gofanco HDwireless10x1 Manuel utilisateur
10x1 Wireless HDMI Extender
Kit 1080p - 20m
User's Guide
G4-0057A
P/N: HDwireless10x1
2
Thank you for purchasing from gofanco. Our
products aim to meet all your connectivity needs
wherever you go. For optimum performance
and safety, please read the instructions carefully
and keep this User’s Guide for future reference.
If you need more information about our
products, please visit www.gofanco.com. For
technical support, please email us at
download, please go to www.gofanco.com/
download.
Important Safety Notices
Please read safety instructions carefully before
installation and operation.
• Please pay close attention to all warnings
and hints for this device
• Do not expose this unit to rain, heavy
moisture, or liquid
• Do not repair the device or open the
enclosure without professional guidance
to avoid electric shocks. Doing so may void
your warranty
• Keep the product in a well-ventilated
location to avoid damage from overheating
3
• Shut off power and make sure environment
is safe before installation
• Do not plug the HDMI cables in/out when
the device is in use to avoid cable damage.
Make sure they are plugged into the correct
ports
• Use the included DC5V power adapters
only. Make sure the specification matches
if using 3rd-party DC power adapters
Introduction
The 10x1 Wireless HDMI Extender Kit 1080p -
20mextendshighdefinition1080pHDMIsignals
from a source device to a display device up to 20
meters.
Note: Wireless transmission distance will
vary due to the environment conditions.
Thick walls, brick, glass or electronic
interference will shorten the wireless
transmission distance or cause signal loss.
4
Features
• Short distance wireless extension ideal for
meeting/conference room applications.
Supports up to 66 feet (20m) in 1080p with
auto quality adjustment
• Supportsupto10Transmitters to1Receiver.
Users can switch source devices to transmit
by hitting the switch button on the
appropriate Transmitter
• AdditionalTransmitters (part # HDwireless
10x1-TX) are sold separately
PackageContents
Transmitter (TX)
Receiver (RX) Power Adapter User's Guide
HDMI (M) to
HDMI (F) Cable
Micro USB Cable
5
Installation Requirements
1. HDMI source device (computer, DVD
player, etc)
2. HDMI display device (SDTV/Monitor,
HDTV/Monitor, projector, etc.)
Product Layout
Figure 1: Transmitter (TX)
1. HDMI Input Connects to the HDMI source device
2. Connection LED
Lights up when HDMI source is detected
Blinks slowly when wireless signal is linked
Blinks fast when wireless signal is transmitting
3. Power Jack Connect the Micro USB cable here (optional)
4. Power LED Lights up when Transmitter is powered on
5. Switch Button Selects the transmitter as the source signal
6
Figure 2: Receiver (RX)
Hardware Installation
1. Power off all devices including your HDMI
source and HDMI display.
2. Connect your HDMI source device to the
Transmitter's HDMI Input with an HDMI
cable (HDMI cable not included).
3. Connect your HDMI display to the
Receiver's HDMI Output with an HDMI
cable (HDMI cable not included).
1. Power Adapter Jack Connects to the included power adapter
2. Connection LED On when powered on
Blinks when wireless connection is linked
3. Data Transmission LED On when transmitting data, otherwise it's off
4. HDMI Output Connects to the HDMI display device
5. Antenna Transmits wireless signals
7
4. Optional: Connect the included Micro USB
cable between the Transmitter's Power Jack
and USB power port or USB charger. This
connection is needed only if the extender is
not working properly.
5. Plug the included power adapter into the
Receiver's power jack, then plug the power
adapter into a reliable power source.
6. Power on the HDMI source and HDMI
display device.
7. The Wireless HDMI extender is ready for
use.
8
Application
One to One Connection
Transmitter
Receiver
HDMI
Cable
Display
Display
HDMI Source
(Computer, DVD, etc.)
Power Adapter
One to Many Connection
Supports up to 10 Transmitters to 1 Receiver.
AdditionalTransmitters (part #HDwireless10x1-
TX) sold separately.
HDMI
Cable
Receiver
Transmitter
Transmitter
Power Adapter
HDMI Source
(Computer, DVD, etc.)
HDMI Source
(Computer, DVD, etc.)
9
FAQ & Solutions
Q: The Transmitter and Receiver can't connect
to each other:
A: 1) Please check if the Connection LED on
Transmitter and Receiver are blinking.
2) Power cycle the transmitter and receiver.
3) Make sure the HDMI cable is firmly
connected to the display.
4) Change the position of the transmitter
and receiver and make sure they are within
the required signal range.
Q: The Transmitter's Connection LED is on
but no image on the display:
A: 1) Reconnect the HDMI cable to the display.
2) Connect the HDMI source directly to the
display to see if there is a signal.
Q: The display is not clear or stable:
A: 1) Change the position of the transmitter
and receiver and make sure they are within
the required signal range.
2) Reconnect the HDMI cable.
3) Power cycle the transmitter and receiver.
4) Remove other wireless signals and move
any obstacles that are blocking the signal.
10
Specifications
Item Specification
HDMI Compliance HDMI 1.3
HDCP Compliance HDCP 1.2
Wireless Transmission 5.0 GHz
Wireless Latency <200ms
Resolution 480P@60Hz, 576p@50Hz,
720p@50/60Hz, 1080p@50/60Hz
Transmission Distance Up to 66ft (20 meters)
Housing Material Plastic
Power Adapter (RX only) Output: DC5V/2A
Power Consumption TX: <2W / RX: <5W
Operating Temperature 32° - 122° F (0° - 50° C)
Storage Temperature 14° - 158° F (-10° 0 70° C)
Humidity 0% - 90% (non-condensing)
Product Dimension TX: 3.49" (L) x 1.53" (W) x 0.60" (H)
RX: 5.44" (L) x 3.37" (W) x 0.76" (H)
Weight TX: 0.04 lbs / RX: 0.26 lbs
