gallon NPT Rigid 255854 255470

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V056 60 Gallon BSPT Rigid 24W641 255459

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V057 60 Gallon BSPP Rigid 24W641 255459

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V058 60 Liter NPT Rigid 24W641 255459

24Z131 60 Liter NPT Rigid 255852 255459

24Z132 60 Liter NPT Flex 255853 255459

24Z133 60 Liter NPT Rigid 255854 255470

Models

333492G 5

The following packages include Bare Meter Model 24U954 and the nozzle and extension kits indicated in the table

below.

The following packages include Bare Meter Model 24U955 and the nozzle and extension kits indicated in the table

below.

See Nozzle and Extension Kits, page 27

† See Nozzle Parts, page 28.

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V059 60 Liter BSPT Rigid 24W641 255459

Model Number Model Description Inlet Extension Nozzle/Extension KitNozzle Parts†

24V060 60 Liter BSPP Rigid 24W641 255459

Warnings

6333492G

Warnings

The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama-

tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When

these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific

hazard symbols and warnings not covered in this section may appear throughout the body of this manual where

applicable.

FIRE AND EXPLOSION HAZARD

When flammable fluids are present in the work area, such as gasoline and windshield wiper fluid, be

aware that flammable fumes can ignite or explode. To help prevent fire and explosion:

• Use equipment only in well ventilated area.

• Eliminate all ignition sources, such as cigarettes and portable electric lamps.

• Keep work area free of debris, including rags and spilled or open containers of solvent and gasoline.

• Do not plug or unplug power cords or turn lights on or off when flammable fumes are present.

• Ground all equipment in the work area.

• Use only grounded hoses.

•Stop operation immediately if static sparking occurs or you feel a shock.Do not use equipment

until you identify and correct the problem.

• Keep a working fire extinguisher in the work area.

SKIN INJECTION HAZARD

High-pressure fluid from dispensing device, hose leaks, or ruptured components will pierce skin. This

may look like just a cut, but it is a serious injury that can result in amputation. Get immediate surgical

treatment.

• Do not point dispensing device at anyone or at any part of the body.

• Do not put your hand over the fluid outlet.

• Do not stop or deflect leaks with your hand, body, glove, or rag.

• Follow the Pressure Relief Procedure when you stop dispensing and before cleaning, checking, or

servicing equipment.

• Tighten all fluid connections before operating the equipment.

• Check hoses and couplings daily. Replace worn or damaged parts immediately.

WARNINGWARNINGWARNING

WARNING

Warnings

333492G 7

EQUIPMENT MISUSE HAZARD

Misuse can cause death or serious injury.

• Do not operate the unit when fatigued or under the influence of drugs or alcohol.

• Do not exceed the maximum working pressure or temperature rating of the lowest rated system

component. See Technical Data in all equipment manuals.

• Use fluids and solvents that are compatible with equipment wetted parts. See Technical Data in all

equipment manuals. Read fluid and solvent manufacturer’s warnings. For complete information

about your material, request MSDS from distributor or retailer.

• Do not leave the work area while equipment is energized or under pressure.

• Turn off all equipment and follow the Pressure Relief Procedure when equipment is not in use.

• Check equipment daily. Repair or replace worn or damaged parts immediately with genuine manu-

facturer’s replacement parts only.

• Do not alter or modify equipment. Alterations or modifications may void agency approvals and create

safety hazards.

• Make sure all equipment is rated and approved for the environment in which you are using it.

• Use equipment only for its intended purpose. Call your distributor for information.

• Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.

• Do not kink or over bend hoses or use hoses to pull equipment.

• Keep children and animals away from work area.

• Comply with all applicable safety regulations.

PRESSURIZED ALUMINUM PARTS HAZARD

Use of fluids that are incompatible with aluminum in pressurized equipment can cause serious chemical

reaction and equipment rupture. Failure to follow this warning can result in death, serious injury, or prop-

erty damage.

• Do not use 1,1,1-trichloroethane, methylene chloride, other halogenated hydrocarbon solvents or flu-

ids containing such solvents.

• Many other fluids may contain chemicals that can react with aluminum. Contact your material sup-

plier for compatibility.

PERSONAL PROTECTIVE EQUIPMENT

Wear appropriate protective equipment when in the work area to help prevent serious injury, including

eye injury, hearing loss, inhalation of toxic fumes, and burns. This protective equipment includes but is

not limited to:

• Protective eyewear, and hearing protection.

• Respirators, protective clothing, and gloves as recommended by the fluid and solvent manufacturer

WARNINGWARNINGWARNING

WARNING

Typical Installation

8333492G

Typical Installation

Key:

A Main air supply line

B Pump air supply line

CAirfilter

D Air regulator

E Bleed-type master air valve (required)

FPump

G Pump grounding wire (required)

H Pressure relief valve (required)

NOTE: The relief pressure cannot exceed the meter’s maximum working pressure

J Fluid shut off valve

K Fluid line

L Fluid shut off valve

M Hose reel

N SDMM8 or SDMP8 meter

P Mounting channel

R Hose reel fluid inlet kit

S Fluid drain valve

FIG. 1

Installation

333492G 9

Installation

NOTE: The letters used in the following instructions

refer to Typical Installation on page 8.

Pressure Relief Procedure

Follow the Pressure Relief Procedure whenever

you see this symbol.

1. Turn off power supply to the pump or close

upstream master air valve (E).

2. Open all fluid shut off valves (J and L) in the system.

3. Trigger the meter (N) into a waste container to

relieve pressure.

4. Open fluid drain valves and leave them open until

you are ready to pressurize the system.

Grounding

Ground all components in the system:

Pump (F): Follow manufacturer’s recommendations.

Air and fluid supply lines (A, B, K): Only use electri-

cally conductive hoses. Check electrical resistance of

hoses. If total resistance to ground exceeds 29 meg-

ohms, replace hose immediately.

Air compressor: Follow manufacturer’s recommenda-

tions.

Fluid supply container: Follow local code.

To maintain grounding continuity when flushing or

relieving pressure: hold a metal part of the meter firmly

to the side of a grounded metal pail, then trigger the

valve.

SDMM8 and SDMP8 Meter (N): When installing the

meter leave at least two threads bare when using thread

sealant. The bare threads ensure a ground is main-

tained.

This equipment stays pressurized until pressure is

manually relieved. To help prevent serious injury from

pressurized fluid, such as skin injection, splashing

fluid and moving parts, follow the Pressure Relief

Procedure when you stop spraying and before

cleaning, checking, or servicing the equipment.

• The equipment must be grounded to reduce the

risk of static sparking. Static sparking can cause

fumes to ignite or explode. Grounding provides

an escape wire for the electric current.

• To prevent electric arcing do not allow the

conductive metal surfaces on the meter to make

contact with any positively charged metal

surface, including (but not limited to), the starter

solenoid terminal, alternator terminal or battery

terminal.

Installation

10 333492G

Component Identification

Key:

1 Swivel

12 Trigger

37 Meter dial

41 Meter pointer

101 Nozzle

102 Extension

FIG. 2

102

101

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Graco Instrument de mesure

Graco

Graco Dispensit 1052 Guide de dépannage

Graco

Graco EFR Manuel d'utilisation

Graco

Graco Pulse TLM Manuel utilisateur

Graco

Graco Magnum Project Painter 5 Manuel utilisateur

Graco

Graco PM8 Manuel utilisateur

Graco

Graco PPM 3050H Manuel d'utilisation

Graco

Graco 26C266 Manuel utilisateur

Graco

Graco ProMix 2KE Manuel d'utilisation et d'entretien

Graco

Graco Accu-Shot 233807 Manuel de la liste des pièces

Graco

Graco 309455C Manuel d'utilisation

Graco

Graco PE14 Manuel utilisateur

Graco

Graco Pulse TLM Manuel d'utilisation

Graco

Graco ProControl 1KE Manuel de la liste des pièces

Graco

Graco EM5 238457 Manuel d'utilisation

Graco

Graco 215474 Manuel utilisateur

Graco

Graco HG6000 Manuel de référence technique

Graco

Graco PD44 Manuel utilisateur

Graco

Graco 244023 Fiche technique

Graco

Graco Pulse TEK 811 Guide de configuration

Graco

Graco Series D Manuel utilisateur

Graco

Graco 234576 Manuel d'utilisation

Graco

Graco EM5 Series Manuel utilisateur

Graco

Graco IM20P Fiche technique

Graco

Graco XDI12 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
